Asko Professional TDC145HPS User manual

Operating Instructions
Tumble dryer
ASKO Professional TDC145HPS
Dear Customer,
Thank you for choosing this quality product from ASKO. We hope it will
meet your expectations and fulfil your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
To get the most out of your new machine, we recommend that you read
the operating instructions before using the machine. The operating
instructions also include information on how you can help protect the
environment.
WARNING: Read the instructions before using the machine.

2
CONTENTS
BEFORE USING YOUR MACHINE FOR THE
FIRST TIME 3
Language selection 3
Laundry labels 3
SAFETY INSTRUCTIONS 4
General 4
Safety 5
Installation 5
Transport/winter storage 5
Packing material 5
Recycling 5
Child safety 6
Child-safe start 6
DESCRIPTION OF THE TUMBLE DRYER 7
ADVICE AND TIPS BEFORE YOU TUMBLE-
DRY 8
Have the clothes been spun? 8
Materials that can be tumble-dried 8
Materials that must not be tumble-dried 8
Static electricity 8
TUMBLE DRYING 9
Sort your fabrics 9
Select the programme 9
Drying programme finished 10
Programme chart 11
SETTINGS 12
You can carry out the following settings 12
How to choose the settings 12
Audible volume 12
Language 12
Child-safe 12
CARE AND CLEANING 13
Cleaning the lint filter 13
Emptying the condensed water container 14
Cleaning the evaporator filter and evaporator 14
Cleaning the outside of the machine 15
TROUBLESHOOTING 16
The machine will not start 16
The machine loses all power during a programme 16
The machine leaks water 16
Drying takes too long 16
Error messages 16
TECHNICAL INFORMATION 17
Information on energy labelling 17
Technical data 18
Standard tests 18
SERVICE 19
Before contacting the service division 19
INSTALLATION 20
Installation 20
Electrical installation 20
Connection on delivery 20
Coin operation 20
DOOR HANGING 21
QUICK GUIDE 24
Original instruction

3
BEFORE USING YOUR MACHINE FOR THE FIRST TIME
LANGUAGE SELECTION
You will be prompted to select the display language when
you have connected your machine and start it for the first
time. Do as follows:
1. Turn the programme selector to choose from: US
English, English, Svenska, Dansk, Norsk, Suomi,
Français, Deutsch, Italiano, Espanol, Русский,
Nederlands.
2. Press Stop to save the setting.
LAUNDRY LABELS
Certain materials are not suitable for tumble drying.
Always check and follow the instructions on each item’s
laundry label.You can find more information in the Advice
and tips before you tumble-dry chapter.
NOTE!
When starting the tumble dryer for the first time or
after a long period without use, you may notice a slight
thumping noise.This noise is completely normal and
will disappear after a few loads.

4
GENERAL
Read the operating
instructions and keep them in
a safe place!
• The machine may be used in public
areas.
• Electrical installation, if required,
should be carried out by a qualified
electrician.
• The machine should only be used for
tumble-drying as described in these
instructions.
• Repairs and maintenance relating
to safety or performance must be
carried out by a qualified professional.
• Damaged mains cables must only be
replaced by a qualified electrician.
• Sufficient ventilation is required to
prevent smoke from open fires or
fumes from equipment burning other
fuels being sucked into the room
when the tumble dryer is running.
• Do not dry dirty laundry in the tumble
dryer.
• Items that are stained with e.g.
cooking oil, acetone, alcohol, petrol,
kerosene, stain remover, turpentine,
wax and wax remover should be
washed in hot water with extra
detergent before they go in the
tumbler dryer.
• Items such as foam rubber, latex,
plastic, waterproof textiles, rubber-
coated items and clothes and foam-
rubber filled cushions must not be
dried in the tumbler dryer.
• Fabric softener or similar products
should be used as per the
recommendations of the detergent
manufacturer.
• This machine can be used by children
aged 8 and upwards, and by people
with reduced physical capacity,
mental ability, memory loss or lacking
experience and knowledge. These
individuals must be supervised
when using the machine or have
instructions on how to use the
machine and understand the risks
that can occur.
• Children must be watched to ensure
they do not play with the machine.
• Children under 3 years should be kept
away from the machine unless they
are not constantly supervised at all
times.
• Remove all objects such as lighters
and matches.
SAFETY INSTRUCTIONS

5
SAFETY INSTRUCTIONS
SAFETY
• The machine must not be used for
drying items that have been dry-
cleaned at home or fabrics that may
contain residues of flammable liquids.
• The tumble dryer is not to be used if
industrial chemicals have been used
for cleaning
• A float shuts offthe machine in the
event of a blockage in the condensed
water hose or if there is a risk of
the condensed water container
overflowing.
• The last part of the dryer cycle occurs
without heat (cool down cycle) to
ensure that the objects are in a
temperature that ensures that items
are not damaged.
WARNING!
When the tumble dryer is operating,
the back of the tumble dryer will get
very hot. Leave the machine to cool
completely before touching the back.
WARNING!
Never stop the machine before the
drying cycle end unless all items are
quickly removed from the machine
and spread out so that the heat is led
away.
INSTALLATION
See the separate installation
instructions.
WARNING!
Do not start the machine until it has
been in position for 24 hours. If for
some reason the tumble dryer needs
to be laid down for transport or
service, it must be laid on its left side
viewed from the front.
TRANSPORT/WINTER STORAGE
If you need to move your machine or
store it over the winter in unheated
premises, make sure that you drain the
condensed water container beforehand.
PACKING MATERIAL
Please sort waste materials in
accordance with local guidelines.
RECYCLING
This machine is manufactured and
labelled for recycling. In order to prevent
personal injury, the machine must be
made inoperable after deciding to take
it out of service. Contact your local
authority for information about where
and how your machine should be
correctly recycled.

6
SAFETY INSTRUCTIONS
CHILD SAFETY
WARNING!
DO NOT ALLOW CHILDREN TO PLAY
WITH THE TUMBLE DRYER.
• If the door is opened when a
programme is running the garments
may be very hot, with a risk of burn
injuries.
• The tumble dryer does not start
automatically when the door is
closed (if a child pulls the door shut
from the inside, for example).
CHILD-SAFE START
By activating the child-safe start
function you can prevent children from
starting the tumble dryer or changing
the current programme.
See the Settings chapter.
ACTIVATING/DEACTIVATING CHILD-
SAFE START.
Do as follows to open the settings
menu:
1. Turn offthe machine using the main
power switch.
2. Press the Stop button and switch
on the machine with the main power
switch. Then press the Stop button 5
times within 10 seconds.
3. Select the setting you want to change
by turning the programme selector.
4. Press the Stop button once.
5. Change and save the setting as
described below.
6. Press the Start button to return to the
programme menu.
You can activate the Child-safe start
option to prevent children from starting
the machine.
1. Turn the programme selector and
choose Child-safe On or Child-safe
Off.
2. Press the Stop button once to save
the setting.
You can temporarily deactivate Child-
safe start by pressing the Start and
Stop buttons at the same time. Child-
safe start will be deactivated for 3
minutes.

7
DESCRIPTION OF THE TUMBLE DRYER
1. Main power switch
2. Condensed water container
3. Panel
4. Type plate
5. Lint filter
6. Outer door
7. Heat pump and filter
1
7
23 4 56

8
ADVICE AND TIPS BEFORE YOU TUMBLE-DRY
Here are some tips that may help you before you begin
tumble-drying.
HAVE THE CLOTHES BEEN SPUN?
Items to be tumble-dried should be spun at 1000 rpm
or faster. Higher spin speeds save energy and reduce
drying time.
MATERIALS THAT CAN BE TUMBLE-
DRIED
This symbol means that the material is suitable for
tumble-drying. Fabrics best suited to tumble-drying are
cotton fabrics, terry cloth and synthetic fibres. Garments
will be softer and lighter when tumbled than when hung
out to dry.
NOTE!
The tumble dryer does not cause any significant wear
on fabrics. The lint that collects in the lint filter consists of
dust and fibre residues formed when the items are used.
MATERIALS THAT MUST NOT BE
TUMBLE-DRIED
This symbol means that the material is not suitable
for tumble-drying. Certain materials may melt or become
a fire hazard if exposed to heat, and others can lose their
shape or shrink.
And do not tumble-dry:
• materials labelled ”Do not dry near heat”.
• garments that have been dry-cleaned at home.
• plastic foam.
• fibre glass material.
• wool must not be tumble-dried because of the risk of
felting.
STATIC ELECTRICITY
To reduce the risk of static electricity in the laundry after
tumble drying you can:
• Use fabric softener when washing.
• Wait five minutes after the drying program ends before
opening the door and removing the laundry from the
dryer.
NOTE!
You can stop the tumble dryer by pressing the Stop
button for three seconds or by opening the door. In both
cases the programme is stopped and starts from the
beginning if restarted. If you do not want to restart the
programme then immediately remove all laundry and
spread it out to allow the heat to dissipate.

9
TUMBLE DRYING
Below are step-by-step instructions to help you achieve
the best possible tumble-drying results.
SORT YOUR FABRICS
You will achieve the most uniform drying results if the
items are made of the same type of material. Do up zips
and buttons, fasten belts, sort the items and adjust the
load and temperature.
NOTE!
Do not overload the drum!
Overloading the dryer will result in poor drying results
and wrinkling.
Guidelines as to what specific programmes can be
used for:
The Auto extra dry, Auto dry and Auto normal dry
programmes have two temperature settings.
Normal temperature but also low temperature for more
delicate items.
Auto extra dry
Temperature normal. This programme is for items that
are particularly difficult to dry, such as jeans with very
thick seams.
Auto dry
Temperature normal. This programme shut offthe heat
once the load is dry but before it is bone dry. The Auto
dry programme shuts offthe heat slightly later than
Auto normal dry . Use trial and error to find out what
works best.
Auto normal dry
Temperature normal. This programme shut offthe heat
once the load is dry.
Auto extra dry (low temperature)
This programme is for items that are particularly difficult
to dry, such as jeans with very thick seams.
Auto dry (low temperature)
These programmes shut offthe heat once the load is dry
but before it is bone dry. The Auto dry programme shuts
offthe heat slightly later than Auto normal dry. Use trial
and error to find out what works best.
Auto normal dry (low temperature)
These programmes shut offthe heat once the load is dry
but before it is bone dry. The Auto dry programme shuts
offthe heat slightly later than Auto normal dry. Use trial
and error to find out what works best.
Auto iron dry (low temperature)
This programme shuts offthe heat once the load is just
damp enough for ironing or pressing.
Select a programme by turning the programme selector. The selected programme is shown in the display window.
Programme selector Display window
Main power switch Start Stopp
SELECT THE PROGRAMME
Press the main power switch until the display lights. Open
the door, load the items and then close the door.
NOTE!
Make sure that objects e.g. detergent dispensing balls,
have been removed from the laundry. They could melt
and cause damage to the dryer or the laundry.
NOTE!
To save energy, always observe the maximum load for
each programme (see Program chart)

10
TUMBLE DRYING
PRESS THE START BUTTON.
An estimate of the remaining drying time will be shown
on the display a few minutes after the drying programme
starts. For example, 1:35 means that it will take
approximately 1 hour and 35 minutes for the load to dry.
If the option.Anti crease has been selected, the drum will
rotate for three seconds per minute for two hours after
the programme is finished. The actual remaining time
may be longer than the estimated time shown on the
display. The remaining time is then shown as 0:15 until
the load is sufficiently dry. If you selected Time Saver the
display will show 0:05 instead. You can stop the tumble
dryer by pressing the Stop button for three seconds or
by opening the door. In both cases the programme is
stopped and starts from the beginning if restarted.
NOTE!
The programme will not be affected if you change the
programme selector after the programme has started.
DRYING PROGRAMME FINISHED
The text Done appears on the display when the
programme is finished. If the Anti crease option has
been selected, the drum will rotate for three seconds per
minute for two hours after the programme is finished.
The compressor’s cooling fan continues to run after the
programme finishes, but stops automatically or when
any button/knob is activated.
Backlighting
Two minutes after the drying programme finishes the
backlighting on the display and options buttons enters
energy saving mode. Turn the programme selector if you
want to activate the machine.
Condensed water
The condensed water container must be emptied after
each load. Remove the condensed water container,
empty out the water and replace the container. If the
condensed water container becomes full to overflowing,
the programme is interrupted and Over Flow appears
on the display. Empty the container and press the Start
button to start a new programme.
TIP!
The condensed water is decalcified and can be used in
steam irons. Pour it through a coffee filter.
Automatic emptying
For connection to a separate drain, see the installation
instructions in the set of documents.
TIP!
Clean the lint filter in the outer door after each load.
See the Care and cleaning chapter.
WARNING!
If the lint filter becomes clogged, the machine’s
automatic overheating cut-out may be triggered.
Clean the filter, wait until the machine has cooled
then try starting it. If it still does not start: Call the
service division.
Once drying has finished
Turn offthe main power switch. Remove the clothes and
close the door to prevent small children from climbing
into the machine.

11
TUMBLE DRYING
PROGRAMME CHART
Here we present the energy and time consumption of a few different programmes. The table shows the effect of using
different spin speeds when washing the load. Consumption can vary depending on room temperature, humidity, load,
variations in the power supply and selected options.
For the consumption values given below, the requirements are as follows:
Temperature of intake air: 23 °C
Moisture content of intake air: 55%
Drying temperature: Normal
Programme Material Load Spin speed
(rpm)
Energy
consumption,
approx. (kWh)
Programme time,
approx. (min)
Auto extra dry Cotton, linen 1/1 800 2,0 200
1000 1,9 190
1200 1,7 170
1400 1,6 160
Auto Dry Cotton, linen 1/1 800 1,9 195
1000 1,8 185
1200 1,6 165
1400 1,5 150
Crease-resistant,
polyester/cotton
1/2 1000 0,7 85
Auto Normal Dry Cotton, linen 1/1 800 1,7 180
1000 1,6 170
1200 1,4 150
1400 1,3 140
Cotton, linen 1/2 1000 0,9 103
Crease-resistant,
polyester/cotton
1/2 1000 0,6 70
Auto Iron Dry Cotton, linen 1/1 800 1,3 135
1000 1,2 125
1200 1,1 115
1400 0,9 90

12
SETTINGS
YOU CAN CARRY OUT THE FOLLOWING
SETTINGS
• Language
• Child-safe
• Audible Volume
HOW TO CHOOSE THE SETTINGS
Do as follows to open the settings menu:
1. Turn offthe machine using the main power switch.
2. Press the Stop button and switch on the machine with
the main power switch. Then press the Stop button 5
times within 10 seconds.
3. Select the setting you want to change by turning the
programme selector.
4. Press the Stop button once.
5. Change and save the setting as described below.
6. Press the Start button to return to the programme
menu.
AUDIBLE VOLUME
1. Turn the programme selector and choose Buzzer On
or Buzzer Offto set whether the tumble dryer should
audibly indicate that the programme is finished or that
an error has occurred.
2. Press the Stop button once to save the setting.
LANGUAGE
You will be prompted to select the display language
when you have connected your machine and start it for
the first time.
Do as follows:
1. Turn the programme selector and choose from: US
English, EU English, Svenska, Dansk, Norsk, Suomi,
Français, Deutsch, Italiano, Espanol, Русский,
Nederlands.
2. Press the Stop button once to save the setting.
CHILD-SAFE
You can activate the Child-safe start option to prevent
children from starting the machine.
1. Turn the programme selector and choose ”Child-safe
start on” or ”Child-safe start off”.
2. Press the Stop button once to save the setting.
You can temporarily deactivate Child-safe start by
pressing the Start and Stop buttons at the same time.
Child-safe start will be deactivated for 3 minutes.

13
CARE AND CLEANING
CLEANING THE LINT FILTER
The lint filter must be cleaned after each load.
1. Grasp the filter holder handle and pull it towards you
to open the lint filter.
2. Open the lint filter. Use your thumb to press on the
edge as illustrated and pull it out.
3. Use your hand or a soft cloth to remove the lint from
all sides of the filter. If necessary, use a damp sponge
and a small amount of washing-up liquid to remove
any deposits. Dry the filter thoroughly with a towel.
NOTE!
Clean the surface of the lint (fluf) filter after each drying
program.
4. To close the lint filter, follow the reverse order of steps
used for opening.Then, replace the filter by sliding it
back into the door. Close the lint filter before closing
the door.

14
CARE AND CLEANING
EMPTYING THE CONDENSED WATER
CONTAINER
If you have not connected the machine to a separate
drain the condensed water container must be emptied
after each load. Remove the condensed water container,
empty out the water and replace the container.
If the condensed water container becomes full to
overflowing, the programme is interrupted and “Over
Flow” appears on the display. Empty the container and
press the Start button to restart the programme.
For connection to a separate drain, see the installation
instructions in the set of documents.
NOTE!
Empty the condensate tank after each drying cycle.
NOTE!
The dryer must not be used without the condenser unit
in place.
CLEANING THE EVAPORATOR FILTER
AND EVAPORATOR
Clean the evaporator and the evaporator filter at the
intervals shown on the machine’s display or more often.
1. Turn offthe Main power switch and open the outer
door.
2. Remove the plinth.
3. Open the heat pump door (on some models is
necessary to use socket wrench).
4. Pull out the filter by lightly pressing the filter support
downwards.
5. Remove the sponge filter (B) from the filter support
(A). Clean it with a vacuum cleaner and wash it under
running water.

15
CARE AND CLEANING
A
B
RECOMMENDATION!
Wash the sponge filter in the washing machine after 30
drying cycles (use the rinse or quick wash program).
6. Clean the heat pump ribs by spraying water on them
(use a plant sprayer). The water will carry away the
lint and the condensate pump will drain the lint and
water mixture.
7. Replace the clean sponge filter into the filter support.
To replace the support, first insert the bottom edge of
the support under an angle, and then lightly press it
towards the heat pump ribs to align it. Close the heat
pump door.
NOTE!
Do not touch the heat pump ribs.They are very thin
an easily damaged. If the ribs are bent or damaged,
the efficiency of the condenser unit will deteriorate
considerably, which in turn leads to poorer drying results.
CLEANING THE AUTO FILTER
Clean the filter at the intervals shown on the machine’s
display or more often
1. Pull the condensed water container out and up.
2. Unscrew and remove the auto filter.
Sealing
3. Rinse the auto filter clean with water.
4. Screw the autofilter back into place. Check that the
seal is properly seated.
NOTE!
Clean the filters after each drying.
Do not replace the filters if they are damp or wet. Damp
or wet filters could cause operational faults.
NOTE!
The dryer should never be operated without the filters
in place, or with damaged filters as excessive amount
of accumulated fibres from the fabric could cause
malfunction or failure of the dryer.
CLEANING THE OUTSIDE OF THE
MACHINE
Clean the outside of the machine and the programme
panel with a mild cleaner. Do not use solvents, as these
can damage the machine. Do not hose down or spray the
machine with water.
NOTE!
Do not allow dust to accumulate around the machine.
Keep the area around the tumble dryer clean and cool;
dust, heat and moisture prolong drying times.

16
TROUBLESHOOTING
NOTE!
When starting the tumble dryer for the first time or
after a long period without use, you may notice a slight
thumping noise.This noise is completely normal and
will disappear after a few loads.
THE MACHINE WILL NOT START
Check
• that the door is properly closed.
• that the main power switch is on.
• that the plug is connected.
• that the main fuses have not blown.
THE MACHINE LOSES ALL POWER
DURING A PROGRAMME
Contact the service division.
THE MACHINE LEAKS WATER
Check that the autofilter and its seal are installed
correctly and not faulty.
DRYING TAKES TOO LONG
• Check that the lint filter is not blocked. See the Care
and cleaning chapter.
• Empty the condensed water container. Clean the
evaporator filter (net filter + foam filter), evaporator, lint
filter and autofilter, see chapter Care and cleaning.
ERROR MESSAGES
• If Over Flow appears on the display, the condensed
water container is full or the evaporator filter is
blocked. Empty the container, clean the filter and
restart the machine. See the Care and cleaning
chapter.
• Read Drying takes too long in this chapter if Max
program time appears on the display.
• If Clean Lint Filter appears on the display, clean the
lint filter.
• If Clean condenser appears on the display, clean the
evaporator. See the Care and cleaning chapter.
• If Clean auto filter appears on the display, clean the
auto filter. See the Care and cleaning chapter.
• Call the service division if Thermistor fault appears on
the display.
• Press the Stop button to close any error messages.

17
TECHNICAL INFORMATION
INFORMATION ON ENERGY LABELLING
Information sheet, in compliance with Commission Delegated Regulation (EU) No. 392/2012
ASKO
Model designation TDC145HPS
Max. drying capacity 8 kg
Energy efficiency class A++
Annual energy consumption (AEc) 194 (kWh/year)
1)
Energy consumption
Auto normal dry with full load (Edry) 1,57 (kWh)
Auto normal dry with half load (Edry1/2) 0,90 (kWh)
Power consumption
Off-mode (Po) 0,5 (W)
Left-on mode (Pl) 0,5 (W)
Condensation efficiency
Auto normal dry with full and half load (Ct) 84 (%)
Auto normal dry with full load (Ctdry) 84 (%)
Auto normal dry with half load (Ctdry1/2) 83 (%)
Drying programme Auto normal dry 2)
Programme time (minutes)
Auto normal dry with full and half load (Tt) 132 (minutes)
Auto normal dry with full load (Tdry) 170 (minutes)
Auto normal dry with half load (Tdry1/2) 103 (minutes)
Airborne acoustical sound 66 (dB(A))
Type of dryer (A=Automatic, NA=Non Automatic) A
Standby mode duration 2 (minutes)
Condensation efficiency class B 3)
1) Based on 160 standard drying cycles for Auto normal dry full and half load, and consumption in accordance with the low power modes.The actual
energy consumption will depend on how the machine is used.
2) The Auto normal dry is intended for drying of normally wet cotton laundry. It is the most efficient program for drying cotton laundry in terms of power
consumption.
3) On a scale from G (least efficient) to A (most efficient).

18
TECHNICAL INFORMATION
TECHNICAL DATA
Height: 850 mm
Width: 595 mm
Depth: 745 mm
Weight (net): 63 kg
Cylinder volume: 145 l
Max. drying capacity: 8 kg
Speed: 50-55 rpm
Sound pressure level: The sound pressure level is below 66 dB (A)
Rated power: See type plate.
Drum material: Stainless steel
Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel
Setup: Stacking or freestanding
STANDARD TESTS
For the standard test the machine's condensed water hose must be connected to a drain.
Europe:
Drying performance: EN 611 21 (392/2012/EU). Auto normal dry , 8 kg cotton
Energy declaration: EN 611 21 (392/2012/EU). Auto normal dry , 8 kg cotton
Test method for noise
measurement:
IEC 60 704-2-6
This product contains fluorinated greenhouse gases.
Type of refrigerant: R134a
Quantity of refrigerant: 0,48 kg
Total GWP: 1430
CO2equivalent: 0,686 t
Hermetically sealed.

19
SERVICE
BEFORE CONTACTING THE SERVICE
DIVISION
See the Troubleshooting and Care and cleaning chapters
to see whether you can rectify the problem. If you need to
contact the service division, make sure that you know the
model designation, type designation and serial number.
The model designation (1) can be found on the first page
of the operating instructions and on the machine panel.
The type designation (2) and serial number (3) can be
found on the type plate, which is found on the front of the
tumble dryer inside the outer door.
NOTE!
For repairs and maintenance, original spare parts must
be used.
1
TYPE
3
2
NOTE!
Repair or any warranty claim resulting from incorrect
connection or use of the dryer shall not be covered by
the warranty. In such cases, the costs of repair shall be
charged to the user.

20
WARNING!
Do not start the machine until it has been in position for
24 hours. If for some reason the tumble dryer needs to
be laid down for transport or service, it must be laid on
its left side viewed from the front.
INSTALLATION
See the separate installation instructions included in the
set of documents.
NOTE!
Do not install the machine in a room where there is a
risk of frost occurring. At temperatures around freezing
point the machine may not be able to operate properly.
The room in which the appliance is installed should be
adequately ventilated, with temperature between 15°C
and 25°C.
ELECTRICAL INSTALLATION
Connect the machine by plugging it into an earthed
wall socket. The electrical wall socket must be placed
outside of the installation area to be easily accessible.
CONNECTION ON DELIVERY
• 230V, 1-Phase, 10A
• 50Hz
• Use a type A residual-current device.
NOTE!
Do not connect the machine to the mains electricity
supply by an extension lead.
INSTALLATION
COIN OPERATION
The machine is prepared for coin operation. Such
installation must be carried out by a qualified professional.
The installation requires a connection cable to power the
coin meter. This connection cable can be ordered using
the factory art. no. 92 090 95.
The coin meter shall be able to short circuit two signal
lines for periods of up to 10 minutes. This is to give the
user time to load the machine, choose a programme and
start the programme after putting the coins in.
“Insert coin” appears on the display when the machine is
started with the main power switch.
