Ash OMNI 3 User manual

OMNI 3 User Manual
1 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h

OMNI 3 User Manual
2 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Contents
Section 1: Introduction...........................................................................................................................................5
Package Contents:..............................................................................................................................................................8
Lens:...................................................................................................................................................................................8
Other:.................................................................................................................................................................................8
Section 2: Installation ...........................................................................................................................................10
Connections: ....................................................................................................................................................................11
The Front Panel ....................................................................................................................................................12
Section 3: Initial Start-up......................................................................................................................................13
Setting the Correct Focal Point:.......................................................................................................................................13
Section 4: System Navigation: The Toolbar ..........................................................................................................14
Extended Toolbar:............................................................................................................................................................15
App Icons: ........................................................................................................................................................................15
Main Toolbar Icons Explained:..............................................................................................................................16
4.1 Toggle:..................................................................................................................................................................16
4.2 Snapshot:..............................................................................................................................................................16
4.3 Auto Focus:...........................................................................................................................................................16
4.4 Spot Focus™: ........................................................................................................................................................16
4.5 Manual Rocker Focus:..........................................................................................................................................16
4.6 Overview: .............................................................................................................................................................16
For Reference: Real Time Lens Distortion Correction (RTLDC): .......................................................................................17
Section 4.7: Settings.........................................................................................................................................................18
4.7 : a(i) Camera:........................................................................................................................................................18
4.7: a(ii) Advanced Camera Settings: ...............................................................................................................................19
4.7 b. System Settings:.....................................................................................................................................................20
Settings: ...........................................................................................................................................................................22
4.7 c. Network Settings:...................................................................................................................................................22
Connecting to the Omni 3 via the Network: ....................................................................................................................22
NFS Configuration: ...........................................................................................................................................................23
Front Panel Capture Image:.............................................................................................................................................23
Settings:................................................................................................................................................................24
4.7 d. Users Settings:........................................................................................................................................................24
Users Settings Continued:................................................................................................................................................25
Settings:................................................................................................................................................................26
4.7 e. Upgrade:.................................................................................................................................................................26

OMNI 3 User Manual
3 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Application Installer:........................................................................................................................................................26
System Language: ............................................................................................................................................................26
Settings:................................................................................................................................................................27
4.7 f. Info:.........................................................................................................................................................................27
Section 4.8 Save File:............................................................................................................................................28
Measurement: .................................................................................................................................................................28
Image: ..............................................................................................................................................................................28
DXF:..................................................................................................................................................................................29
CSV:..................................................................................................................................................................................29
Section 4.9: Open File:..........................................................................................................................................29
Section 5.1: Graticule, Measurement & Annotation Apps (AP 100-001): .................................................31
5.1 (a) Graticule (Overlay): .................................................................................................................31
To Create a Graticule: ......................................................................................................................................................31
Using existing Graticule(s):...............................................................................................................................................31
Save Merged Graticule Image:.........................................................................................................................................32
5.1(b) Measurement Plus & Annotation:..............................................................................................................33
Measurement Toolbar:....................................................................................................................................................33
Measurement Toolbar continued:........................................................................................................................34
Measurement Settings:........................................................................................................................................35
Snap to Edge:........................................................................................................................................................36
Snap to Edge Settings: ..........................................................................................................................................36
Grid Settings:........................................................................................................................................................37
Single Zoom Level Calibration:..............................................................................................................................38
5.1(c) Z Height Measurement (AP 100-008):........................................................................................................39
Method: ...........................................................................................................................................................................39
Z Height Measurement continued:.......................................................................................................................40
Snap to Node:.......................................................................................................................................................41
Snap to Line Centre: .............................................................................................................................................41
Snap to Grid:.........................................................................................................................................................41
Restore View: .......................................................................................................................................................41
Section 5.2: Image Stacking App (AP 100-002):....................................................................................................42
Image Stacking Procedure: ..............................................................................................................................................42
Section 5.3: Side by Side Image Comparator App (AP 100-004):..........................................................................45
Section 5.4: Overlay Image Comparator App (AP 100-003):.................................................................................47
Method: ...........................................................................................................................................................................47
Section 5.5: DXF Import App (AP 100-004):..........................................................................................................49

OMNI 3 User Manual
4 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Section 5.6: Object Counting App:........................................................................................................................51
Method: ...........................................................................................................................................................................51
Section 5.7: Colour Analysis App: .........................................................................................................................53
Note: Colour Analysis Update Software Rev. 5.00...............................................................................................54
Section 5.8: XY Stage Controller: ..........................................................................................................................55
Section 5.9: AI App:..............................................................................................................................................56
Section 6: Presets: ................................................................................................................................................59
Creating A New Preset:....................................................................................................................................................59
Section 7: Measurement Accuracy:......................................................................................................................60
Technical Specifications:.......................................................................................................................................61
Camera Lens and Accuracy Specifications: ...........................................................................................................62
Declaration of Conformity:...................................................................................................................................63
Warranty: .............................................................................................................................................................63

OMNI 3 User Manual
5 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Section 1: Introduction
The OMNI 3 (Fig. 1) is a full HD (1080p) digital microscope inspection system that operates without a
PC. The OMNI 3 platform has a powerful image processing and control engine that delivers superb
full live video image quality at 50/60 frames per second, enabling it to be utilised as a solution in a
broad range of quality control, testing, network, assembly, inspection, and documentation tasks.
The OMNI 3’s flexible, custom platform is highly configurable with advanced inspection and
measurement applications such as: 2D Measurement & Graticule (AP 100-001), Image Stacking (AP
100-002), Image Overlay Comparator (AP 100-003), Side by Side image Comparator (AP 100-004),
DXF Importer (AP 100-005), Z Height (AP 100-008), Colour Analysis (AP 100-009) and Object
Counting (AP 100-010) apps.
Fig. 1

OMNI 3 User Manual
6 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
The OMNI 3 platform has the following key features and benefits.
AshCal™Auto-Calibration:
•The AshCal™auto-calibration feature removes the need for time-consuming zoom change
re-calibrations. Its unique ability to maintain calibration over the entire zoom range is one of
the many features that differentiate the OMNI 3 from other digital inspection systems.
Image Capture:
•Image stamping with time, date, user details and magnification level allows for
traceability of inspection.
•Capture annotation and measurement values on an image (if unit has 2-D measurement
& graticules app).
Auto-Focus:
•The OMNI 3 features a one-click auto-focus on-screen indicator. This allows the user to
rapidly change between auto-focus and manual-focus as required (auto-focus should only be
enabled for inspection; measurements are not possible when auto-focus is active).
Manual Rocker Focus:
•Automatically and rapidly adjust the focus using the manual rocker focus icons to inspect the
area of interest on a sample part when in manual focus mode. No need to manually adjust
to change focus position.
Spot Focus™:
•Quickly focus on the area of interest by simply using the mouse pointer. Improve accuracy
and reduce human error with the capabilities of SpotFocus™*.
AshTruColour™-True Colour Reproduction:
•View true colour reproduction of your sample with the OMNI 3. Replicate real colours as
seen with the naked eye.
RTLDC™Real-Time Lens Distortion Correction*:
•Lens distortion is inherent in all microscopes. Image distortion at the outer edges of large
samples is automatically corrected with OMNI 3.
Internal Storage:
•10GB for storage of images or measurement files for off-network saving.

OMNI 3 User Manual
7 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Save & Recall Inspection Settings:
•Custom system settings such as brightness, exposure and magnification can be saved into an
individual measurement file and easily recalled enabling standardisation of inspection
conditions.
User Privileges:
•Access to functionality can be restricted to enable operational control and traceability.
Intuitive GUI (Graphical User Interface):
•The OMNI 3’s GUI (Graphical User Interface) is a custom designed, mouse-controlled
interface, delivering intuitive and efficient operation and control of the full app suite.
Camera Control Functions:
•Auto and manual focus, exposure, gain, brightness, and white balance customization ensure
ultra-sharp, high contrast imaging.
Illumination Options:
•OMNI 3 offers several quick release, cable free, interchangeable illumination options. With
illumination intensity control and quadrant control, the user can ensure they have shadow-
free illumination and glare reduction.
* Global Patent applied for by ASH.

OMNI 3 User Manual
8 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Package Contents:
Your OMNI 3 package contains:
•OMNI 3
•Quadrant Controllable Ring Light (attached)
•Lens +5 (attached)
•Keyboard and Mouse
•Mouse Mat
•Power Supply
•HDMI to HDMI Cable
•Mini USB Cable
•USB Memory Stick (containing User Manual)
•Grounding Cable –connected to grounding mat or plug if required (not supplied)
•Arm Bracket
•Arm Receiver
•Cleaning Cloth
Optional OMNI 3 Apps & Components
Apps:
•2D Measurement & Graticule (AP 100-001)
•Z Height Measurement (AP 100-008 Add-on to Measurement app)
•Colour Analysis (AP 100-009)
•Object Counting (AP 100-010)
•Image Stacking (AP 100-002)
•Image Overlay Comparator (AP 100-003)
•Side by Side image Comparator (AP 100-004)
•Import DXF (AP 100-005)
Lens:
•+5 Lens (AI 280-150)
•+10 Plan 1x Lens (AI 100-055)
•+25 Lens (AI 280-053)
•+50 Lens (AI 100-064)
Other:
•Motorized XY Stage (AI 100-050)
•OMNI 3 Touchscreen Workflow Controller (AI 100-049)
•Diffused LED Dome Light (AI 100-045) - For use with metallic sample analysis
•UV LED Light Ring: (AI 801-421)
•Ash 360⁰ Rotating Viewer: (AI 801-458)

OMNI 3 User Manual
9 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
•Footswitch (AI 801-419) - Comfortably work handsfree by programming each individual pedal.
•External Keypad KPII (FI806-002) - Optional extra for use with Pre-set function (see Section
6.). Useful to improve workflow speed and for user access control.
*For full list of system components please contact us: [e-mail]
Please retain the packaging in case there is a need to return the unit for service or repair.

OMNI 3 User Manual
10 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Section 2: Installation
Setup:
1. Attach the Arm Receiver to the Stand using the 4 screws provided (Fig. 2).
2. Hook the Arm Bracket onto the Arm Receiver using the 4 hooks, tighten the two thumb
screws at the rear of the Arm Receiver.
Cabling (Fig. 3):
3a. Route all cables, such as power supply and ESD cables, through the hole of the underside
of the Arm Bracket and ground the ESD cable to bench. Route the HDMI cable to the
monitor. Insert the mouse dongle and keyboard dongle into the side ports on the OMNI 3.
Note: The mouse dongle must be plugged in before powering the unit on. This will enable
the mouse to be detected.
3b. Connect the cables to their corresponding ports on the OMNI 3.
4. Hook the OMNI 3 onto the front hooks on the Arm Receiver using the 4 hooks.
5. Tighten the front two thumb screws on the Arm Receiver to secure OMNI 3.
1
4 2
5
Cables feed through
hole in the Arm Bracket
3 cable routing
Fig. 3
Fig. 2

OMNI 3 User Manual
11 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Connections:
Rear:
1. HDMI connector to TV/Monitor
2. 2 x USB Ports
3. Ethernet Connection to Network
4. DC Power Jack to Power Supply
5. External Aerial Connection
6. 3 x Auxiliary Communications Ports
7. Grounding Connection (grounding cable supplied)
Side:
8. 2 x USB Ports
9. Mini USB (PC) Connection (OMNI 3 shows as removable media, read only, files and folders
can be browsed and copied to PC).
Never look directly at the LED light source for any prolonged period.

OMNI 3 User Manual
12 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
The Front Panel
The OMNI 3 *Front Panel (Fig. 4) operates by selecting the function you wish to adjust via the
Control Buttons, and then adjusting by turning the Intuitive Return Dial to the Right or Left.
*Note: Front Panel is disabled
when a menu is active or can be
disabled in settings
White Balance
Overview
Zoom
Image Brightness
Return Dial
Image Capture
Ring Light
Intensity
Manual/Auto
Focus Toggle
Fig. 4
Power

OMNI 3 User Manual
13 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
A s h
Section 3: Initial Start-up
Setting the Correct Focal Point:
Before using the OMNI 3 the user must set the focal point of the lens first to suit the height of the
object.
•Power up the unit.
•Ensure camera focus is set to Measurement Ready (Settings Section 4.7)
•Place the unit in Overview Mode by clicking the Overview icon in the menu bar.
•Move the object until the desired viewing area is under the crosshair of the screen.
•You can exit Overview mode by again selecting the Overview tab in the menu bar.
•Zoom to full magnification.
•Manually adjust the height of the OMNI 3 up or down on the stand until the object is in
focus. You have now achieved your optimal focal point.
•When the focal plane is set you can only measure points at that plane. You can now zoom
in and out freely to take measurements of areas on the same plane as the focal point. The
OMNI 3 will automatically adjust the measurement value as you zoom. If the user wishes to
view/measure a different object with a different height, then the focal point will have to
be set again.
•To recall a Graticule/overlay file, you must also ensure the focal plane is set prior to opening
the overlay file.
•You can now zoom out from full magnification (via zoom out icon) until the area you wish to
measure can be viewed.
For best accuracy at low magnifications, try to align the area being measured to the center third of
the screen.
Fig. 5
The image shows the focal
point has been set to
measure Plane A. If the
object is moved so that
Plane B is within the field of
view, then the Focal point
will need to be set again for
Plane B before you can
measure.
*Refer to OMNI 3 Quick Start
User Guide

OMNI 3 User Manual
14 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
5.00
A s h
Section 4: System Navigation: The Toolbar
Omni3 Main Toolbar icons (fig.6)
Zoom in *
Zoom out *
Toggle between live and static image
Take snapshot of a live image
Auto- focus
Manual Rocker Focus buttons
Camera Overview
Settings menu
Save file
Open file
Extended Toolbar
Log-in/Off
Fig. 6
* Ensure camera focus is set to ‘Measurement Ready’ (see Settings Section 4.7) when changing
zoom levels so focus tracking is maintained.
Live
Magnification
Field
Note: The Toolbar can be hidden by selecting 'Auto Hide
Main Toolbar' in System Settings (see Section 4.7 b.)

OMNI 3 User Manual
15 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
5.00
A s h
Extended Toolbar:
Fig. 7
Click on the Extended Toolbar icon to display Extended Toolbar (Fig. 7) selection. To display any of
the Apps on the main toolbar enable the check boxes for the App based on your preference and
workflow requirements. Once selected, they are easily accessible on the main toolbar. You can also
launch the App from within the extended toolbar by clicking on the App icon. A max. of 5 apps can
be added to the main toolbar at any one time.
To save the current toolbar setup click the small Save icon at the bottom right (Fig. 7).
Light blue coloured icons indicate the App is in trial mode. Trial mode allows the App to be
launched 30 times. Grey icons indicate the trial period for that app has expired.
Contact [e-mail] for further details if a full version of an app needs to be purchased.
App Icons:
*Functions explained in detail Apps Section 5
AI
Graticule
Measurement
Image Stack
Side by Side Comparator
Comparator Overlay
DXF Importer
Object Counting
Colour Analysis
Motorized XY Stage

OMNI 3 User Manual
16 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
5.00
A s h
Main Toolbar Icons Explained:
4.1 Toggle:
Use the toggle icon to switch between LIVE and Saved/Captured images.
4.2 Snapshot:
To capture an image from a Live video feed, click on the Snapshot icon. A still
image from the camera is captured and displayed (basic toolbar functions will
“grey out” i.e. deactivate). To switch back to the Live video feed, use the
Toggle icon as explained above.
4.3 Auto Focus:
When this icon is highlighted in green, the OMNI 3 is in autofocus. Click the icon to
disable/enable autofocus. The icon will flash red as the camera makes a refocus.
Note: When AF is enabled measurements are not possible and measurement tools
deactivate; suitable for inspection only. If Autofocus on a sample cannot be achieved
on a surface the working height may not be set correctly, adjust working height to correct.
4.4 Spot Focus™:
When autofocus has been enabled an additional focus feature becomes active, Spot Focus.
The Spot Focus icon appears in place of the Rocker focus buttons, when clicked this
Intuitive feature allows the user to quickly focus on an area of interest by simply using
the mouse pointer.
4.5 Manual Rocker Focus:
Automatically and rapidly adjust the camera focus using the focus rocker icons to
inspect the area of interest on a sample part when in manual focus mode. Use the
Rocker focus up button to fine adjust focus and increase focal length, use the Rocker
focus down button to decrease focal length.
4.6 Overview:
The Overview function will move the zoom position to the lowest magnification for
an overview of the object being viewed. A crosshair is provided allowing the sample
and area of interest to be centred. When the Overview icon is clicked again, the
camera will return to the original zoom level.
*After Focus features have been used, Measurement Ready (Settings Section 4.7) may have to be set
to allow measurement and correct focus tracking.

OMNI 3 User Manual
17 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
5.00
A s h
For Reference: Real Time Lens Distortion Correction (RTLDC):
Lens Distortion is an inherent characteristic of vision systems, because of the curviture of a lens
images can display distortion around the edges at very low magnification. Lens Distortion can be
seen as a bend on the straight edge of the object at the very edge of the screen (Fig 8.). This effect is
not as visible at higher magnification levels (>10X). Lens Distortion Correction is now applied
automatically in the software, eliminating any distortion on objects that are viewed at lower
magnifications.
Fig. 9 below shows how Lens Distortion Correction has processed and removed the Pin Cushioning
effect
Fig. 8
Fig. 9
Distorted Image:
Undistorted image:

OMNI 3 User Manual
18 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
5.00
A s h
Section 4.7: Settings
4.7: a(i) Camera:
Fig. 10
Exposure: Switch between Auto & Manual exposure modes. In Auto Exposure mode,
the Gain and Iris settings are automatically adjusted, and the user can adjust
the image Brightness if required. In Manual Exposure mode the user can
adjust both the gain and the iris settings of the camera. Higher gain values
will increase noise on the image. Lower iris value will reduce the amount of
light entering the camera but will improve focus depth.
Auto Exposure: Auto Exposure can be set to Normal or Minimise Noise setting. Camera
settings are adjusted when Minimise Noise is selected, and this may improve
an inspection scenario. (Please Note: When Auto Exposure is enabled, Gain, Iris and
Shutter adjustments are disabled and automatically adjusted. The values for these disabled
settings are not relevant when auto exposure is set as active).
White Balance: White balance can be carried out to colour balance the camera (also
possible via camera front panel if panel is enabled)
*N.B. Measurements are only valid if the Focus Measurement Ready icon shows
.
If the focus settings are not valid for measurement, then click on the icon
to Measurement Ready mode.
to set the focus

OMNI 3 User Manual
19 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
5.00
A s h
Focus: Switch between Auto & Manual Focus modes and set Measurement Ready
focus (Infinity Focus). In Manual mode the focal point can be adjusted and
set by the user.
Lighting Control: Select which ring light LED quadrant to turn on/off. Set the intensity value of
the LEDs and toggle all the LEDs ON/OFF. The OMNI 3 will auto-detect the
type of ring light that is connected.
* Note: when the OMNI 3 Diffused Dome light is connected, the quadrant buttons are disabled.
4.7: a(ii) Advanced Camera Settings:
When the Show Advanced Camera Settings button is clicked some additional camera settings can be
accessed (Fig. 11).
Fig. 11
Sharp:
Sharp or sharpness control is a function which adjusts the edge enhancement of objects. There are
15 levels of adjustment, a low value will produce a softer image vs a high value will produce a
sharper image.
Cont:
Cont or Contrast allows the user to adjust the contrast of an image. The contrast level range can be
adjusted from 1 to 64.
Please Note: A higher contrast value coupled with a high sharpness value can introduce noise into an image.
Shutter:
When Auto Exposure is deselected the shutter speed can be adjusted. Increasing the value speeds
up the shutter allowing less light to travel to the camera sensor, decreasing does the reverse.

OMNI 3 User Manual
20 | P a g e
OMNI 3 English Rev 5.00B SW Rev 5.00
5.00
A s h
Colour:
The camera colour can be adjusted to enhance the vibrancy of colours making use of the AshTru
Colour™algorithm.
Mirror and Flip:
The camera image can be mirrored or flipped to suit the needs of an application or the orientation of
the camera head.
*Any changes that wish to be applied can be saved via Settings>System>Save Startup Settings or can
be saved for a specific inspection or measurement by saving as a .ash measurement file. These
specific camera settings will reload when the file is reopened.
4.7 b. System Settings:
Fig. 12
Lens Diopter: Choose a lens from the drop-down list to correspond with the lens
that is fitted to the OMNI 3.
Screen Size: Enter the correct screen size to correctly display the magnification.
Default Save Mode: Set the default file type to save as an image file or as a
measurement Ash files.
System Language: Select your preferred system language.
Scale Bar Colour: Change the on-screen scale bar colour if required.
Show Preset Toolbar: Enable if using defined presets (see presets Section 6).
Show Scale Bar: Enable to show on-screen dynamic scale bar.
