The ASK Proxima C500 digital projector offers 5000 lumens, XGA
resolution, and simplied installation and integration. Interchangeable
lenses and horizontal/vertical lens shift power large venue images
measured in feet, not inches. The administrator-friendly C500 offers a
networked diagnostic & control utility to monitor & alert users of projector
status and function control. Connectivity includes: BNC style computer and
component video connectors, HDMI 1.3 for digital computer and video, RJ-
45 for network utilities, RS232 for remote commands, USB for presentation
control and wireless-compatible with InFocus’ LiteShow II wireless adapter.
The new assignable audio inputs (4) make for ultimate control in audio
pairing with visual content from any source.
Standout power & features
C500
Easy Lamp Door
A ceiling-accessible lamp door allows for lamp removal and lens
adjustments without removing the projector.

C500
©2008 ASK Proxima. All rights reserved. Specications are subject to change without further notice. InFocus and
ASK Proxima are either trademarks or registered trademarks of InFocus Corporation in the United States and other
countries. DLP, the DLP logo, and the DLP medallion are trademarks of Texas Instruments. All trademarks are used with
permission or are for identication purposes only and are the property of their respective companies.
0820_C500.
www.askproxima.com
InFocus Corporate Headquarters: 27500 SW Parkway Avenue
Wilsonville, Oregon 97070-9215, USA • Phone: [phone]
(1) 800-294-6400 • Fax: [phone]
In Europe: InFocus International BV • Louis Armstrongweg 110 • 1311 RL Almere
The Netherlands • Fax: [phone]
Freephone: 008000 4636287 (008000 INFOCUS)
In Asia: 19 Tanglin Road • 7th Floor
Singapore 247909 • Telephone: [phone] • Fax: [phone]
Native Resolution C500 - XGA 1024 x 768
Display Technology C500 - 0.8”P.Si TFT LCD x 3 MLA (Micro Lens Array)
Input Sources VGA (Component to VGA adapter available)
HDMI (w/audio)
5 BNC (RGBHV/YPbPr)
Component
S-Video
Composite Video2 – 3.5 mm Stereo jacks
2 – RCA Stereo Jacks
Output Sources Monitor Out
Audio Out
Max Resolution UXGA
Control Projector keypad, IR remote control, USB, RS232, RJ45
Computer Compatibility PC, Macintosh
Video Compatibility SDTV (NTSC, PAL, SECAM, 480i, 576i), ED/HDTV (480p, 576p,
720p,1080i,1080p)
Brightness C500 - 5000 max ANSI Lumens,
Contrast Ratio 1000:1
Number of Colors 16.7 million
Projection distance 3.75’to 43.75’ standard lens (1.1m -13.3m)
H-Synch Range 15-91 kHz
V-Synch Range 50-120 Hz
Dot Clock 13.5 MHz to 140 MHz
Standard Projection Lens Manual Focus and Zoom.Four Optional lenses available.
Zoom: 1.2:1
Throw Ratio: 1.5-1.8:1 (dstance/image width)
F No.: 1.74-2.06
Minimum Distance: 3.75 ft / 1.14m
Digital Keystone Correction Vertical +/-40° , Horizontal +/-20°
Lens Shift Vertical 9:1 to 1:1 offset,Horizontal 6:4-4:6
Aspect Ratio 4:3 Native.Will resize 5:4,16:9,16:10
Image Size (diagonal) 2.5’- 29.2’/ 0.76m - 8.9m
Projection Methods Front, ceiling, rear, rear ceiling
Audio 2 x 4W Stereo
Product Dimensions 5.11”H x 16.53”W x 12.4”D (12.9cm H x 42cm W x 31.4cm D)
Product Weight 15.7lbs / 7.1kg
Product Color Black with Silver
Power Supply 100-240 Volts at 50-60 Hz
Lamp Life 2000 hrs high power; 3000 hrs eco
Lamp Power UHB - Normal 275W Low Power 220W
Operating Temperature 10-35ºC at sea level to 7500’(2286 m), 50-95ºF
Ships with RGB Cable,Remote Control,
Safety Instruction, Power Cable AV cable User Manual
Menu Languages English, German, French, Italian, Spanish, Swedish, Dutch, Finnish,
Danish,Turkish, Portuguese, Russian, Chinese, Korean
Audible Noise 32 dBA normal (30 dBA eco mode)
Approvals UL and c-UL (US/Canada), FCC (US/Canada), CE (CE member
countries), GOST (Russia), TUV GS (Germany), CCC (China), IRAM
(Argentina), NOM (Mexico), PSB (Singapore), RoHS
SPECIFICATIONS
* Product specications, terms, and offerings are subject to change at any time without notice.
** Actual lamp life may vary based on the ambient environment and projector usage. Conditions that may
affect lamp life include temperature, altitude, and rapidly switching the projector on and off.
OPTIONAL LENSES
Short Throw Projection Lens (LENS-038)
Zoom Ratio
Throw Ratio
F No.
Fixed Short Throw Projection Lens (LENS-037)
Zoom Ratio
Throw Ratio
F No.
Long Throw Projection Lens (LENS-039)
Zoom Ratio
Throw Ratio
F No.
Ultra Long Throw Projection Lens (LENS-040)
Zoom Ratio
Throw Ratio
F No.
Throw Ratio
1.6:1
1.2-2.0:1
1.94-2.55
1.0:1
0.8:1
2.3
1.2:1
1.9-3.9:1
2.10-2.92
1.85:1
3 .9 -7. 4 :1
2.24-3.10
1.7:1-2.1:1
WARRANTY
Providing the highest quality products and support is very important to
InFocus. Just one reason why the C500 digital projector comes standard
with a 2-year limited factory warranty (including parts and labor) and a
6 month limited lamp-replacement warranty. Extended product & lamp
warranty programs are also available. For more information about warranty
and service programs in your region, please visit:
www.infocus.com/service
OPTIONAL LENSES
Projection Screens (4:3, 16:10 & 16:9)
LiteShow II Wireless Adapter
Cables & Adaptors
Ceiling Mount (SP-CEIL-UNIV)
Security Lock (SEC-LOCK-01)
Replacement Lamp (SP-LAMP-038)
