Asgard Addition User manual

It is always recommended to anchor the unit in to the ground. Drill
through the four holes in the base of the unit using 6mm dia masonry drill
to a depth of 70mm. Screw in the anchor fixings. (These have a self
cutting thread). If not anchoring the unit, fit the self-seal plugs
BEFORE BUILDING to block the fixing holes 4 from underneath and
4 from sides of base.
TOOLS REQUIRED
Power driver POSI-DRIV screwdriver, 6mm dia. masonry drill and a
10mm socket or spanner.
ADDITION
ZSCREW32 x4
ZSCREW100 x128
ZSCREW340 x18
32670 x12
6mm
Dia.
Posi-Driv
Screwdriver
10mm
Spanner
18V
ZCOMPPLZS02 x8
ZCOMPPLAS22-23-24 x6
2x 2mm, 2x 3mm, 2x 5mm
RH DOOR 36935 x1
LH DOOR 33867 x1
FRT PNL TRAP PLATE 36934 x1
LARGE FRT PANEL 36560 x1
LH SIDE PANEL 36555 x1
RH SIDE PANEL 36556 x1
RH BACK PANEL 36558 x1
LH BACK PANEL 36557 x1
TOP PANEL 32604 x1
BASE PANEL 36443 x1
FASCIA 36561 x1
RAIN GUARD 32615 x1
BASE INSTRUCTIONS
Flat and firm base. Recommended: concrete, tarmac or paving flags.
Min. distance from walls/ shrubbery: 1000mm.
Min. base size (WxDxH) 1990mm x 1100mm x 50mm.
LEVELING THE UNIT
Correctly level the constructed unit using the shims (ZCOMPPLAS)
provided prior to fixing the unit to the ground. Slide the packing pieces
under the corners of the unit base as required until an equal gap has
been achieved around the door allowing for its smooth operation and
alignment.
For maintenance instructions of this product visit www.asgardsss.co.uk
Warning: some panels may weigh over
20Kg. Beware of manual handling
Warning: Please keep
this key card safe! Refer
to if replacement key is
required.
x2
00001
YOUR UNIQUE
KEY CODE

1
3
5 6
4
2
PLEASE NOTE ALL SCREWS ARE FIXED FROM THE INSIDE
RH SIDE PANEL 36556
RH BACK PANEL 36558
x11 x4
x16
x9
x19
x13
LH BACK PANEL 36557
BASE PANEL 36443
LH SIDE PANEL 36555
LARGE FRT PANEL 36560
ATTACH PANEL 36560 TO LEFT OR
RIGHT HAND SIDE TO DETERMINE
DOOR LOCATION
!
x5
x6
x3 x5
x6
x6
x5
x2
x3
x3
x5
x3
BASE PANEL 32605 x1
NOTE IF NOT ANCHORING THE UNIT
FIT 4X SELF-SEAL PLUGS TO THE
UNDERSIDE OF THE BASE. ALSO FIT
4X ZCOMPPLAZS02 TO SIDES OF BASE
(AS SHOWN)
!
x5
x6
x2
x3

7 8
910
11 12
x7
x8
x21
x12
FRT PNL TRAP PLATE 36934
TOP PANEL 32604
x10 x4
x3
x4
32670
x12
FASCIA 36561
x4
x2
x2
x4
10A. TRAP RAIN GUARD
BETWEEN FASICA &
LID. 10B. SCREW IN
!
RAIN GUARD 32615
x8
x7

13
15
14
www.asgardsss.co.uk
x4
x18
RH DOOR 36935
LH DOOR 33867
36936/08.01.20/KW/REV4
LEVEL SHED UNTIL DOORS
ALIGN USING ZCOMPPLAS
AS SUITABLE
!
ZCOMPPLAS22-23-24
x3
x3
x3
x3
x3
x3
