Aruba EdgeConnect EC-US User manual

Aruba
6280 America Center Drive
San Jose, CA 95002
1.877.210.7325 (toll-free in USA)
+1.408.935.1850
www.silver-peak.com/support
EdgeConnect
Quick Start Guide
EC-US
© 2021 Aruba, a Hewlett Packard Enterprise company All rights reserved. PN 201784 Rev A
Before You Begin
Check your packing slip to verify
that you have all the necessary
items.
On the network equipment, iden-
tify the 10/100/1000 Ethernet
ports.
1Install the Appliance into the Network
a. Identify the relevant ports on the rear of the appliance.
b. Connect the supplied network cables from the appliance to the identied network equipment
ports.
c. DO NOT connect the power cable yet.
All copper RJ-45 Gigabit Ethernet interfaces in the Silver Peak appliance support MDI/MDI-X and
auto-negotiation.
2Connect Power Cord
Connect the power cable to the Silver Peak appliance and to your local power source.
3Turn the Power On
a. The appliance powers up as soon as it’s plugged in.
b. On the front panel, verify that the Power LED illuminates green.
You’ve now completed the physical installation and are ready to register the product with Unity
Orchestrator.
Part 1 - Physical Installation
IMPORTANT - READ THIS FIRST: You must install and register your Orchestrator
with the Silver Peak Cloud Portal BEFORE setting up an EdgeConnect appliance. After
Orchestrator is registered with your account name and key, you can proceed with
EdgeConnect installation.
If you don’t know or are unsure what role the Orchestrator plays, please contact your
network architect or deployment lead.
Static Assignment of IP Address
If an IP address is not dynamically assigned to wan0 or wan1, then you
must congure it manually. To do this, access the appliance conguration
wizard through lan0.
Silver Peak assigns the lan0 ethernet interface a default IP address of
169. 254.0.1 and a subnet mask of /16 (the same as 255.255.0.0).

Aruba
6280 America Center Drive
San Jose, CA 95002
1.877.210.7325 (toll-free in USA)
+1.408.935.1850
www.silver-peak.com/support
EdgeConnect
Quick Start Guide
EC-US
© 2021 Aruba, a Hewlett Packard Enterprise company All rights reserved. PN 201784 Rev A
1Approve the Discovered Appliance
After you power on the EdgeConnect appliance, it automatically registers its serial number with
the Silver Peak Cloud Portal. The portal knows how to associate a serial number with a particular
account.
a. Go to the Orchestrator.
b. In the header, click the blinking box named Appliances Discovered.
The Discovered Appliances page opens, listing the most recently discovered appliances rst.
c. After verifying that the appliance is yours, click Approve.
d. Select the group and click Apply.
The Appliance Manager Conguration Wizard opens.
2 Complete the Appliance Manager Conguration Wizard
a. If you’ve also purchased EdgeConnect Boost or EdgeConnect Plus, and you want to apply it to this
appliance, select the relevant check box(es) on the Deployment Prole page.
b. At the end, click Apply. It may take up to two minutes to register the appliance.
c. Complete the remaining wizard screens.
• On the Deployment page’s default conguration, the WAN–side interfaces use DHCP IP ad-
dresses, unless you manually enter static IP addresses.
Before You Begin
Make sure that Orchestrator is
installed and registered.
Verify that you’ve received the
email containing your Account
Name and Account Key.
Part 2 - Registration
IMPORTANT - READ THIS FIRST: You must install and register your Orchestrator
with the Silver Peak Cloud Portal BEFORE setting up an EdgeConnect appliance. After
Orchestrator is registered with your account name and key, you can proceed with
EdgeConnect installation.
If you don’t know or are unsure what role the Orchestrator plays, please contact your
network architect or deployment lead.
