Ascentic TouchSelect User manual

User Manual
TouchSelect
USB Touch Panel Interfaces
TS04-USB, TS09-USB, TS22-USB

Introduction
The Audio Authority® TouchSelect USB series o󰀨ers exible solutions
for any interactive display. TouchSelect panels come in three congurations:
4 position (TS04-USB), 9 position (TS09-USB), and 22 position (TS22-USB).
The TouchSelect RS-485 series o󰀨ers the same congurations with di󰀨erent
features. A compatible USB device such as a switch module or media player
can be programmed to respond to TouchSelect panels.
Features
• Use only the locations you need on each panel.
• Use any non-conductive material for graphic overlay.
• Bright blue LEDs shine through many overlay materials.
• The connected player or switching device interprets each
position connected.
USB-A
COMMUNICATION
BUS
TS04 REAR
POSITION 1 POSITION 2 POSITION 3 POSITION 4
TS04 FRONT
COMPATIBLE WITH
BRIGHTSIGN® MEDIA
PLAYERS

USB-A Communication
The TouchSelect USB series communicates via a standard USB connection.
Any of the TouchSelect control panels may be connected to a compatible device
such as a BrightSign player or Ascentic MediaHub. When touched, the TouchSelect
panel transmits the touch location and its address over the bus. Any USB-A
capable device can be programmed to respond to these messages, enabling player
controls and switching activity.
Installation
• Connect USB cable from touch panel
to switcher.
• Attach the touch panel to the xture.
• A󰀩x the overlay to the surface of the
touch panel.
• Touch each position to validate
programmed commands.
TS09 (HxWxD, inches): 2.5 x 4 x 1
TS22 (HxWxD, inches): 3.5 x 11.75 x 1
TS04 (HxWxD, inches): 1 x 5 x 1
Command Arguements Example
[PRESS_#] [PRESS_[POSITION]] [PRESS_1]
[RELEASED] [RELEASED] [RELEASED]
[BLINK_#] [BLINK_[POSITION]] or [BLINK_
[POSITION1],[POSITION2], ...]
[BLINK_3,5,6]
[LEDON_#] [LEDON_[POSITION]] or [LEDON_
[POSITION1],[POSITION2], ...]
[LEDON_1,3,7]
[LEDOFF_#] [LEDOFF_[POSITION]] or [LEDOFF_
[POSITION1],[POSITION2], ...]
[LEDOFF_3]
[LEDALLOFF] none [LEDALLOFF]
USB Serial Command List

• A touch panel controls volume and plays video tracks.
• Start a demo by touching “Play Next” and adust volume by touching
“Volume” keys.
• Touch panels connect via USB to the MH6-4K MediaHub
E-169
Rev. 20221020
TS04-USB Example System:
