Asko W6641 User manual

THE CONTROL PANEL
Models W6641 and W661 have ASKOs state-of-the-art EasyControl panel, as ill strated below. To select a wash program, simply press
one of the preset program b ttons then press Start. Refer to Preset Programs below for a definition of these programs.
Door Open Button
Press to open the
glass door.
Preset Programs
Press one of these buttons to
select a program.
LCD Window
Displays the wash program, spin speed,
temperature settings, and program run time.
Power Button
Press to turn on
power to the
machine.
Program Selection Controls
These buttons allow you to customize the preset program settings,
such as wash temperatures, spin speed, rinses, display language,
etc. Refer to the Use and Care Guide for instructions.
Power Indicator Light
Glows when the power
is turned on.
Start/Stop Button
Press to start or
stop a program.
Preset Programs
This model has fo r preset programs, as defined in the table below. To select a program, simply press one of the program b ttons then press Start.
Preset Wash Spin # of Short Long
Program Wash Cycle ypes of Laundry emp (1) Speed (1) (2) Rinses Spin Spin
P1 Light wash Normally soiled loads 140° F 1600 rpm (3) 5 2 yes
P2 Light wash Normally soiled perma press 105° F 1600 rpm (3) 5 2 yes
P3 Q ick wash Lightly soiled fabrics 105° F 1600 rpm (3) 3 0 yes
P4 Hand wash Washable silks, nylon, etc. 85° F 800 rpm 3 1 no
NOT S: (1) Yo can temporarily adj st the temperat re settings and spin speed. (See Temporary Program Changes below.)
(2) These are the maxim m spin speed settings allowed for the program.
(3) Model W640 has a maxim m spin speed of 1400 rpm.
Temporary Program Changes
Yo can make temporary changes to the wash temperat re and/or spin speed on the preset programs. Simply press the b tton for the preset
program yo want to se then follow the instr ctions below. The settings will revert to normal at the end of the program.
Temperature  Press ntil the desired temperat re displays in the LCD window. (The options are 85°, 105°, 120°, 140°, 160°, 175°, and
205°.) If yo also want to change the spin speed, read the following paragraph, otherwise, press Start.
Spin Speed  Press ntil the desired spin speed displays in the LCD window then press Start. (The spin speeds advance in 200 rpm
increments.)
Yo can easily c stomize the preset programs to best fit yo r la ndry needs. See C stomizing the Preset Programs in yo r Use and Care Guide.
Power Button
The Power b tton t rns the power to the machine on and off. When the power is on, the power indicator light glows red. The power m st be
on before yo can open the glass door, set the programs or start the machine.
Start/Stop Button
This b tton starts or stops a program. To stop a program, press and hold this b tton for a few seconds. If yo stop a program sing the Start/
Stop b tton, yo will have to reselect a program and press Start/Stop to restart the machine.
Door Open Button
If yo need to open the door d ring a program, press and hold Door Open for a few seconds. The machine will stop and a tomatically drain
eno gh water so the door can be opened safely. The program will res me when yo close the door. For instr ctions on how to open the door
man ally in case of power fail re, refer to yo r Use and Care Guide.
We know yo re excited abo t owning an ASKO washing machine and yo re anxio s to get started, so here is a brief s mmary of the
operating proced res. To get the most of the feat res of yo r machine, we recommend that yo read yo r Use and Care Guide.
Washer Quick Start Guide W6641/W6661

UNDERSTANDING THE LCD WINDOW
The LCD window is easy to read and nderstand. It displays the wash program selection along with the wash temperat re, spin speed, and
program r n time. The ill stration below explains what each item on the LCD window is.
rpm
Spin speed for the selected program.
Program ime
When you start a program, the total time
the program runs is displayed. As the
program progresses, the time remaining
displays. The program time toggles
between the hours (e.g., 1h) and the
minutes (e.g., 22).
emperature
Wash temperature for the
selected program.
Stop
Indicates that the program has ended
or that you pressed Stop.
Start
Indicates that you pressed Start
and the program is running.
Preset Programs
Displays the program that
is selected/running.
Program
When you press the Power button,
the display toggles between the
program numbers and the wash
program names, (e.g., Normal,
Super quick, etc.)
Door Open
Displays when you press
the Door Open button.
THE DETERGENT DRAWER
The detergent drawer on ASKO washers a tomatically dispenses the detergent and
fabric softener at the appropriate times. The drawer is located to the left of the control
panel. Simply p ll the drawer o t and po r the meas red amo nts of detergent and
softener into the proper compartments (as ill strated) and close the drawer.
If yo se liq id detergent, yo will need to se the main wash compartment partition
packaged with yo r washer. (See yo r Use and Care Guide.)
DETERGENT AND FABRIC SOFTENER AMOUNTS
Beca se ASKO washers se less water than conventional top-loading washers, yo need less detergent and fabric softener. We recommend
that yo se a low-s dsing powder detergent only, preferably a high-efficiency (HE) detergent designed specifically for front-loading washers.
(Liq id detergents tend to s ds more, which make them more diffic lt to rinse o t.)
Detergent  The amo nt of detergent needed varies, depending on the detergent yo se. For high-efficiency detergent specifically for
front-loading washers, yo sho ld se the amo nts recommended by the man fact rer. For reg lar la ndry detergent, 1 to 3 tablespoons of
detergent is all you need for a normal wash load. More heavily soiled items, however, may need slightly more detergent. Also, the amo nt
of detergent needed can vary d e to differences in water hardness. (Refer to yo r Use and Care Guide for more details.) If yo choose to se
a liq id detergent, start o t with a very small amo nt, s ch as one or two tablespoons.
Fabric Softener  We recommend that yo se only 2 tablespoons of fabric softener. If more softening is desired, try sing slightly more
with the next load.
Prewash detergent
Main wash
detergent
Fabric
softener
We recommend that you dont use bleach in your ASKO washer.
The t mbling wash action, temperat re control options and
extended wash times are s fficient to remove most stains.
NOTE:
The detergent drawer is equipped with an optional
child safety catch. (See your Use and Care Guide.)
Refer to yo r Use and Care Guide for additional programming and operational information as well as care and cleaning instr ctions.
QUICK START PROCEDURES
1.
2.
3.
4.
5.
6.
7.
Press the Power b tton to t rn on the machine.
Press the Door Open b tton to open the inner door and load the wash. (The door will open in a few seconds.)
Check that the door is clear of la ndry then close it firmly. (The door wont sh t if its slammed.)
Po r the detergent and fabric softener into the proper compartments in the detergent drawer, as ill strated below.
(Dont p t detergent in the prewash compartment nless yo plan to prewash.)
Close the detergent drawer sec rely. (Do not slam it closed.)
Press the b tton for the desired program. If desired, change the temperat re and/or spin speed.
Press Start. The machine will start.
W6641/W6661
Art. no. 80 646 41 Rev. 03
