Arrow X2-Cadet User manual

SEAT POSITION CHART
X2-CADET / ROOKIE
NOTES:
- All dimensions refer to Kartech ‘RT’ type seats only
- All above measurements are with the rear axle in 920 centre position and chassis in high
position (axle low)
ASSEMBLY NOTES
Arrow self-aligning seat washers:
The Arrow karts are supplied with Arrows unique self-centring seat washer
system. Fitting between the chassis seat supports and seat, these washers
insure there are no torsional loads placed on the seat through mis-
matching angles between the seat and the chassis. The seat does have an
influence on the handling characteristics of the kart as it is an important
torsional member on a karts chassis structure. As such, the Arrow self-
aligning seat washers are major asset in alleviating pre-loads within the
kart. (See diagram above).
SUGGESTED STARTING SET-UP
FRONT CRASH BAR:
Loose
REAR CRASH BAR:
Tight
REAR RIDE HEIGHT:
High (axle low in kart)
REAR TRACK:
1105 (ONLY MOVE IN 5MM INCREMENTS)
REAR AXLE TYPE:
Standard
FRONT RIDE
HEIGHT:
Central
FRONT TOE:
2mm OUT Overall
FRONT TRACK:
10mm (ONLY MOVE IN 5MM INCREMENTS)
FRONT CASTER:
Central, both lines pointing back
FRONT CAMBER:
2mm POSITIVE Overall
FRONT TORSION
BAR:
Removed
SIDE POD BARS:
Loose
REAR HUB LENGTH:
50mm
ACKERMAN:
Middle, top hole on stub arm
SMALL DRIVER
28KG-130 CM TALL
MEDUIM DRIVER
35KG-138CM TALL
LARGE DRIVER
40KG-147CM TALL
A
B
C
A
B
C
A
B
C
SEAT SIZE
MS
100
Use
KSE15D
seat
bracket
240
95
60
215
120
N/A
N/A
N/A
‘SL
Tyre.
Eg.
Dunlop
SL1
MRC
N/A
N/A
N/A
50
215
110
40
215
105

CHASSIS ADJUSTMENTS – what we have found from our testing
ACKERMAN –top holes on stub arm will speed up reaction of steering,
lower hole will slow reaction on steering
SOFTER AXLE –Softer axle will give more grip.
FRONT RIDE HIEGHT –lowering front of chassis will give more steering
REAR CRASH BAR –loosening rear crash bar will give more grip
900 mm WHEELBASE –this wheelbase may work better on smaller
tighter tracks, it will generally give the kart better change of direction
920 mm WHEELBASE –this is standard wheelbase
940 mm WHEELBASE –this wheelbase may work better on long flowing
tracks as it will give more grip and stability
LEAD –we recommend placing lead under the seat. If you require more
than 4 kg you can place on side of seat or if need be on rear of seat. We
only recommend putting lead on rear of seat if driver is small or kart is lack
rear grip. Note –that placement of lead on kart WILL have an effect to the
kart balance, so testing lead position is a good idea.
DUEL CASTOR ADJUSTER TABLE
FORWARD
BACK
RESULT
TOP
X
NEUTRAL CASTOR
BOTTOM
X
FORWARD
BACK
RESULT
TOP
X
DOUBLE MINIMUM
BOTTOM
X
FORWARD
BACK
RESULT
TOP
X
DOUBLE MAX
BOTTOM
X
FORWARD
BACK
RESULT
TOP
X
NEUTRAL CASTOR
BOTTOM
X
X2 –CADET / ROOKIE
