Lightolier Lighting Systems SORA-4 User manual

Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems SORA-4
1BHFPG -JHIU51FS'PPU/PNJOBM4FDUJPO
#
Ordering Information
S 2
Body
S
Family Lamps Wattage Style Length Finish
Family Item Suspension Length Finish
* Intermediate only.
2= 2 Lamps Per 28 = 28 Watt
54 = 54 Watt without
Wings
CO = Suspended 4= 4 Foot
Nominal
SC = Platinum
WH = White
E= End Set
I= Intermediate
CO = Cable
SO = Stem
PO = Power Feed*
30 = 30” (76.20cm)
36 = 36” (91.44cm)
SC = Platinum
WH = White
Complete Ordering Instructions below.
4-Foot Section
Features
1. Housing: Aluminumextruded upto 12-foot nominal lengths.
2. Lamp: T5 linear fluorescent, 28 or 54 watt. (by others).
3. Reflector: Die-formed high reflectance semi-specular aluminum.
Electrical
Ballast is electronic, low harmonic distortion, high power and ballast factor, uni-
versal voltage with two conductors and a ground. Mark X dimming (no extra control
wire required) is available. EM battery pack not available. Modules can be
continuously wired row mounted, but cannot exceed amperage limits of electrical
supply cords. Cable suspended fixtures have 18/3 SJT cord, stemproducts have
three 18 gauge wires provided in stem, and both versions must be hard wired.
Factory installed ballast disconnect allows the ballast to be disconnected fromand
reconnected to incoming power under load without turning the entire circuit off.
Mounting
Cable mounting utilize 1/16” (0.16cm) diameter SSTL aircraft cable, and are
continuously adjustable via a cable gripper. Stemmountings utilize 1/8 IP stems
(three wires only) with ball swivel mounting at ceiling line. Stems cannot be cut in
field and should be ordered to required length. 4-1/2” (11.43cm) diameter canopies
are used on both styles. 12-foot fixtures may have up to 1/4” (0.64) deflection in
luminaire housings.
Finish
Powder coated Steelcase Platinumor White baked enamel.
Customcolors available, consult factory.
Labels
UL (1598), cUL and I.B.E.W.
CO
Continuos Rows:
1. Determine run length.
2. Order the appropriate number of Modules to complete the run.
3. Order one End Set per run.
4. Order one Intermediate suspension per Module minus one per run.
5. For runs that exceed amperage limits, order the appropriate number of
Intermediate suspension Power (for cable suspended units only).
Ordering Instructions
Individual fixtures:
1. Order number of Modules required.
2. Order one End Set per module.
8= 8 Foot
Nominal
12 = 12 Foot
Nominal
Suspension
Stem
Cable
2.40”
(6.10cm)
8.00” (20.32cm)
1 2 3

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt #
Lighting Systems SORA-4
1BHFPG -JHIU51FS'PPU/PNJOBM4FDUJPO
Mounting Accessories
Power Feed Cable End Set
Distance is fromthe ceiling
line to the top of the lumi-
naire housing.
36” (91.44cm) Platinum: SECO36SC
36” (91.44cm) White: SECO36WH
Stem End Set
Distance is fromthe ceiling
line to the top of the lumi-
naire housing.
30” (76.20cm) Platinum: SESO3
Ø SC
30” (76.20cm) White: SESO3 Ø WH
Intermediate Cable
Distance is fromthe ceiling
line to the top of the lumi-
naire housing.
36” (91.44cm) Platinum:SICO36SC
36” (91.44cm) White: SICO36WH
Notes: Suspended luminaires can be continuously
row mounted longer than 20-foot but the electrical
capacity of power cords cannot be exceeded.
Intermediate Stem
Distance is fromthe ceiling
line to the top of the lumi-
naire housing.
30” (76.20cm) Platinum: SISO3
Ø SC
30” (76.20cm) White: SISO3 Ø WH
Intermediate Cable/Cord
Distance is fromthe ceiling
line to the top of the lumi-
naire housing.
36” (91.44cm) Platinum: SIPO36SC
36” (91.44cm) White: SIPO36WH
80% 70% 50%
70 50 30 70 50 30 50 30 10
0 909090 7777 77 525252
1 827875 7067 62 464443
2 746863 6358 50 403735
3 686043 5851 42 353229
4 624346 5345 35 312825
5 464639 4840 30 272421
6 524134 4436 26 252118
7 483730 4032 22 221816
8 443327 3729 19 201614
9 413024 6526 17 181412
10 38 27 21 32 24 15 16 13 11
CANDLEPOWER
ZONE 0 22 45 67 90
DEG. CANDELAS
180 1333 1333 1333 1333 1333
175 1338 1345 1351 1355 1366
165 1287 1358 1468 1555 1598
155 1196 1355 1604 1789 1874
145 1052 1323 1722 2035 2167
135 874 1261 1825 2292 2500
125 660 1169 1941 2653 2934
115 435 1069 2154 2831 3019
105 215 1057 1929 2078 2057
95 42 556 517 535 468
90 00000
Performance
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
REPORT NO.: ITL53330
LAMPS: 2-F54T5
LUMENS: 5000
EFFICIENCY: 94.5%
CAT NO.: S254C04WH
CANDLEPOWER CURVE
WALL R EFLE CTANCE
20% FLOOR CAVITY REFLECTANCE
DISTRIBUTION
Zone Lumens % Lamp%Luminaire
0-90 0 0.0 0.0
90-180 9946 94.5 100.0
0-180 9946 94.5 100.0
Fixture Lengths & Mounting Locations
Mounting Accessories
4-Foot
8-Foot
12-Foot
16-Foot
20-Foot
4' 3-1/4” (130.15cm)
4' 2-1/8” (127.32cm)
8' 6-5/8” (260.67cm)
8' 5-3/8” (257.49cm)
12' 9-7/8” (390.84cm)
12' 8-3/4” (387.99cm)
12' 9-3/8” (389.57cm)
17' 1-1/4” (521.34cm)
12' 9-3/8” (389.57cm)
4' 2-3/4” (128.91cm)
21' 4-1/2” (651.51cm)8' 6" (259.08cm)
