Ashly MQX-1310 Quick start guide

MQX-1310
The graphic equalizer shall be monaural (1 channel).
It shall consist of 31 bands centered on standard ISO
frequencies at intervals of 1/3 octave and covering a
frequency range of 20Hz to 20kHz. Individual bands
shall be activated by linear slide faders with a 25mm
travel , and a tactile center detent. The range of equal-
ization per band shall be either ±6dB or ±15dB selected
via a 2-position switch. The equalizer shall have a gain
of unity with all sliders centered, and shall have a maxi-
mum in/out level of +23dBu. Frequency response shall
be ±.25dB 20Hz to 20kHz. Hum and noise shall be at
least -92dBu and SMPTE intermodulation distortion or
THD shall be less than .01% at full output. Input
impedance shall be 20k balanced, 10k ohm unbal-
anced. Output impedance shall be 200 ohm balanced,
100 ohm unbalanced. Inputs and outputs shall be
active (tranformerless) balanced type on both XLR, 1/4
phone jacks and barrier strip terminals. Individual fil-
ters shall be Wein-bridge type and connected in a sum-
ming circuit optimized for minimum filter interaction
and constant bandwidth at any slider setting. Boost and
cut characteristics shall be fully symmetrical, with the
filter being electrically removed from the circuit in the
center (flat) position. Individual filters shall be accurate
to within 3% of indicated center frequency and shall be
non-adjust-able to insure long term accuracy.
The equalizer shall also include an 18dB per octave
high pass filter at 40Hz, equipped with a bypass switch.
Green signal presence and red clip indicators shall show
critical operating levels. Input gain shall be adjustable
over -infinity to +6dB, and an overall EQ bypass
switch shall be included. The equalizer shall weigh 6.5
lbs net and mount in a standard 19 rack using 1 space
(1.75 high). The power requirement shall be 90-
125VAC, 50-60Hz, 10W. The unit shall be an Ashly
Audio MQX-1310.
TECHNICAL NOTES & SPECIFICATIONS
ARCHITECTS SPECIFICATIONS
MQX-1310 Miniature 31-Band Graphic Equalizer
Features:
 Constant "Q" design for low
ripple and minimum interac-
tion
Precision Wein Bridge Filters
Balanced XLR, 1/4 TRS & Barrier
Strip Screw Terminals on Inputs and
Outputs
Selectable 15dB or 6dB Range
Switchable 18dB/Octave High
Pass Filter
Low Noise Design
Silent In/Out Switching
Signal Present and Clip LEDs
25mm Fader with Center-Off
Position
5-Year Worry-Free Warranty

Ashly Audio Inc., 847 Holt Road, Webster, NY 14580-9103, Toll Free [phone], Telephone [phone], FAX [phone]
Internet: http://www.ashly.com, email: [email protected]
Ashly manufactures a complete and comprehensive line of Graphic and Parametric Equalizers,
Electronic Crossovers, Power Amplifiers, Compressor-Limiters, Mixers, and
Amplifier Input Options. Please call, write or visit our web site for information on any of these Ashly Products.
Applications:
Churches, Studios, Concerts, Dance/Night Clubs, PA Systems, Auditoriums, Lecture Halls, Sports Stadiums, Outdoor Festivals
General Specifications MQX-1310
INPUT TYPE: Active Balanced
INPUT IMPEDANCE: 20K ohm Balanced, 10k ohm
Unbalanced
MAX. INPUT LEVEL: +23dBu
OUTPUT TYPE: Pseudo-Balanced*
OUTPUT IMPEDANCE: 200 ohm Balanced, 100 ohm
Unbalanced
MAX. OUTPUT LEVEL: +23dBu
CONNECTORS: 1/4 Phone jack, XLR and Barrier
Strip
FREQUENCY RESPONSE: ± .25dB
TOTAL HARMONIC DISTORTION: < 0.01% @ +20dBu
IM DISTORTION (SMPTE): < 0.01% @ +20dBu
OUTPUT HUM AND NOISE: < -92dBu (20Hz - 20kHz unweighted)
CROSSTALK: NA
FILTER TYPE: Constant Q/Wein Bridge
BANDWIDTH: 1/3 octave
TOLERANCE: ±3%
RANGE: ±6 or ±15 dB
SUBSONIC FILTER: 18dB/octave @ 40Hz, switchable
POWER REQUIREMENTS:
Nominal Voltage: 90-125VAC, 50-60Hz,
(240VAC available)
Minimum Voltage: 90VAC
Power: 10W
SHIPPING WEIGHT: 8 lbs
DIMENSIONS: 19L x 1.75H x 6D
Rear Panel MQX-1310
*Pseudo-balanced output is single ended signal with balanced impedance
