Asko BO4CS2T1-42 OCS8476S User manual

Dear customer!
Thank you for choosing this quality product from ASKO. We hope it will
meet your expectations and fulfil your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
Operating instructions
BO4CS2T1-42 OCS8476S

2
We thank you for your trust and the
purchase of our appliance.
This detailed instruction manual is supplied to make the
use of this product easier. The instructions should allow
you to learn about your new appliance as quickly as
possible.
Make sure you have received an undamaged appliance.
If you do find transport damage, please contact the
seller from which you purchased the appliance, or the
regional warehouse from which it was supplied. The
telephone number can be found on the invoice or on the
delivery note.
Instructions for installation and connection are supplied
on a separate sheet.
Instructions for use are also available at our website:
www.asko.com / < http://www.asko.com />
Important information
Tip, note

3
COMBINED STEAM OVEN 4
TECHNICAL SPECIFICATIONS 4
CONTROL UNIT 7
IMPORTANT SAFETY INSTRUCTIONS 8
BEFORE CONNECTING THE OVEN: 9
BEFORE USING THE APPLIANCE FOR
THE FIRST TIME 10
FILLING THE WATER TANK 11
STEPS OF THE COOKING
PROCESS (1–6) 12
STEP 1: SWITCHING ON THE APPLIANCE
FOR THE FIRST TIME 12
STEP 2: CHOOSING THE BASIC COOKING
MENUS AND SETTINGS 14
STEP 3: STARTING THE COOKING PROCESS 24
STEP 4: END OF COOKING AND SWITCHING
OFF THE OVEN 24
STEP 5: SELECTING ADDITIONAL
FUNCTIONS/EXTRAS 25
STEP 6: CHOOSING THE GENERAL
SETTINGS 27
DESCRIPTIONS OF SYSTEMS (COOKING
MODES) AND COOKING TABLES 28
MAINTENANCE & CLEANING 45
CONVENTIONAL OVEN CLEANING 45
USING THE STEAM CLEAN FUNCTION
TO CLEAN THE OVEN 46
CLEANING THE FILTER FOAM 47
REMOVING AND CLEANING THE WIRE
GUIDES 48
REMOVING AND INSERTING THE OVEN
DOOR 49
REMOVING AND INSERTING THE OVEN
DOOR GLASS PANE 50
REPLACING THE BULB 51
TROUBLESHOOTING TABLE 52
DISPOSAL 53
COOKING TEST 54
CONTENTS

4
3.5 kW
XXXXXX
SER. Nr: XXXXXX
ART. Nr:
max
TN XXXXX
Pn :
TYPE:
XXXXXX
220-240V ~
220V-240V, 50/60Hz
Control unit
Oven door
Oven handle
Guides
– Cooking levels
Water tank door
4
3
2
1
(DESCRIPTION OF THE OVEN AND EQUIPMENT – DEPENDING ON THE MODEL)
The figure represents one of the built-in appliance models. Since the appliances for which these instructions were drawn
up may have different equipment, some functions or equipment may be described in the manual that may not be present
in your appliances.
TECHNICAL SPECIFICATIONS
(DEPENDING ON THE MODEL)
The rating plate indicating the basic information about
the appliance is located at the edge of the oven and it is
visible when the oven door is opened.
COMBINED STEAM OVEN

5
WIRE GUIDES
The wire guides allow preparation of the food on 4 levels
(please note that the levels/guides are counted from the
bottom up).
Guides 3 and 4 are intended for grilling.
TELESCOPIC GUIDES
Telescopic pull-out guides may be fitted for the 2nd, 3rd,
and 4th level.
There are several different designs of the pull-out guides
(depending on the model):
three partially extendible, one fully and two partially
extendible, and three fully extendible guides.
OVEN DOOR SWITCH
The switches deactivate oven heating and the fan when
the oven door is opened during the cooking process.
When the door is closed, the switches turn the heaters
back on.
COOLING FAN
The appliance is fitted with a cooling fan that cools the
housing and the appliance control panel.
EXTENDED OPERATION OF THE COOLING FAN
After the oven is switched off, the cooling fan continues
to operate for a short while in order to cool the oven.
(Extended cooling fan operation depends on the
temperature in the center of the oven).
OVEN EQUIPMENT AND ACCESSORIES
GLASS BAKING DISH is used for cooking with all oven
systems. It can also be used as a serving tray.
The GRID is used for grilling or as support for a pan,
baking tray or baking dish with the food.
There is a safety latch on the grid. Therefore, the
grid has to be lifted slightly at the front when pulling it out
from the oven.
The SHALLOW BAKING SHEET is used for baking
pastry and cakes.
The DEEP BAKING TRAY is used for roasting meat and
baking moist pastry. It can also be used as a drip tray.
Never place the deep baking tray in the first guide
during the cooking process, except when grilling food or
using the roasting spit and you are only using the deep
tray as a drip tray.
PERFORATED DEEP TRAY is used for cooking
vegetables, potatoes, fish or meat. The tray prevents
contact between the food and condensate collected in
the deep tray.
When using the perforated tray, always place the
deep tray underneath it. This combination is only used
for steam cooking on the 2nd guide.
The grid or the tray should always be inserted into the
groove between the two wire profiles.

6
With telescopic extendible guides, first pull out the
guides of one level and place the grid or the baking tray
onto them. Then, push them in with your hand as far as
they will go.
2
3
4
Close the oven door when the telescopic guides are
retracted all the way into the oven.
The appliance and some of the accessible parts tend
to heat up during cooking. Use oven mitts.

7
CONTROL UNIT
NOTE:
The keys will respond better if you touch them with a larger area of your fingertip. Each time you press a key, this will be
acknowledged by a short acoustic signal.
Navigate the menu by sliding your finger up and down or left and right. Confirm your selection with a touch.
1ON/OFF KEY 2BACK KEY
Touch briefly to
return to previous
menu.
Touch and hold
to return to main
menu.
3DISPLAY – For
selection and
display of settings 4START/STOP
KEY 5CHILD LOCK KEY

8
CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM FOR FUTURE REFERENCE.
This appliance may only be used by children aged 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge
if supervision or instructions are provided to them concerning use of the appliance in a
safe way and if they understand the hazards involved. Do not let the children play with
the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
WARNING: The appliance and some of its accessible parts may become very hot during
use. Be careful not to touch the heaters. Children younger than 8 years should be constantly
supervised.
The appliance becomes very hot during use. Be careful not to touch the oven heaters.
WARNING: The accessible parts of the appliance may become hot during use. Children
should be kept away from the oven.
Only use the temperature probe recommended for use in this oven.
WARNING: Before replacing the light bulb, make sure the appliance has been disconnected
from the power mains, in order to prevent the hazard of an electric shock.
Do not use abrasive cleaners or sharp metal scrapers to clean the oven as they may damage the
finish or the protective enamel coating. Such damages may lead to cracking of the glass.
Do not use steam cleaners or high pressure cleaners to clean the appliance as this may result in an
electric shock.
The appliance is not intended to be controlled with external timers or special control systems.
The appliance is intended for household use. Do
not use it for any other purpose, such as room heating,
drying of pets or other animals, paper, fabrics, herbs etc.
as this may lead to injury or fire hazard.
The appliance may only be connected to the power
mains by an authorized service technician or expert.
Tampering with the appliance or non-professional repair
thereof may result in risk of severe injury or damage to
the product.
If the power cords of other appliances located near
this appliance are caught in the oven door, they may
be damaged, which may in turn result in a short circuit.
Therefore, keep the power cords of other appliances at a
safe distance.
If the power cord is damaged, it should be replaced by
the manufacturer or an authorized service technician, in
order to avoid hazard.
Do not line the oven walls with aluminium foil and do
not place baking trays or other cookware on the oven
bottom. Aluminium foil would prevent air circulation
in the oven, hinder the cooking process, and ruin the
enamel coating.
Oven door become very hot during operation. A
third glass is installed for extra protection, reducing
the temperature of the outside surface (only with some
models).
Oven door hinges may be damaged when under
excessive load. Do not place heavy pans on open oven
door and do not lean against open oven door when
cleaning the oven cavity. Never stand on the open oven
door and do not let children to sit on it.
Make sure the vents are never covered or obstructed in
any other way.
IMPORTANT SAFETY INSTRUCTIONS

9
Safe and correct use of the steam oven
Leave the appliance at room temperature for some
time before connecting it to the power mains to allow all
components to adapt to room temperature. If the oven
is stored at a temperature near or below freezing point,
there is a danger for some components, especially the
pumps.
The appliance should not operate in an environment
with a temperature below 5 °C. Below this temperature,
the water that remains in the pumps could freeze. If the
appliance is turned on in such conditions, the pumps
could be damaged.
If the appliance does not work correctly, disconnect it
from the power mains.
Do not store items in the oven, which could cause
danger when the oven is switched on.
Do not use distilled water that is not suitable for
ingestion.
After the steam cooking is completed, there is some
residual steam in the oven. Open the oven door carefully,
as there is danger of scalding with steam.
Clean the oven once it has cooled down to room
temperature.
After the cooking process, the remaining water in the
steam system is pumped back into the water tank.
Therefore, the water there could be hot. Be careful when
emptying the water tank.
To prevent the build-up of limescale, leave the oven door
open after cooking to allow the oven cavity to cool down to
room temperature.
BEFORE CONNECTING THE OVEN:
Carefully read the instructions for use before
connecting the appliance. Repair or any warranty
claim resulting from incorrect connection or use of the
appliance shall not be covered by the warranty.

10
After receiving the appliance remove all parts, including
any transport equipment (cardboard and polystyrene
inserts), from the oven.
Clean all accessories and utensils with warm water and
regular detergent. Do not use any abrasive cleaners.
When the oven heats up for the first time, the
characteristic smell of a new appliance will be emitted.
Ventilate the room thoroughly during the first use.
STEAM COOKING
Healthy and natural, steam cooking preserves the full
flavour of foods. This cooking method releases no
odours. There is no need to add salt to the water or to
add herbs and spices.
Following are the advantages of steam cooking:
Cooking (braising, roasting)starts before the
temperature inside the oven reaches 100 °C. Slow
cooking (braising, roasting)is also possible at lower
temperatures.It is healthy: vitamins and minerals are
well preserved because only a small share of them is
dissolved in the condensation water that touches the
food.
There is no need to add any fat during the cooking
process. The steam maintains the taste of food. It does
not add odours, nor the taste of the grill or the pan.
Furthermore, it takes nothing away because the food
is not diluted in the water. Steam does not spread the
flavour or smell; therefore, meat or fish can be cooked
together with vegetables. Steam is also suitable for
blanching, defrosting and reheating or keeping the food
warm.
BEFORE USING THE APPLIANCE FOR THE FIRST TIME

11
FILLING THE WATER TANK
The tank allows for independent water supply to the steamer. The tank volume amounts to approx. 1.2 litres (maximum
water level –see marking).
Clean the water tank before the first use.
Always fill the water tank with clean and cool water from the
pipeline, bottled water without additives, or distilled water
suitable for use in cooking. Water that is poured into the
water tank should be at a temperature of 20 °C +/- 10 °C.
klik
klik
MAX
MAX
1Apply pressure to open the water tank door.
2Remove the water tank from the housing by grabbing
the notch.
3Open the water tank cover and wash it with water.
Before use, add fresh water up to the MAX marking
on the tank.
4Push the water tank back into the housing to the
position in which the position switch is activated.
Then, press the tank door to close it.
After the cooking process, the remaining water in the
steam system is pumped back into the water tank. Empty,
clean, and dry the water tank. Add fresh water to the tank
before next use.

12
STEP 1: SWITCHING ON THE APPLIANCE FOR THE FIRST TIME
SETTING THE CLOCK
After connecting your appliance to the power mains or after an extended power outage, CLOCK settings will appear on
the display.
Navigate the menu by sliding your finger up and down.
Set the CLOCK by touching the display. Confirm the setting with the START/
STOP key.
The oven will also work if the clock is not set. However, timer functions are not available in this case (see chapter
SETTING THE TIMER FUNCTIONS). After a few minutes of idling, the appliance will switch to standby mode.
CHANGING THE CLOCK SETTING
Clock settings may be changed when no timer function is activated (see chapter CHOOSING THE GENERAL
SETTINGS).
SELECTING THE LANGUAGE
If you are not happy with the language in which the messages on the display are presented, select another one. English
is the preset language.
When you touch the line with the desired language, the size of the letters in
that line will increase.
Press the key to return to MAIN MENU.
STEPS OF THE COOKING PROCESS (1–6)

13
TESTING WATER HARDNESS
Water hardness test should be carried out before first use.
A warning will appear on the display: ”Use the test paper to measure water hardness.”
Soak the test paper strip (supplied with the appliance)in water for one (1)
second.
Wait one minute and observe the number of stripes on the paper. Enter the
information on the number of stripes into the appliance. Confirm by pressing
the START/ STOP key.
4 green stripes Soft
1 red stripe Slightly hard
2 red stripes Medium hard
3 red stripes Hard
4 red stripes Very hard
The highest water hardness is set as a factory default.
CHANGING THE WATER HARDNESS SETTING
Water hardness can also be set in the menu CHOOSING THE GENERAL SETTINGS.
If the correct water hardness level is not set, this could
affect appliance operation and its useful life.

14
STEP 2: CHOOSING THE BASIC COOKING MENUS AND SETTINGS
The process of preparing food in your oven can be controlled in several ways:
Navigate the menu by sliding your finger left and right.
Select the desired mode by touching the corresponding image. The name of
the selected menu will appear at the top.
Professional mode
Use this mode when you wish to prepare any type and amount of food. All settings are selected by the user.
Automatic mode
In this mode, first select the type of food. This is followed by automatic setting of the quantity, level of doneness, and
cooking end time.The program offers a broad choice of preset recipes reviewed by professional chefs and nutrition
experts.
My recipes
This mode allows you to prepare your food the way you like it, with the same steps and settings each time. Save your
favourite recipes to oven memory and retrieve them the next time you need them.
Steam mode
This is a natural cooking mode that preserves the full flavour of the food.

15
A) COOKING BY SELECTING THE TYPE OF FOOD (Auto mode)
Choose the Auto mode.
Select the type of food and the dish.
Preset values will be displayed:
- amount,
- doneness level (intensity),
- cooking time (cooking end time is displayed in grey).
Amount and doneness level can be adjusted. Selected values will appear.
EXTRA SETTINGS (EXTRAS)Choose them by touching the upper strip or the
corresponding sign.
- oven lighting
- method and ingredients for the selected recipe
- step mode (see chapter STEP COOKING)
- cooking end time setting (see chapter TIMER FUNCTIONS)
- minute minder (see chapter EXTRA SETTINGS/EXTRAS)

16
PREHEAT
Some dishes in the Auto mode also include the preheat function .
When you select the food, the following note will appear: ”Selected program includes preheating.” Preheating
started. Do not insert the food yet. The symbol °C will flash on the display.
When the selected temperature is reached, the preheating process stops and an acoustic signal is emitted.
The following note will appear on the display: ”Preheating complete”. Please insert the food. Open the door. The
program then resumes the cooking process with selected settings.
When the preheat function is set, delayed start function cannot be used.

17
B) COOKING BY SELECTING THE OPERATING MODE (Professional mode and Steam mode)
Choose Professional (Pro) mode.
Choose your own default settings:
- system
-oven temperature
Touch the symbol to select the cooking time.
(cooking end time is displayed in grey).
EXTRA SETTINGS (EXTRAS):Choose them by touching the upper strip or the
corresponding sign.
- oven lighting
- preheating
- step mode (see chapter STEP COOKING)
- minute minder (see chapter EXTRA SETTINGS/EXTRAS)
If you select Duration, extra settings will allow you to select delayed start (see chapter TIMER
FUNCTIONS)
- adding steam (see section STEAM INJECTION)
Touch the START key.
Rising oven temperature and elapsed cooking time will be displayed.

18
PREHEAT
Use the preheat function if you wish to heat the oven to the desired temperature as quickly as possible.
When this symbol is selected, the preheat function will be switched on and a warning will appear. »Preheating started.«
Do not insert the food yet. The symbol °C will fl ash on the display.
When the selected temperature is reached, the preheating process stops and an acoustic signal is emitted.
The following note will appear on the display: »Preheating complete«. Please insert the food. Open the door. The program then resumes
the cooking process with selected settings.
When the preheat function is set, delayed start function cannot be used.

19
COOKING SYSTEMS (depending on the model)
SYSTEM DESCRIPTION PRESET TEMPERATURE
(°C)
COOKING SYSTEMS
UPPER AND BOTTOM HEATER
The heaters in the bottom and in the ceiling of the oven cavity will radiate
heat evenly into the oven interior. Pastry or meat can only be baked/
roasted at a single height level.
200
UPPER HEATER
Only the heater on the oven cavity ceiling will radiate heat. Use this heater
to brown the upper side of the dish.
150
BOTTOM HEATER
Only the heater on the bottom of the oven cavity will radiate heat. Use this
heater to brown the lower side of the dish.
160
GRILL
Only grill heater, a part of the large grill set, will operate.
Use this heater to grill a few open sandwiches or beer sausages, or for
toasting bread.
240
LARGE GRILL
The upper heater and the grill heater will operate. The heat is radiated
directly by the grill heater installed in the oven ceiling. To boost the heating
effect, the upper heater is activated as well. This system is used for grilling
a smaller amount of open sandwiches or beer sausages, and for toasting
bread.
240
GRILL WITH FAN
Grill heater and the fan will operate. This combination is used to grill meat
and to roast larger chunks of meat or poultry at a single height level. It is
also appropriate for dishes au gratin and for browning to a crispy crust.
170
HOT AIR AND BOTTOM HEATER
Bottom heater, round heater, and the fan will operate. This is used to bake
pizza, moist pastry, fruitcakes, leavened dough and shortcrust on several
levels simultaneously.
200
360 HOT AIR
Round heater and the fan will operate. The fan installed in the back wall
of the oven cavity makes sure the hot air constantly circulates around the
roast or pastry. This mode is used for roasting meat and baking pastry at
several levels simultaneously.
180
ECO COOKING 1)
In this mode, power consumption during the cooking process is optimized.
This mode is used for roasting meat and baking pastry.
180
BOTTOM HEATER AND FAN
This is used for baking leavened but low-rising pastry and for preserving
fruit and vegetables.
180
AUTOMATIC COOKING OF MEAT – AUTO ROAST MODE
In the Auto Roast mode/system, the upper heater will operate in
combination with the grill heater and the round heater. It is used for
roasting all types of meat.
180
1)It is used for determining the energy efficiency class pursuant to the EN 60350-1 standard.
In this mode, the actual temperature in the oven is not displayed due to a special appliance operation algorithm and use of
residual heat.

20
SYSTEM DESCRIPTION PRESET TEMPERATURE
(°C)
COMBINED SYSTEMS / STEAM SYSTEM
HOT AIR WITH STEAM
Used for cooking and defrosting. They allow quick and efficient cooking
without changing the colour or shape of the food. Three options are
available:
180
high
medium
low
STEAM
Use this for all types of meat, stews, vegetables, pies, cakes, bread, and
dishes au gratin (i.e. food that require longer cooking time).
100
