HIOS CLT-30, CLT-45, CLT-60, and CLT-80
Power Supply Operaonal Manual
Important: Please read and save the operang instrucons.
Danger: To reduce the risk of re or electric shock, carefully follow these instrucons.
Storage, Operaon, Set-Up
1. Be sure that the power source is equipped with a circuit breaker.
2. Store the power pack in a place free from excessive humidity, temperature, and dust. Keep
it away from metallic objects.
3. Do not place objects on the unit.
4. Use the ngs provided to secure the unit. The installaon area should be vibraon free.
5. Do not store the unit next to high voltage equipment.
Cauon
1. Do not drop the power supply.
2. Connect to a power source of only the specied voltage.
3. Only use compable screwdrivers with the power supply.
4. Do not drag the unit by its power cord. Keep the cord away from foreign objects, oil, and sharp
implements.
5. Grasp the plug when disconnecng the power cord.
6. Do not disassemble or modify the unit.
7. If the unit overheats, acvates a circuit breaker, or exhibits other abnormalies, stop operaon
immediately, unplug the unit, and contact ASG for repair.
8. When the unit is not in use, turn the power switch o and disconnect it from its power source.
9. For connecon to a supply not in the USA, use an aachment plug adapter of the proper
conguraon for the power outlet.
10. Install a leakage breaker and safety breaker on the input power source and connect the ground
to use the unit.
Specicaons
Compable Screwdrivers
Power Supply For use with Compable Screwdrivers
CLT-30 1 screwdriver CL-2000, CL-3000, SS-2000, SS-3000
CLT-45 1 screwdriver CL-2000, CL-3000, CL-4000, CL-6000, CL-6500, SS-2000, SS-3000, SS-4000, SS-
6500, A-4500, A-5000
CLT-60 1 screwdriver CL-2000, CL-3000, CL-4000, CL-6000, CL-6500, CL-7000, SS-2000, SS-3000, SS-
4000, SS-6500, SS-7000, A-4500, A-5000, A-6500
CLT-80 1 screwdriver CL-9000
T-45BL 1 screwdriver BLG-ZERO1: BLG-4000ZERO1, BLG-5000ZERO1, BLG-5000ZERO1-15*, BLG-
5000ZERO1-HT*
BLG-BC2: BLG-4000BC2, BLG-5000BC2, BLG-5000BC2-15*, BLG-5000BC2-HT*
BLG-BC1: BLG-4000BC1, BLG-5000BC1, BLG-5000BC1-15*, BLG-5000BC1-HT*
BLG: BLG-4000, BLG-5000, BLG-5000-15*, BLG-5000-HT*
BLG-OPC: BLG-4000-OPC, BLG-5000-OPC, BLG-5000-OPC-15*,
BLG-5000-OPC-HT*
BL: BL-2000, BL-3000, BL-5000, BL-5000-15*, BL-5020*
BL-OPC: BL-2000-OPB, BL-3000-OPC, BL-5000-OPC, BL-5020-OPC*
T-70BL 1 screwdriver BL Series, BLG Series, BLG-4000BC2 Series, BLG-5000BC2 Series, BLG-
4000BC1 Series, BLG-5000BC1 Series
Model Number CLT-30 CLT-45
Input Voltage AC100-240V 47-63Hz AC100-240V 47-63Hz
Power Consumpon 40W 45VA-78VA
Fuse Capacity 2A/250V (Built-in) 3.15A/250V (Built-in)
Output Voltage 2(30V), 1(20V) Two Stage Sengs 2(30V), 1(20V) Two Stage Sengs
Size (mm) 62 x 134 x 40(H) 146 x x 42.6(H)
Weight (g) 300 300
AC Cord Length 1.8m (inlet cord) 1.8m (inlet cord)
Accessories (2) Aachment plates
(4) aachment screws
(1) Mounng Bracket
(1) aachment screws
1
1: Primary Side

ASG, Division of Jergens, Inc.
15700 S. Waterloo Road | Cleveland, OH 44110-3898 | Phone: [phone] | Fax: [phone] | Email: [email protected] | Web: www.asg-jergens.com
HIOS CLT-30, CLT-45, CLT-60, and CLT-80
Power Supply Operaonal Manual
Specicaons
1: Primary Side
Aachment Plates and Dimensions
CLT-30, CLT-60, CLT-80, and T-70BL: Please use both plates to secure the pack for operaon. Use the
screws provided. Be sure the plates are securely aached and then use them to aach the power
pack to an appropriate work staon.
Model Number CLT-60 CLT-80
Input Voltage AC100-240V 47-63Hz AC100-240V 47-63Hz
Power Consumpon 60W
Fuse Capacity 5A/250V (Built-in) T5A/250V (Built-in)
Output Voltage 2(30V), 1(20V) Two Stage Sengs 2(30V), 1(20V) Two Stage Sengs
Size (mm) 88 x 210 x 52(H) 116 x 210 x 55(H)
Weight (g) 715 1370
AC Cord Length 1.8m (inlet cord) 1.8m (inlet cord)
Accessories (2) Aachment plates
(4) aachment screws
(2) Aachment plates
(4) aachment screws
1
Model Number T-45BL T-70BL
Input Voltage AC100-240V (47-63Hz) AC100-240V 47-63 Hz
Power Consumpon 45VA-78VA 45VA-78VA
Fuse Capacity 3.15A/250V (Built-in) 3.15A/250V (Built-in)
Output Voltage HI(2): DC30V / LOW(1): DC20V
(2-step switchable)
2(30V), 1(20V) Two Stage Sengs
Size (mm) 71.5 × 146 × 42.6 88 ×210 ×52(H)
Weight (g) 320 685
AC Cord Length 1.8m (inlet cord) 1.8m (inlet cord)
Accessories (1) Mounng Bracket
(1) Screw
(2) Aachment plates
(4) aachment screws
1
CLT-30:
CLT-45, T-45BL:
CLT-60 , CLT-80, T-70BL:
Be sure to use the aached mounng bracket and the screw to x the unit securely. The
green LED light turns on when the power is on. Contact ASG if the light does not turn on. The
dimensions do not include concavity and convexity and is not to full scale.
Aachment
Plate (2)
Aachment
Plate (2)
Mounng
Bracket (1)
Screw (4)
Screw (4)
Screw (1)
Aachment Plates and Dimensions (Connued)
Power Switch
I: ON
O: OFF About
Connector for AC Cord
Connector for Electric Screwdriver
DC Output Switch
Unit: mm
