Array electronic TC-Pro481 Series User manual

Ver:3.0

1
Multifunction LCD Digital Counter
Multifunction LCD Digital Counter
TC-Pro481×××
Highly visible display with backlit negative transmissive LCD
Visual alert when output status changes
PNP/NPN switchable DC-voltage input
Finger-safe terminals(screw terminal block models)
Three-language instruction manual
Applied to connect PC/HMI
Contents
Model Number Structure....................................................2
Specifications.....................................................................3
Nomenclature.....................................................................5
Operating Procedures........................................................8
Counter Function .............................................................11
Tachometer Function .......................................................20
Dimensions ......................................................................24
Input Connections ............................................................26
Safety Precautions...........................................................28
Additional Information ......................................................30
List of Settings .................................................................32
■
■
■
■
■
■

2
Multifunction LCD Digital Counter
Model Number Structure
List of Models
Output type Supply voltage
Model
Standard Communication
Contact output 100~240 VAC TC-Pro481SRA (-D) TC-Pro481CRA (-D)
24 VDC/24 VAC TC-Pro481SRD (-D) TC-Pro481CRD (-D)
Transistor output 100~240 VAC TC-Pro481STA (-D) TC-Pro481CTA (-D)
24 VDC/24 VAC TC-Pro481STD (-D) TC-Pro481CTD (-D)
Note: The model with communication must be used with cable.
Model Number Legend
TC-Pro 481 -
1 2 3 4
Accessories (Order Separately)
Name Models
9-pin Female D-sub cable for RS-232 connector, 1.5m Cable CAB-090A232
9-pin Female D-sub cable for RS-485 connector, 1.5m Cable CAB-090A485
9-pin Female D-sub cable for RS-422 connector, 1.5m Cable CAB-090A422
9-pin male D-sub adapter for
CAB-090A232/CAB-090A485/CAB-090A422 ADP-090401
9-pin Female D-sub cable for RS-232 connector, 1.5m Cable CAB-090B232
9-pin Female D-sub cable for RS-485 connector, 1.5m Cable CAB-090B485
9-pin Female D-sub cable for RS-422 connector, 1.5m Cable CAB-090B422
Mounting Track 0F-A
Panel Protective Cover SVF-A
Communication Protective Cover TTL-11
Note：CAB-090A232/485/422 is used for Flush mounting products
CAB-090B232/485/422 is used for DIN track mounting products
■
■
■
Communication
S: Standard (no communication)
C: Communication
Output type
R: Contact
T: Transistor
1.
2.
Supply voltage
A: 100V~240VAC
D: 24VDC、24VAC
Mounting method
None: Flush mounting
D: DIN track mounting
3.
4.

3
Multifunction LCD Digital Counter
Specications
Ratings
Item TC-Pro481□□□-□
Classication Digital counter
Supported
congurations
1-stage counter, 2-stage counter, total counter, batch counter, dual counter, and tachometer
(selectable)
Rated supply voltage 100~240VAC (50/60Hz), 24VAC (50/60Hz),24VDC (permissible ripple:20% (p-p) max.)
Operating voltage
range 85% to 110% rated supply voltage (24VDC; 90% to 110%)
Power consumption
Approx. 6.2VA at 264VAC,
Approx. 5.1VA at 26.4VAC,
Approx. 2.4W at 24VDC
Mounting method Flush mounting, DIN track mounting
External connections Screw terminals
Terminal screw
tightening torque 0.5 N•m Max.
Display
7-segment, LCD display
Present value: 9-mm-high characters, white
Set value: 4-mm-high characters, white
Digits 6 digits, PV/SV (-99,999~999,999)
Input signals CP1, CP2, Reset 1, Reset 2
Max. counter speed 30Hz or 5KHz (10KHz for tachometer) selectable, ON/OFF ratio 1:1, common setting for CP1
and CP2
Input mode Increment, decrement, command, individual, and quadrature
Input method
No-voltage input/voltage input (switchable)
No-voltage input
ON impedance: 1kΩ max. (leakage current: 5~20 mA at 0Ω)
ON residual voltage: 3V max.
OFF impedance: 100kΩ min.
Voltage Input
High (logic) level: 4.5 to 30 VDC
Low (logic) level: 0 to 2 VDC
(Input resistance: approx. 4.7 kΩ)
※
◆
◆
Reset input Minimum reset input signal width: 1 or 20ms(selectable), common setting for all inputs
Reset system External, manual, and automatic reset (internal according to C,R,P, and Q mode operation)
Output modes N,F,C,R,K-1,P,Q,A,K-2,D,L,H
One-shot output time 0000.01~9999.99s
Output method Relay/transistor output
Control output
SPDT contact output: 5A at 250 VAC, resistive load (cosФ=1)
Minimum applied load: 10 mA at 5 VDC (failure level: P, reference value)
Transistor output: NPN open collector, max. 100mA at 30 VDC
Residual voltage: 1.5 VDC max. (approx. 1V)
Output category according to EN60947-5-1 for timers with Contact outputs
(AC-15; 250V 3A / AC-13; 250V 5A / DC-13; 30V 0.5A)
Output category according to EN60947-5-2 for timers with Transistor outputs
(DC-13; 30V 100 mA)
NEMA B300 Pilot Duty, 1/4 HP 5-A resistive load at 120 VAC, 1/3 HP 5-A resistive load at 240
VAC
External power supply 12VDC (15%), 80mA
Key protection Yes
Prescaling function Yes (000.001~999.999)
Decimal point
adjustment Yes (rightmost 3 digitals)
Sensor waiting time Approx. 250 ms (control output is turned OFF and no input is accepted during sensor waiting
time)
Memory backup EEPROM (overwrites: 100,000 times min.) that can store data for 10 years min.
Ambient temperature Operating: -10 to 55°C (with no icing or condensation)
Storage: -25 to 65°C (with no icing or condensation)
Ambient humidity 25% to 85%
Case color Flush mode: black, DIN track mode: gray-black
Attachments Waterproof packing, ush mounting adapter
■

4
Multifunction LCD Digital Counter
Characteristics
Item TC-Pro481□□□-□
Life expectancy Mechanical: 10,000,000 operations min.
Electrical: 100,000 operations min. (5 A at 250 VAC, resistance load)
EMC
(EMI)
Emission Enclosure:
Emission AC mains:
(EMS)
Immunity ESD:
Immunity RF-interference:
Immunity Conducted Disturbance:
Immunity Burst:
Immunity Surge:
Immunity voltage Dip/interruption:
EN61326
EN55011
EN55011
EN61326
EN61000-4-2
EN61000-4-3
EN61000-4-6
EN61000-4-4
EN61000-4-5
EN61000-4-11
Weight Approx. 168g
■

5
Multifunction LCD Digital Counter
Nomenclature
Reset Operation by Reset Key
Conguration Reset operation
1-stage/2-stage
counter Resets the present value and outputs
Total counter
Resets the present value and outputs
When the total count value is displayed, resets the present value, the total count
value, and outputs.
Batch counter
Resets the present value and OUT1
When the batch count value is displayed, resets the present value, the batch count
value, and outputs.
Dual counter Resets the CP1 present value, CP2 present value, dual count value and outputs
tachometer Maintains the measured value and outputs
■
Reset Indicator
Control Output Indicator
Present Value (character height: 9 mm)
Set Value (character height: 4 mm)
The First Setting Key
The Second Setting Key
The Third Setting Key
The Fourth Setting Key
The Fifth Setting Key
The Sixth Setting Key
Reset Key (resets present value and output)
Mode Key (changes modes and setting items)
Key Protection Indicator (the preset value is OFF)
Set Value (Range) A, B Display

6
Multifunction LCD Digital Counter
Block Diagram
Output circuit
Basic isolation
Display circuit
Key switch circuit
Input circuit Internal control circuit
Power supply circuit
Basic isolation
I/O Functions (Counter)
Inputs
CP1, CP2
In general (except for dual counter mode)
Reads counting signals
Increment, decrement, command, individual, and quadrature inputs
accepted.
When used as a dual counter
Reads CP1 count signals with CP1 input and CP2 count signals with
CP2 input.
Increment signals can be input.
1.
2.
Reset or Reset 1
In general (except for dual counter mode)
Resets present value and outputs
Counting can not be performed during reset/reset 1 input
The reset indicator is lit during reset input.
When used as a dual counter
Resets CP1 present value
Counting for CP1 input can not be performed during reset 1 input.
The reset indicator is lit during reset 1 input.
1.
2.
Total Reset or Reset 2
(see note 2.)
When used as 1-stage/2-stage counter
Does not operate (Not used).
When used as a total and present counter
Resets the total count value
Hold the total count value at 0 during total reset input
When used as a batch counter
Reset the batch count value and batch output (OUT1)
Holds the batch count value at 0 during total reset 2 input
When used as a dual counter
Resets the CP2 present value
Counting for CP2 input can not be performed during reset 2 input
1.
2.
3.
4.
Output Control output
(OUT)
Outputs take place according to designated output mode when
corresponding preset is reached.
Note:
In increment mode or increment/decrement mode, the present value returns to 0, in decrement mode,
the present value returns to the set value with 1-stage models, and returns to set value 2 with 2-stage
models.
The reset indicator will not be lit when the total reset or reset 2 input is ON.
■
■
1.
2.

7
Multifunction LCD Digital Counter
I/O Functions (Tachometer)
Inputs
CP1, CP2 Reads counting signals. (CP2 input is not used)
RESET1, RESET2 Holds the measurement value and outputs. (CP2 input is not used)
The reset indicator is lit during hold.
Outputs OUT1, OUT2 Outputs signals according to the specied output mode when a set value
is reached.
■

8
Multifunction LCD Digital Counter
Operating Procedures
1-stage/2-stage/Total/Batch/Dual Counter/Tachometer Selection Mode
Run mode
1-stage/2-stage/total/batch/dual counter/tachometer selection mode
Note: when the mode is changed to 1-stage/2-stage/total/
batch/dual counter/tachometer selection mode,
counter will be reset.
1-stage counter setting mode
(See Run Mode on page 10)
2-stage counter setting mode
(See Run Mode on page 10)
Total counter setting mode
(See Run Mode on page 17)
Batch counter setting mode
(See Run Mode on page 17)
Dual counter setting mode
(See Run Mode on page 18)
Tachometer setting mode
(See Run Mode on page 19)
Power ON
See note
3s min.
See note
3s min.
■

9
Multifunction LCD Digital Counter
Communication Format Function Selection Mode
Power ON
See note
3s min
See note
3s min
Note: Counter will reset when changing into the communication
format setting mode during operation
Transmission
Speed
Parity Check
Date bit
Stop bit
Station
address
Communication
on/off
Set the transmision speed with key
Set the parity check with key
Set the date bit with key
Set the stop bit with key
Set the Station address (HEX) with key
Set communication on/off with key
Transmission speed:1200,2400,4800,9600,14400,19200,28800,38400,57600bps
(NONE) (ODD) (EVEN)
(8 bit) (7 bit)
(1 bit) (2 bit)
(01) (FF)
(ON) (OFF)
Note: The communication format function is not performed for the model without the
communication function.
Run mode
Communication Format Function Selection Mode
■

10
Multifunction LCD Digital Counter
Key Protection Setting Mode
Power ON
Note: the forecast setting value is not changed if the mode is
switched to K/P setting mode and returned to Run Mode
during operation.
When key protection switch is set to ON, it is
possible to prevent setting errors by prohibiting
the use of certain operation keys by specifying
the key protection level (KP1 to KP-5). The key
protection indicator is lit while the key protection
switch is set to ON
See note
3s min.
See note
3s min.
K/P ON
Setting mode
K/P OFF
Setting mode
Run Mode
K/P Setting Mode
Level Meaning Changing mode
(see note)
Switching display
during operation Reset key Up/down key
KP- 1
(default setting) No Yes Yes Yes
KP- 2 No Yes No Yes
KP- 3 No Yes Yes No
KP- 4 No Yes No No
KP- 5 No No No No
Note: Changing mode to 1-stage Counter, 2-Stage Counter, Total Counter, Batch Counter, Dual Counter and
Tachometer selection mode ( 3 min.), Communication Format Function Mode
( 3min.), and Basic Function setting ( 3s min.)
■

11
Multifunction LCD Digital Counter
Counter Function
Setting for Counter Function
Power ON
Run mode
1-stage counter function setting mode
See note 1 See note 2
3s min.
See note 3
See note 6
3s min.
(See note 3) when using as a dual counter:
Dual counter calculating mode
Note: Displayed for output modes other than K-2,
D, L and H only.
See note 4 See note 4
Note: displayed for output modes other than K-2, D, L and H only.
(UP) (DOWN) (UP/DOWN A) (UP/DOWN B) (UP/DOWN C)
Note : Displayed only when the output mode is C, R, K-1, P, Q, A or K-2.
(000.001s) (000.005s) (099.990s) (999.999s)
(000.001) (001.000) (999.999)
See note 5 See note 5
Note 5: displayed only when the input mode is UP/DOWN A, B or C.
(N) (F) (C) (R) (K-1) (P) (Q) (A) (K-2) (D) (L) (H)
(30Hz) (5KHz)
(20ms) (1ms)
(no decimal point) (one digit after
decimal point)
(two digit after
decimal point)
(three digit after
decimal point)
(NPN input) (PNP input)
(K-1) (K-2) (K-3) (K-4) (K-5)
(See note 6)when using as a 2-stage counter :
when using as a batch counter:
One-shot output 2 time
One-shot output 1 time
One-shot output 2 time
Note: Displayed only when the output mode is C, R,K-1,P,Q,A or K-2.
(000.001s) (000.500s) (999.999s)
(000.001s) (000.500s) (999.999s)
(HOLD) (000.001s) (999.999s)
Input mode
Output mode
Counting
speed
Decimal point
position
Prescale value
Key protection
level
One-shot
output mode
Input signal
width
NPN / PNP
input mode
■

12
Multifunction LCD Digital Counter
Explanation of functions
Input mode (cntm)
Set increment mode(UP)、decrement mode
(DOWN)、or increment/ decrement mode (UP/
DOWN A、UP/DOWN B、UP/DOWN C) as the
input mode.
Dual count calculating mode (calm)
When using a dual counter, select ADD (addition)
or SUB (subtraction) as the calculation method for
the dual count value. SUB mode can be used only
when K-2, D, L or H is selected as the output mode
with 6-digit models.
ADD: Dual count value=CP1 PV+CP2 PV
SUB: Dual count value =CP1 PV-CP2 PV
Output mode (outm)
Set the way that control output for the present value
is output. The possible settings are N,F,C,R,K-
1,P,Q,A,K-2,D,L and H.
One-shot output 2 time (otm2)
Set one-shot output time for control output (OUT2)
when using as a 2-stage counter or batch counter.
(000.001 to 999.999)One-shot output can be used
only when C, R, K-1, P, Q, A or K-2 is selected as
the output mode.
One-shot output 1 time (otm1)
Set one-shot output time (000.001 to 999.999)
for control output (OUT1) when using as 2-stage
counter. One-shot output can be used only when D,
L or H is selected as the output mode. If the output
time is set to 0.00, HOLD is displayed, and outputs
are held. HOLD can not be set when the output
mode is K-2.
Counting speed (cnts)
Set the maximum counting speed (30Hz/5KHz) for
CP1 and CP2 inputs together. If contacts are used
for input signal, set the counting speed to 30Hz.
Processing to eliminate chattering is performed for
this setting.
■
Input signal width (it)
Set Reset input signal width (20ms/1ms) for reset/
reset1 and total reset/reset2 inputs together. If
contacts are used for input signals, set the counting
speed to 20ms. Processing to eliminate chattering
is performed for this setting.
Decimal point position (dp)
Decide the decimal point position for the present
value, CP1/CP2 present values, set value (SV1,
SV2), total count value and dual count set value.
Prescale value (pscl)
Pulses input to the counter are converted according
to the specified prescale value. (Setting range:
000.001~99.999)
Example: To display the feed distance for systems
that output 25 pulses for a feed length of 0.75m in
the form □□□.□□□m:
1. Set the decimal point position to 2 decimal places
2. Set the prescale value to 0.03
25 pulses
Encoder
NPN/PNP input mode (imod)
Select either NPN input (no-voltage input) or PNP
input (voltage input) as the input format. The same
setting is used for all external inputs.

13
Multifunction LCD Digital Counter
Operation in Run Mode
Set values for each digit as required with the keys.
1-stage Counter
Present value
Set value
Present value: Shows present count value
Set value(Set value 1,2): Set the set value. When the present
value reaches the set value, signals
are output according the specified
output mode.
Dual Counter
Dual count value
Set value for
Dual counting
CP1 Present value
CP2 Present value
Dual count value:
Shows the sum of the CP1 present value and the CP2 present value
when the dual count calculating mode is ADD and shows the value
obtained by subtracting the CP1 present value from the CP2 present
value when the dual count calculating mode is SUB.
Dual count value:
Set dual count value. When the dual count value reaches the dual count
set value, signals are output according to the specified output mode.
CP1/ CP2 present value:
Show the present count values for CP and CP2 present values
respectively.
2-stage Counter
Present value
Set value 1
Present value
Set value 2
Total and forecast counter
Present value
Set value
Total count
value
Present value/ Set value:
Same as 1-stage counter
Total count value:
Shows the present total count value
Batch Counter
Present value
Set value
Batch count value
Set value for
Batch counting
Present value/ Set value:
Same as 1-stage counter
Batch count value: shows the number of times the count has
been completed for the present value.
Batch count set value: set the batch count set value. When batch
count value reaches the batch count set value,
batch output (OUT1) turns ON.
■
2

14
Multifunction LCD Digital Counter
Input Modes and Present Value (Counter)
UP (increment) Mode DOWN (decrement) mode
UP / DOWN A command input mode
UP / DOWN B individual input mode
UP / DOWN C Quadrature input mode
■
Note:
If the conguration selection is set to dual count,
CP1 and CP2 input will operate in the same
way as the count input (CP1) of UP (increment)
mode.
The meaning of the H and L symbols in the
tables is explained below.
Input method
symbol
No-voltage
(NPN input)
Voltage input
(PNP input)
H Short-circuit 4.5~30VDC
L OPEN 0~2VDC
1.
2.

15
Multifunction LCD Digital Counter
Input/Output Mode Setting(Counter)
Operation for 1-stage models is the same as that for
OUT2.
When using a 2-stage model as a 1-stage counter, or
dual counter, total and preset counter, OUT1 and OUT2
turn ON and OFF simultaneously.
Output mode
UP DOWN UP/DOWN A, B, C Operation after
count completion
N
The outputs and
present value display
are held until reset/
reset1 is input.
F
The present value
display continues to
increase/decrease.
The outputs are held
until reset/reset1 is
input.
C
As soon as the count
value reaches SV,
the present value
display returns to the
reset start status. The
present value display
does not show the
present value upon
count-up. The outputs
repeat one-shot
operation. OUT1 self-
holding output turns
OFF after the OUT2
one-shot output
time. The OUT1 one-
shot output time
is independent of
OUT2.
R
The present value
display returns to the
reset start status after
the one-shot output
time. OUT1 self-
holding output turns
OFF after the OUT2
one-shot output
time. The OUT1 one-
shot output time
is independent of
OUT2.
Note:
The full scale (FS) for TC-Pro 6-digit models is 999999.
When the present value reaches 999999, it returns to 0.
Counting can not be performed during reset/reset1 input.
If reset/reset1 is input while one-shot output is ON, one-shot output turns OFF.
Do not use the counter function in applications where the count may be completed (again) while
one-shot output is ON.
■
1.
2.
3.
4.
5.
(the one-shot output time can be
set in the range 0.001to 999.999s)
Self-holding
output
One-shot One-shot output
Output mode setting

16
Multifunction LCD Digital Counter
Output mode
UP DOWN UP/DOWN A, B, C Operation after
count completion
K-1
The present value
display continues to
increase/decrease.
OUT1 self-holding
output turns OFF
a f t e r t h e O U T 2
one-shot output
ti m e . T h e OU T 1
one-shot output
time is independent
of OUT2.
P
The present value
display does not
change during the
one-shot output
time, but the actual
count returns to the
reset status.
The outputs return
to the one-shot start
state and repeat
one-shot operation.
OUT1 self-holding
output turns OFF
a f t e r t h e O U T 2
one-shot output
ti m e . T h e OU T 1
one-shot output
time is independent
of OUT2.
Q
The present value
c o n t i n u e s t o
increase/decrease
fo r th e o ne -s h ot
output time, but
returns to the reset
start status after
the one-shot output
time has elapsed.
The outputs repeat
one-shot operation.
OUT1 self-holding
output turns OFF
a f t e r t h e O U T 2
one-shot output
ti m e . T h e OU T 1
one-shot output
time is independent
of OUT2.
A
The present value
display and OUT1
self-holding output
is held until reset/
reset1 is input.
OUT1 and OUT2
are independent.
Note:
The full scale (FS) for TC-Pro 6-digit models is 999999.
When the present value reaches 999999, it returns to 0.
Counting can not be performed during reset/reset1 input.
If reset/reset1 is input while one-shot output is ON, one-shot output turns OFF.
Do not use the counter function in applications where the count may be completed (again) while
one-shot output is ON.
1.
2.
3.
4.
5.
Output mode setting

17
Multifunction LCD Digital Counter
(the one-shot output time can be set in the range 0.001to 999.999s)
Self-holding
output
One-shot One-shot output
Output mode
UP/DOWN A, B, C Operation after count
completion
K-2
The display continues to increase/
decrease until the overflow or
underow value is reached. One-
shot output only.
D
The display continues to increase/
decrease until the overflow or
underflow value is reached. The
outputs are ON while the count is
equal.
L
The display continues to increase/
decrease until the overflow or
underow value is reached. OUT1
is held while the present value is
less than or equal to set value 1.
OUT2 is held while the present
value is less than or equal to set
value 2.
A
The display continues to increase/
decrease until the overflow or
underow value is reached. OUT1
is held while the present value is
less than or equal to set value 1.
OUT2 is held while the present
value is less than or equal to set
value 2.
Note: H mode is available for
2-stage models only.
Note:
Counting can not be performed during reset/reset 1 input.
If reset/reset 1 is input while one-shot output is ON, one-shot output turns OFF.
Do not use the counter function in applications where the count may be completed (again) while
one-shot output is ON.
1.
2.
3.
Output mode setting

18
Multifunction LCD Digital Counter
Total Operation
TC-Pro481 has a total counter, separate from the 1-stage present counter, for counting the total accumulated
value.
the total counter continues to
count the total accumulated
value when the present value is
reset using reset/reset 1 input
(reset key).
the total count value is reset
when the total reset/reset
2 input is turned ON. If the
reset key is pressed while the
total count value is reset. The
present value is also reset at
this time.
the counting range of the total
counter is -99,999 to 999,999
(-999 to 9,999). The total count
val u e return s t o 0 when it
reaches the full scale limit.
◆
◆
◆
Batch Counter Operation
TC-Pro481 has a batch counter, separate from the 1-stage present counter, for counting the number of times
the count value returns to 0 when it reaches the full scale limit.
The batch counter continues
after count completion.
Batch output is held until batch
counter reset is input.
When the batch counter reset
input is turned ON, the batch
count value is reset, and batch
output turns OFF.
If the reset key is pressed
while the batch count value is
displayed, the batch count value
is displayed, the batch count
value is reset and batch output
turns OFF. The present value is
also reset at this time.
◆
◆
◆
◆
Note:
The batch count value is held at 0 during batch counter reset input.
If the batch count set is 0, batch count will be performed but there will be no batch output.
The batch count value returns to 0 when it reaches 999,999.
Once batch input has been turned ON, it will return to the ON state after power interruptions.
If the batch count set value is changed from a value that is greater than the batch count value to one that
is less, batch output will turn ON.
■
■
1.
2.
3.
4.
5.

19
Multifunction LCD Digital Counter
Operation (Dual Counter)
Using the dual counter allows the count from 2 inputs to be added or subtracted and the result displayed.
It is possible to specify a set value for which output turns ON when the set value matches the added or
subtracted result.
OUT1 and OUT2 turn ON and OFF simultaneously.
Dual Count Calculating Mode = ADD
Dual count value = CP1 PV + CP2 PV
Dual Count Calculating Mode = SUB
Dual count value = CP1 PV -CP2 PV
Note: the above is for when the output mode is N. Note: the above is for when the output mode is K-2. SUB
mode can be used only when K-2, D,L or H is
selected as the output mode with 6-digit models.
the operation after count completion for the dual counter value is determined by the output mode.
the CP1 present value is reset when reset 1 input is turned ON and the CP2 present value is reset when reset 2
input is turned ON.
if the reset key is pressed while the dual count value, CP1 present value or CP2 present value is displayed, all of
the present values are reset and outputs turn OFF. At this time, counting is not possible for CP1 or CP2 input.
◆
◆
◆
Note:
Counting is not possible for CP1 during reset 1 input. CP2 will not be affected. The dual count value will
be calculated based on a CP1 present value of 0.
Counting is not possible for CP2 during reset 2 input. CP1 will not be affected. The dual count value will
be calculated based on a CP2 present value of 0.
The counting range for dual count value is -99,999 to 999,999.
Reset Function List
Function
1-stage/2-
stage
counter
Total counter Batch counter Dual counter
Screen
displayed in
run mode
Present
value/set
value(1,2)
Present
value/set
value
Total count
value
Present
value/set
value
Batch count
value/ batch
count set
value
Dual count
value/dual
count set
value
CP1 present
value/ CP2
present
value
Reset/reset
1
Present
value and
output reset
Present value and output
reset
Present value and output
reset
Only the CP1 present
value is reset
Total reset/
reset 2 No effect Only the total count value is reset
Batch count value and
batch output reset.
Only the CP2 present
value is reset
Reset key
Present
value and
output reset
Present
value and
output reset
Present
value, total
count value,
and output
reset
Present
value and
output reset
Present
value, batch
count value,
output and
batch output
reset.
CP1 present value, CP2
present value, dual count
value, and output reset.
■
1.
2.
1.
2.
3.
■
