Arrow Storage Products ED108 Use and care manual

Model No. ED108
ED108LG
SBVD108 A
WR108
ED108SB
WR108EU
ED108BS
ED108T
VD108 A
ED108L
ED108Z
VD108EUA
VDGY108
VDGY108EU
697.68618
BUILDING DIMENSIONS * Size rounded off to the nearest foot
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS
PIECES TO AVOID A MISHAP. FOR SAFETY SAKE,
PLEASE READ SAFETY INFORMATION PROVIDED IN
THIS MANUAL BEFORE BEGINNING CONSTRUCTION.
WEAR GLOVES WHEN HANDLING METAL PARTS.
Exterior Dimensions Interior Dimensions Door
*Approx. Base (Roof Edge to Roof Edge) (Wall to Wall) Opening
Size Size Width Depth Height Width Depth Height Width Height
10' x 8' 121" x 92 3/4" 123 1/4" 95 1/4" 82 1/8" 118 1/4" 90" 80 7/8" 55 1/2" 69 1/4"
3,0 m x 2,3 m
307,3 cm x 235,6 cm
313,1 cm
241,9 cm
208,6 cm
300,4 cm
228,6 cm
205,4 cm
141,0 cm
175,9 cm
Owner's Manual &Assembly Instructions
ED01
723710717
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
[email protected]
Do not return to dealer, they are not
equipped to handle your requests.
Storage Area: 74 Sq. Ft. 470 Cu. Ft.
6,9 m2 13,3 m3

Owner's Manual
Before beginning construction, check local building codes regarding footings,
location
and other requirements. Study and understand this owner's manual.
Important information and helpful tips will make your construction easier and more
enjoyable.
Assembly Instructions: Instructions are supplied in this manual and contain all
appropriate information for your building model. Review all instructions before you
begin, and during assembly, follow the step sequence carefully for successful results.
Flooring and Anchoring: Your storage building must be anchored to prevent wind
damage. A base is necessary to construct a square and level building. Anchoring
and base materials are not included with your building. We recommend the
combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an
effective method of securing your building to the ground (Available at your local dealer,
Arrow's website arrowsheds.com or call Arrow's Customer Service department 1-800-
851-1085) or you may construct a base and anchoring system of your choice. Your
assembly instructions provide information on a few methods commonly used to secure
and level a storage building.
Parts and Parts List: Check to be sure that you have all the necessary parts for
your building.
•All part numbers can be found on the parts. All of these numbers (before the -) must agree
with thenumbers on the Parts List page.
•If you find that a part is missing, include the model number of your building and contact:
Arrow Shed, LLC Customer Service
Department1101 North 4th StreetBreese, Illinois
62230
1-800-851-1085or [email protected]
•Separate contents of the carton by the part number while reviewing parts list. The first few
A03
BEFORE YOU BEGIN....

stepsshow how to join related parts to make larger sub assemblies which will be used later.
•Familiarize yourself with the hardware and fasteners for easier use during construction.
These arepackaged within the carton. Note that extra fasteners have been supplied for your
convenience.

Watch the Weather: Be sure the day you select to install your building is dry and
calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy
ground.
Teamwork: Whenever possible, two or more people should work together to
assemble your building. One person can position parts or panels while the other is able to
handle the fasteners and the tools.
Tools and Materials: These are some basic tools and materials you will need for the
construction of your building. Decide which method of anchoring and the type of
base youwish to use in order to form a complete list of the materials you will need.
Required
•Eye Goggles
•No. 2 Phillips Screwdriver
(With Hardened Magnetic Tip)
Note: A power screwdriver or vari-
able speed drill with Phillips-tip
attachment can speed assembly by
as much as 40%.
Required
•Work Gloves
•Step Ladder
•Utility Knife /
Scissors
•Pliers
•Carpenter's Level
•Tape Measure
Optional Time-
Savers
•Wrench / Nut Driver
•Electric / Cordless Drill
•Square
•String (for squaring frame)
Base Preparation
•Hammer and Nails
•Spade or Shovel
•Hand Saw / Power Saw
•Lumber and/or Concrete
Selecting and Preparing Your Site: Before assembly, you will want to decide on a
location for your building. The best location is a level area with good drainage.
•Allow enough working space for ease of moving parts into position during assembly. Be sure
there will be enough space at entrance for doors to open fully and enough space around the building to
be able to fasten the panel screws from the outside.
A04
PLAN AHEAD....

•Before you begin the first steps in assembling your parts, a base should be constructed
andan anchoring system should be ready to use.

Safety precautions are important to follow throughout the construction of your building.
•Care must be taken when handling various
pieces of your building since some contain
sharp edges. Please wear work gloves, eye
protection and long sleeves when
assembling or performing any
maintenance on your building.
•Practice caution with the tools being used in
the assembly of this building. Be familiar with
the operation of all power tools.
sharp edge
safety edge
sharp edge
safety edge
•Keep children and pets away from
worksite to avoid distractions and any
accidents which may occur.
•Never concentrate your total weight on the
roof of the building. When using a step
ladder make sure that it is fully open and on
evenground before climbing on it.
•Do not attempt to assemble the building if
parts are missing because any building left
partially assembled may be seriously
damaged by light winds. Call 1-800-851-1085
or assist@ arrowsheds.com
•Do not attempt to assemble the building on a
windy day, because the large panels acting as
a "sail", can be whipped about by the wind
making construction difficult and unsafe.
A05
SAFETY FIRST....

Do not store swimming pool chemicals in your building. Combustibles
andcorrosives must be stored in air tight approved containers.
Finish: For long lasting finish, periodically clean and wax the exterior surface. Touch-up
scratches as soon as you notice them on your unit. Immediately clean the area with a
wire brush; wash it and apply touch-up paint per manufacturer's recommendation.
Roof: Keep roof clear of leaves and snow with long handled, soft-bristled broom.
Heavy amounts of snow on roof can damage building making it unsafe to enter. In snow
country, Roof Strengthening Kits are available for most Arrow Buildings for added
protection against heavy snow accumulation. Contact Arrow as outlined on the
Ordering Accessories pageto place an order.
Doors: Always keep the door tracks clear of dirt and other debris that prevent them
from sliding easily. Lubricate door track annually with furniture polish or silicone spray.
Keep doors closed and locked to prevent wind damage.
Fasteners: Use all washers supplied to protect against weather infiltration and to
protect the metal from being scratched by screws. Regularly check your building for
loose screws, bolts, nuts, etc. and retighten them as necessary.
Moisture: A plastic sheet (vapor barrier) placed under the entire floor area with good
ventilation will reduce condensation.
Other Tips....
•Wash off inked part numbers on coated panels with soap and water.
•Silicone caulking may be used for watertight seals throughout the building.
Keep this Owner's Manual and Assembly Instructions for future reference.
A06
CARE & MAINTENANCE....

ROOF STRENGTHENING
(heavy snow load) KITS
Extra roof beams and gable braces
designed for added protection
againstheavy snow accumulation.
Increases
FLOOR FRAME KITS
the strength of your roof.
ANCHOR KITS
Model No.AK4
Anchor Kit contains heavy-duty
steelaugers, 60' (18 m) of steel
cable and
BEFORE
AFTER
MODELS FB47410, FB5465,
FB106-AFB109-A and
FB1014-A
A simple new floor frame system made of heavy-duty, hot-
dipped
4 cable clamps. No digging or
concretepouring, just insert cable
under roof, over roof beams, into
augers and twist augers into the
ground. For buildings
larger than 10'x9' (3,0 m x 2,6 m), use 2 kits.
Model No. AK100
New concrete anchor system
permits anchoring any size Arrow
building directly to a concrete slab.
Each kit contains heavy-duty, hot-
dipped galvanized steel corner
gussets and perimeter clips which fit
over the floor frame and lag bolt
into a concrete slab.Full assembly
instructions and a 1/4" masonary
drill bit are included.
Model No. AK600
Earth Anchor Kit anchors any
sizeArrow building to the
ground.
Each kit contains heavy
duty,hot-dipped
galvanized steel
corner gussets and 4 earth anchors.
galvanized steel. Use as base for plywood, sand or stone.
ATTIC KIT / WORKBENCH KIT
Model No.AT101
Heavy-duty galvanized steel bars
thatfit all 10' (3,0 m) wide Arrow
buildings.
They install quickly and easily to
help organize space and create
more useable space as an attic
or workbench. Will hold up to
250 lbs.(113 kg) evenly
distributed.
Some drilling required to fit buildings without mid-wall bracing.
SHELF UNITS
Heavy-duty, galvanized steel shelf units help organize storage
space. They easily mount on the wall or sit on the floor. Fits all
Arrow buildings.*
TOOL HANGING RACK
Model No. TH100
The perfect tool organizer.
Twin 25 1/2" (64,8 cm) steel
channels plus five heavy-duty
s
n
a
p
-
i
n
ha
n
g
A07
ACCESSORIES....

ers and a small tool holder for
screwdrivers, pliers, etc. Holders
slide along channel for fully
adjustable spacing. Great for
garage, basement, or the back
of any door. Fits all Arrow
Model No. SS404
•Makes 8" to 12" (20,3-30,5
cm)wide shelves in any
length.
•Brackets, braces,
hardware included.
Lumber is not
included.
Model No. SS900-B
•Grey color
•3 shelves
•Holds up to 85 lbs. (38
kg)(even weight
distribution)
storage
buildings.
* Some drilling required to fit buildings without mid-wall bracing.

We recommend that you purchase accessory items from your local storage building dealer whenever
possible; however, because the full line of accessories is not always available from all dealers, Arrow
is offering themto you on a direct basis.
There are two ways to order Arrow Storage Building Accessories:
Option 1
Option 2
Accessories can be
purchased
through
Order accessories by telephone
using your MasterCard or Visa credit
card.
arrowsheds.co
m
Call toll free 1-800-851-
1085(Customer
Service).
Allow 2 weeks for
delivery.
SPECIAL NOTE:
If your accessory is shipped via truck line a day time phone number is required to arrange delivery.
If no one is available to sign for the delivery, you may be subject to a re-delivery charge assessed
by the carrier.
A08
ORDERING ACCESSORIES....
02/13

9
No matter which of the options below you choose for a base, an ARROW ANCHORING KIT is
recommended as an effective method of properly securing your building after assembly is complete.
OPTION1: Directlyon ground (earth)
Assemble your building directly on level ground (grass, dirt, rock, sand, etc.). If you choose this option Arrow has a simple kit
available to provide a floor inside the shed to keep stored items off the ground. This kit can be used to support a plywood floor
(wood not included) or be filled with sand/rock to provide a solid surface. (Order No. FB109-A or 68385-A)
Allow 1 - 2 hours for construction.
OPTION2:WoodPlatform
If you decide to build your own base, be sure to select the appropriate
materials.These are the recommended materials for your base:
�2 x 4's (38 mm x 89 mm) Pressure Treated Lumber
�5/8" (15,5 mm) 4 x 8 (1220 mm x 2440 mm) Plywood-exterior grade NOTE: Pressure Treated Lumber must not be used
where itwill make contact with your storage building. The properties of Pressure Treated Lumber will cause accelerated
corrosion.
If Pressure Treated Lumber comes in contact with your storage building your warranty will be voided.
�10 & 4 penny Galvanized Nails �Concrete Blocks (optional)
The platform should be level and flat (free of bumps, ridges
etc.) to provide good support for the building. The necessary
materialsmay be obtained from your local lumber yard.
To construct the base follow instructions and diagram.
Construct frame (using 10 penny galvanized nails)
Measure 16"/24" (40,6 cm/61,0 cm) sections to
constructinside frame (see diagram)
Secure plywood to frame (using 4 penny galvanized nails)
Allow 6 - 7 hours for construction.
OPTION3: ConcreteSlab
Note: Platform/Slab will extend 9/16" (1,4 cm) beyond
floor frame on all four sides. Seal this 9/16" (1,4 cm) of
wood with aroofing cement (not included), or bevel this
9/16" (1,4 cm) of concrete when pouring, for good water
drainage.
The slab should be at least 4" (10,2 cm) thick. It must be level and flat to provide good support for the
frame.The following are the recommended materials for your base.
�1 x 4's (19 mm x 89 mm) (will be removed once the concrete cures)
�Concrete �Sheet of 6 mil plastic
�We recommend for a proper strength concrete to use a
mix of:1 part cement �3 parts pea sized gravel �2 1/2
parts clean sand
Prepare the Site/Construct a Base
1. Dig a square, 6" (15,2 cm) deep into the ground (remove grass).
2. Fill up to 4" (10,2 cm) in the square with gravel and tamp firm.
3. Cover gravel with a sheet of 6 mil plastic.
The Base For Your Building
A09
Base
FRONT
(DOOR
)
FRONT
(DOOR
)

10
4.Construct a wood frame using four planks of 1x4 (19 mm x 89
mm)lumber.
5. Pour in concrete to fill in the hole and the frame
giving atotal of 4" (10,2 cm) thick concrete. Be sure
surface is level.
Allow 3 - 5 hours for construction and a week for concrete curing
time.
Note: Finished Slab dimensions, with lumber removed.

11
Anchoring Down The Building
It is important that the entire floor frame be anchored after the building is erected.
Below are recommended ways of anchoring.
ArrowAnchoring Kit: (Model No. AK4 or
60298)Recommended for use with any suggested
base.
Contains: 4 Anchors with Cable, Clamps
andinstallation instruction.
Anchoring into Wood/Post:
Use 1/4" (6 mm) Wood Screws. There are 1/4" (6
mm) dia. holes provided in the frames for proper
anchoring.
ArrowAnchoring Kit: (Model No. AK100 or
68383)Recommended for use with the concrete
base.
Contains: Corner gussets, perimeter clips,
hardware,1/4" masonary drill bit and installation
instruction.
Anchoring into Concrete:
1. For poured concrete slab or footing or patio
blocks:Use 1/4" x 2" (6 mm x 51 mm) Lag Screws.
2. For Anchor Post of Concrete poured after
building iserected: Use 1/4" x 6" (6 mm x 152 mm)
Lag Screws.
A10
Anchoring
1.
2.
OVER THE BEAMS
AND INTO THE
GROUND

12
1. 2.

13
Remove from bag of
screwsand save for the
last step
65900A
#10Bx1/2" (13 mm)
65923
65004
65103
Black Screw (8)
#8-32x3/8" (10
mm)
#8Ax5/16" (8
mm)
#8-32 Hex Nut
(145)
(Packed with
Screws)
Bolt (145)
Screw (324)
66045
Handle
(2)
66646
Washer (212)
(6 sheets of
40)
67293
Weather Stripping
(1)
5971
Roof Beam Bracket
(4)
66769
Door Slide
(4)
66382
Lower Door Guide
(4)
66183
Roof Trim Cap
(2 right & 2
left)
67468
Peak Cap
(2)
BB11ctr
Hardware

14
6228
Track Support
(2)

15
Assembly
Key No.
Part
Number
Part
Description
Quantity
in Carton
Check
List
1
8934
Ramp
1
2
9367
Front Floor Frame
2
3
8936
Rear Floor Frame
2
4
9338
Right Rear Wall Angle
1
5
9366
Door Track
2
6
5287
Splice Post
3
7
9339
Left Rear WallAngle
1
8
6001
Left Gable
2
9
6000
Right Gable
2
10
9203
Side Floor Frame
4
11
5288
Corner Post
4
12
9341
Left Side WallAngle
2
13
9340
Right Side WallAngle
2
14
9365
Front Wall Channel
2
15
7311
Door Jamb
2
16
9344
Siding Stud
6
17
8584
Side Siding
12
18
7483
Roof Panel
4
19
8736
Rear Siding
6
20
8486
Ridge Cap
1
21
8737
Front Siding
6
22
10470
Roof Beam
8
23
8468
Right Roof Panel
2
24
6529
Roof Panel
2
25
8469
Left Roof Panel
2
26
8840
Ridge Cap
1
27
8485
Left Side Roof Trim
2
28
8836
Right Side Roof Trim
2
29
10472
Right and Left Doors
2
30
10497
Horizontal Door Brace
4
31
3719
Door Handle Brace
2
32
6301
Vertical Door Brace
2
33
6635
Gable Brace
2
34
6403
Door Track Splice
1
35
69835
Edge Trim Green
4
ED12
Parts List

ED13
Assembly by Key No.
17
15
27
24
28 20
18
25 26
18
22 9 33 23
23
22 22
35 22
8 33
22 22 18
22 8 28
24
18
35 22 25 27
9
11
12
16 19
13 17 16
6 19
5 17 17
19
16
21 30 34
4
6 19 7
19 16 13
19 17 11
11 30
17 29 5
21 14 10 29
3 12 17
21 31 31
10 32 15
32
2 30
21
21 14 11
17 6
17
17
17 3
1610
1 30 21 16
10
2
13
17
