Artistic Licence railSplit uno User manual

Artistic Licence
railSplit uno User Guide
railSplit uno
Version 1-0
User Guide

Page 2
railSplit uno User Guide
Please read these instructions before using the product.
This product has been designed & manufactured for professional use only.
It should only be installed by a suitably qualied technician and in accordance with
electrical regulations in the country of use.
Unless directed in the instructions there are no user serviceable parts inside the
outer case of this product.
Always disconnect from the power supply when not in use.
Any specic IP rating, where appropriate, is given in the instructions. Unless
otherwise stated this product is designed for indoor use only. If used outdoors it
MUST be installed in an appropriate IP rated cabinet. Do not allow this product to be
exposed to rain or moisture. Do not allow liquid to penetrate the product.
Please recycle all packaging.
Copyright © Artistic Licence Engineering Ltd. All rights reserved.
Download the user guide by scanning the following QR code:

Page 3
railSplit uno User Guide
Reference Type Description
1LED Data Good
2LED Power / Fix
3LED Protection / Fault
4Connection Power 9-48 VDC
5Connection Fault tally
6Connection DMX512 Output
7Switch Split/Fix mode
8Connection Input terminate*
9Connection DMX512 input
Connections
Mounting Diagram
* The DMX512 input can also be used as a
passive loop-through connection allowing
onward connection to other DMX512 devices. If
this feature is not required then the signal must
be terminated. The product contains an internal
termination resistor. This is enabled by tting the
internal jumper under the terminal guard. It is
tted by default.

railSplit uno User Guide
Overview
railSplit uno is a fully bi-directional DMX512 isolator and signal booster, with the added feature
of a ‘data xer’ for DMX. The latter functionality is used for resolving ickering problems arising
from product incompatibility issues - see ‘Fix Mode’ on page 6 for more information.
railSplit uno oers industry leading levels of protection on input, output and power terminals. It
features electrocution protection (self-healing) on the DMX512 ports (up to 425 VAC continuous
connection).
Additionally, railSplit uno provides surge protection on all terminals. This feature protects the
product and connected equipment against voltage surges of the type generated by lightning.
The protection is sacricial which means that after a certain number of protection events, the
protection circuitry will fail (see Specication on page 8). When the protection circuitry fails it
is guaranteed to fail short-circuit, which continues to provide protection to the DMX512 cables.
DMX512 output protection failure or shorted cable is reported with a front panel indicator and
via the fault tally output (see Connections diagram on page 3).
Page 4
Key features
yInput optical isolation
yBi-directional outputs
yOptimized for electrically noisy
environments
yMains electrocution protection (self-
healing) on DMX512 input and output
ySurge protection (sacricial) on all
terminals
yFront panel fault indication
yFault report tally output for BMS
integration
yRDM supported
ySurface mount or DIN rail mounted
yDMX-Fix mode to handle compatibility
issues
Connections
Input
The DMX512 input is attached via three screw
terminals. Please refer to the Connections
diagram.
Loop-Through
The DMX512 input can also be used as a
passive loop-through connection allowing
onward connection to other DMX512 devices.
If this feature is not required then the signal
must be terminated. The product contains an
internal termination resistor. This is enabled by
tting the internal jumper under the terminal
guard. It is tted by default.
Output
The output is capable of driving 32 additional
DMX512 devices. A terminator must be
connected to the nal DMX512 device.
XLR Pin (Convention) Function Colour
1Ground Black
2Data - Blue
3Data + Red
DMX512 Wiring

Page 5
railSplit uno User Guide
Application Diagram
The diagram below shows how railSplit uno could be utilised in a typical application.
Internal Earth and Isolation
The following table summarises the internal earth interconnection and isolation.
Please note that we use the term Earth-Ground to avoid international confusion. In Europe
Earth-Ground is called Earth; in the USA, Earth-Ground is called Ground.
Circuit Description
DMX512 Input Type: Isolated
Pin 1: Connects to internal isolated
circuit. No connection to
Internal Logic Ground
DMX512 Output Type: PSU referenced
Pin 1: Connected to Internal Logic
Ground
Internal Logic Ground Connected to power supply 0V. If the selected PSU has a connection
between Earth-Ground and 0V the DMX outputs become Ground
Referenced. Otherwise the DMX outputs are Floating. When the
recommended PSU is used, DMX outputs are Floating.

Page 6
railSplit uno User Guide
Operating Modes
The product can operate in two modes. In its default mode, the product is a fully-featured RDM
Splitter. In the second mode, it acts as a DMX Fixer.
Splitter Mode
In splitter mode, the output operates as a bi-directional RDM port and all DMX data received is
passed onto the output. The indicators have the following meaning:
Top (Data):
yOFF = no data received
yGreen = DMX and RDM received
yYellow = DMX only received
Middle (Power):
yGreen = Power
yRed = Data error or collisions detected
Fix Mode
Fix mode is intended to solve product compatibility problems. Unfortunately, there are numerous
products on the market which will not accept the wide range of legal DMX timings and data. Fix
mode cleans out any unusual or non-standard timing and data before sending to the output. This
includes stripping out all non-zero start codes (including RDM), forcing a 512-channel footprint
and calming any timing jitter. Indicators have the following meaning:
Top (Data):
yAs above
Middle (Power):
yGreen = Power
yRed = I am xing something
Detailed Fix Specication
Accepts and corrects break in range 56 µs – 1000 µs and outputs 250 µs
Accepts and corrects MaB in range 5 µs – 1000 µs and outputs 30 µs
Accepts and corrects MaB in range 0 µs – 1000 µs and outputs 30 µs
Accepts channel count 1 – 512 and outputs 512
Accepts refresh period from 23 ms – 1000 ms and outputs 30ms
Filters out multiple consecutive breaks
Re-times bytes of 1 stop bit to 2 stop bits
Filters out all non-zero start code packets
Re-times digital signal

railSplit uno User Guide Page 7
Protection and Reporting
The DMX512 output surge protection contains a sacricial element that will fail after a certain
number of protection events (see Specication on page 8). When this failure occurs, the output
will short together all 3 terminals.
Output short-circuit is monitored and reported by the product as follows:
Indicator
Tally output
The bottom LED indicator shows the monitoring status as follows:
yOFF = The product is analysing the output or there is no DMX512 input
yGreen = DMX512 output is operating normally
yRed = DMX512 output is short-circuit. This indicates that either there is a short-circuit on
the DMX512 output or that the sacrical protection has failed.
A tally output is provided to allow protection status to be monitored remotely. The tally output is
open-collector allowing multiple products to connect to a single reporting signal.
The output is designed to drive 12 VDC at 5 mA without an additional external resistor.
yTo drive 24 VDC add a 2k2 external resistor.
yTo drive 48 VDC add a 5k6 external resistor.
The output is as follows:
yFloat = The product is analysing the output or there is no DMX512 input or DMX512 output
is operating normally
ySink = DMX512 output is short-circuit. This indicates that either there is a short-circuit on
the DMX512 output or that the sacrical protection has failed.

Page 8
railSplit uno User Guide
railSplit uno Specication
Mechanical
yHousing: DIN rail case
yMaterial: Lexan Plastic - UL94-V0 rated
yOverall dimensions: 90 mm (H) x 36 mm
(W) x 32 mm (D)
yWeight: 0.1 kg
yMounting: 35 mm DIN rail or surface
mount
yCountry of manufacture: UK
Environmental
yOperating temperature: 0°C to 40°C
yStorage temperature: -10°C to +50°C
yOperating relative humidity (max): 80%
non-condensing
yIP rating: IP20 indoor use only
yCertication: UKCA, CE, WEEE, RoHS
yWarranty: 2-year (return to base)
Power & Electrical
yInput voltage: 9-48 VDC
yInput connector: 2 - p i n s c r e w t e r m i n a l
(1 no.)
yInput power (max): 1.5 W
yDuty cycle: 100% @ 25°C
yDC fuse: internal resettable fuse for
control electronics
ySurge protection (sacricial):
- IDC 30,000A (8/20uS) 1 operation
- IDC 20,000A (8/20uS) 10 operations
- IDC 20A (10/1000uS) 1500 operations
DMX512 Output
yMode: PSU referenced
yIsolation: n/a
yElectrocution protection: output is
protected against continuous connection
to 425 VAC (self-healing)
y Surge protection (sacricial):
- IDC 30,000A (8/20uS) 1 operation
- IDC 20,000A (8/20uS) 10 operations
- IDC 20A (10/1000uS) 1500 operations
DMX512 Input
yMode: Optically isolated
yIsolation: 1 kV
yElectrocution protection: Input & Loop
protected against continuous connection
to 425 VAC (self-healing)
ySurge protection (sacricial):
- IDC 30,000A (8/20uS) 1 operation
- IDC 20,000A (8/20uS) 10 operations
- IDC 20A (10/1000uS) 1500 operations
Tally Ouput
yMode: Open collector
yDefault current 5mA
ySurge protection (sacricial):
- IDC 30,000A (8/20uS) 1 operation
- IDC 20,000A (8/20uS) 10 operations
- IDC 20A (10/1000uS) 1500 operations
Control
yInput Protocols: DMX512, DMX512 (1990),
DMX512-A, RDM V1.0 (E1.20 - 2006
ESTA Standard)
yOutput Protocols: Same as input
Data Connections
y3-pin Screw Terminal DMX Input (1 no.)
y3-pin Screw Terminal DMX Output (1 no.)
LED Indication
yPower / DMX / RDM / Protection
Package Contents
yrailSplit uno
Ordering Info
yProduct code: railSplit uno
Accessories (not included)
yPSU-24-0.75-FER

Warranty
All products are covered from date of purchase
by a two-year return to base warranty.
By return to base, we mean that the customer
is responsible for all costs of transport to and
from Artistic Licence.
Returns will not be accepted without prior
authorisation. In order to discuss a request to
return goods, please email:
Sales@ArtisticLicence.com
Compliance
railSplit uno is UKCA &CE compliant when
installed in a shielded and earthed metal
case
Compliance
All Products manufactured or sold by Artistic
Licence Engineering Ltd are fully compliant
with the appropriate UKCA, CE and RoHS
regulations. Product specic information is
available on request.
Waste Electrical & Electronic Equipment
(WEEE)
Artistic Licence is a member of a WEEE
compliance scheme and will happily recycle
any of our products that you, at your expense,
return to us.
Due to our policy of continuing product improvement
specications are subject to change without notice
Artistic Licence
The Mould Making Workshop
Soby Mews
Bovey Tracey
TQ13 9JG
United Kingdom
Telephone +44 (0) 20 8863 4515
Email: Sales@ArtisticLicence.com
Web: www.ArtisticLicence.com
Support@ArtisticLicence.com
The information contained in this document is subject to change
without notice. Artistic Licence Engineering Ltd. makes no warranty
of any kind with regard to this material, including, but not limited to,
the implied warranties of tness for a particular purpose.
Artistic Licence Engineering Ltd. shall not be liable for errors
contained herein or for incidental or consequential damages in
connection with the furnishing, per formance or use of this material.
All trademarks are acknowledged.
© Artistic Licence Engineering Ltd.
Table of contents
Other Artistic Licence Multiplexer manuals
Popular Multiplexer manuals by other brands

Digital Equipment
Digital Equipment DMO9AL instruction manual

Phoenix Contact
Phoenix Contact GW PL ETH/UNI-BUS user manual

Quark-Elec
Quark-Elec QK-A031 manual

Tunstall
Tunstall Flamenco 77 0270 00 installation instructions

Patton electronics
Patton electronics MicroStat II 3022 user manual

Fiber Options
Fiber Options 9900V-T instruction manual
