Asano AK10141 User manual

AK Block Type III-A Instruction manual
Before use
・
For proper and safe use of the product, the prevention of injury to yourself and others around you, and the
prevention of damage to property, read and understand this document thoroughly before handling the product.
・
After reading this document, store it in a place where it can be easily referenced.
・
Have an expert plan and install equipment such as cranes that will be used with the product.
・
Follow the industrial safety and health regulations and safety ordinance for cranes when handling the product.
・
The product is manufactured for the purpose of hoisting or pulling heavy loads. Do not use it for any other
purpose.
・
The product is for professional use only. It is not for general home use.
Safety precautions
The descriptions in these “Safety precautions” and in the text are for you to follow in order to prevent injuries and property damage.
■The danger and degree thereof resulting from incorrect handling are classified as follows.
Ignoring this indication and handling the product incorrectly may result in serious injury or death.
The following symbols are used to indicate the descriptions for you to follow.
Ignoring this indication and handling the product incorrectly may result in minor injury or property damage.
Describes something you must not do. Describes something you must do.
In low temperature environments, check that the sheave is not
frozen before working.
Failure to do so may damage the rope from rotation failure of the
sheave due to freezing.
In high temperature environments, lubricate periodically.
In high temperature environments, depletion of lubricant is severe and
if the lubricant dries up, it will cause damage to the sheave and shaft
and rotation failure for the sheave.
Do not use or store in the following environments.
・
Places with extreme temperature changes
・
Places with corrosive or acidic gas
Doing so will cause rotation failure or strength deterioration.
Do not use while submerged such as in the sea or water.
Doing so will lead severe rotation failure or strength deterioration due
to adhesion of foreign matter or corrosion.
Do not let the pulley touch sharp objects or abrasive surfaces.
Doing so will cause the pulley to weaken due to damage or abrasion.
Do not let the sheave rotate continuously at high speeds for long
periods of time.
Doing so will cause the lubricant to dry up and wear out the sheave
and shaft due to frictional heat.
Use within the temperature range between -18℃ and 66℃.
Using outside of this temperature range will cause rotation failure or
strength deterioration.
Pulley type Model
Size
(sheave dia.)
（mm）
Max.
rope dia.
(mm)
Used
hex key
wrench dia.
（mm）
Unit
weight
(kg)
Working
load limit
(kg)
Dimensions
(mm)
d D L L1 L2 B B1 t t1
AK10141
AK10142
AK10143
AK10144
AK10146
AK10147
AK10148
AK10149
AK10151
AK10152
AK10156
AK10157
A K10 161
AK10162
AK10163
AK10164
AK10171
AK10172
75
100
125
150
75
100
125
150
75
100
75
100
75
100
125
150
75
100
Body / Nut = Special stainless steel , Sheave = SCS13 (equivalent to SUS304)
Swivel / Hook / Side plate / Sheave pin / Set screw = SUS304 , Bush = Bronze
16
22
25
30
16
22
25
30
16
22
16
22
16
22
25
30
16
22
14.5
16
22
25.5
14.5
16
22
25.5
22
32
22
32
14.5
16
22
25.5
22
32
18
23
26
31
18
23
26
31
18
23
18
23
18
23
26
31
18
23
237
297
364
433
237
297
364
433
259
340
259
340
237
297
364
433
259
340
38
44
54
60
38
44
54
60
−
−
−
−
38
44
54
60
−
−
115
143
174
204
115
143
174
204
129
170
129
170
115
143
174
204
129
170
80
108
135
160
80
108
135
160
80
108
80
108
80
108
135
160
80
108
L3
59
78
100
120
59
78
100
120
59
78
59
78
59
78
100
120
59
78
19
22
27
30
19
22
27
30
23
30
23
30
19
22
27
30
23
30
24
28
32
38
24
28
32
38
24
28
24
28
24
28
32
38
24
28
54
62
73
82
82
95
111
130
54
62
82
95
54
62
73
82
54
62
1.5
1.5
2
3
1.5
1.5
2
3
1.5
1.5
1.5
1.5
1.5
1.5
2
3
1.5
1.5
1.2
2.2
4
6
1.6
3.1
5.7
9
1.25
2.7
1.8
3.75
1.3
2.4
4.4
6.8
1.4
2.85
500
1000
1200
2500
500
1000
1200
2500
500
1000
500
1000
500
1000
1200
2500
500
1000
Single Sheave
(Eye)
Single Sheave (Eye)
Double Sheave
(Eye)
Double Sheave (Eye)
Single Sheave (Hook)
Single Sheave (Hook)
Double Sheave (Hook)
Double Sheave (Hook)
Single Sheave
(Snatch/Eye)
Single Sheave (Snatch/Eye)
Single Sheave
(Snatch/Hook)
Single Sheave (Snatch/Hook)
Material
2866 Tsukioka, Sanjo, Niigata, 955-0803, JAPAN
TEL [phone] FAX [phone]
Homepage http://www.asano-metal.co.jp/en/
E-mail [e-mail]
Manufacturer
Asano Metal Industry Co., Ltd.
Dealer
Revised April 10, 2019
6. Product specifications
B
Size
(sheave dia.)
B1
L
L1
Max.
rope dia.
L2
L3
d
t1
D
Set screw
t
Size
(sheave dia.)
B1
B
L
L1
Max.
rope dia.
L2
L3
d
t1
D
t
Set screw
B
Size
(sheave dia.)
Max.
rope dia.
L2
L3
t1
D
Set screw
t
L
B1
d
Size
(sheave dia.)
Max.
rope dia.
B
L
L2
L3
d
t1
t
D
Set screw
B1
Max.
rope dia.
L2
L3
t1
D
t
Set screw
Size
(sheave dia.)
B
L
B1
d
Size
(sheave dia.)
B1
Max.
rope dia.
B
L
L2
L3
L1
d
t1
t
D
Set screw
Do not use for the purpose of hoisting people or equipment with
people in it.
Doing so may lead to serious injury or a fatal accident.
Do not apply loads that exceed the working load limit.
Doing so may damage the pulley, drop the hoisted load, and lead to
serious injury or a fatal accident.
Do not apply impact loads.
Doing so may lead to serious injury or a fatal accident due to a broken
pulley or other part, or falling hoisted loads.
Do not ride on top of hoisted loads or pulley equipment.
Doing so may lead to serious injury or a fatal accident due to falls or
falling hoisted loads.
Do not use when there are people within the movement range of
the hoisted load or under the pulley.
Doing so may lead to serious injury or a fatal accident.
When hoisting, stay away from the pulley, rope, and around and
under the hoisted load.
Failure to do so may get your hands or body caught or you may get
crushed under the falling hoisted load, lead to serious injury or a fatal
accident.
Do not use the swivel for purposes such as constant rotation.
Doing so may damage the swivel, drop the hoisted load, and lead to
serious injury or a fatal accident.
Do not perform modifications such as welding or cutting.
Doing so may lead to serious injury or a fatal accident due to a
weakened or broken pulley.
Inspect before use and periodically.
Failure to do so will overlook abnormalities or damage to the pulley,
and may lead to serious injury or a fatal accident.
Do not let the rope fixture touch the pulley.
Doing so may damage the pulley and lead to an accident of a falling
hoisted load.
Attach the hoisted load so that the sheave and hoisted load
fixture are in tandem.
If the load is applied to the pulley from the side, it may lead to serious
injury or a fatal accident due to breakage.
After starting to hoist a load, check that the rope is in the groove
of the sheave.
Failure to do so may drop the hoisted load due to rope damage, and
lead to serious injury or a fatal accident.
Do not use during bad weather such as in strong winds.
Doing so may drop the hoisted load and lead to serious injury or a
fatal accident.
When attaching, removing, or transporting a pulley, use
slip-resistant protective gloves and perform work in a stable
place.
Failure to do so may drop the pulley and lead to serious injury or a
fatal accident.
Warning
Warning
Caution
Caution
Important
10141 MAE

●If a problem occurs while using the pulley, discontinue use immediately,
and check the items in .
<Inspection of movable parts>
■Single Sheave (Eye)
(Size 75, 100, 125, 150)
Insert the sheave pin so
that its triangular rib fits
into the notch on the body.
①Set the spring.
③Put it inside the hook while
tilting to the side so avoids
the hook tip.
●Rotation of sliding parts
○The swivel (or hook) and sheave
rotate smoothly.
●Safety latch opening and closing
○The safety latch opens and closes
smoothly to its specific positions.
○The spring is not permanently damaged.
The nut is not loose or defective.
●Perform periodic inspection at least once a year.
●If you use the product under harsh conditions such as frequent hoisting
of loads equal to the working load limit, impact loads, or intense rolling,
perform inspection early because the parts will wear out substantially.
●For periodic inspection, inspect all of the items in
Inspection before use ,
perform maintenance, and check the dimensions of each part. If the
dimensions are 10% different from the original dimensions or the
dimensions in the catalog, replace the part or product.
(Refer to for the dimensions.)
Follow local regulations when disposing.
●For inquiries about pulleys, please consult the dealer where you
purchased the product.
●Nut securing the sheave pin and the set screw are not loose or
defective.
*For the checking method, refer to Removing and attaching the nut .
●Snatch opening and closing
○The snatch hook opens and closes smoothly to its specific positions.
○The spring is not permanently damaged.
○The snatch cap opens and closes smoothly to its specific positions.
②Align the safety latch and spring
with the hook holes and insert
the bolt. (*1)
④Insert the bolt all the way through
and secure it with the nut.
⑤Pound the bolt tip with a hammer to
prevent the nut from getting loose.
Insert the sheave pin so that
its notch fits into the
squared notch on the body.
①Remove the set screw.
②Remove the nut.
①Tighten the nut.
②Screw in the set screw.
*If the set screw hits a rib, it will not go all
the way in and protrude out. In such
cases, loosen the nut just to move the rib
out of the way, and then screw in the set
screw all the way.
If you try to remove the nut first, the tip of the set screw will bend and
you will be unable to remove it.
■Single Sheave (Snatch/Eye)
(Size 75, 100, 125, 150)
[Replacement parts]
■Sheave pin ■Sheave
(Size 75, 100, 125, 150)
■Safety latch
(Size 75, 100)
■Single Sheave (Hook)
Double Sheave (Hook)
Single Sheave (Snatch/Hook)
(Size 75, 100)
■Double Sheave (Eye)
(Size 75, 100, 125, 150)
Snatch cap
Body
Body
Trigger
Swivel
Swivel
Sheave pin
Hook
(Size 75, 100)
With ball oil cap
(Size 125)
With grease nipple
(Size 150)
Sheave
Sheave
Bush
Nut
Set screw
Safety latch
(sold separately)
<Nut and set screw inspection>
●There are no cracks or corrosion in the
swivel and welded part of the swivel pin.
There are also no cracks or corrosion in
the other parts.
●There are no bends, twists, distortions, or
stretches.
●There is no excessive wear, denting, or
hollowing out.
●There is no wire scratch marks on the
sheave surface.
●Foreign matter or dirt is not attached.
●Casted characters on the body shall be
readable.
<Visual inspection of appearance>
1. Part names
3. Inspection and maintenance
4. In case of trouble
5. Disposal of the product
2. Part removal and attachment
When rotating the set screw with a hex key wrench, do not use a
worn-out hex key wrench or a hex key wrench with an incorrect size.
Doing so will strip the hexagon hole and you will be unable to
remove the set screw.
<Removal>
<Sheave pin>
(Size 75, 100, 125)
<Sheave pin>
(Size 150)
<Attachment>
Removing and attaching the nut
Attaching the sheave pin
Assembling the safety latch
Inspection before use
Periodic inspection
Maintenance
Bush
Bolt
Nut
Safety latch
Spring
Set screw
Nut
Protrusion is not OK
Snatch hook
Snatch cap
Spring
Notch
Body
Body
Triangular rib
Notch
*1
Do not let it go
through the
safety latch hole.
Do not use products that are in the following conditions.
・
Products that are deformed, cracked, or worn out
・
Products with signs of corrosion such as rust stains or
galvanic corrosion
Doing so may lead to serious injury or a fatal accident due to
falls or falling hoisted loads.
Do not let the product touch other types of metal for long
periods of time.
Doing so will cause corrosion.
When disassembling the pulley for sheave replacement,
remove it from high places and disassemble on the ground.
Failure to do so may drop the pulley and lead to serious injury or
a fatal accident.
When replacing parts, use ASANO-specified parts.
Failure to do so may result in lower functionality of the pulley
due to incompatible parts.
If it does not go into its specific positions even if you apply
grease, the cause may be deformation or bending.
Discontinue use and replace the product.
If rotation is poor, not centered, significantly rattles, or if rotation
stops, discontinue use and replace the part or product.
If the spring is significantly damaged and does not go into its
specific positions, replace the safety latch.
Inspect before using the pulley.
Using the product when there is a problem accelerates the
damage and may lead to strength deterioration, damage to the
product, or an accident of a falling hoisted load.
In the unlikely event the pulley deforms or breaks and a load is
hanging in midair, first take down the hoisted load, unload the
pulley, and take safety measures to prevent secondary disaster.
Spring
Nut
Rib
Squared notch
Sheave
Swivel
(Hook)
Welded part of
the swivel pin
Stretching
Apply to the gap of the swivel
pin in the body.
(Size 75, 100, 125)
Apply to the gap between the
sheave and the sheave pin.
(Size 75, 100)
*Lubricate from the ball oil cap of the
sheave pin with a grease gun.
(Size 125)
*Lubricate from the grease nipples of
the swivel pin and the sheave pin with
a grease gun. (Size 150)
●Applying to the snatch
●Applying to the swivel pin and sheave pin
<Applying grease (or lubricant)>
Swivel
(Hook)
Swivel pin
Sheave
Sheave pin
Body
Grease nipple
Ball oil cap Grease nipple
Apply to the movable parts of
the snatch.
Do not let grease on the swivel pin dry up.
Drying up will lead to breakage of the swivel pin or the crack of
the welded portion.
①For light dirt (such as hand marks, sand, or mud), wipe with a damp soft
cloth or sponge, and then wipe with a neutral detergent.
②If dirt still remains, wiping with a store-bought cleaner (cleaning
solution), remover, or thinner is effective.
③If rust stains (spots of rust caused by iron particles in dirt) remain after
performing ①and ②, use a store-bought rust remover.
④If the rust cannot be removed with a store-bought rust remover, rub it
off with sandpaper or an abrasive compound.
⑤Remove foreign matter by scraping it away with sharp-tipped object
such as a slotted screwdriver, and then perform ①and ②. Rub off
persistently attached foreign matter with a file or abrasive compound
because you may damage the product if you use excessive force.
<Removing corrosion (rust), dirt, and foreign matter>
Wipe frequently.
Attached foreign matter such as sea water, soot, or iron
particles will cause corrosion.
6. Product specifications
3. Inspection and maintenance
