Taiji HS-8N User manual

Instruction Manual
TAIJI SAKE WARMER
Thank you very much for purchasing TAIJI Sake warmer.
Before operating this product, please read this instruction manual for instructions and
proper operation.
Table of Contents

Safety Precautions

Installation

Applications

peration

perating Concept

After Use

Parts Identification

Servicing

Specifications
MODEL: HS- N



Please read these “Safety Precautions” carefully.

The Safety instructions explained here are to help you to use this product safely and
correctly, and prevent danger or injury to yourself or other people.

The safety instructions shown here are classified by follows. As they are very
important for your safety, be sure to follow both of them.
:Indicates contents which may lead to death or serious injury.
:Indicates contents which may lead to serious personal injury.

After reading these instructions, keep this manual where it is always accessible by
the user.
What precautionary measures should be abided by are expressed by certain marks and
explained as follows:

mark denotes that “Warning and caution is urged.”
(The one on the left indicates beware of electrical shock.)
mark with a diagonal line means “Forbidden.”
(The one on the left indicates disassembling forbidden.

indicates “Instructions” which should be followed by all means.
(The one on the left indicates grounding is a requirement.)
Failing to adhere to the following warnings may cause danger
to human life or inflict a severe injury.

Contact a disposal service provider, municipal government office or your distributor
for proper disposal of this product according to environmental regulations.

This product should be connected to an exclusive wall outlet supplying power of
AC110-120V 15A or AC220-240V 7.5A (minimum). Do not use an extension cord.

Do not tamper with the plug blades.

This product is to be operated by persons who understand its functions and
operations. Keep children away from this product or any other commercial
appliances.

Install this product on a level, steady surface.

Do not disassemble, tamper or attempt to repair this product. Contact your
distributor for servicing.

Do not immerse this product in water or splash water on this product.

Avoid damaging the power cord. Do not place any object on the cord. Do not nip
or tamper with the cord. Keep the cord away from any heat sources.

Do not use this product outdoors. This product is for indoor use only.
WARNING
CAUTION
WARNING


Failing to adhere to the following cautions may result in personal
injuries or property damages.
This product is for heating Sake by putting Sake server bottles into bathtub with
water/hot water. Also, this is indoor use only. Do not use for any other purposes.
This product heats Sake into the sake bottle indirectly. The water bath is heated by
the heating element. The water temperature is controlled by the temperature control device.

Do not heat Sake too much. Failure to do so may lose flavor and also
there is a danger that you may get burned.

This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do play with the appliance.

Do not operate this product if it has been damaged or dropped.

Properly and promptly discard the packaging materials such as plastic bags.

Do not heat empty bathtub. Failure to do so may result in a fire, burns or
malfunction.

Do not put your hand on the product as it gets hot during operation and
immediately after use.

When not in use, turn off the power and remove the plug from the outlet.

Turn off the switch and disconnect the plugs if the thunder starts to roll.

Do not pull the plug pulling by the cord. Pull the plug from the base of it
when inserting into or removing from the outlet.

Make sure your hands are dry when plugging/unplugging the power plug or
turning on/off the power switch.
CAUTION


Bathtub
Power plug
OTHER ACCESSORIES
Sake Temperature Indicator Lid Bottle Cap
Drain Board
Power Cord
(accessories)
Temperature Control
Body
Power Lamp
Power Switch
Heating Lamp


1. Take the unit out of the shipping carton and remove all packaging materials. Check all
parts and accessories are included.
2. For installing, the location must have/be:

A level and steady surface.

Sufficient space for air circulation around the unit.

At least 50 cm away from any heat source.

No direct sunlight.

Avoid high-humidity areas and locations near water.
1. Check the power switch is FF.
2. Check the temperature control knob is come by FF.
3. Check no foreign object is into the bathtub and place a drain board on it.
Pour water or hot water (approx. 3.5 liter) into the bathtub to the line displayed inside.
This line is a standard in the case of putting 12 of 180ml service bottles.
Adjust the quantity of water according to the bottle to be used.
However, please be sure to follow the warning and notes which have been
indicated below.
Do not add water to the limit of a bathtub. There is a risk of water
overflowing and it may result in a fire and/or electrical shock.
Do not heat empty bathtub. Failure to do so may result in a fire,
burns or malfunction.
4. Turn on the switch. The power lamp (Green) will light up.
(Water Line)
水位
It is about 3.5 liters
in the position of
this line.
WARNING
WARNING


5. Adjust the temperature control knob. The heating lamp ( range) will light up.
(A lamp is not turned on when temperature is higher than a preset temperature.)
A heating lamp will go out if the temperature of the water in a bathtub rises to
the preset temperature. If temperature falls, the heating lamp will light up and
a heater will turn on electricity again.
6. A useful bottle cap is attached to this product. You may use it when you pour Sake
into a serving bottle from a Sake bottle.
(1) Attach a bottle cap to the mouth of the Sake bottle.
(2) Insert a bottle cap to the serving bottle and pour out Sake, fixing a bottle or
pressing down by your hand.
(3) Sake will stop if it comes to the mouth of the bottle cap.
(4) Pull out the Sake bottle from the serving bottle.
1. Turn off the temperature control knob.
2. Turn off the power switch.
3. Pull out the power plug from the outlet.
4. Take out a drain board after checking that the water in a bathtub has fully got
cold. Then, drain by the following method.
Dewatering Method
Lean the angle of the side opposite to a switch, and drain from the corner.

The numerical value of a temperature control
knob is a standard of temperature setting.
Temperature control knob
Heating lamp
(Color: range)
Switch Side
FRONT BACK
Drainage Position
FRONT


5. Clean the inside of a bathtub and a drain board. If there is a foreign substance,
remove it. When Sake or dirt adheres, wash them away.
 When you drain water, please refer to the above-mentioned dewatering method.
Wipe off a drop of water with the dry cloth after drainage.
 When you use a sponge, please use a soft one.
 When you use a detergent, please choose a neutral type.
 Be careful not to apply strong pressure against a heater.
 Be careful not to damage a finger by the end face when you wash a drain board.
 inse well so that detergent does not remain in a bathtub.

For servicing of this product, please contact your distributor, nearest TAIJI sales
representative or TAIJI & C ., LTD.

If the power supply cord is damaged, it must be replaced by the manufacture, its
service agent or similarly qualified persons in order to avoid a hazard.
TAIJI & C ., LTD.
8-2 kawa-cho, Kawasaki-ku, Kawasaki-shi, Kanagawa-pref., 210-0858, Japan
TEL:[phone]
FAX:[phone]
[email protected]
http://www.taiji.co.jp/e
 



 
 



!" "!!#
Inner Dimensions: W249 x D194 x D170mm
Weight: 3 kg
Accessories: Drain board, Sake temperature indicator, Lid,
Bottle cap x 1 each
Power Consumption:
500W
Temperature Control:
Variable Thermostat
uter Dimensions: W251 x D196 x D253mm
Model: HS-8N
Power Supply: Single Phase AC100V, 50/60Hz
$
