> > > > > > > Mobile Performance
Have it all
ASK Proxima has steamrolled the mobile projector power/portability argument
pancake at. The ASK Proxima M9 slim projector is revealed as a fusion of
conference-room performance in an ultra mobile body. Sharply brandishing
2500 lumens and an 1800:1 contrast ratio, the M9 is contained in a
mysteriously slim, briefcase-friendly design. This brilliance and contrast is
perfect for mobile professionals who deal with new presentation spaces where
ambient light may not be controlled, as the M9 will shine through in amazing
clarity. At its core, the M9 incorporates DLP® technology with XGA native
resolution, which promotes breathtakingly clear images and optical longevity
without any lters to clean – ever.
It’s your turn
The M9 is certainly one of the easiest projectors to use right out of the box.
It has a completely automatic image setup which perfectly sets the optimal
focus, keystone, and input source. Once your image is squared-up, zoom
control can be managed from the remote with an immensely exible 2.0x
magnication. The 2x zoom allows for larger images in smaller rooms, and
properly sized images in huge conference spaces. The back panel of the
M9 exposes digital and analog inputs, promoting connectivity to all of your
presentation material no matter where your travels take you.
Motorized zoom & automatic image
setup makes for worry-free projection.
The ultra-slim 1.69”h prole is amazingly
portable, especially in your briefcase.
M9
• 2500 max ANSI lumens will illuminate your presentations in any room,
no matter how well-lit.
• Motorized internal micro-adjust zoom & focus allow for the nest image alignment.
• Wireless-ready with the InFocus LiteShow II Wireless Adaptor.
• D -Sub-15 VGA interface and composite video inputs make for easy connectivity.
• DLP® XGA display chipset provides brilliant, reliable images.
• Full-featured remote control with unique DLP “laser pointer” feature.
Packed with advanced features

M9
OPTIONAL ACCESSORIES
Projection Screens
High Performance Digital Cables
Cable Adapters
Briefcase and Rollercase
Security Lock
Replacement & Accessory Lamps
SERIOUS COMMITMENT
ASK Proxima’s dedication to quality and customer satisfaction
is reected in service options that will bring you a greater
return on your investment. ASK Proxima projectors come with
a standard two-year limited factory warranty, including parts
and labor, a 90-day or one-year accessory warranty, and a ve-
month lamp replacement warranty. Our customer support offers
you premium service and convenience, whatever your needs.
For service program details in your region, please visit:
www.infocus.com/service/service_offerings
©2007 ASK Proxima. All rights reserved. Specications are subject to change without further notice. InFocus and
ASK Proxima are either trademarks or registered trademarks of InFocus Corporation in the United States and other
countries. DLP, the DLP logo, and the DLP medallion are trademarks of Texas Instruments. All trademarks are used with
permission or are for identication purposes only and are the property of their respective companies.
Month/06 PART NUMBER: 825-0156-00.
www.askproxima.com
InFocus Corporate Headquarters: 27500 SW Parkway Avenue
Wilsonville, Oregon 97070-9215, USA • Phone: [phone]
(1) 800-294-6400 • Fax: [phone]
In Europe: InFocus International BV • Louis Armstrongweg 110 • 1311 RL Almere
The Netherlands • Phone: [phone] • Fax: [phone]
Freephone: 008000 4636287 (008000 INFOCUS)
In Asia: 19 Tanglin Road • 7th Floor
Singapore 247909 • Telephone: [phone] • Fax: [phone]
TECHNICAL SPECIFICATIONS*
Native Resolution XGA (1024 x 768)**
Display Technology 0.55" DLP DMD
Input Sources VGA; Component Video with VGA adapter; Composite Video
Output Sources N/A
Computer Compatibility VGA, SVGA, XGA, SXGA***
Video Compatibility NTSC-M/NTSC-4.43;PAL-60/PAL-M/PAL-N/PAL-B/PAL-D/PAL-G/PAL-H/PAL-I
Brightness 2500 ANSI lumens (2000 in eco mode)
Contrast Ratio 1800:1
Number of Colors 16.7 million
Brightness Uniformity N/A
H-Synch Range 31 – 69 KHz
V-Synch Range 60 – 85 Hz
Digital Keystone Correction +/- 30 degrees vertical correction
Standard Projection Lens Zoom lens with motorized focus and motorized zoom adjustment
Zoom Ratio 2.0:1 (distance/image /width)
Throw Ratio 1.7:1 - 2.4:1
Minimum Projection Distance 2.8 feet /0.84 meter
Lens Shift N/A
Aspect Ratio 4:3
Image Size (diagonal) 15” – 300”
Projection Methods Front, rear
Audio N/A
Control Projector keypad; IR remote control
Lamp 210w high pressure mercury; 2000 hr lamp life****
Product Dimensions 1.7” x 10.6” x 7.8” / 4.3cm x 26.9cm x 19.9cm
Product Weight 3.9 lbs / 1.8 kg
Product Color Black
Shipping Weight 8.8 lbs / 4 kg
Shipping Dimensions 14.75" x 11.25" x 7" / 3.75 x 28.5 x 17.5 cm
Power Consumption Normal: 270W; Eco: 210 W
Power Supply AC100 to 240V; 50/60Hz
Operating Temperature 0 degrees C – 40 degrees C (32 degrees F – 104 degrees F);
90% maximum humidity
Ships with Wireless remote; AC cord; RGB cable; User’s Guide; CD-ROM;
soft case and accessories pouch
Menu Languages English, German, Spanish, French, Italian, Swedish, Japanese,
Simple Chinese, Korean
Audible Noise 38dBA; eco: 34dBA
Approvals UL/cUL; GOST; CCC; Nemko/GS; NOM; C-tick;
FCC class A; CE; IRAM; MIC EK; (W120)
Security Kensingston lock
 *Allspecicationssubjecttochange
** Some resolutions may require Component/Vesa adapter
***Resolutionsupportmaybeproductspecic
****Actuallamplifemayvarybasedontheambientenvironment.Conditionsthatmayaffect
 lamplifeincludetemperature,altitude,ceiling-mountingwithSP-LAMP-029,andrapidly
 switchingtheprojectoronandoff.
