Information for Safe Operation
1. Intended use of the device
Device applying High-frequency energy to human body to massage, etc.
2. Outline of the device
Using physical energy such as pressure and stimulation and applying
High-frequency energy to human body.
3. Risk of Explosion and Fire
Do not operate the equipment in the presence of volatile substances such as an
inflammable anesthetic mixture, alcohol, gasoline or solvent. Keep a fire extinguisher
around.
4. The Use of Suitable Power Supply and Power Plug
Use power supply and power plug in compliance with the specification of the
equipment. Use power plug in good condition.
Always disconnect a power cord by pulling a plug not a power cord.
5. Connection of Devices
This equipment is connected with a protective earth ground through the power
cord. Proper and sufficient grounding is essential for safe operation of the
equipment. Use only power strips with 3 prongs to maintain the best condition of
earth grounding.
6. Replacement of Fuse
User can replace a fuse located in the compartment beside of the power cord
socket. Only a qualified service personnel is allowed to access to the internal parts
of the equipment. Correct type and rating of fuse should be used for a safety
purpose.
7. Intended Operator
a) Education :
–. Junior college graduate or above
b) Knowledge :
–. Understand High frequency treatment
–. Understand hygiene
c) Language :
–. English (languages provided in user's manual), or literacy to properly understand
user's manual
d) Experience :
–. No particular experience required
e) Permissible impairments :
–. mild reading vision impairment or vision corrected to log MAR 0,2 (6/10 or 20/32)
–. 40% of disability causing 60% of normal hearing in the range of 500 Hz ~ 2 kHz
–. One hand to lead and hold the device

●
1. Main Body
Accessory : Handpiece(Large, Medium, Small), Power Cable
Handpiece
Handpiece Cale
Cradle of handpiece cable
Power and control button
LED Display
Logo
Ventilation part of cooling fan
DC Adapter socket
Vacuum pump filter
Cable socket
Cradle of handpiece cable
- 05-
Description of the device
Front Side
●
●
Rear Side

- 06 -
2. Handpiece
Description of the device
●Handpiece L
●Handpiece M
●Handpiece S

①
①
High frequency(RF) level up button : Increase the RF level step by step.
②
②
⑨
RF output display : Informs start of high frequency operation.
③
③ ⑥
⑪
⑩
⑧⑫
⑬
RF level down button : Decrease the RF level step by step.
④
④
RF output level display : Displays 1 to 10 level of high frequency output.
⑤
⑤ ⑦
Time display
⑦ Vacuum suction mode display
⑨ Vacuum suction level display
⑩ Vacuum level up button
⑪ Vacuum output display
⑫ Vacuum level down button
⑥ Time control button
⑧ Vacuum suction mode control button
⑬ Start/stop button
: Displays time of use.(It goes down by a minute from initial 15 minutes)
: Display vacuum suction mode in 3 types.
: Displays 1 to 4 level of vacuum suction.
: Increas the Vacuum level step by step.
: Informs start of Vacuum suction operation.
:Decrease the Vacuum level step by step.
: It can be controlled by 5 minutes from 5 to 60 minutes.
: Fast, slow, continous modes.
: Button to start/stop operation of device.
- White LED : ON
: OFF
: Error (disconnected handpiece cables)
- Blue LED
- Red LED
LCD Screen
- 07 -
Description of the function

- 08 -
Performance
1. Performance
① Rated Voltage & Rated Frequency : AC 220V , 50/60Hz
② Time display of operation : Time down counter by minute
③ Power consumption : 70VA
④ Protection type and level regarding electric shock : Ist Grade, BF type Equipment
⑤ Frequency : 500KHz ± 10%
⑥ Pulse Duration : 1.0㎲ ± 10%
⑦ Output voltage : Max. 45rms-V ± 10%
⑧ Output current : Max. 90mA ± 10%
⑨ Vacuum pressure : Max. 550mmHg ± 10%
⑩ Timer : 5 min.~60 min.
2. Product Specification
3. Environment Condition
Model BOTEM CUBE / ABC-01P
240(Length) X 250(Width) X 170(Depth)
Weight 5kg/set
0.5MHz
Max. 90mA
Max. 550mmHg
220V/50-60Hz
Frequency
Output current
Output current
Rated Voltage &
Rated Frequency
Size(mm)
① Temperature : 0~40 ℃
② Humidity : 20~80 %
③ Air pressure : 500~1060 hPa

1. Connection of handpiece cable
①
Connect one plug of handpiece cable to the connector
socket of the main body.
②
Connect the plug and socket at the right position of connection and
complete the connection by turning the connector cap to the
screw locking direction.
2. Connection of handpiece
① Connect the handpieces to the cable and screw locking direction.
② Check and complete the connection as the same as #1.
4. Power switch conditions
①
☞ Power LED light colors
White : ON
Blue : OFF
Red : Error (disconnected the handpiece cables)
When turn on upon pressing power button,
white LED light is shown.
3. Connection of power switch
①
①
Connect the DC adapter into the power socket at the back of
main body.
②②
④⑤
Connect both sides.
③
③
Connect the power socket and power cord at the back of
main body to AC 220V/100V outlet.
④
Display the blue LED light when the connection is correctly.
⑤
hen the connection is normal, the logo sign is flickering.
(파란색 램프)
(하얀색 램프)
(하얀색 램프)
- 09 -
Operation of the device

5. Control of time settings
①
Setting the time by the time control buttons when the power is on.
②
Increase 5 times each pressing the time button up to 60 minutes.
(5,10,15,20 ~ 55,60)
6. Control of High frequency output
①
When press the level up button(▲),
the RF output levels up step by step.
(The handpiece LED is on and the time decreased per a minute)
②
The RF level is from 1 to 10 controlled by (▲), (▼) buttons.
7. Control of vacuum suction pressure
①
When press the level up button(▲),
the Vacuum suction levels up step by step.
(In the condition of Vacuum suction only, the LED is off and the
time decreased er a minute)
②
The Vacuum suction level is from 1 to 4 controlled by (▲), (▼) buttons.
3 modes for Vacuum suction pressure (fact, slow, continues)
by controlling the mode control button.
③
- 10 -
8. Power off
① The device goes back to initial mode (the mode when it is powered)
(The the power off = the blue LED light)
② Setting values are maintained and operation stops upon pressing
Start/Stop button during treatment and operation restarts upon pressing
Start/Stop button again .
Operation of the device

3. Clean of the main body
① Clean the main body with soft cloth.
② Do not clean it with water or organic solvent (thinner, benzene, etc).
4. Clean of the handpieces
① Clean the head of handpiece thoroughly with alcohol.
② Clean the edge of handpiece and passage to
vacuum suction with cotton swab.
③ Prevent skin infection through cleaning the device after every use.
2. Clean of the power socket and the adapter socket
① Check if there is dust or foreign substance when connecting
power cable into power socket and the adapter socket.
② If any, remove dust and foreign substance with soft brush.
- 11 -
1. Maintenance after treatment
① Disconnect the DC adapter from the power socket
and the power cord.
③ Vacuum pump filter at the back of main body should be
regularly checked and cleaned to remove foreign substances.
② Disconnect handpiece from the cable and clean it with alcohol,
cotton swab and soft cloth for maintenance.
Storage and Maintenance after use

6. Storage method
① Avoid direct sunlight.
② Avoid where heat is generated with inflammable materials.
③ Separate from chemicals.
④ Unplug the device when it is not used.
⑤ Avoid dust and foreign substance.
⑥ Avoid humidity and keep in a place where it is not exposed to water.
- 12 -
5. Clean of the vacuum pump filter
① Frequently check if filter is full of foreign substance at the
back of main body.
②
If the filter is full enough, turn the filter to the right.
③ Clean the filter thoroughly.
④ Reassemble the filter clearly.
Storage and Maintenance after use

Warning : Matters that can incur serious danger such as death or serious injury
Caution : Matters that can incur slight injury or potential danger
- Make sure to understand and observe 'Safety Warning' since it is to prevent any accident or risk in advance
through right and safe use of the device.
- 'Safety Warning' includes all cautions both before and during use.
- 'Safety Warning' is divided into 'Warning' and 'Caution,' which means as follows.
Warning
Stop using the device when power cord or power plug is
damaged or shaken.
* It can cause electric shock or fire.
* Replace the power cord and power plug immediately.
Use the device only with the supplied DC adapter and
power cord and do not simultaneously use
different plugs in one outlet.
* Wrong voltage and current rating can cause electric shock or fire.
* Using a transformer can cause electric shock or fire.
- 13 -
Hold the power plug when unplugging it.
* Pulling the plug out by force can cause electric shock or fire
due to abnormality of power cord.
Safety Warning

Warning
Clean the power cord and power plug
with dry cloth when it is contaminated.
* Dust or pollutant can cause electric shock or fire.
Do not bend, tie or pull the power cord by force.
Dry your hand when plugging in and eliminating the power cord.
* It can cause electric shock or fire due to short circuit.
* Holding the power plug with wet hand can cause electric shock or fire.
* Do not disassemble the adapter, and it can cause electric shock,
fire or explosion.
Do not disassemble or arbitrarily alter the device.
* The device should not be disassembled or arbitrarily altered by
anyone other than service engineer.
* It can cause abnormality or breakdown of the device.
- 14 -
Do not install or use the device in a place with
inflammable materials or danger of explosion.
* It can cause electric shock, fire or explosion.
Safety Warning

Warning
Start treatment with high frequency and
vacuum suction from low level.
* It can cause injury.
Do not use the device in a bathroom or a place
with high humidity.
* It can cause electric shock or fire due to short circuit.
Only use the RF cream for the skin care or massage the body.
* It can cause injury.
Do not use high frequency or vacuum suction on
wound, lips, eye or ear.
* It can cause injury.
- 15 -
Do not apply high frequency or vacuum
suction at a single spot.
* It can cause burn or injury.
* Do not exceed a second as to treatment at a single spot.
Safety Warning

Warning
Do not bend or pull the handpiece cable by force.
* It can cause injury or breakdown of the device.
Do not use with other inductive electric appliances.
* It can cause breakdown of the device.
Do not apply to children and keep and use it out of the
reach of children.
* It can cause injury, electric shock or fire.
Stop using the device and immediately
contact to the service center
when it makes strange sound, smell or smoke.
* It can cause electric shock or fire.
- 16 -
Disconnect the power plug unless the device is being used.
* It can cause electric shock, short circuit or fire.
Safety Warning

Caution
Do not apply excessive force on the device when installing it.
* It can cause breakdown of the device.
Install the device on flat and hard floor.
* It can cause vibration or noise.
* It can cause breakdown of the device.
Install the device for the back side of main body not to
lean against the wall.
* It can cause breakdown of the device.
* Install the device at least 20cm off from the wall.
Apply the handpiece head into skin as close as possible.
* It can cause injury.
•
- 17 -
Do not disconnect the power plug and DC adapter or
move the device during operation.
* It can cause injury or breakdown of the device.
Safety Warning

Caution
Check for abnormal operation or damage of
handpiece before contact with skin.
* It can cause burn or injury.
Lower the high frequency and vacuum suction level
when a patient complains of pain during use.
* It can cause burn or breakdown of the device.
Stop using the device immediately
when any abnormality on skin is detected.
* It can cause burn or breakdown of the device.
Clean the handpiece head and hole with
cotton swab and soft cloth and sterilize them
with alcohol after use.
* It can cause infection or side effects.
* It can cause breakdown of the device.
- 18 -
Check the filter at the back side and
if any foreign substance is detected,
clean the device after use.
* It can cause breakdown of the device.
* It is recommended to regularly clean the filter.
Safety Warning

Caution
Keep the handpiece, handpiece cable, main body and
power cord separately after cleaning the device.
* It can cause breakdown of the device.
When the device is of abnormality or does not work,
read through 'Checklist before after-sales service request' and
contact to the service center if the problem you have is not subject to any item.
Use the handpiece after checking the label. As to handpiece,
what is provided by the company should only be used.
Do not use the device in the same place where there is equipment
generating strong electromagnetic wave (e.g. X-ray, MRI, etc).
☞ Contact : Asnac Corp., Service Center : 051-634-2929
- 19 -
Safety Warning

Do not use the device under conditions below.
- Children
- Pregnant woman
- Disease (Heart disease, Skin disease, Liver disease, Kidney disease, Malignant tumor , Cancer, Diabetes)
- Abnormal blood pressure
- Perceptual disorder
- Patient with infectious disease
- hose who are taking medicine for infection
- Sensitive Skin
- Hypertrophic scar
- Those who are with implantable medical devices
(people with implantable medical device which affects to electromagnetic waves such as implantable cardiac pacemaker,
implantable defibrillator, implantable electronic stimulator for medical use, implantable electronic urination suppressor, etc.)
- 20 -
When the device cannot be used
