Ascent Communication Technology AH1000 HFC User manual

AH1000 HFC
Headend
Solution NMS
Quick Reference
Guide
Revision A

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 2 of 15
ACT AH1000 Headend Solution NMS
Quick Reference Guide
ACT Document Number: ACT AH1000 NMS Quick Reference Guide
User Guide Revision A
Copyright © 2016 Ascent Communication Technology Limited.
All rights reserved. Reproduction in any manner whatsoever without the express written permission of Ascent
Communication Technology is strictly forbidden.
This document is produced to assist professional and properly trained personnel with installation and maintenance
issues for the product. The capabilities, system requirements and/or compatibility with third-party products
described herein are subject to change without notice.
For more information, contact ACT: [e-mail]
Revision History
Revision Date Reason for Change
A 09/28/2016 Initial release

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 3 of 15
Table of Contents
1 Introduction ........................................................................................................................... 4
2 Installation, Login................................................................................................................... 4
3 Device Tree............................................................................................................................. 5
4 Parameter Settings................................................................................................................. 5
4.1 Supported Modules ······································································································· 5
4.2 Basic Parameter Settings································································································ 7
4.3 Parameter Threshold Settings························································································ 7
4.4 Parameters Real-Time Monitoring················································································· 8
4.5 HFC Common Parameter Settings·················································································· 8
4.6 Modify Network Management Read and Write Group Name ········································ 9
5 Detect/Search ...................................................................................................................... 11
6 Alarm.................................................................................................................................... 12
7 Log........................................................................................................................................ 12

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 4 of 15
AH1000 Headend NMS is a powerful SNMP-based network management applications.
Basic environment
Windows Server 2003, Windows XP, Windows 7, Windows 8, Win 10
.NET Framework 2.0
a. vjredist.exe
Install "…\VJSharpRDP\vjredist.exe"
Run "..\AH1000 Headend Platform NMS\AH1000 Headend Platform NMS.exe"
Initial login information:
User: admin
Password: admin

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 5 of 15
Right click the tree node. You can create, delete equipment/group. Or edit their basic
information.
AH10-PS-AC AH1000 Power Supply 90-260VAC
AH10-PS-DC AH1000 Power Supply 48VDC
AH10-SMM AH1000 SMM module
AH10-F3ST-xx-S AH1000 1310 Single Forward Transmitter, xxdBm, SC/APC
AH10-M3ST-xx-yy-S AH1000 1310 Single CWDM Fwd Transmitter, xxdBm, CWDM 1yy0, SC/APC
AH10-F5ST-xx-S AH1000 1550 DMOD TX, 1550nm, xxdBm, 1GHz, up to 20km SC/APC
AH10-F5ST-xx-yy-S AH1000 1550 DMOD TX, 1550nm, xxdBm, ITU channel yy, up to 20km SC/APC
AH10-EDFA-xx-01-S AH1000 EDFA Optical Amplifier, xxdBm output power, 1 output port, SC/APC
AH10-ARQR-ST-S AH1000 Analog 200MHz Quad Return Receiver Standard version SC/APC
AH10-CRQR-ST-S AH1000 Analog 300MHz Quad Return Receiver Standard version SC/APC

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 6 of 15
AH10-FRDR-S AH1000 Forward Redundant Receivers, 2 Optical In, 1 RF Out, SC/APC
AH10-RCST-xx-yy-S AH1000 Return CWDM Transmitter, xx dBm, CWDM channel yy, SC/APC
AH10-RFAF-20 AH1000 RF Forward Amplifier Module 20dB Gain
AH10-OPSW-S AH1000 Optical Switch Module SC/APC
AH10-RFSW-S AH1000 RF Switch Module SC/APC
Double-click the treenode (equipment), if the device is online, it shows the parameter
monitor view.

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 7 of 15
Double click the parameter value textbox, it shows the parameter simple setting dialog.
Double click the parameter(with threshold) value textbox, it shows the dialog as follows.

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 8 of 15
(Make sure that "real time parameter analyzer" button is in enable status)
Double click the parameter(with threshold) value textbox.

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 9 of 15
Right click on the current device as shown below
In the pop-up dialog box, select: ”Modify read-write community”

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 10 of 15
Change default setting from “public” to “private” then click ‘OK’
If you want to view the alarm information, please modify the TRAP address into the same IP
address the same as the network management software PC

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 11 of 15
Click “Address search” on toolbar .It shows the search dialog.
Right click the device in search list, select “regist new device”, it shows the regist dialog.

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 12 of 15
Alarm sound:
Click “alarm voice on/offf” button to control the alarm sound.
Current alarm log:
The realtime alarms/traps are appended on the log-listview under the software main form.
Click “history alarm logs” button on toobar, it shows the log filter dialog.

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 13 of 15
Click “Activity event log” button on toobar, it shows the log filter dialog.

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 14 of 15

AH1000 HFC Headend Solution NMS
Solutions Provider for FTTx, RFoG and HFC www. ascentcomtec.com
Page 15 of 15
Ascent Communication Technology Ltd
AUSTRALIA
HONG KONG SAR
961 Mountain Highway, Boronia
Unit 9, 12th Floor, Wing Tuck Commercial Centre
Victoria 3155, AUSTRALIA
177 Wing Lok Street, Sheung Wan, HONG KONG
Phone: [phone]
Phone: [phone]
CHINA
USA
Unit 1907, 600 Luban Road
2710 Thomes Ave, Cheyenne
200023, Shanghai CHINA
WY 82001, USA
Phone: [phone]
Phone: [phone]
EUROPE
VIETNAM
Pfarrer-Bensheimer-Strasse 7a
15 /F TTC Building, Duy Tan Street, Cau Giay Dist.
55129 Mainz, GERMANY
Hanoi, VIETNAM
Phone: [phone]
Phone: [phone]
WEB: www. ascentcomtec.com EMAIL: [e-mail]
Specifications and product availability are subject to change without notice.
Copyright © 2016 Ascent Communication Technology Limited. All rights reserved.
Ver. ACT_AH1000_NMS_ QRG_v1e_Sep_2016
