Thank you for purchasing an ELAM START system.
Please first check the completeness of the scope of delivery.
For each item you will find our unique STAMA No. and the Quickstep (QS), which describes the installation,
setup and assembly. Some basic devices are already described in this Quickstep, more complex devices,
such as the scanner, are described separately in their own Quickstep.
3 x SWA Ident Keys
STAMA-Nr.: 3095
QS –Hardware installation
1x SWA Server
STAMA-Nr.: 3287
QS - Hardware installation
1. Scope of delivery base
1x SWA Power supply
STAMA-Nr.: 5520
QS –Hardware installation 1x Touch monitor 23“ with connection cables
STAMA-Nr.: 3158
QS –Hardware installation
1x Hand scanner
STAMA-Nr.: 3450
QS - Scanner

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 4
SWA-Electrical cabinet
STAMA-Nr.: 3574 / 3575
QS –Hardware installation
USB-Hub
STAMA-Nr.: 3576
QS –Hardware installation
SWA Keys
STAMA-Nr.: 3095
QS –Hardware installation
Key reader external
STAMA-Nr.: 3410
QS –Hardware installation
Sensor distributor
STAMA-Nr.: 3586
QS –Sensor distributor
Screw driver adapter
STAMA-Nr.: 3890
QS –Kolver-Screw driver
Kolver-Screw driver
STAMA-Nr.: 3860/3861/3865
QS –Kolver-Screw driver
Network switch
STAMA-Nr.: 3635
QS –Hardware installation
Docu-Camera
STAMA-Nr.: 3038
QS –Docu-Camera
WIFI-Accesspoint
STAMA-Nr.: 3578
QS –Hardware installation
Quick change mount
STAMA-Nr.: 3180
QS –Hardware installation
1.1 Optional hardware group 1

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted.
Kolver K-Ducer
STAMA-Nr.: 3867
QS –Kolver K-Ducer
HS-T
NutBee/RivBee/TorqBee
STAMA-Nr.:
3840/3841/3842
QS –Screw HS-T
Handlingarm
STAMA-Nr.: 3864
QS - Sensorbox
Sensorbox
STAMA-Nr.: 3850
QS –Sensorbox
Kolver-Handlingarm
STAMA-Nr.: 3868
QS –Sensorbox
AmbosIO
STAMA-Nr.: 3693
QS –AmbosIO
Labelprinter with ethernet
STAMA-Nr.: 3460
QS –Labelprinter
Ethernet Bitcube
STAMA-Nr.: 3562
QS –Bitcube
Measuring probe
STAMA-Nr.: 3870
QS –Sensorbox
5
Pick to Light-Sets
STAMA-Nr.: 3648/3649
QS –Pick to Light
1.2 Optional hardware group 2

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 6
Burster Digiforce
STAMA-Nr.: 3886
QS –Burster Digiforce
Scale
STAMA-Nr.: 3882
QS –Scale
CoBot
STAMA-Nr.: 3524/3525/3526
QS –CoBot
Camera
STAMA-Nr.: 3035
QS –Docu-Camera
Caliper
STAMA-Nr.: 3871 bis 3875
QS –Caliper
1.3 Optional hardware group 3

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 7
M4 thread
The SWA is delivered with an adapter plate on the back of the device. With this adapter plate you have the
possibility to attach a mount with VESA standard (75/100, M4 thread) to integrate the SWA in your
workstation.
If you have decided to use our quick-change device (STAMA no.: 3180), please follow the instructions on
the following page.
2. Installation of the SWA

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 8
Mount the head section on the
adapter plate of the SWA.
Insert the monitor holder into
the wall bracket and fix it with
the adjusting screw.
Slide the SWA with head section
over the monitor holder until it
clicks into place.
Flip the safety clip forward to fix
the SWA in place.
2.1 Assembly of the SWA with the quick device mount

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted.
This picture shows the polarity of
the plug.
9
+--+
Plug assignment
Connect the power supply unit with the
socket of the SWA. Fix the plug with the help of the two
screws.
2.2 Power supply

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 10
Connect the scanner to one of
the USB 2.0 ports of the SWA.
More information is available in
the Quickstep:
„0.6-QS_Scanner“
Additional devices can be connected to the SWA using a USB
hub (STAMA no. 3576).
2.3 Further connections of the SWA
Touch-Function:
Connect the USB cable to a
USB-A 3.0 port of the SWA and
the USB-B 3.0 connector of the
monitor.

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 11
Connect monitor to SWA via
HDMI cable.
Connect the pick-to-light connector to the PTL port.
More information in the QS: „2.1-QS_PTL“
Integrate the SWA into your
network via the Ethernet socket.
Optionally, you can use a switch
(STAMA no. 3635) for the
connection of several network
devices
or an access point (STAMA no.
3578) for the connection of wireless
devices to the SWA:

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 12
2.4 Assignment of inputs and outputs
Digital input and output
connectors of the SWA.
Use the plugs provided for this
purpose.
Optional electrical cabinet
(STAMA-No.: 3574 / 3575):
To assign your inputs and
outputs

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 13
Connect the wires to the corresponding sockets
of the plug. Then insert the plug into the input
socket.
The earthing, power supply and the desired
inputs have to be connected according to the
wiring scheme shown on the right.
2.4.1 Assignment of the inputs
Pay attention to the maximum voltage of 24
VDC. Exceeding the voltage or reversing the
polarity will destroy the device!
No liability can be accepted for improper
wiring.
SWA Input
Client

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 14
Connect the wires to the corresponding sockets
of the plug. Then insert the plug into the output
socket.
2.4.2 Assignment of the outputs
Client
The earthing, power supply and the desired
outputs have to be connected according to the
wiring scheme shown on the right.
Pay attention to the maximum current of 500
mA. Exceeding the current or reversing the
polarity will destroy the device!
No liability can be accepted for improper
wiring.

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 15
Every SWA server and SWA client contains a
built-in internal key reader. Three keys are
provided, which can be assigned to different
user data.
For additional information on setting up the
keys, please refer to the Quickstep: „0.2-
QS_Assistant“
2.5 Key reader internal and external
External key reader:
The functionalities and set up are identical to
the internal key reader. The connection is made
via a USB port on the SWA. A USB hub may also
be required (see page 10).
Connection via USB
For additional information on setting up the
keys, please refer to the Quickstep: „0.2-
QS_Assistant“

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 16
3. System start
When everything has been connected, start the SWA
by pressing the „On/Off“ switch once. The LED ring
will now light up green. In case it does not, please
check the power supply.

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 17
4. Shortcuts and definitions
Shortcuts
Description
ELAM Electronic line connection of assembly systems
ETH Ethernet
I/O Input / Output
Key RFID-Chip for employee identification
PTL Pick to Light
QS Quickstep, Quick guides for ELAM system components
STAMA Nr. Internal part number at Armbruster Engineering
SWA Smart Work Assistent

ELAM SYSTEM
Quicksteps –Hardware installation
Confidential. All rights reserved. Dissemination or reproduction without the written permission of Armbruster Engineering is not permitted. 18
Contact
Armbruster Engineering GmbH & Co.KG
Neidenburger Straße 28
28207 Bremen
Tel: [phone]
Fax: [phone]
Mail: [e-mail]
Web: www.armbruster.de
Contact for the Quicksteps
Mr. Christoph Nordheim
Tel: [phone]
Mail: [e-mail]
All rights reserved. The transfer or
duplication without a permission of
Armbruster Engineering is prohibited.
© Copyright 2023
Armbruster Engineering GmbH & Co. KG
Link to the latest Quicksteps:
https://www.armbruster.de/downloads/
