Article MERTO 19561 User manual

Assembly Instructions
MERTO
Bookcase
VERSION 1.0

Page 2 of 9
ASSEMBLY INSTRUCTIONS
Read these instructions carefully and keep for future
reference. Refer to parts inventory for guidance, and
ensure you have all pieces before starting.
When assembling, place all parts on a soft, clean, and flat
surface such as a carpet to prevent scratches.
If you’re having diculty, our friendly Customer Care
team is always here to help. Call us at 1.888.746.3455
during business hours, email [email protected] or chat
live at article.com.
MERTO Bookcase
PARTS INVENTORY
ID DESCRIPTION QTY
CABINET 1
TOP PANEL 1
FIXED SHELF 2
CABINET SHELF 1
LEG 2
WOODEN DOWEL 12
CAMLOCK NUT 12
PARTS INVENTORY CONT.
ID DESCRIPTION QTY
CAM LOCK SCREW 12
SHELF PIN 4
M6 x 30MM BOLT 8
LOCK WASHER 12
WASHER 12
M6 x 15MM BOLT 4
ALLEN KEY 1
LATCH 2
20 min
3
TIME
REQUIRED TOOLREQUIRED TOOL
# OF PEOPLE DIFFICULTY

Page 3 of 9
MERTO Bookcase
1
2
×2
× 2
× 4
Camlock nut (G) is
screwed from the
Camlock nut (G) is
screwed from the top.
Top panel (B) assembly:
!
Fixed shelf (C) assembly:
!
Insert the latches (O) from
the hardware bag.
!
×2
×2

Page 4 of 9
MERTO Bookcase
3
4
×2
× 4
×8
× 2
Camlock nut (G) is
screwed from the top.
Top panel (B) assembly:
!
× 4
Camlock nut (G) is screwed
from the bottom.
Fixed shelf (C) assembly:
!
×2

#
#
Page 5 of 9
MERTO Bookcase
×4
5
6
Adjust levelers as needed.
!

Page 6 of 9
MERTO Bookcase
During shipping, the doors of your cabinet may have
shifted slightly. This can easily be corrected by tightening
a few screws. Always start by adjusting the top hinge on
the aected door.
REQUIRED TOOL
DOOR ADJUSTMENT INSTRUCTIONS
If the door needs adjustment forward or backward:
7A

Page 7 of 9
MERTO Bookcase
7B
7C
If the door is crooked, adjust hinge(s) up or down:
If the door needs adjustment side to side:

MERTO BookcaseMERTO Bookcase
WARNING!
ANTI-TIP RESTRAINT INSTALLATION
Serious or fatal crushing injuries can occur from furniture
tip-over. To help prevent tip-over:
• Install tip-over restraint provided.
• Do not set heavy objects on top of this product,
unless the product is specifically designed to
accomodate them.
• Never allow children to climb or hang on mirrors,
shelves, consoles, or cabinets with doors and/or
drawers.
Use of tip-over restraints may only reduce but not
eliminate, the risk of tip-over.
20 min
3
TIME
REQUIRED TOOLREQUIRED TOOL
# OF PEOPLE DIFFICULTY
PARTS INVENTORY
ID DESCRIPTION QTY
BRACKET 2
M4 ×15MM SCREW 2
M8 ×51MM PLUG 2
M6 ×70MM SCREW 2
WASHER 2
Hardware (C/D) to attach brackets to wall is
designed for drywall. To attach this unit to another
type of wall, consult with your local hardware store.
Page 8 of 9

MERTO Bookcase
Place unit in desired location and mark on
wall where holes should be drilled.
× 2
2
1
Drill holes into drywall, and attach unit
to wall with appropriate hardware.
×2×2
