Asko OM8487S / BO4SM3F3-77 User manual

Instructions for use
OVEN
OM8487S / BO4SM3F3-77
OM8487A / BO4SM3F3-78

EN Manual EN 3 - EN 33
Pictograms used
Important information
Tip

EN 3
YOUR MICROWAVE
Your microwave
Introduction 4
Control panel 5
Description 6
Guide rails/Telescopic guide rails 6
Accessories 6
Door 7
Cooling fan 7
Main functions 7
Keys 8
Navigation 9
Initial use
What to do first 11
Operation
Selecting your function 13
Functions settings mode 13
Progress mode 15
Finish display 15
Changing settings during the progress 16
Use
Functions table 17
Using the microwave 18
Settings menu 20
Plus menu 22
Cooking information 22
Stage cooking 23
Go to manual cooking 24
Programs and Favourites 24
Egg timer 24
Child lock 25
Extra functions 26
Cleaning
Cleaning the appliance 27
Aqua clean 27
Removing and cleaning the guide rails 28
Replacing the oven lamp 28
Solving problems
General 30
Your oven and the environment
Disposing of the appliance and the packaging 32
Cooking test
Food tested in compliance with the EN 60705-2 standard 33

EN 4
Introduction
Congratulations on choosing this Asko microwave.
This product is designed to offer simple operation and optimum
user-friendliness. The microwave has a wide range of settings enabling
you to select the correct cooking method every time.
This manual shows how you can best use this microwave. In addition
to information about operating the microwave, you will also find
background information that may be useful when using the appliance.
Please read the separate safety instructions
carefully before using the appliance!
Read this manual before using the appliance and keep it in a safe
place for future use.
Installation instructions are supplied separately.
YOUR MICROWAVE

EN 5
YOUR MICROWAVE
Control panel
1. Function knob (in ‘Off’ position)
2. Defrost programs
3. Programs & Favourites
4. Defrost
5. My microwave
6. Microwave
7. Warming
8. Clean air
9. Aqua clean
10. Display
11. Selection knob
12. On/off key and stop key (cancel)
13. Light key
14. Timer key
15. Navigation key left
16. Navigation key right
17. Plus key
18. Child lock key (lock key)
19. Confirm key (+ 30 seconds microwave (6) time)
Note:
The keys respond best if you touch them with a large area of your
fingertip. Every time you press a key during use, a short acoustic signal
will sound.
12 13 14 15 16 17 18 19
1 10 116 7 8 95432

EN 6
YOUR MICROWAVE
Description
1. Control panel
2. Oven levels
3. Oven door
4. Door handle
Guide rails/Telescopic guide rails
• The oven has four or five guide rails (Level 1 to 4/5), depending on
the model. Level 1 is mainly used in combination with bottom heat.
The two upper levels are mainly used for the grill function.
• Place the oven rack, baking tray or steam dish in the gap between
the guide rail sliders.
• A number of shelf levels can have fully-retractable telescopic guide
rails, depending on the model.
▷Pull the telescopic guide rails out of the oven cavity completely
and place the oven rack / baking tray / steam dish on them.
Then slide the oven rack / baking tray / steam dish on the
telescopic guide rails, back into the oven cavity.
▷Only close the oven door when the telescopic guide rails have
been returned completely back into the oven cavity.
Accessories
Your appliance is accompanied by a range of accessories, depending
on the model. Only use original accessories; they are specially suited
toyour appliance.
1
3
Level 1
Level 2
Level 3
Level 4
2
4

EN 7
Note: not all accessories are suitable/available for every appliance
(itmay also differ by country). When purchasing, always provide the
exact identification number of your appliance. Please see the sales
brochures or check online for more details about optional accessories.
Accessories that can be supplied with your appliance (depending on the model)
Glass baking tray; for microwave and oven use.
• NOT suitable for pyrolysis cleaning.
Door
• The door switches interrupt the operation of the microwave when
the door is opened during use. The microwave continues operating
when the door is closed.
• This oven has a ‘Soft close door system’. When closing the oven
door, this system dampens the movement, from a certain angle, and
silently closes the oven door.
Cooling fan
• The appliance is equipped with a cooling fan that cools the casing
and control panel.
Main functions
With the function knob you can select the main functions of your
microwave.
Setting Description
Off/standby mode
My microwave
Programs and favourites
Favourites
Programs
YOUR MICROWAVE

EN 8
YOUR MICROWAVE
Defrost
Manual defrost
Microwave
Microwave
Clean air
Warming
Aqua clean
Defrost programs
Keys
In the table below you can find the discription of the different keys.
Keys Description of the keys
On/off key and stop key:
- Press short: cancel operation or go one step back in
the menu.
- Press long: turn the appliance off or on.
Light key:
- To turn the cavity light on or off.
Egg timer
- The egg timer can be used independent of the oven
function.
- The longest possible timer setting is 23:59.
Navigation key left
- To move the active area to the left.

EN 9
Navigation key right
- To move the active area to the right.
Plus key
- To open or exit the settings menu (in standby-mode).
- To open or exit the plus menu with the extra options
possible at that moment (in on-mode).
Child lock key
- Press and hold the left navigation key and right
navigation key simultaniously to lock the appliance.
Confirm key
- To confirm all the white settings/elements in the
screen.
- Add 30 seconds microwave time (microwave
function).
Navigation
active area
stop key confirm keyfunction knob selection knobnavigation keys
By turning the function knob away from the 0-position, the icon of the
chosen main function is lit. The display will show the icon and name
of the activated function for about 1,5 seconds. Next you will see the
chosen main function and sub-function at the top of the display in the
feedback bar. Also the function settings mode will become active (grey
background). In this activated area you can select your settings using
the selection knob.
750 W 1:00
MICROWAVE 14:30
YOUR MICROWAVE

EN 10
YOUR MICROWAVE
Within every menu the navigation is as follows:
• Use the navigation keys or press the selection knob to move the
active area (grey background).
• The setting in the active area can be changed by turning the
selection knob (left = decrease, right = increase). The setting will be
saved automaticallly.
• When all elements in the screen are set, then confirm these settings
by pressing the confirm key (this key will start blinking when it is
possible to start the program).
• Press the stop key to go one step back in the menu.
At the top of the display is a feedback bar. This bar shows where you
are in the menu and what setting you are changing. Functions / settings
are separated with a vertical line.
SETTINGS l GENERAL l SOUND l KEY SOUND
PROGRAMS l ... l CHICKEN
