ASAHI Type23 User manual

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”)
Contents
1. Be sure to read the following
warranty clauses of our product 1
2. General operating instructions 2
3. General instructions for transportation,
unpacking and storage 3
4. Name of parts 4
5. Working pressure vs. Temperature 5
6. Specifications of actuator 6
7. Specifications of filter regulator 6
8. Specifications of solenoid valve 7
9. Specifications of limit switch box 8
10. Specifications of speed controller 8
11. Installation procedure 9
Flanged end 10
Threaded end 11
Socket end (PVC, C-PVC) 12
Socket end (PP, PVDF ) 13
Spigot end (PP, PVDF) 13
12. Support setting procedure 14
13. Air piping procedure 15
14. Connection of limit switch
procedure 17
15. Connection of solenoid valve
procedure 18
16. Operating procedure 19
1) Operating procedure by air 19
2) Manual operation procedure 21
3) Adjustment of opening / closing
speed procedure 22
17. Actuator removal procedure 24
18. Method of adjusting face pressure
between ball and seat 25
19. Disassembling method for replacing
parts 26
20. Inspection items 27
21. Troubleshooting 28
22. How to inquire about defects or
replacement 29
23. Handling of residual and waste
materials 29
Serial No. H-A070-E-3
3-Way Ball Valve Type23
Pneumatic Actuated
Type AR
15～50mm(1/2”-2”)
User’s Manual

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 1
This user’s guide contains very important information for the proper installation, maintenance and safe
use of an ASAHI AV Product.
Please store this manual in an easily accessible location.
＜Warning & Caution Signs＞
This symbol reminds the user to take caution due to the potential for serious injury or
death.
This symbol reminds the user to take caution due to the potential for damage to the valve
if used in such a manner.
＜Prohibited & Mandatory Action Signs＞
Prohibited: When operating the valve, this symbol indicates an action that should not be
taken.
Mandatory action: When operating the valve, this symbol indicates mandatory actions
that must be adhered to.
1. Be sure to read the following warranty clauses of our product
- Always observe the specifications of and the precautions and instructions on using our product.
- We always strive to improve product quality and reliability, but cannot guarantee perfection.
Therefore, should you intend to use this product with any equipment or machinery that may pose
the risk of serious or even fatal injury, or property damage, ensure an appropriate safety design
or take other measures with sufficient consideration given to possible problems. We shall
assume no responsibility for any inconvenience stemming from any action on your part without
our written consent in the form of specifications or other documented approval.
- The related technical documents, operation manuals, and other documentation prescribe
precautions on selecting, constructing, installing, operating, maintaining, and servicing our
products. For details, consult with our nearest distributor or agent.
- Our product warranty extends for one and a half years after the product is shipped from our
factory or one year after the product is installed, whichever comes first. Any product abnormality
that occurs during the warranty period or which is reported to us will be investigated immediately
to identify its cause. Should our product be deemed defective, we shall assume the responsibility
to repair or replace it free of charge.
- Any repair or replacement needed after the warranty period ends shall be charged to the
customer.
- The warranty does not cover the following cases:
(1) Using our product under any condition not covered by our defined scope of warranty.
(2) Failure to observe our defined precautions or instructions regarding the construction,
installation, handling, maintenance, or servicing of our product.
(3) Any inconvenience caused by any product other than ours.
(4) Remodeling or otherwise modifying our product by anyone other than us.
(5) Using any part of our product for anything other than the intended use of the product.
(6) Any abnormality that occurs due to a natural disaster, accident, or other incident not
stemming from something inside our product.
* Note that damage induced by a defect of our product is not covered by warranty.
- This guarantee applies to the use of our product only in Japan. If it is used overseas, please
inquire with us separately.
Warning
Caution

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 2
2. General operating instructions
- Never attempt to disassemble an actuator.
- Using a positive-pressure gas with our plastic piping may pose a dangerous condition
due to the repellent force particular to compressible fluids even when the gas is under
similar pressures used for liquids. Therefore, be sure to take the necessary safety
precautions such as covering the piping with protective material. For inquiries, please
contact us. For conducting a leak test on newly installed piping, be sure to check for
leaks under water pressure. If absolutely necessary to use a gas in testing, please
consult your nearest service station beforehand.
- Do not step on or apply excessive weight on valve. (It can be damaged.)
- Keep the valve away from excessive heat or fire. (It can be damaged, or destroyed.)
- Do not use the valve to fluid containing slurry. (The valve will not operate properly.)
- Do not use AV valves in a place where they may become submerged in water.
- Do not remove a dust-proof cap provided to piping port before piping work starts.
- Be careful of the environment where the valve is installed. In particular, avoid places
exposed to salty wind, corrosive gas, chemical solution, sea water, steam, etc.
- Do not apply a great impact or vibration to the actuator.
(Any such practice may result in breakdown.)
- Use the valve working pressure, working temperature, ambient temperature within an
allowable range.
(The valve can be damaged or deformed by operating beyond the allowable range.)
- Allow sufficient space for maintenance and inspection.
- Select a valve material that is compatible with the media. For chemical resistance
information, refer to “CHEMICAL RESISTANCE ON ASAHI AV VALVE”.
(Some chemicals may damage incompatible valve materials.)
- Do not use the valve in conditions where the fluid may have crystallized.
(The valve will not operate properly.)
- Keep the valve out of direct sunlight, water and dust. Use cover to shield the valve. (The
valve will not operate properly.)
- Be careful not to allow foreign matters, water droplets, oil, and other substances to enter
from the air pipe opening and intake/exhaust hole of the actuator. (In areas that are likely
to have snow, melted water of snow that falls on the valve may enter from the air pipe
opening and intake/exhaust hole of the actuator.)
- Perform periodic maintenance. (Leakage may develop due to temperature changes or
over periods of prolonged storage, rest or operation.)
- When installing the valve, provide an appropriate support. (Failure to do so may cause
breakage due to excessive force applied to the valve body and pipes.)
- The AV valves must be used within the specifications specifically applicable to the product.
(May not work.)
- If the actuator is used in an environment below 5°C temperature, its operating fluid must be
free from the water and moisture contained in it because of possible problems due to the
freeze.
- When you use the valve in a low-temperature environment, put a cover or such that covers
the entire actuator to prevent it from freezing, and check the operating conditions on a
regular basis. (If it freezes, it does not operate normally.)
- Use dehumidified and dust-removed clean operation air. When using highly dry air at a dew
point of -40°C or less, please consult us separately.
Warning
Caution

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”)
3
General operating instructions (continued)
- The "P1", "P2", "P3" stickers showing the ports are
affixed to the side of the valve body.
"P1" is the left opening side, "P2" is the right opening
side, and "P3" always shows open side.
3. General instructions for transportation, unpacking and storage
- When suspending and supporting a valve, take care and do not stand under a suspended
valve.
- This valve is not designed to handle impacts of any kind. Avoid throwing or dropping the
valve.
- Avoid scratching the valve with any sharp object.
- Do not over-stack cardboard shipping boxes. Excessively stacked packages may
collapse.
- Avoid contact with any coal tar creosote, insecticides, vermicides or paint.
(These chemicals may cause damage to the valve.)
- Store products in their corrugated cardboard boxes. Avoid exposing products to direct
sunlight, and store them indoors (at room temperature). Also avoid storing products in
areas with excessive temperatures. (Corrugated cardboard packages become weaker as
they become wet with water or other liquid. Take care in storage and handling.)
- After unpacking the products, check that they are defect-free and meet the specifications.
Warning
Caution

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 4
4. Name of parts
15-50mm (½”-2”)
[1] Body [6] Stem [23] Actuator
[2] Ball [7] Seat [165] Base plate
[3] Carrier [8] O-ring (A) [165t] Tapping screw
[4b] End connector (Flanged end) [9] O-ring (B) [166] Connector plate
[4c] End connector (Socket end) [10] O-ring (C) [166b] Bolt
[4d] End connector (Threaded end) [11] O-ring (D) [166r] Rubber cap
[4e] End connector (Spigot end) [12] O-ring (E) [167] Shaft adapter
[5] Union nut [13] Stop ring
Double acting type (15-25mm [½”-1”])
Single acting type (15-50mm [½”-2”])
Double acting type
(32-50mm [1¼”-2”])

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 5
5. Working pressure vs. temperature

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 6
6. Specifications of actuator
Actuation Nominal size Angle adjustment
range
Standard operating
pressure
Ambient
temperature range
Double acting
Air to open
Air to shut
15-50mm
(½”-2”)
Cannot adjust
an angle
0.4-0.7 MPa
{4.1-7.1 kgf/ cm2}
[70-105 psi]
-10 to 60°C
[14 to 150°F]
7. Specifications of filter regulator
Actuation Nominal size Type sign Air supply bore Element rated
filtration
Double acting
Air to open
Air to shut
15-50mm
(½”-2”) ARU2-02-8A-B Rc1/4 5μm
Actuation Nominal size Actuator type
Air consumption
NL per 1 open & shut
at 0.4MPa
Air supply bore
Double acting
15-25mm
(½”-1”) AR040DA20 0.6 Rc1/8
32-50mm
(1¼”)-2”) AR050DA30 1.3 Rc1/4
Air to open
Air to shut
15-20mm
(½”-¾”) AR040NC20 0.2 Rc1/8
25mm
(1”) AR050NC30 0.4
Rc1/4
32-50mm
(1¼”)-2”) AR063NC40 0.8
JIS sign

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 7
8. Specifications of solenoid valve
Actuation Nominal size Type sign Power consumption
Double acting
Air to open
Air to shut
15-50mm
(½”-2”)
4N3S102K-
W □-G31193 AC：6VA
DC：5.5W
4N3S102K- D □-G31193
Actuation Air supply bore Effective cross section Additional functions
Double acting
Air to open
Air to shut
Rc1/4 10mm2or more
- Built-in bypass valve
- Silencer with throttle valve attached
(to be used as speed controller)
4N3S102K-□ □-G31193
( ) is special order.
sign Specification
1 100V AC 50/60Hz
(2) 110V AC 50/60Hz
3 200V AC 50/60Hz
(4) 220V AC 50/60Hz
5 24V DC
(6) 48V DC
(7) 100V DC
(8) 125V DC
(9) 110V DC
Sign Protection level
W Water tight cover type
(Equivalent to IP 55)
D DIN connector type
( Equivalent to IP 55)
JIS sign
Connection diagram
Port “a”
Double acting & Air to open: Right open
A
ir to shut: Left open
a b
Port “b”
Double acting & Air to open: Left open
A
ir to shut: Right open

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 8
9. Specifications of limit switch box
Actuation Nominal size Type sign Switch contact Protection grade
Double acting
Air to open
Air to shut
15-50mm
(½”-2”)
CFC-6301 Silver contact
IP67 (IEC529)
CFC-6302 Gold contact
（Micro-load）
Ratings
Type sign Rated voltage Max current
CFC-6301 250V AC 10 A
24V DC 2.5 A
CFC-6302 250V AC 0.1 A
24V DC 0.1 A
10. Specifications of speed controller
Actuation Nominal size Actuator type
Air
supply
bore
Type sign
Applicable
tube outer
diameter
(mm)
Number of
needle
rotations
Double
acting
15-25mm
(½”-1”) AR040DA20
Rc1/8 AS2201FG-01-06A φ6 11 turns
Air to open
Air to shut
15-20mm
(½”-¾”) AR040NC20
Double
acting
32-50mm
(1¼”)-2”) AR050DA30
Rc1/4 AS2201FG-02-06A φ6 11 turns
Air to open
Air to shut
25-50mm
(1”-2”)
AR050NC30
AR063NC40
JIS sign
Internal Circuits
Double acting
& Air to open: Left open
Air to shut: Right open
Double acting
& Air to open: Right open
Air to shut: Left open
Solenoid valve side
Valve side

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 9
11. Installation procedure
- When suspending and supporting a valve, take care and do not stand under a suspended
valve.
- Be sure to conduct a safety check on all hand and power tools to be used before beginning
work.
- When conducting piping work, wear personal protective equipment appropriate to the
contents of work. (Failure to do so may cause an injury.)
- Take care not to over-tighten the Union nut. (The valve can be damaged.)
-Do not use the pipe wrench. (The valve can be damaged.)
- When installing pipes and valves, ensure that they are not subjected to tension,
compression, bending, impact, or other excessive stress.
- When loosening the Union nut on the Carrier side, fix the End connector (hold it with your
hand) and do work. (If the end connector turns, the union will turn together, resulting in the
union and ball separating from the body.)
- If the union is loosened, retighten the union.
- When installing, disassembling, or reassembling the piping, fix the end connector.
- Before a water test, be sure that the Union nut is tightly fastened.
- Fasten the Union nut while avoiding the parallelism and axial misalignment of the flange
surface.
- When connecting a ASAHI AV Valve to metal piping, take care not to let the pipe stress on
the ASAHI AV Valve.
Warning

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 10
Flanged end (PVC, C-PVC, PP, PVDF)
- Use flat faced flanges for connection to AV Valves.
- Ensure that the mating flanges are of the same standards.
- Be sure to use sealing gaskets (AV Gasket), bolts, nuts, and washers and tighten them to
specified torques. (When a non-AV gasket is used, a different tightening torque instruction
should be followed.)
●Torque wrench ●AV gasket ●Spanner wrench ●Bolt, Nut, Washer for piping
Procedure
1) Set the AV gasket between the flanges.
2) Insert washers and bolts from the pipe side, insert washers and nuts from the valve side, then temporarily
tighten by hand.
- The parallelism and axial misalignment of the flange surface should be under the values
shown in the following table to prevent damage the valve. (A failure to observe them can
cause destruction due to stress application to the pipe.)
Unit : mm {inch}
Nominal size axial
misalignment
parallelism
(a-b)
15～32mm (½”-1¼”) 1.0 {0.04} 0.5 {0.02}
40, 50mm (1½”, 2”) 1.0 {0.04} 0.8 {0.03}
3) Tighten the bolts and nuts gradually with a torque wrench to the specified torque level in a diagonal
manner. (Refer to Fig.11-1.)
4) Tighten it more than 2 turns clockwise with specified torque. (Refer to Fig.11-1.)
- Do not tighten above the specified torque value. (The valve can be damaged or leaks.)
Specified torque value Unit :N-m｛kgf-cm｝[lb-inch]
AV gasket
material
15, 20mm
(½”, ¾”)
25～40mm
(1”-1½”)
50mm
(2”)
PTFE coted
PVDF coted 17.5 {179} [155] 20.0 {204} [177] 22.5 {230} [200]
Rubber 8.0 {82} [71] 20.0 {204} [177] 22.5 {230} [200]
※ When Union nut is loosened or removed, please install in the
following way.
1) Make sure that the O-ring (A) is properly mounted to the body.
2) Set the end connector directly on the body without allowing
the O-ring (A) to come off.
3) Tighten Union nut on each valve until hand tight.
4) Using a strap wrench tighten Union nuts uniformly on each
side approx. 90°- 180°turns, 1/4 to 1/2 turns.
Fig.11-1
Necessary items
O-ring（A）
Caution
Caution
（Axial misalignment）（Parallelism）
b
a
Caution

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 11
Threaded End (PVC, C-PVC, PP, PVDF)
- Avoid excessive tightening. (The valve can be damaged.)
- The Union nut of this product is fastened lightly so that it can be loosened easily. Be sure
to remove the end connector before carrying out the work. (Failure to so may cause
external leakage.)
- Make sure that the threaded connections are plastic x plastic. (Metallic thread can cause
damage.)
- Wrap the threaded joints on our plastic piping with sealing tape. Using a liquid sealing
agent or liquid gasket may cause stress cracks (Environmental Stress Cracking). Our
product warranty shall not apply in case of said use, even when said use is unavoidable.
●Sealing tape ●Strap wrench ●Spanner wrench or Motor wrench
Procedure
1) Wind a sealing tape around the external thread of joint,
leaving the end (about 3mm) free.
2) Loosen the Union nut with a strap wrench.
3) Remove the Union nut and the end connector.
4) Tighten the external thread of the joint and the end
connector hardly with hand.
5) Using a spanner wrench or motor wrench, screw in the
end connector by turning 180° -360° carefully without
damaging it.
6) Make sure that the O-ring (A) is properly mounted to the
body.
7) Set the end connector nut directly on the body without
allowing the O-ring (A) to come off.
8) Tighten Union nut on each valve until hand tight.
9) Using a strap wrench tighten Union nuts uniformly on
each side approx. 90°- 180°turns, 1/4 to 1/2 turns.
Necessary items
O-ring (A)
Sealing tape
End
connecto
r
Union nut
Fitting joint
Caution
Caution

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”)
12
Socket end (PVC, C-PVC)
- When using an adhesive, ventilate the space sufficiently, prohibit the use of a fire in the
vicinity, and do not inhale adhesive vapors directly.
- If an adhesive gets into contact with your skin, wash it off immediately. If you feel sick or find
anomaly, receive a physician's diagnosis and take appropriate measures promptly.
- Do not under any circumstances try to insert a pipe into another fitting or valve by striking it.
(Which may break the piping.)
- Take care in doing work at low temperatures. Solvent vapors are hard to evaporate and
are likely to remain. (Solvent cracks may occur, damaging the equipment.)
After assembling the piping system, open both ends of the piping and use a fan (of the
Low-Voltage Type) or something similar to ventilate the space, thus removing the solvent
vapors.
- Do not apply more adhesive than necessary. (The valve can be damaged due to solvent
cracking.)
- The Union nut of this product is fastened lightly so that it can be loosened easily. Be sure to
remove the end connector before carrying out the work. (Failure to so may cause external
leakage.)
- Use the appropriate Asahi AV cement.
- Conduct a water test at least 24 hours after joining the pipes with an adhesive.
●Asahi AV cement ●Strap wrench ●Waste cloth
Procedure
1) Loosen the Union nut with a strap wrench.
2) Remove the Union nut and the end connector.
3) Lead the Union nut through the pipe.
4) Make sure the hub part of the end connector is clean with
waste cloth.
5) Apply adhesive evenly to the hub part of the end connector
and the pipe spigot.
- Do not apply more adhesive than necessary.
(The valve can be damaged due to solvent cracking.)
Adhesive quantity (guideline)
6) After applying adhesive, insert the pipe quickly to the end connector and leave it alone for at least
60 seconds.
7) Wipe away overflowing adhesive.
8) Make sure that the O-ring (A) is properly mounted to the body.
9) Set the end connector directly on the body without allowing
the O-ring (A) to come off.
10) Tighten Union nut on each valve until hand tight.
11) Using a strap wrench tighten Union nuts uniformly on each
side approx. 90°- 180°turns, 1/4 to 1/2 turns.
Nominal size 15mm (½”) 20mm (¾”) 25mm (1”) 32mm (1¼”) 40mm (1½”) 50mm (2”)
Quantity (g) [oz] 1.0 [0.035] 1.3 [0.046] 2.0 [0.071] 2.4 [0.085] 3.5 [0.123] 4.8 [0.169]
Necessary items
O-ring (A)
Warning
Caution
Caution
Caution

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 13
Socket end (PP, PVDF)
- The Union nut of this product is fastened lightly so that it can be loosened easily. Be sure to
remove the end connector before carrying out the work. (Failure to so may cause external
leakage.)
●Strap wrench ●Sleeve welder or automatic welding machine
●User’s manual for sleeve welder or automatic welding machine
Procedure
1) Loosen the Union nut with a strap wrench.
2) Remove the Union nut and the end connector.
3) Lead the Union nut through the pipe.
4) For the next step, refer to the user’s manual for the sleeve welder or the automatic welding
machine.
5) After welding, make sure that the O-ring (A) is properly mounted to the body.
6) Set the end connector directly on the body without allowing the O-ring (A) to come off.
7) Tighten Union nut on each valve until hand tight.
8) Using a strap wrench tighten Union nuts uniformly on each side approx. 90°- 180°turns,
1/4 to 1/2 turns.
Spigot end (PP, PVDF)
- The Union nut of this product is fastened lightly so that it can be loosened easily. Be sure to
remove the end connector before carrying out the work. (Failure to so may cause external
leakage.)
●Strap wrench ●Sleeve welder or automatic welding machine
●User’s manual for sleeve welder or automatic welding machine
Procedure
1) Loosen the Union nut with a strap wrench.
2) Remove the Union nut and the end connector.
3) Lead the Union nut through the pipe.
4) For the next step, refer to the user’s manual for the sleeve welder or the automatic welding
machine.
5) After welding, make sure that the O-ring (A) is properly mounted to the body.
6) Set the end connector directly on the body without allowing the O-ring (A) to come off.
7) Tighten Union nut on each valve until hand tight.
8) Using a strap wrench tighten Union nuts uniformly on each side approx. 90°- 180°turns, 1/4 to 1/2
turns.
Necessary items
Caution
Caution
Necessary items

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 14
12. Support setting procedure
- When installing a pipe support by means of a U- type clamp or something similar, take care
not to over-tighten. (Excessive force may damage the pipe.)
●Spanner wrench ●U-type clamp (with bolt) ●Rubber sheet
Level plumber
1) Spread the rubber sheet under the pipe and valve
flange and secure pipe with U-type clamp.
2) When the actuator is facing downward, spread the
rubber sheet under the actuator and secure pipe with
U-type clamp.
The conditions and nominal size that do not require
actuator support are as follows.
a) Specifications of actuator
- Without options
- With standard speed controller
- With standard limit switch box
b) Nominal size (mm [inch]
Actuation 15
[½]
20
[¾]
25
[1]
32
[1¼]
40
[1½]
50
[1]
Double
acting ○○○○○○
Air to open
Air to shut ○○○
Perpendicular plumber
1) Spread the rubber sheet under the actuator and secure
pipe with U-type clamp.
The conditions and nominal size that do not require
actuator support are the same as for piping with the
actuator facing downward.
(Supporting example)
Caution
Necessary items
(Supporting example)
(Supporting example)
Rubber
sheet U-type
clamp
Stand
U-type
clam
p
Rubber
sheet
Stand
Stand
Rubber
sheet

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 15
13. Air piping procedure
- Do not remove a dust-proof cap provided to piping port before piping work starts.
- Avoid excessive tightening for joint. (The threaded area can be damaged.)
- Check the connection locations, air pipe sizes, and screw types with the approved drawings
and other documents for the product. Then lay the air piping.
- Use dehumidified and dust-removed clean operation air. When using highly dry air at a dew
point of -40°C or less, please consult us separately.
- If the actuator is used in an environment below 5°C temperature, its operating fluid must be
free from the water and moisture contained in it because of possible problems due to the
freeze.
- Steel pipes must always be of the plated.
- Before installing an actuator in pipeline, flash the inside of pipeline completely.
- When connecting the air piping, be careful not to let foreign matter inside the piping.
- Threaded area of a pipe must be free from the sharp edges and burr.
●Steel pipe or tube for piping ●Joint for steel pipe or tube
●Spanner wrench ●Sealing tape
＜ For a standard type and an attached speed controller type ＞
Procedure
1) Wind a sealing tape around the external thread of joint, leaving the end (about 3mm) free.
2) Screw the joint in the piping female screw of the actuator by hand fully.
3) Screw the joint one turn with a spanner wrench.
- Avoid excessive tightening for joint. (The threaded area can be damaged.)
4) Mount a steel pipe or a tube.
Standard type or
with speed controller
Double acting Air to open / Air to shut
AR040DA20 AR050DA30 AR040NC20 AR050NC30
AR063NC40
Standard type
With speed controller
Necessary items
Caution
Caution

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 16
＜ For a solenoid valve and a filter regulator ＞
- Set the secondary pressure of the filter regulator to meet the equipment specification.
(Failure to do so may cause a malfunction and failure.)
- Discharge drain of the filter regulator regularly.
●Steel pipe or tube for piping ●Joint for steel pipe or tube
●Spanner wrench ●Sealing tape
Procedure
1) Wind a sealing tape around the external thread of joint, leaving the end (about 3mm) free.
2) Screw the joint in the piping female screw of the actuator by hand fully. (Refer to the lower fig.)
3) Screw the joint one turn with a spanner wrench.
- Avoid excessive tightening for joint. (The threaded area can be damaged.)
4) Mount a steel pipe or a tube.
With solenoid valve With solenoid valve and filter regulator
Necessary items
Caution
A
ir supply
bore
A
ir supply
bore

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 17
14. Connection of limit switch procedure
＜ CFC-6301,CFC-6302 ＞
- Shut down the power on the equipment before connecting or disconnecting wires. (There
are risks of electrical shock depending or machine start suddenly.)
- Be sure that the terminal cover and body cover are put on during the operation.
- Firmly tighten the cover. (Rainwater etc. will invade and cause breakdown.)
●Phillips head screw driver ●Flathead screw driver ●Wire stripper
●Connector (G1/2)
Procedure
1) Loosen the four screws used to attach the limit switch cover with a Phillips head screwdriver and
remove cover from the limit switch. (The screw is made so that it will not detach from the cover.)
2) Remove a protective cover made of resin.
3) Draw a cable through the connector.
4) Strip cable with a wire stripper.
5) Connect terminal screw with a flat head screwdriver according to the internal circuit diagram
shown in Specifications of limit switch.
- Tighten the screws. (If not, electric leaks or shocks may occur.)
6) Tighten the above four screws with a Phillips head screwdriver to install cover on the limit
switch.
7) Tighten the cable by connector.
Warning
Caution
Necessary items
Caution
Screw of the limit
switch cove
r
Limit switch cover
Connector

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”) 18
15. Connection of solenoid valve procedure
- Shut down the power on the equipment before connecting or disconnecting wires. (There
are risks of electrical shock depending or machine start suddenly.)
- Check the solenoid voltage and supply voltage.
●Phillips head screw driver ●Terminal crimping tool ●Wire stripper
●Connector (G1/2)
Procedure
1) Loosen the cover setting screw by Phillips head screw driver, and remove the cover.
- Don’t loss O-ring. (Short circuit or shocks may occur.)
2) Remove the Fasten terminal inserted into coil
side and the insulating sleeve. (Insulating
sleeve isn’t attached in Faston terminal.)
3) Draw the cable through the connector to the
cover.
4) Strip cable with a wire stripper.
5) Draw the lead wire through the cover.
6) Install the Faston terminal on the lead wire
with a terminal-crimping tool.
7) Insert the Faston terminal into the coil side,
and fit the cover. (DC power supply, there is
no polarity.)
8) Tighten the cover setting screw to fix it.
(The cover can be set with the wire extraction
opening turned upward or downward.)
9) Tighten the cable by connector.
Necessary items
Caution
Cable
Caution
Cover gasket
O-ring
Cover setting screw
Faston terminal
(With insulating sleeve)
Faston terminal
(For ground)
Coil
Cover

Installation, Operation and Maintenance Manual
【H-A070-E-3】 3-Way Ball Valve Type23 Pneumatic Actuated Type AR 15-50mm (1/2”-2”)
19
16. Operating procedure
1) Operating procedure by air
- Confirm that a wrench for manual operation is not fitted into the output shaft located in the
upper part of the actuator.
- The AV valves must be used within the specifications specifically applicable to the product.
(May not work.)
Procedure
1) Supply air to the air supply opening.
2) Check that the air supplying side and the indicator position are matching.
3) Stop supplying air.
Left open
＜Double acting & Air to open＞
Right open
Right open
＜
A
ir to shut＞
Left open
For the limit switch box
(Double acting, air to open, air to shut)
Left open Right open
Caution
Warning
