Copyright ©2016 Zilog®, Inc. All rights reserved.
www.zilog.com
UM026302-0916
User Manual
Z8F64820100ZCOG
Z8 Encore! XP®F6482 Series
Development Kit

UM026302-0916
ii
Z8 Encore! XP®F6482 Series Development Kit
User Manual
DO NOT USE THIS PRODUCT IN LIFE SUPPORT SYSTEMS.
LIFE SUPPORT POLICY
ZILOG’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE
SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS PRIOR WRITTEN APPROVAL OF
THE PRESIDENT AND GENERAL COUNSEL OF ZILOG CORPORATION.
As used herein
Life support devices or systems are devices which (a) are intended for surgical implant into the body, or (b)
support or sustain life and whose failure to perform when properly used in accordance with instructions for
use provided in the labeling can be reasonably expected to result in a significant injury to the user. A criti-
cal component is any component in a life support device or system whose failure to perform can be reason-
ably expected to cause the failure of the life support device or system or to affect its safety or effectiveness.
Document Disclaimer
©2016 Zilog, Inc. All rights reserved. Information in this publication concerning the devices, applications,
or technology described is intended to suggest possible uses and may be superseded. ZILOG, INC. DOES
NOT ASSUME LIABILITY FOR OR PROVIDE A REPRESENTATION OF ACCURACY OF THE
INFORMATION, DEVICES, OR TECHNOLOGY DESCRIBED IN THIS DOCUMENT. ZILOG ALSO
DOES NOT ASSUME LIABILITY FOR INTELLECTUAL PROPERTY INFRINGEMENT RELATED
IN ANY MANNER TO USE OF INFORMATION, DEVICES, OR TECHNOLOGY DESCRIBED
HEREIN OR OTHERWISE. The information contained within this document has been verified according
to the general principles of electrical and mechanical engineering.
Z8, Z8 Encore!, and Z8 Encore! XP are trademarks or registered trademarks of Zilog, Inc. All other prod-
uct or service names are the property of their respective owners.
Warning:

UM026302-0916 Revision History
Z8 Encore! XP®F6482 Series Development Kit
User Manual
iii
Revision History
Each instance in the Revision History table below reflects a change to this document from
its previous version. For more details, click the appropriate links in the table.
Date Revision Level Description Page
Sep
2016 02 Removed RS-232 to 6-pin circuit adapter in the Kit Contents 3,12
Oct
2013 01 Original issue. n/a

Safeguards UM026302-0916
iv
Z8 Encore! XP®F6482 Series Development Kit
User Manual
Safeguards
The following precautions must be observed when working with the devices described in
this document.
Always use a grounding strap to prevent damage resulting from electrostatic
discharge (ESD).
Caution:

UM026302-0916 Table of Contents
Z8 Encore! XP®F6482 Series Development Kit
User Manual
v
Table of Contents
Revision History. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
The Z8 Encore! XP F6482 Series Development Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Kit Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Kit Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Board Support Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Supported Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Download and Install the ZDSII Software and Documentation . . . . . . . . . . . . . . . . . 4
Connect the F6482 Series Development Board to your PC . . . . . . . . . . . . . . . . . . . . 6
Start the Z8F6482 Demonstration Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
HyperTerminal Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
F6482 Series Development Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Z8F6482 MCU Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
SBLCDA4 LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
32Mbit Flash with SPI Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
MIC5318 Low Voltage Drop-Out Regulator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
RE200B Pyroelectric Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
TPA301D Mono Audio Power Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
CVS-1508 Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
TEFT4300 PhotoTransistor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
LM285 Adjustable Micropower Voltage Reference . . . . . . . . . . . . . . . . . . . . . . . . . 27
J16 DBG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Jumper Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
ZDSII Flash Loader Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Z8F6482 Sample Projects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
F6482 Series Development Kit Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Appendix A. Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Appendix B. Installing the USB SmartCable Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Windows 7 32/64 Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Windows Vista 32/64 Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Windows XP-32(SP3) Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Appendix C. Tera Term Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Customer Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

UM026302-0916
Z8 Encore! XP®F6482 Series Development Kit
User Manual
vi
List of Figures
Figure 1. The F6482 Series Development Kit . . . . . . . . . . . . . . . . . . . 2
Figure 2. The Downloadable Software category in the Zilog Store . . 5
Figure 3. Connecting the 6-Circuit Ribbon Cable to the USB
SmartCable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 4. Debug Connector J16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 5. Power Supply Port P1 Connector . . . . . . . . . . . . . . . . . . . . 8
Figure 6. Open Project from the ZDSII File Menu . . . . . . . . . . . . . . . 9
Figure 7. Select the ledblink.zdsproj Project . . . . . . . . . . . . . . . . . . . . 9
Figure 8. Select Z8F64820100ZCOG and USB SmartCable . . . . . . 10
Figure 9. Select Go from the Debug Menu . . . . . . . . . . . . . . . . . . . . 11
Figure 10. Console Output Using Hyperterminal (Windows XP) . . . 11
Figure 11. Console Output Using Tera Term (Windows 7) . . . . . . . . 12
Figure 12. The F6482 Series Development Board . . . . . . . . . . . . . . . 14
Figure 13. F6482 Series Development Kit Block Diagram . . . . . . . . 15
Figure 14. Seven-Segment LCD from Softbaugh . . . . . . . . . . . . . . . . 18
Figure 15. LCD1 Pin Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 16. LCD1 on the F6482 Series Development Board . . . . . . . . 19
Figure 17. 32MBit Flash with SPI Bus . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 18. S25FL032A Pin Configuration . . . . . . . . . . . . . . . . . . . . . 20
Figure 19. U2 on the F6482 Series Development Board . . . . . . . . . . 21
Figure 20. MIC5318 Low Voltage Drop-Out Regulator Pin
Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 21. The MIC5318 Low Voltage Drop-Out Regulator Circuit . 22
Figure 22. The MIC5318 Low Voltage Drop-Out Regulator . . . . . . . 22
Figure 23. RE200B Pyroelectric Sensor Circuit . . . . . . . . . . . . . . . . . 23
Figure 24. The RE200B Pyroelectric Sensor . . . . . . . . . . . . . . . . . . . 23
Figure 25. TPA301D Mono Audio Power Amplifier Pin
Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 26. TPA301D Mono Audio Power Amplifier Circuit . . . . . . . 24

UM026302-0916
vii
Z8 Encore! XP®F6482 Series Development Kit
User Manual
Figure 27. The TPA301D Mono Audio Power Amplifier . . . . . . . . . 25
Figure 28. The CVS-1508 Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Figure 29. TEFT4300 PhotoTransistor Circuit . . . . . . . . . . . . . . . . . . 26
Figure 30. The TEFT4300 PhotoTransistor . . . . . . . . . . . . . . . . . . . . 26
Figure 31. LM285 Adjustable Micropower Voltage Reference . . . . . 27
Figure 32. LM285 Adjustable Micropower Circuit . . . . . . . . . . . . . . 27
Figure 33. The LM285 Adjustable Micropower Device . . . . . . . . . . . 28
Figure 34. The J16 DBG Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 35. The J16 DBG Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 36. An Example Flash Loader Screen . . . . . . . . . . . . . . . . . . . 30
Figure 37. F6482 Series Development Board Schematic
Diagram, #1 of 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 38. F6482 Series Development Board Schematic
Diagram, #2 of 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Figure 39. F6482 Series Development Board Schematic
Diagram, #3 of 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Figure 40. F6482 Series Development Board Schematic
Diagram, #4 of 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

UM026302-0916
Z8 Encore! XP®F6482 Series Development Kit
User Manual
viii
List of Tables
Table 1. Z8F64820100ZCOG Contents . . . . . . . . . . . . . . . . . . . . . . . 3
Table 2. USB to TTL Serial Converter Connections . . . . . . . . . . . . 13
Table 3. LCD1 Pin Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 4. Jumper Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Table 5. Z8F6482 MCU Sample Projects . . . . . . . . . . . . . . . . . . . . 31
Table 6. F6482 Series Development Kit Documentation . . . . . . . . 31

UM026302-0916 The Z8 Encore! XP®F6482 Series Development Kit
Z8 Encore! XP®F6482 Series Development Kit
User Manual
1
The Z8 Encore! XP®F6482 Series
Development Kit
This document describes how to set up the F6482 Series Development Kit (Zilog part
number Z8F64820100ZCOG) and use it to evaluate your Z8F6482-based designs and
applications. The Kit features a development board consisting of four LEDs, three push-
buttons, a buzzer/speaker, a 7.1 seven-segment LCD, a pyroelectric sensor, a phototransis-
tor, 32Mbit SPI Flash, port pin headers, and USB and UART ports. The Board features the
Z8F6482 MCU in a 80-pin LQFP package, plus a DBG connector to connect the Board to
a host development PC using Zilog’s USB SmartCable. To learn more about the Z8F6482
MCU, refer to the F6482 Series Product Specification (PS0294).
This document provides instructions for setting up and configuring Z86482 Development
Board and includes schematic diagrams and a discussion of Board features and ZDSII.
The first sections of this document guide you through the following tasks:
• Download and Install the ZDSII Software and Documentation – see page 4
– Installing the USB SmartCable Driver – see Appendix B. Installing the USB
SmartCable Driver on page 36
• Connect the F6482 Series Development Board to your PC – see page 6
• Start the Z8F6482 Demonstration Program – see page 8
Further details, including memory configurations, jumper settings, and a listing of sample
projects can be found in the Z8F6482 Sample Projects section on page 30.
Figure 1 shows an image of the F6482 Series Development Kit.

The Z8 Encore! XP®F6482 Series Development Kit UM026302-0916
2
Z8 Encore! XP®F6482 Series Development Kit
User Manual
Figure 1. The F6482 Series Development Kit

UM026302-0916 Kit Contents
Z8 Encore! XP®F6482 Series Development Kit
User Manual
3
Kit Contents
Table 1 lists the contents of the F6482 Series Development Kit.
Kit Features
The key features of the F6482 Series Development Kit are:
• F6482 Series Development Board, which includes:
– Z8F6482 MCU in an 80-pin LQFP package operating at 24MHz with 64KB of
internal Flash memory and 3.75KB of internal RAM memory
– 32Mbit SPI Flash
– A USB interface that provides:
○Power to the Board with overcurrent protection
○Connection to the Z8F6482 MCU’s USB port
– 7.1 segment LCD module
– Speaker: SP1
– Pyroelectric sensor
– Phototransistor
– UART(s) port J20
– Test points, headers, and prototype area
– External source of reference voltage (2.5V)
– MCU current measurement test points J5 and J6
– Power supply level adjustable with potentiometer R13
• USB SmartCable
• ZDSII software, samples, and documentation available free for download
– Z8F6482 Board Support Package (BSP) source code and sample programs
Table 1. Z8F64820100ZCOG Contents
Item Description Quantity
1 F6482 Series Development Board 1
2 USB SmartCable 1
3 6-circuit ribbon cable 1
4 A (male) to Mini-B USB cable 1
5 F6482 Series Development Kit Flyer (FL0160) 1

The Z8 Encore! XP®F6482 Series Development Kit UM026302-0916
4
Z8 Encore! XP®F6482 Series Development Kit
User Manual
Board Support Package
The ZDSII software download includes a Board Support Package (BSP) that provides an
application programming interface (API) to configure and control select Z8F6482 MCU
peripherals. This BSP API is accessible through a static library linked to customer applica-
tions and is a blend of macros and C functions that facilitate application development by
abstracting direct SFR manipulation from the programmer. Macros provide near-assem-
bly-level access to SFRs without incurring the overhead (i.e., code size and execution
time) of C functions for basic operations (e.g., stopping a timer). More complex operations
are implemented in C functions, thereby eliminating the customer requirement for recreat-
ing code for frequently-used operations (e.g., transmitting a block of data through the
UART under DMA control). By using the BSP library, customers can develop applications
that access Z8F6482 MCU peripherals with only a few function calls, effectively reducing
development effort to a minimum.
The ZDSII software download also includes complete source code to all peripheral
devices supported by the BSP API. Advanced programmers can cut and paste code snip-
pets from the BSP into their own applications, or simply study the BSP source code to
gain a better understanding of the Z8F6482 Series of MCUs.
To learn more about the BSP API, refer to the F6482 Series Board Support Package Refer-
ence Manual (RM0064).
Supported Operating Systems
The F6482 Series Development Board supports the following operating systems:
• Microsoft Windows 8 (32-bit/64-bit)
• Microsoft Windows 7 (32-bit/64-bit)
• Microsoft Windows Vista (32-bit/64-bit)
• Microsoft Windows XP
Download and Install the ZDSII Software and Documenta-
tion
Observe the following steps to install your ZDSII software and documentation.

UM026302-0916 Download and Install the ZDSII Software and
Z8 Encore! XP®F6482 Series Development Kit
User Manual
5
If you have already installed ZDSII – Z8 Encore! <version> and have downloaded the soft-
ware and documentation by following the procedure on the paper insert in your kit
(FL0160), you’re ready for Appendix B. Installing the USB SmartCable Driver on page 36.
1. Prior to connecting the F6482 Series Development Board to your development PC,
download ZDSII for Z8 Encore! v5.2.2 (or later) from the Downloadable Software
category in the Zilog Store; see Figure 2.
2. When your download is complete, double-click the installation file named
ZDS2_Z8Encore!_<version>.exe, and follow the on-screen instructions.
Figure 2. The Downloadable Software category in the Zilog Store
Note:

The Z8 Encore! XP®F6482 Series Development Kit UM026302-0916
6
Z8 Encore! XP®F6482 Series Development Kit
User Manual
Connect the F6482 Series Development Board to your PC
Observe the following procedure to connect the F6482 Series Development Board to your
PC.
Disconnect or turn off the power to the F6482 Series Development Board before con-
necting or disconnecting the USB SmartCable.
1. Ensure that the following F6482 Series Development board default jumper settings
are configured (see Table 5 on page 31 for reference):
J1 IN
J2 OUT
J9 IN
J19 OUT
J21 1-2 IN
J21 5-6 IN
J23 1-2 IN
2. Connect one end of the 6-circuit ribbon cable provided in your Kit to the USB Smart-
Cable unit, ensuring that the ribbon’s male connector is aligned correctly with the
female connector on the unit, as indicated by the red stripe in Figure 3.
Figure 3. Connecting the 6-Circuit Ribbon Cable to the USB SmartCable
Caution:

UM026302-0916 Connect the F6482 Series Development Board to
Z8 Encore! XP®F6482 Series Development Kit
User Manual
7
3. Connect the other end of the ribbon cable to Debug Connector J16 on the Develop-
ment Board. Ensure that Pin 1 on the ribbon cable is aligned with Pin 1 on the target
connector, as highlighted in Figure 4.
Figure 4. Debug Connector J16

The Z8 Encore! XP®F6482 Series Development Kit UM026302-0916
8
Z8 Encore! XP®F6482 Series Development Kit
User Manual
4. With the USB A (male) to Mini-B cable, connect Port P1 on the F6482 Series Devel-
opment Board to a USB port on the development PC to apply power to the Develop-
ment Board, as highlighted in Figure 5.
Start the Z8F6482 Demonstration Program
The F6482 Series Development Kit includes a sample program that demonstrates a blink-
ing LED application. An optional terminal emulation program and a 3rd Party USB to
TTL Serial converter (not supplied) maybe used and must be configured for 57600-8-N-1
with no flow control, as described in the HyperTerminal Configuration section on page 12.
To get started with the Z8F6482 demonstration, observe the following procedure.
1. Launch ZDSII by navigating from the Windows Start menu to Programs →Zilog
ZDSII – Z8 Encore! <version> →ZDSII – Z8 Encore! <version>.
2. From the File menu in ZDSII, select Open Project as shown in Figure 6, and navigate
via the following filepath.
<ZDS Install>\samples\XP_F6482\XP_F6482_LedBlink_C
Figure 5. Power Supply Port P1 Connector

UM026302-0916 Start the Z8F6482 Demonstration Program
Z8 Encore! XP®F6482 Series Development Kit
User Manual
9
3. Select the ledblink.zdsproj project from within the XP_F6482_ledBlink_C
folder and click Open, as shown in Figure 7. A list of source files will appear in the
workspace panel.
Figure 6. Open Project from the ZDSII File Menu
Figure 7. Select the ledblink.zdsproj Project

The Z8 Encore! XP®F6482 Series Development Kit UM026302-0916
10
Z8 Encore! XP®F6482 Series Development Kit
User Manual
4. From the Build menu, select Set Active Configuration to open the Select Configura-
tion dialog box.
5. Select Debug, then click OK to close the Select Configuration dialog box.
6. From the Project menu in ZDSII, select Settings to open the Project Settings dialog
box. In the Project Settings dialog box, click the Debugger tab.
7. On the Debugger page, select Z8F64820100ZCOG from the Target list, then select
USB SmartCable from the Debug Tool drop-down menu, as shown in Figure 8.
8. Click OK to close the Project Settings dialog box.
9. If you are prompted to rebuild any affected files, click Yes. Otherwise, choose Build
from the menu bar, then click Rebuild All.
10. To run the application, select Go from the Debug menu, as indicated in Figure 9. As a
result, LEDs D4, D5, and D6 will blink in sequence.
Figure 8. Select Z8F64820100ZCOG and USB SmartCable

UM026302-0916 Start the Z8F6482 Demonstration Program
Z8 Encore! XP®F6482 Series Development Kit
User Manual
11
11. After the application has started, console output should be visible in the terminal emu-
lation program, as shown in Figures 10 and 11.
Figure 9. Select Go from the Debug Menu
Figure 10. Console Output Using Hyperterminal (Windows XP)
