Article WABASH User manual

Assembly Instructions
WABASH
Sideboard
VERSION 1.0

Page 2 of 9
ASSEMBLY INSTRUCTIONS
Read these instructions carefully and keep for future
reference. Refer to parts inventory for guidance, and
ensure you have all pieces before starting.
When assembling, place all parts on a soft, clean, and flat
surface such as a carpet to prevent scratches.
If you’re having diculty, our friendly Customer Care
team is always here to help. Call us at 1.888.746.3455
during business hours, email [email protected] or chat
live at article.com.
WABASH Sideboard
30 min
3
PARTS INVENTORY
ID DESCRIPTION QTY
LEG FRAME 2
CROSS BAR 1
DOORS 4
PARTS INVENTORY CONT.
ID DESCRIPTION QTY
ALLEN KEY 1
M6 ×32MM BOLT 4
M6 ×15MM ALLEN BOLT 6
LOCK WASHER 10
WASHER 10
TIME # OF PEOPLE DIFFICULTY
ANTI-TIP
Installation Required
REQUIRED TOOL

#
Page 3 of 9WABASH Sideboard
1
×6
Lay the top on a clean and padded
surface to prevent scratches.
!

#
Page 4 of 9WABASH Sideboard
2
×4
Adjust levelers as needed.
!

#
Page 5 of 9WABASH Sideboard
Assemble left and right (C) doors on
the inside slide rail of sideboard.
!
3
Assembly location
Step 1
Step 2
The location of door (C) will
be on the inside slide.
!
!

#
Page 6 of 9WABASH Sideboard
Assemble center (C) doors on the
outside slide rail of sideboard.
!
4
Assembly location
Move door (C) down on the
outside slide.
!
!
Step 1
Step 2

Page 7 of 9WABASH Sideboard
Serious or fatal crushing injuries can occur from furniture
tip-over. To help prevent tip-over:
• Install tip-over restraint provided.
• Do not set heavy objects on top of this product,
unless the product is specifically designed to
accomodate them.
• Never allow children to climb or hang on mirrors,
shelves, consoles, or cabinets with doors and/or
drawers.
Use of tip-over restraints may only reduce but not
eliminate, the risk of tip-over.
20 min
3
TIME
REQUIRED TOOL
# OF PEOPLE DIFFICULTY
ANTI-TIP RESTRAINT INSTALLATION
WARNING!
REQUIRED TOOL
8MM / 5/16" DRILL BIT
1010 Raymur Ave.
Vancouver, BC V6A 3T2
PARTS INVENTORY
ID DESCRIPTION QTY
BRACKET 4
M4 ×20MM SCREW 4
M8 ×51MM PLUG 4
M6 ×70MM SCREW 4
STRAP 2

Page 8 of 9WABASH Sideboard
12
Attach pair of brackets to top corners
of the back of the unit. Note there are
no existing pilot holes on the product.
Mark on wall where second pair
of brackets should be placed.
× 4 × 2
3
× 4× 4 × 4
Drill holes in wall using
8mm / 5/16"drill bit.

#
#
Page 9 of 9WABASH Sideboard
Align brackets on unit
with brackets on wall.
4A
4B
Pull strap down until it snap-locks.
× 2 × 2
