Asko OM8487S User manual

Instructions for use
OVEN
OM8487S / BO4SM3F3-77
OM8487B / BO4SM3F3-77
OM8487A / BO4SM3F3-78
688917_en_naslovnica_drug_papir.indd EN3688917_en_naslovnica_drug_papir.indd EN3 22. 11. 2021 10:51:4122. 11. 2021 10:51:41

EN Manual EN 3 - EN 32
Pictograms used
Important information
Tip
688917_en_naslovnica_drug_papir.indd EN4688917_en_naslovnica_drug_papir.indd EN4 22. 11. 2021 10:52:0722. 11. 2021 10:52:07

EN 3
YOUR MICROWAVE
Your microwave
Introduction 4
Control panel 5
Description 6
Guide rails/Telescopic guide rails 6
Accessories 6
Door 7
Cooling fan 7
Main functions 7
Keys 8
Navigation 9
Initial use
What to do first 11
Operation
Selecting your function 13
Functions settings mode 13
Progress mode 15
Finish display 15
Changing settings during the progress 16
Use
Functions table 17
Using the microwave 18
Settings menu 20
Plus menu 22
Cooking information 22
Stage cooking 23
Go to manual cooking 24
Programs and Favourites 24
Egg timer 24
Child lock 25
Extra functions 26
Cleaning
Cleaning the appliance 27
Aqua clean 27
Removing and cleaning the guide rails 28
Replacing the oven lamp 28
Solving problems
General 30
Your oven and the environment
Disposing of the appliance and the packaging 32
688917_en_naslovnica_drug_papir.indd EN3688917_en_naslovnica_drug_papir.indd EN3 22. 11. 2021 10:52:0822. 11. 2021 10:52:08

EN 4
Introduction
Congratulations on choosing this Asko microwave.
This product is designed to offer simple operation and optimum
user-friendliness. The microwave has a wide range of settings enabling
you to select the correct cooking method every time.
This manual shows how you can best use this microwave. In addition
to information about operating the microwave, you will also find
background information that may be useful when using the appliance.
Please read the separate safety instructions
carefully before using the appliance!
Read this manual before using the appliance and keep it in a safe
place for future use.
Installation instructions are supplied separately.
YOUR MICROWAVE
688917_en_naslovnica_drug_papir.indd EN4688917_en_naslovnica_drug_papir.indd EN4 22. 11. 2021 10:52:0822. 11. 2021 10:52:08

EN 5
YOUR MICROWAVE
Control panel
1. Function knob (in ‘Off’ position)
2. Defrost programs
3. Programs & Favourites
4. Defrost
5. My microwave
6. Microwave
7. Warming
8. Clean air
9. Aqua clean
10. Display
11. Selection knob
12. On/off key and stop key (cancel)
13. Light key
14. Timer key
15. Navigation key left
16. Navigation key right
17. Plus key
18. Child lock key (lock key)
19. Confirm key (+ 30 seconds microwave (6) time)
Note:
The keys respond best if you touch them with a large area of your
fingertip. Every time you press a key during use, a short acoustic signal
will sound.
12 13 14 15 16 17 18 19
1 10 116 7 8 95432
688917_en_naslovnica_drug_papir.indd EN5688917_en_naslovnica_drug_papir.indd EN5 22. 11. 2021 10:52:0822. 11. 2021 10:52:08

EN 6
YOUR MICROWAVE
Description
1. Control panel
2. Oven levels
3. Oven door
4. Door handle
Guide rails/Telescopic guide rails
• The oven has four or five guide rails (Level 1 to 4/5), depending on
the model. Level 1 is mainly used in combination with bottom heat.
The two upper levels are mainly used for the grill function.
• Place the oven rack, baking tray or steam dish in the gap between
the guide rail sliders.
• A number of shelf levels can have fully-retractable telescopic guide
rails, depending on the model.
▷Pull the telescopic guide rails out of the oven cavity completely
and place the oven rack / baking tray / steam dish on them.
Then slide the oven rack / baking tray / steam dish on the
telescopic guide rails, back into the oven cavity.
▷Only close the oven door when the telescopic guide rails have
been returned completely back into the oven cavity.
Accessories
Your appliance is accompanied by a range of accessories, depending
on the model. Only use original accessories; they are specially suited
toyour appliance. Be sure that all the accessories that are being used
are able to withstand the temperature settings of the chosen oven
function.
1
3
Level 1
Level 2
Level 3
Level 4
2
4
688917_en_naslovnica_drug_papir.indd EN6688917_en_naslovnica_drug_papir.indd EN6 22. 11. 2021 10:52:0822. 11. 2021 10:52:08

EN 7
Note: not all accessories are suitable/available for every appliance
(itmay also differ by country). When purchasing, always provide the
exact identification number of your appliance. Please see the sales
brochures or check online for more details about optional accessories.
Accessories that can be supplied with your appliance (depending on the model)
Glass baking tray; for microwave and oven use.
• NOT suitable for pyrolysis cleaning.
Door
• The door switches interrupt the operation of the microwave when
the door is opened during use. The microwave continues operating
when the door is closed.
• This oven has a ‘Soft close door system’. When closing the oven
door, this system dampens the movement, from a certain angle, and
silently closes the oven door.
Cooling fan
• The appliance is equipped with a cooling fan that cools the casing
and control panel.
Main functions
With the function knob you can select the main functions of your
microwave.
Setting Description
Off/standby mode
My microwave
Programs and favourites
Favourites
Programs
YOUR MICROWAVE
688917_en_naslovnica_drug_papir.indd EN7688917_en_naslovnica_drug_papir.indd EN7 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 8
YOUR MICROWAVE
Defrost
Manual defrost
Microwave
Microwave
Clean air
Warming
Aqua clean
Defrost programs
Keys
In the table below you can find the discription of the different keys.
Keys Description of the keys
On/off key and stop key:
- Press short: cancel operation or go one step back in
the menu.
- Press long: turn the appliance off or on.
Light key:
- To turn the cavity light on or off.
Egg timer
- The egg timer can be used independent of the oven
function.
- The longest possible timer setting is 23:59.
Navigation key left
- To move the active area to the left.
688917_en_naslovnica_drug_papir.indd EN8688917_en_naslovnica_drug_papir.indd EN8 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 9
Navigation key right
- To move the active area to the right.
Plus key
- To open or exit the settings menu (in standby-mode).
- To open or exit the plus menu with the extra options
possible at that moment (in on-mode).
Child lock key
- Press and hold the left navigation key and right
navigation key simultaniously to lock the appliance.
Confirm key
- To confirm all the white settings/elements in the
screen.
- Add 30 seconds microwave time (microwave
function).
Navigation
active area
stop key confirm keyfunction knob selection knobnavigation keys
By turning the function knob away from the 0-position, the icon of the
chosen main function is lit. The display will show the icon and name
of the activated function for about 1,5 seconds. Next you will see the
chosen main function and sub-function at the top of the display in the
feedback bar. Also the function settings mode will become active (grey
background). In this activated area you can select your settings using
the selection knob.
750 W 1:00
MICROWAVE 14:30
YOUR MICROWAVE
688917_en_naslovnica_drug_papir.indd EN9688917_en_naslovnica_drug_papir.indd EN9 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 10
YOUR MICROWAVE
Within every menu the navigation is as follows:
• Use the navigation keys or press the selection knob to move the
active area (grey background).
• The setting in the active area can be changed by turning the
selection knob (left = decrease, right = increase). The setting will be
saved automaticallly.
• When all elements in the screen are set, then confirm these settings
by pressing the confirm key (this key will start blinking when it is
possible to start the program).
• Press the stop key to go one step back in the menu.
At the top of the display is a feedback bar. This bar shows where you
are in the menu and what setting you are changing. Functions / settings
are separated with a vertical line.
SETTINGS l GENERAL l SOUND l KEY SOUND
PROGRAMS l ... l CHICKEN
688917_en_naslovnica_drug_papir.indd EN10688917_en_naslovnica_drug_papir.indd EN10 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 11
INITIAL USE
What to do first
• Clean the microwave interior and accessories with hot water and
washing-up liquid. Do not use aggressive cleaning agents, abrasive
sponges and similar.
• The microwave will emit a particular odor when it is used for the
first time; this is normal. Make sure that there is good ventilation
during initial use.
When the appliance is first plugged in or after connection when the
appliance was disconnected from the power mains for a long period of
time, you have to set ‘Language’, ‘Date’ and ‘Time’.
Setting the language
English
Deutsch
LANGUAGE
In case you are not comfortable with the language on the display, you
can select another language. The default setting is ‘English’.
1. Turn the selection knob and select your preferred language from the
displayed list.
2. Confirm the setting by pressing the confirm key.
The next screen will be displayed.
Setting the date
01 2015
01
02
DATE l DAY
1. Turn the selection knob and change the first setting (Day).
2. Confirm this setting by pressing the right navigation key or by
pressing the selection knob.
3. Turn the selection knob and change the next setting (Month).
4. Confirm this setting by pressing the right navigation key or by
pressing the selection knob.
5. Turn the selection knob and change the last setting (Year).
6. Confirm this setting by pressing the confirm key.
The next screen will be displayed.
688917_en_naslovnica_drug_papir.indd EN11688917_en_naslovnica_drug_papir.indd EN11 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 12
Setting the time
: 00
11
12
13
TIME l HOUR
1. Turn the selection knob and change the hours.
2. Confirm this setting by pressing the right navigation key or by
pressing the selection knob.
3. Turn the selection knob and change the minutes.
4. Confirm this setting by pressing the confirm key.
All the start-up settings are now set and the display will show the
standby screen. The appliance is now ready for use.
The language, time and date can be adjusted in the settings menu (see
‘Settings menu’ chapter). The settings menu can be opened from the
start display via the ‘Plus’ menu.
Stand-by display
The standby display will show the time, date and the timer (if set).
The appliance goes to standby mode after:
• Turning the function knob to 0 (‘off’ position).
• Pressing the stop key multiple times (deeper in the menu).
12 : 00
03 •05 •2015
Off mode
• Default the appliance will shut down after no action for a set time of
30 minutes.
• Press and hold the stop key to shut down the appliance manually.
Switching the appliance on
• Press and hold the stop key to switch on the appliance.
• The appliance can also be switched on by turning the function knob
to a function.
INITIAL USE
688917_en_naslovnica_drug_papir.indd EN12688917_en_naslovnica_drug_papir.indd EN12 22. 11. 2021 10:52:0922. 11. 2021 10:52:09

EN 13
Selecting your function
Select a function appropriate for the meal you are cooking. Consult the
table in chapter ‘Functions table’ to see which functions are available.
• Go directly to the progress mode by pressing the confirm key (this
key is blinking if it is possible to start the program).
After you have chosen a main function, the function settings mode is
active (grey background). In this activated area, it is now possible to
change the settings in this funtion.
Function settings mode
Example (Microwave / one minute)
1. Choose a main function by turning the function knob.
The first sub-function setting is active.
750 W 1:00
MICROWAVE 14:30
Now the settings can be changed as desired.
There is the possibility to set:
• The function (consult the table in chapter ‘Functions table’).
• The power.
• The time.
2. Turn the selection knob and change the setting.
750 W 1:00
MICROWAVE 14:30
3. Confirm the setting by pressing the right navigation key or by
pressing the selection knob.
The next sub-function setting becomes active.
200 °C
600
750 W
1000
1:00
MICROWAVE 14:30
4. Turn the selection knob and change the setting.
200 °C
750
1000 W
1:00
MICROWAVE 14:30
OPERATION
688917_en_naslovnica_drug_papir.indd EN13688917_en_naslovnica_drug_papir.indd EN13 22. 11. 2021 10:52:1022. 11. 2021 10:52:10

EN 14
5. Confirm the setting by pressing the right navigation key or by
pressing the selection knob.
The next sub-function setting becomes active.
1000 W
MICROWAVE 14:30
1:00
▷The default timer setting is displayed. Press the confirm key to
start the program directly with the chosen settings (see step 7).
▷To set the timer, go to step 6.
6. Turn the selection knob and change the setting.
1000 W
MICROWAVE l COOKING TIME 14:30
0:39
0:40 M:S
0:41
▷M:S notation.
7. If preferred, select any additional setting using the plus menu (for
example fast preheat). See for more information chapter ‘Plus
menu’.
8. Start the program: press the confirm key to go to the progress
mode.
The program will start with the chosen settings; the oven will go to
the progress mode and the progress screen is shown.
1000 W
14:30
0:40
MICROWAVE
14:31
OPERATION
688917_en_naslovnica_drug_papir.indd EN14688917_en_naslovnica_drug_papir.indd EN14 22. 11. 2021 10:52:1022. 11. 2021 10:52:10

EN 15
Progress mode
• Left side on the screen, the power is displayed.
• Right side on the screen, the time (counting down) is displayed.
Next to the cooking time you can see the finishing time.
1000 W
14:30
0:40
MICROWAVE
14:31
Finish display
When the timer is finished, the ‘finish display’ will appear.
Now it is possible to:
• Stop the progress.
• Add extra time.
• Save as favourite.
FINISH l ENJOY 14:30
Stop the progress
1. Press the confirm key.
The finish display will be closed and the standby screen will be
shown.
▷If there is no action within 10 minutes, the display will switch to
standby mode.
Add extra time
1. Press the right navigation key to select ‘Add extra time’.
2. The time setting becomes active and can be changed directly by
rotating the selection knob.
3. Confirm by means of the confirm key.
The previous process is activated again.
OPERATION
688917_en_naslovnica_drug_papir.indd EN15688917_en_naslovnica_drug_papir.indd EN15 22. 11. 2021 10:52:1022. 11. 2021 10:52:10

EN 16
OPERATION
Save as favourite
1. Press the right navigation key to select ‘Save as favourite’.
The next screen will show 10 positions where the program can be
positioned.
2. Select a position for your recipe by rotating the selection knob and
press the confirm key to save it.
If there is already another program at the selected position, then
a popup will be shown: ‘program will be overwritten’ (accept or
cancel).
3. Give the recipe a name. Rotate the selection knob to select the
appropriate letter and press the selection knob to confirm and go to
the next letter.
▷You can delete a character by means of the backspace function
in the character list (arrow).
4. Press the confirm key to save the recipe.
Changing settings during the progress
• During progress, pressing the navigation keys will show the active
area. The selected setting can now be changed, see chapter
‘Function settings mode’.
• After confirmation with the confirm key the progress screen will be
shown with the changed settings.
• After 5 seconds without actions the progress settings are cancelled
and the display will return to the progress screen.
688917_en_naslovnica_drug_papir.indd EN16688917_en_naslovnica_drug_papir.indd EN16 22. 11. 2021 10:52:1022. 11. 2021 10:52:10

EN 17
USE
Functions table
Consult the table to select the preferred function. Also consult the
instructions for preparation on the dish packaging.
• In ‘Microwave function’: do not use metal cookware or
utensils and do not preheat the oven.
Function Description
Microwave
• Microwave energy is used to cook and defrost
foods. It provides fast efficient cooking without
changing the colour or form of food.
• Place the glass dish on level 1.
• Suggested power: 1000 W
1
Defrost programs
• Use ‘Defrost programs’ for defrosting by selecting a
setting from the list of pre-programmed settings.
Programs and Favourites
• Use ‘Programs’ for baking and roasting by selecting
a dish from a list of pre-programmed dishes.
• Favourites: you can select your own stored recipes.
Defrost
• This function uses microwaves. Dishes are
defrosted quickly and efficiently.
• Suggested power: 90 W
My microwave
• Microwave power and cooking time can be
adjusted for the ‘My microwave’ function.
Warming
• Keep warm: this function is used to keep already
cooked dishes warm.
Clean air
• The fans are operated for cooling and
deodorization.
Aqua clean
• Grease and grime can easily be removed from the
oven walls with a damp cloth.
688917_en_naslovnica_drug_papir.indd EN17688917_en_naslovnica_drug_papir.indd EN17 22. 11. 2021 10:52:1022. 11. 2021 10:52:10

EN 18
USE
Using the microwave
Microwaves are high-frequency electromagnetic waves. The energy
makes it possible to cook or warm up dishes without affecting the form
or colour.
Cooking principle
1. The microwaves generated by the microwave are spread evenly by
a distribution system. This cooks the dish evenly.
2. The food absorbs the microwaves to a depth of approximately 2.5 cm.
Cooking then continues, because the heat is spread in the dish.
3. The cooking times vary and depend on the dish you use and the
properties of the food:
▷Quantity and density
▷Moisture content
▷Starting temperature (whether or not it is cooled)
Important
The dish is cooked from the inside out by means of heat distribution.
The cooking continues even when you take the dish out of the oven.
Standing times in recipes and in this manual should therefore be
adhered to, in order to ensure:
• Even heating into the middle of the dish;
• Equal temperatures in all parts of the dish.
Power Use
1000 W • For quick heating of drinks, water and dishes
containing a lot of moisture.
• For cooking fresh or frozen vegetables.
750 W • For prepairing and heating of drinks and dishes.
600 W • For melting chocolate.
• For cooking fish and seafood.
• For heating on two levels.
• For cooking dried beans at low temperatures.
• For heating or cooking delicate dishes with eggs.
360 W • For cooking dairy products or jam at low
temperatures.
180 W • For fast defrosting of dishes.
• For softening butter or ice cream.
90 W • For defrosting cakes containing cream.
688917_en_naslovnica_drug_papir.indd EN18688917_en_naslovnica_drug_papir.indd EN18 22. 11. 2021 10:52:1022. 11. 2021 10:52:10

EN 19
USE
Guidelines for microwave cookware
Cookware that you use for the microwave function should not block
the microwaves. Metals such as stainless steel, aluminium and copper
reflect microwaves. For that reason, do not use metal cookware.
Cookware which is designated as microwave-safe can be used safely.
For more information about suitable cookware, consult the following
guidelines and always use the glass baking tray on level 1 if you use the
microwave function.
Cookware Microwave safe Remarks
Aluminium foil  Can be used in small quantities to prevent certain parts
of the dish from overcooking. Arcing can occur if the foil
is too close to the oven wall or if too much foil is used.
Porcelain and
earthenware
Porcelain, earthenware, glazed earthenware and ivory
porcelain are usually suitable, unless they have a metal
edge.
Disposable crockery
made from polyester
or cardboard
Frozen meals are sometimes packaged in disposable
tableware.
Fast food packaging
• Polystyrene cups
• Paper bags or
newspaper
• Recycled paper
or metal edges



Can be used to warm up dishes.
Polystyrene can melt if it overheats.
Can catch fire.
Can cause arcing.
Glassware
• Oven dishes
• Fine glassware
• Glass jars
Can be used, unless it has a metal edge.
Can be used to warm up dishes or liquids. Thin glass can
break or shatter with sudden heating.
The lid must be removed. Only suitable for warming.
Metal Can cause arcing or fire.
Paper
• Plates, cups,
kitchen paper
• Recycled paper


For short cooking times and warming. For absorbing
excess moisture.
Can cause arcing.
688917_en_naslovnica_drug_papir.indd EN19688917_en_naslovnica_drug_papir.indd EN19 22. 11. 2021 10:52:1122. 11. 2021 10:52:11

EN 20
USE
Cookware Microwave safe Remarks
Plastic Especially heat-resistant thermoplastic material.
Other types of plastic can warp or discolour at high
temperatures. Do not use melamine plastic.
Can be used to hold moisture.
May not touch the food.
Be careful when you remove the film; hot steam can escape.
Only if boil-proof or ovenproof. Must not be airtight.
If necessary, prick it with a fork.
 : Recommended
 : Careful
 : Unsafe
Settings menu
The settings menu is only available by pressing the plus key when the
appliance is in standby mode.
Setting Description
General
Language
Time
Date
Sound
Display
Brightness
Clock size
Night mode
Appliance to stand-by mode
Cooking
My microwave
Default program intensity
System
Appliance information
Factory settings
Oven light
General
You can set the following from this menu:
• Language (language of the display)
• Time (always in 24H format)
688917_en_naslovnica_drug_papir.indd EN20688917_en_naslovnica_drug_papir.indd EN20 22. 11. 2021 10:52:1122. 11. 2021 10:52:11
