Arrow Everest-CortexM1-SFP+Loop-Demo User manual

Project: Everest-CortexM1-SPF+Loop-Demo
Getting Started
created:
S. Rieche
Date
2018-02-19
edited:
S. Rieche
Date:
2018-06-18
approved:
Date:
Filename:
Everest-CortexM1-SPF+Loop-Demo--Getting_Started_1p1.docx
Arrow Central Europe GmbH
Version:
1.1
Page 1 of 19
Everest-CortexM1-SFP+Loop-Demo
Getting Started

Arrow Central Europe GmbH
page 2
User Guide
Everest-CortexM1-Demo
Contents
1. Revision History................................................................................................. 5
1.1 Revision 1.1............................................................................................................... 5
1.2 Revision 1.0............................................................................................................... 5
2. Getting Started................................................................................................... 6
2.1 Prerequisites............................................................................................................. 6
2.2 Handling the Board................................................................................................... 7
2.3 Board-Setup Revision PROTO................................................................................. 7
2.3.1 Toggle-Switch S1 –PCIe ................................................................................. 7
2.3.2 Toggle -Switch S5 –SC SPI-Flash enable....................................................... 7
2.3.3 DIP-Switch S8 –FMC Voltage Selector............................................................ 7
2.3.4 Toggle -Switch S9 –VDDAUX2 & VDDAUX5 Voltage...................................... 7
2.4 Board-Setup Revision A and B................................................................................ 8
2.4.1 Toggle-Switch S1 –PCIe ................................................................................. 8
2.4.2 Toggle -Switch S5 –SC SPI-Flash enable....................................................... 8
2.4.3 DIP-Switch S8 –FMC Voltage Selector............................................................ 8
2.4.4 Toggle -Switch S9 –VDDAUX2 & VDDAUX5 Voltage...................................... 8
2.5 Powering up the Board............................................................................................. 9
3. Demo Design.................................................................................................... 10
3.1 SFP+ related differences between Everest DEV Board PROTO and Revision A and
B 10
3.2 Prerequisites............................................................................................................12
3.3 Design Implementation ...........................................................................................13
3.4 Running the Design.................................................................................................16

Arrow Central Europe GmbH
page 3
User Guide
Everest-CortexM1-Demo
Figures
Figure 1: Everest Board........................................................................................................................... 9
Figure 2: SFP+ hardware Everest DEV Board PROTO........................................................................ 10
Figure 3: SFP+ hardware Everest DEV Board Rev. A and B................................................................ 11
Figure 4: Design Implementation –Top Level Everest DEV Board PROTO ........................................ 13
Figure 5: Design Implementation –Top Level Everest DEV Board Rev. A and B................................ 14
Figure 6: Design Implementation –Modul PF_XCVR_8b10b............................................................... 14
Figure 7: SoftConsole v5.1 workspace launcher................................................................................... 16
Figure 8: SoftConsole v5.1 - starting the debug session ...................................................................... 16
Figure 9: SoftConsole v5.1 - running the design................................................................................... 17
Figure 10: terminal output after startup ................................................................................................. 18
Figure 11: Terminal Output - sending some characters via SFP+ Loop............................................... 19

Arrow Central Europe GmbH
page 4
User Guide
Everest-CortexM1-Demo
Tables
Table 1: Software / IP Requirements .................................................................................................... 12
Table 2: Hardware Design Clock Frequencies...................................................................................... 13

Arrow Central Europe GmbH
page 5
User Guide
Everest-CortexM1-Demo
1. Revision History
The revision history describes the changes that were implemented in the document. The
changes are listed by revision, starting with the most current publication.
1.1 Revision 1.1
The document was updated for Libero SoC PolarFire v2.2.
1.2 Revision 1.0
Revision 1.0 is the first publication of this document.

Arrow Central Europe GmbH
page 6
User Guide
Everest-CortexM1-Demo
2. Getting Started
This demo design implements a SFP+ loop based on the Cortex M1 Demo design, offering a
soft processor subsystem with GPIO’s, UART and I2C functionality. Internal SRAM blocks are
used for both, program and data memory. Two UART terminals are operated through USB
connector J9.
The application prints “Hello World” on both terminals. Characters entered on UART 0 are
printed on UART 1 and vice versa. LEDs 1 and 2 are toggled by a software counter in the main
loop, that could be reseted by pressing one of the four push buttons. LED 4 indicates that the
receiver of XCVR lane 0 is ready and LED 3 is on between the transmission and reception of
a frame. Every frame consists of the comma character “BC”, the actual frame counter value
and the hexadecimal representation of the ASCII character and is printed out on UART 0.
2.1 Prerequisites
For the Everest Cortex M1 SFP+ Loop Demo the following is needed:
Item
Quantity
Everest DEV Board
1
12 V / 5 A wall-mounted power adapter
1
USB 2.0 A male to mini-USB B cable for UART / Programming interface to PC
1
Intel X520-DA2 10GbE Adapter PCIE
1
Finisar FTLX8574D3BCV 10G Optical Transceiver
2
Tripp Lite N820-03M Optical Duplex LC Cable
1
Free one-year Libero Silver software license
1
Note 1: The Everest DEV Board offers an on-board FlashPro5 programmer, which can be
used to program and debug with Identify, SmartDebug and embedded application software
using SoftConsole.
Note 2: There are differences between Everest Dev Board PROTO and Rev. A and B
concerning the configuration of the SFP+ interface that are descripted in chapter 3.1.

Arrow Central Europe GmbH
page 7
User Guide
Everest-CortexM1-Demo
2.2 Handling the Board
Pay attention to the following points while handling or operating the board:
Handle the board with electrostatic discharge (ESD) precautions to avoid damage.
For information about ESD precautions see
https://www.microsemi.com/documentportal/doc_view/126483-esd-appnote.
2.3 Board-Setup Revision PROTO
2.3.1 Toggle-Switch S1 –PCIe
Warning: S1-1 and S1-2 must not be at position on at the same time!
SWITCH ON
PCIe LANES
S1-1
x1
S1-2
x4
2.3.2 Toggle -Switch S5 –SC SPI-Flash enable
Warning: S5-1 and S5-2 must not be at position on at the same time!
SWITCH ON
SC SPI-FLASH
S5-1
ENABLE
S5-2
DISABLE
2.3.3 DIP-Switch S8 –FMC Voltage Selector
Warning: S8-1 to S8-4 must not be at position on at the same time!
SWITCH ON
FMC VOLTAGE
S8-1
3.3 V
S8-2
2.5 V
S8-3
1.8 V
S8-4
undefined (not connected)
2.3.4 Toggle -Switch S9 –VDDAUX2 & VDDAUX5 Voltage
Warning: S9-1 and S9-2 must not be at position on at the same time!
SWITCH ON
VDDAUX2 & VDDAUX5
S9-1
2.5 V
S9-2
FMC voltage

Arrow Central Europe GmbH
page 8
User Guide
Everest-CortexM1-Demo
2.4 Board-Setup Revision A and B
2.4.1 Toggle-Switch S1 –PCIe
SWITCH
PCIe LANES
S1-1 (marking)
x4
S1-2
x1
2.4.2 Toggle -Switch S5 –SC SPI-Flash enable
SWITCH
SC SPI-FLASH
S5-1 (marking)
DISABLE
S5-2
ENABLE
2.4.3 DIP-Switch S8 –FMC Voltage Selector
SWITCH
FMC VOLTAGE
S8-1 off, S8-2 off
1.8 V
S8-1 on, S8-2 off
2.5 V
S8-1 off, S8-2 on
undefined (not recommended)
S8-1 on, S8-2 on
3.3 V
2.4.4 Toggle -Switch S9 –VDDAUX2 & VDDAUX5 Voltage
SWITCH
VDDAUX2 & VDDAUX5
S9-1 (marking)
2.5 V
S9-2
FMC voltage

Arrow Central Europe GmbH
page 9
User Guide
Everest-CortexM1-Demo
2.5 Powering up the Board
Insert the Finisar Optical Transceiver into the J1 connector (SFP+ module cage). A loop has
to be built by connecting the transmitter with the receiver with an optical fiber cable. The
Everest DEV Board is powered up using the 12 V DC jack. For programming connect it
although with your computer using USB mini B connector J9.
Figure 1: Everest Board

Arrow Central Europe GmbH
page 10
User Guide
Everest-CortexM1-Demo
3. Demo Design
3.1 SFP+ related differences between Everest DEV Board PROTO and
Revision A and B
On Everest DEV Board PROTO the SFP+ signals RX_LOS, RS0, RS1, TX_DIS and
TX_FAULT could only be accessed via the I2C I/O expander PCA9538 that is connected to
the same I2C bus as the SFP+ interface itself.
Figure 2: SFP+ hardware Everest DEV Board PROTO

Arrow Central Europe GmbH
page 11
User Guide
Everest-CortexM1-Demo
On Everest DEV Board Rev. A and B these signals are routed directly to GPIOs.
Figure 3: SFP+ hardware Everest DEV Board Rev. A and B

Arrow Central Europe GmbH
page 12
User Guide
Everest-CortexM1-Demo
3.2 Prerequisites
Software and IP core requirements are the same for Everest DEV Board PROTO and Rev. A
and B.
Table 1: Software / IP Requirements
Software
Version
Libero SoC PolarFire
V2.2
Synplify Pro
L2017.09M-SP1-1
FlashPro PolarFire
V2.0
IP
CortexM1
3.0.100
PF_SRAM_ABHL_AXI
1.1.125
PF_INIT_MONITOR
2.0.103
CoreAHBLite
5.3.101
CoreAHBTOAPB3
3.1.100
CoreAPB3
4.1.100
PF_OSC
1.0.102
PF_CCC
1.0.113
CoreUARTapb
5.6.102
CoreGPIO
3.2.102
COREI2C
7.2.101
PF_XCVR_REF_CLK
1.0.103
PF_TX_PLL
1.0.112
PF_XCVR
1.0.231
Before you start you have to make sure, that all cores are downloaded to your local vault.

Arrow Central Europe GmbH
page 13
User Guide
Everest-CortexM1-Demo
3.3 Design Implementation
The following table lists the clock frequencies used in the design.
Table 2: Hardware Design Clock Frequencies
Clock
Frequency (MHz)
PF_OSC
160
PF_CCC OUT0_FABCLK
27.5
HCLK / PCLK
27.5
PF_TX_PLL
156.25
DIV_CLK
125
The top-level design implementation for Everest DEV Board PROTO is shown in Figure 4.
Figure 4: Design Implementation –Top Level Everest DEV Board PROTO
The top-level design implementation for Everest DEV Board Rev. A and B has an extra
CoreGPIO called SFP_CTRL that receives the signal SFP_MOD, SFP_TX_FAULT and
SFP_RX_LOS, including interrupt generation for those signal, and drives the signals
SFP_TX_DIS, SFP_RS0 and SFP_RS1.

Arrow Central Europe GmbH
page 14
User Guide
Everest-CortexM1-Demo
Figure 5: Design Implementation –Top Level Everest DEV Board Rev. A and B
The implementation of submodule PF_XCVR_8b10b is the same for all revisions.
Figure 6: Design Implementation –Modul PF_XCVR_8b10b

Arrow Central Europe GmbH
page 15
User Guide
Everest-CortexM1-Demo
The design is already fully implemented and ready to be programmed on the Everest Board.
The board has to be connected with the power supply and to the PC with the USB cable. All
drivers have to be installed (which should happen automatically when plugged in the first time)
To program the design, there are two possibilities:
- Programming via Libero PolarFire SoC: Programming is started with the “Run
PROGRAM Action” Button in the Design Flow Pane
- Programming via FlashPro Software: There is a STAPL-File (“<Design
Directory>\designer\CortexM1_Subsystem\export\CortexM1_Subsystem.stp”) which
can be programmed with the FlashPro Software. A new FlashPro project has to be
generated and the programming file loaded into.

Arrow Central Europe GmbH
page 16
User Guide
Everest-CortexM1-Demo
3.4 Running the Design
In Order to run the design, the CortexM1-Processor has to be loaded with the firmware. To do
so, load the provided SoftConsole Workspace.
Figure 7: SoftConsole v5.1 workspace launcher
Figure 8: SoftConsole v5.1 - starting the debug session
A debug configuration is provided to download the firmware to the CortexM1 processor and
start the application.

Arrow Central Europe GmbH
page 17
User Guide
Everest-CortexM1-Demo
Figure 9: SoftConsole v5.1 - running the design

Arrow Central Europe GmbH
page 18
User Guide
Everest-CortexM1-Demo
Figure 10: terminal output after startup
Any character entered in terminal 1 will be looped through the fiber of the SFP+. The output of
terminal 0 shows the contend of the receiver module. Every line starts with the comma
character “BC” followed by the actual frame counter value. The end represents the
hexadecimal value of the ASCII character (0x78 = ‘x’, 0x20 = ‘space’, etc.). Figure 11 shows
the terminal output after sending some characters.

Arrow Central Europe GmbH
page 19
User Guide
Everest-CortexM1-Demo
Figure 11: Terminal Output - sending some characters via SFP+ Loop
