This planning guide provides unit dimensions, cutout
dimensions, and utility locations only. For more
details, refer to the installation instructions that are
supplied with the unit.

Specifications are subject to change without notice. See installation instructions for additional details. 15
UNIT DIMENSIONS
U Metric
Height 33-1/2"–34-1/2" 850–876 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 167 lb 73 kg
MODEL W6021
TECHNICAL DATA
S pply voltage Single-phase 230 V, 60 Hz
Water Press re 15-146 psi
Heating element 2000 W
Internal F se 15 A
Power cord (attached) 220 V, 20 Amp
ASKO WASHER
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. If the washer is sed separately or with
another dryer, it m st be on a separate 220 V, 20 Amp single-
phase circ it.
Second-floor (above grade) installations m st meet all local
b ilding codes.
When placing the washer next to a wall or cabinet, be s re to
leave 1/2" (12 mm) of space between the washer and the wall
or cabinet.
See pages 23–25 for stacked asher/dryer dimensions.
See pages 28–30 for cutout dimensions for closet and under-
cabinet installations.

Specifications are subject to change without notice. See installation instructions for additional details.
16
MODEL W6441
ASKO WASHER
UNIT DIMENSIONS
U Metric
Height 33-1/2"–34-1/2" 850–876 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 167 lb 73 kg
TECHNICAL DATA
S pply voltage Single-phase 230 V, 60 Hz
Water Press re 15-146 psi
Heating element 2000 W
Internal F se 15 A
Power cord (attached) 220 V, 20 Amp
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. If the washer is sed separately or with
another dryer, it m st be on a separate 220 V, 20 Amp single-
phase circ it.
Second-floor (above grade) installations m st meet all local
b ilding codes.
When placing the washer next to a wall or cabinet, be s re to
leave 1/2" (12 mm) of space between the washer and the wall or
cabinet.
See pages 23–25 for stacked asher/dryer dimensions.
See pages 28–30 for cutout dimensions for closet and under-
cabinet installations.
Stain
Programs
Heavy
Normal
Perma
press
Quick
Super quick
Drain
Spin
Rinse
Hand/
Delicate
Wool

Specifications are subject to change without notice. See installation instructions for additional details. 17
ASKO WASHER
MODEL W6661
UNIT DIMENSIONS
U Metric
Height 33-1/2"–34-1/2" 850–876 mm
Width 23-7/16" 595 mm
Depth 23-7/16" 595 mm
Weight 174 lb 79 kg
TECHNICAL DATA
S pply voltage Single-phase 230 V, 60 Hz
Water Press re 15-146 psi
Heating element 2000 W
Internal F se 15 A
Power cord (attached) 220 V, 20 Amp
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. If the washer is sed separately or with
another dryer, it m st be on a separate 220 V, 20 Amp single-
phase circ it.
Second-floor (above grade) installations m st meet all local
b ilding codes.
When placing the washer next to a wall or cabinet, be s re to
leave 1/2" (12 mm) of space between the washer and the wall
or cabinet.
See pages 26–27 for stacked asher/dryer dimensions.
See pages 28–30 for cutout dimensions for closet and under-
cabinet installations.

Specifications are subject to change without notice. See installation instructions for additional details.
18
UNIT DIMENSIONS
U Metric
Height 33-1/2"–34-1/2 850–876 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 86 lb 39 kg
MODEL T701 VENTED DRYER
TECHNICAL DATA
S pply voltage Single-phase 230 V, 60 Hz
Heating element 2500 W
Internal F se 15 A
NOTE: When on a separate o tlet, se 220 V, 15 Amp
single-phase circ it. When an ASKO washer is
connected, se 220 V, 30 Amp single-phase circ it.
The door hinges on ASKO dryers are shipped left-hinged, b t they
are reversible. See the Dryer Use and Care G ide for more
information.
When placing the dryer next to a wall or cabinet, be s re to leave
1/2" (12 mm) of space between the dryer and the wall or cabinet.
See page 23 for stacked asher/dryer dimensions.
See pages 28–30 for cutout dimensions for closet and under-
cabinet installations.
Venting Requirements
WARNING To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
The hose sho ld be r n with as few bends as possible to the point
of discharge. If necessary, it can be extended to a maxim m of 20
feet (610 mm) of 4 in (10 cm) diameter ridged pipe. Make any
bends as gentle as possible. A maxim m of fo r 90˚ bends may
S btract 4 feet (660 mm)
for every 90˚ elbow.
be fitted in the hose, otherwise the performance of the dryer will
be impeded. S btract 4 feet of hose for every 90˚ elbow.
If the hose is taken to a wall o tlet, a ventilation grill sho ld be
fitted to prevent reverse flow of cold air. Fit the ventilation grill to
the o tside or inside of the wall.
This appliance sho ld not be exha sted into a chimney, a wall, a
ceiling, or a concealed space of a b ilding. Only a metal ventilation
grill sho ld be sed.
ASKO DRYER
Installation Examples

Specifications are subject to change without notice. See installation instructions for additional details. 19
ASKO DRYER
UNIT DIMENSIONS
U Metric
Height 33-1/2"–34-1/2 850–876 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 103 lb 47 kg
MODEL T721 CONDENSER DRYER
TECHNICAL DATA
S pply voltage Single-phase 230 V, 60 Hz
Heating element 2500 W
Internal F se 15 A
NOTE: When on a separate o tlet, se 220 V, 15 Amp
single-phase circ it. When an ASKO washer is
connected, se 220 V, 30 Amp single-phase circ it.
The door hinges on ASKO dryers are shipped left-hinged, b t they
are reversible. See the Dryer Use and Care G ide for more
information.
When placing the dryer next to a wall or cabinet, be s re to leave
1/2" (12 mm) of space between the dryer and the wall or cabinet.
See page 24 for stacked asher/dryer dimensions.
See pages 28–30 for cutout dimensions for closet and under-
cabinet installations.
Condensation Drain Requirements
If possible, yo sho ld install the dryer so the condensed water
will contin o sly flow into a drain or sink. To do this, follow the
instr ctions below:
1. Disconnect the short hose (1) from the bl e connection.
(It’s okay to let the hose hang down.)
2. Connect the r bber hose s pplied with the dryer to the bl e
nipple (2).
3. R n the hose to a drain or sink, as ill strated.
NOTE: The drain hose m st not be more than 40" above the floor
or the bottom of the nit.
Back of dryer
1
3
3
40"
(1016 mm)
maximum
height
2

Specifications are subject to change without notice. See installation instructions for additional details.
20
ASKO DRYER
UNIT DIMENSIONS
U Metric
Height 33-1/2"–34-1/2 850–876 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 86 lb 39 kg
MODEL T731 VENTED DRYER
TECHNICAL DATA
S pply voltage Single-phase 230 V, 60 Hz
Heating element 2500 W
Internal F se 15 A
NOTE: When on a separate o tlet, se 220 V, 15 Amp
single-phase circ it. When an ASKO washer is
connected, se 220 V, 30 Amp single-phase circ it.
The door hinges on ASKO dryers are shipped left-hinged, b t they
are reversible. See the Dryer Use and Care G ide for more
information.
When placing the dryer next to a wall or cabinet, be s re to leave
1/2" (12 mm) of space between the dryer and the wall or cabinet.
See page 25 for stacked asher/dryer dimensions.
See pages 28–30 for cutout dimensions for closet and under-
cabinet installations.
Venting Requirements
WARNING To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
The hose sho ld be r n with as few bends as possible to the point
of discharge. If necessary, it can be extended to a maxim m of 20
feet (610 mm) of 4 in (10 cm) diameter ridged pipe. Make any
bends as gentle as possible. A maxim m of fo r 90˚ bends may
S btract 4 feet (660 mm)
for every 90˚ elbow.
be fitted in the hose, otherwise the performance of the dryer will
be impeded. S btract 4 feet of hose for every 90˚ elbow.
If the hose is taken to a wall o tlet, a ventilation grill sho ld be
fitted to prevent reverse flow of cold air. Fit the ventilation grill to
the o tside or inside of the wall.
This appliance sho ld not be exha sted into a chimney, a wall, a
ceiling, or a concealed space of a b ilding. Only a metal ventilation
grill sho ld be sed.
Installation Examples
Extra dry
Dry
Normal dry
Iron dry
Timed dry
Air fluff
Programs

Specifications are subject to change without notice. See installation instructions for additional details. 21
ASKO DRYER
UNIT DIMENSIONS
U Metric
Height 33-1/2"–34-1/2 850–876 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 86 lb 39 kg
MODEL T761 VENTED DRYER
TECHNICAL DATA
S pply voltage Single-phase 230 V, 60 Hz
Heating element 2500 W
Internal F se 15 A
NOTE: When on a separate o tlet, se 220 V, 15 Amp
single-phase circ it. When an ASKO washer is
connected, se 220 V, 30 Amp single-phase circ it.
The door hinges on ASKO dryers are shipped left-hinged, b t they
are reversible. See the Dryer Use and Care G ide for more
information.
When placing the dryer next to a wall or cabinet, be s re to leave
1/2" (12 mm) of space between the dryer and the wall or cabinet.
See page 26 for stacked asher/dryer dimensions.
See pages 28–30 for cutout dimensions for closet and under-
cabinet installations.
Venting Requirements
WARNING To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
The hose sho ld be r n with as few bends as possible to the point
of discharge. If necessary, it can be extended to a maxim m of 20
feet (610 mm) of 4 in (10 cm) diameter ridged pipe. Make any
bends as gentle as possible. A maxim m of fo r 90˚ bends may
S btract 4 feet (660 mm)
for every 90˚ elbow.
be fitted in the hose, otherwise the performance of the dryer will
be impeded. S btract 4 feet of hose for every 90˚ elbow.
If the hose is taken to a wall o tlet, a ventilation grill sho ld be
fitted to prevent reverse flow of cold air. Fit the ventilation grill to
the o tside or inside of the wall.
This appliance sho ld not be exha sted into a chimney, a wall, a
ceiling, or a concealed space of a b ilding. Only a metal ventilation
grill sho ld be sed.
Installation Examples

Specifications are subject to change without notice. See installation instructions for additional details.
22
ASKO DRYER
UNIT DIMENSIONS
U Metric
Height 33-1/2"–34-1/2 850–876 mm
Width 23-7/16" 595 mm
Depth 23-7/16" 595 mm
Weight 103 lb 47 kg
MODEL T781 CONDENSER DRYER
TECHNICAL DATA
S pply voltage Single-phase 230 V, 60 Hz
Heating element 2500 W
Internal F se 15 A
NOTE: When on a separate o tlet, se 220 V, 15 Amp
single-phase circ it. When an ASKO washer is
connected, se 220 V, 30 Amp single-phase circ it.
The door hinges on ASKO dryers are shipped left-hinged, b t they
are reversible. See the Dryer Use and Care G ide for more
information.
When placing the dryer next to a wall or cabinet, be s re to leave
1/2" (12 mm) of space between the dryer and the wall or cabinet.
See page 27 for stacked asher/dryer dimensions.
See pages 28–30 for cutout dimensions for closet and under-
cabinet installations.
Condensation Drain Requirements
If possible, yo sho ld install the dryer so the condensed water
will contin o sly flow into a drain or sink. To do this, follow the
instr ctions below:
1. Disconnect the short hose (1) from the bl e connection.
(It’s okay to let the hose hang down.)
2. Connect the r bber hose s pplied with the dryer to the bl e
nipple (2).
3. R n the hose to a drain or sink, as ill strated.
NOTE: The drain hose m st not be more than 40" above the floor
or the bottom of the nit.
Back of dryer
1
3
3
40"
(1016 mm)
maximum
height
2

Specifications are subject to change without notice. See installation instructions for additional details. 23
DIMENSIONS
U Metric
Height 67"–69" 1702–1753 mm
Width 23-7/16" 595mm
Depth 24-7/16" 621 mm
Weight 253–258 lbs 115–117 kg
WARNING Never stack a washer on top of a dryer
Any A KO dryer can be mounted on top of any matching
A KO washer. Stacking kits are packed inside the dryer. Refer
to the ASKO Dryer Use and Care Guide for stacking instr ctions.
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. When an ASKO washer is connected to the
dryer, se 220 V, 30 Amp single-phase circ it. When the dryer is
W6021/W6441 AND T701 VENTED DRYER
on a separate o tlet, se 220 V, 15 Amp single-phase circ it. If
the washer is sed separately or with another dryer, it m st be on
a separate 220 V, 20 Amp single-phase circ it.
When placing a stacked set next to a wall or cabinet, be s re to
leave 1/2" (12 mm) of space between the washer and the wall
or cabinet.
See page 18 for venting requirements.
See pages 29 for stacked cabinet or closet dimensions.
WARNING To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
ASKO STACKED LAUNDRY PAIRS

Specifications are subject to change without notice. See installation instructions for additional details.
24
ASKO STACKED LAUNDRY PAIRS
DIMENSIONS
U Metric
Height 67"–69" 1702–1753 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 270–275 lbs 122–125 kg
WARNING Never stack a washer on top of a dryer
Any A KO dryer can be mounted on top of any matching
A KO washer. Stacking kits are packed inside the dryer. Refer to
the ASKO Dryer Use and Care G ide for stacking instr ctions.
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. When an ASKO washer is connected to the
W6021/W6441 AND T721 CONDENSER DRYER
dryer, se 220 V, 30 Amp single-phase circ it. When the dryer is
on a separate o tlet, se 220 V, 15 Amp single-phase circ it. If
the washer is sed separately or with another dryer, it m st be
on a separate 220 V, 20 Amp single-phase circ it.
When placing a stacked pair next to a wall or cabinet, be s re to
leave 1/2" (12 mm) of space between the washer and the wall or
cabinet.
ASKO condenser dryers can be installed to contin o sly drain
thro gh a hose attached to the rear of the machine. To ensure
proper drainage, the drain must not be higher than 40" above
the bottom of the dryer.
See page 19 for condensation drain requirements.
See page 29 for stacked cabinet or closet installation
dimensions.

Specifications are subject to change without notice. See installation instructions for additional details. 25
W6441 AND T731 VENTED DRYER
ASKO STACKED LAUNDRY PAIRS
DIMENSIONS
U Metric
Height 67"–69" 1702–1753 mm
Width 23-7/16" 595mm
Depth 24-7/16" 621 mm
Weight 253–258 lbs 115–117 kg
WARNING Never stack a washer on top of a dryer
Any A KO dryer can be mounted on top of any matching
A KO washer. Stacking kits are packed inside the dryer. Refer
to the ASKO Dryer Use and Care Guide for stacking instr ctions.
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. When an ASKO washer is connected to the
dryer, se 220 V, 30 Amp single-phase circ it. When the dryer is
on a separate o tlet, se 220 V, 15 Amp single-phase circ it. If
the washer is sed separately or with another dryer, it m st be
on a separate 220 V, 20 Amp single-phase circ it.
When placing a stacked set next to a wall or cabinet, be s re to
leave 1/2" (12 mm) of space between the washer and the wall or
cabinet.
See page 20 for venting requirements.
See pages 29 for stacked cabinet or closet dimensions.
WARNING To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
Extra dry
Dry
Normal dry
Iron dry
Timed dry
Air fluff
Programs
Stain
Programs
Heavy
Normal
Perma
press
Quick
Super quick
Drain
Spin
Rinse
Hand/
Delicate
Wool

Specifications are subject to change without notice. See installation instructions for additional details.
26
DIMENSIONS
U Metric
Height 67"–69" 1702–1753 mm
Width 23-7/16" 595 mm
Depth 24-7/16" 621 mm
Weight 253–260 lbs 115–118 kg
WARNING Never stack a washer on top of a dryer
Any A KO dryer can be mounted on top of any matching
A KO washer. Stacking kits are packed inside the dryer. Refer
to the ASKO Dryer Use and Care Guide for stacking instr ctions.
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. When an ASKO washer is connected to the
dryer, se 220 V, 30 Amp single-phase circ it. When the dryer is
on a separate o tlet, se 220 V, 15 Amp single-phase circ it. If
the washer is sed separately or with another dryer, it m st be
on a separate 220 V, 20 Amp single-phase circ it.
When placing a stacked pair next to a wall or cabinet, be s re to
leave 1/2" (12 mm) of space between the washer and the wall or
cabinet.
See page 21 for venting requirements.
See page 29 for stacked cabinet or closet installation
dimensions.
WARNING To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
W6661 AND T761 VENTED DRYER
ASKO STACKED LAUNDRY PAIRS

Specifications are subject to change without notice. See installation instructions for additional details. 27
ASKO STACKED LAUNDRY PAIRS
DIMENSIONS
U Metric
Height 67"–69" 1702–1753 mm
Width 23-7/16" 595mm
Depth 24-7/16" 621 mm
Weight 270–277 lbs 122–126 kg
WARNING Never stack a washer on top of a dryer
Any A KO dryer can be mounted on top of any matching
A KO washer. Stacking kits are packed inside the dryer. Refer to
the ASKO Dryer Use and Care Guide for stacking instr ctions.
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. When an ASKO washer is connected to the
dryer, se 220 V, 30 Amp single-phase circ it. When the dryer is
on a separate o tlet, se 220 V, 15 Amp single-phase circ it. If
the washer is sed separately or with another dryer, it m st be on
a separate 220 V, 20 Amp single-phase circ it.
When placing a stacked pair next to a wall or cabinet, be s re to
leave 1/2" (12 mm) of space between the washer and the wall or
cabinet.
ASKO condenser dryers can be installed to contin o sly drain
thro gh a hose attached to the rear of the machine. To ensure
proper drainage, the drain must not be higher than 40" above
the bottom of the dryer.
See page 22 for condensation drain requirements.
See page 29 for stacked cabinet or closet installation
dimensions.
W6661 AND T781 CONDENSER DRYER

Specifications are subject to change without notice. See installation instructions for additional details.
28
ASKO LAUNDRY
CUTOUT DIMENSIONS
U Metric
Height 68" to 70" 1727 to 1778 mm
Width 24-1/2" minim m 622 mm
Depth 25" 635 mm
CONDENSER DRYER OPENING
ASKO condenser dryers can be installed to contin o sly drain
thro gh a hose attached to the rear of the machine.
To ensure proper drainage, the drain must not be higher
than 40" above the bottom of the dryer. See page 19 for
condensation drain requirements.
STACKED CABINET OR CLOSET INSTALLATIONS
ASKO’s front panel controls make it possible to install the washers
and dryers nder a cabinet or in a closet. Make s re there is a
1/2" (12 mm) minim m clearance between nits and between
nits and cabinet or wall. To ens re proper ventilation, we
recommend lo vered doors, partic larly for condenser dryers.
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. When an ASKO washer is connected to
the dryer, se 220 V, 30 Amp single-phase circ it. When the dryer
is on a separate o tlet, se 220 V, 15 Amp single-phase circ it. If
the washer is sed separately or with another dryer, it m st be on
a separate 220 V, 20 Amp single-phase circ it.
VENTED DRYER OPENING
T701 and T721 dryers can be vented from the rear or the left or
right side. The cabinet c to t ill strated below gives the dimensions
for a rear exha st. See page 18 for venting requirements.
WARNING To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
NOTE: To avoid crimping the electrical and water connections, do
not install the hook ps between the area of 26" to 35" from
the floor (as indicated by shaded area in ill strations above).
For stacked installations, we recommend a 6-foot cord.

Specifications are subject to change without notice. See installation instructions for additional details. 29
ASKO LAUNDRY
ASKO’s front panel controls make it possible to install the washers
and dryers nder a cabinet or in a closet. Make s re there is a
1/2" (12 mm) minim m clearance between nits and between
nits and cabinet or wall.
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. When an ASKO washer is connected to
the dryer, se 220 V, 30 Amp single-phase circ it. When the dryer
is on a separate o tlet, se 220 V, 15 Amp single-phase circ it. If
the washer is sed separately or with another dryer, it m st be on
a separate 220 V, 20 Amp single-phase circ it.
CUTOUT DIMENSIONS
U Metric
Height 34"–35" 863–889 mm
Width 24-1/2" minim m 622 mm
Depth 25" 635 mm
NOTE: For these installations, a c stom co ntertop may be req ired.
SINGLE UNIT CABINET INSTALLATIONS
WASHER OPENING
VENTED DRYER OPENING
ASKO vented dryers can be vented from the rear or the left or
right side. The cabinet c to t ill strated below gives the dimensions
for a rear or left exha st.
See page 18 for venting requirements.
CONDENSER DRYER OPENING
WARNING To reduce the risk of fire, vented dryers
must be exhausted OUTDOORS or the equivalent.
See page 18 for venting requirements.
Never cover the end of the dryer stub or vent hose with
anything to catch lint, except for a UL-approved vent
basket.
Condenser Dryers
ASKO condenser dryers can be installed to contin o sly drain
thro gh a hose attached to the rear of the machine. To ensure
proper drainage, the drain must not be higher than 40" above
the bottom of the dryer.
See page 19 for condensation drain requirements.

Specifications are subject to change without notice. See installation instructions for additional details.
30
ASKO LAUNDRY
CUTOUT DIMENSIONS
U Metric
Height 68" to 70" 1727 to 1778 mm
Width 24-1/2" minim m 622 mm
Depth 25" 635 mm
NOTE: For these installations, a c stom co ntertop may be req ired.
SIDE BY SIDE UNDER COUNTER INSTALLATIONS
ASKO’s front panel controls make it possible to install the washers
and dryers nder a cabinet or in a closet. Make s re there is a
1/2" (12 mm) minim m clearance between nits and between
nits and cabinet or wall.
Every ASKO washer is delivered ready-fitted with a pl g and is
intended for connection to an ASKO dryer, which is eq ipped with
a matching receptacle. When an ASKO washer is connected to
the dryer, se 220 V, 30 Amp single-phase circ it. When the dryer
is on a separate o tlet, se 220 V, 15 Amp single-phase circ it. If
the washer is sed separately or with another dryer, it m st be on
a separate 220 V, 20 Amp single-phase circ it.
NOTE: To avoid crimping the electrical and water
connections, do not install the hook ps between
the area of 26" to 35" from the floor.
OPENING FOR WASHER AND
VENTED DRYER
T701 and T721 dryers can be vented from the rear or the
left or right side. The cabinet c to t ill strated at right
gives the dimensions for a rear and left exha st. See
page 18 for venting requirements.
WARNING To reduce the risk of fire, vented
dryers must be exhausted OUTDOORS or the
equivalent.
Never cover the end of the dryer stub or vent
hose with anything to catch lint, except for a
UL-approved vent basket.
OPENING FOR WASHER AND
CONDENSER DRYER
ASKO condenser dryers can be installed to contin o sly
drain thro gh a hose attached to the rear of the machine.
To ensure proper drainage, the drain must not be
higher than 40" above the bottom of the dryer. See
page 19 for condensation drain requirements.

Specifications are subject to change without notice. See installation instructions for additional details. 31
OPTIONAL LAUNDRY ACCESSORIES
ASKO LAUNDRY
SLIDE OUT SHELF
Installs between stacked pair. Extends 15" from nits.
8061907-0 White
8061907-26 Black
STEEL LAUNDRY PLATFORM
Will raise a washer or a dryer (one machine per platform) 12" off the floor.
8052000 White
8052000-B Black
WHITE SPACE TRIM KIT
Installs between stacked pair to provide a single nit appearance.
8063981

ASKO Inc. • P.O. Box 851805 • Richardson, Texas 75085-1805 • Advisor Center: 800-898-1879
© ASKO Inc. 2002 Form 073017-0602
Underwriters Laboratories, Inc.
Printed on Recycled Paper
ASKO Inc. retains the right to vary the model specifications at any time. All facts were accurate at time of printing. Before purchasing any ASKO product, read important energy cost and efficiency information available from retailer.
BUILT TO LAST LONGER
www.askousa.com
THE AWARD JU T KEEP TACKING UP.
91% 0F HOUSEHOLDS
SAY ASKO IS QUIETEST.
Dishwashers selected by 91%
of homeowners as the quietest
in independent tests.
D1996FI Dishwasher
W660 Washer T760 Dryer
W660 and T760 for 2000 W600 for 2001
W6661 Washer T761 Dryer
2002
W660 Washer T760 Dryer
2000
★
★
★
★
★
★
ASKO dishwashers and washers
meet the Energy Star®requirements.
All ASKO products are covered
by the Good Housekeeping Seal.
1805 Dishwasher
Excellence In
Design Innovation
