Asoni SVR611 User manual

H.264 Network Video Transceiver
SVR611 / SVR611W / SVR611-PoE
User’s Manual
Date: 7/20/2012
Firmware Version: TV1.0.16

1
Content
Content .......................................................................................................................................1
1. Preface.................................................................................................................................3
2. Product Specifications.......................................................................................................3
3. Product Installation ............................................................................................................6
A. Hardware Installation......................................................................................................6
Cable Connections................................................................................................................6
I/O Connections....................................................................................................................8
B. Monitor Setting..............................................................................................................10
C. IP Assignment................................................................................................................11
4. Live Video..........................................................................................................................13
5. Configuration ....................................................................................................................18
A. System ...........................................................................................................................18
System Information.............................................................................................................18
User Management..............................................................................................................21
System Upgrade.................................................................................................................23
System Logs.......................................................................................................................24
B. Video/Audio Setting ......................................................................................................25
Video Format ......................................................................................................................25
Image Setting......................................................................................................................28
Audio Setting ......................................................................................................................29
Receiver Setting .................................................................................................................30
C. Network Setting.............................................................................................................34
Network Setting ..................................................................................................................34
Wireless Setting..................................................................................................................36
Mail & FTP Setting..............................................................................................................39
PPPoE Setting....................................................................................................................41
DDNS Setting .....................................................................................................................42
D. Event Handling..............................................................................................................44
Event Setting ......................................................................................................................44
I/O Setting...........................................................................................................................50
Schedule.............................................................................................................................52

2
SD Card..............................................................................................................................54
6. Network Configuration.....................................................................................................56
A. Intranet Only..................................................................................................................56
Connects to PC Directly......................................................................................................56
Connects to an Exist LAN...................................................................................................57
B. Internet Only..................................................................................................................58
Connects to ADSL with Fixed Public IP Address.................................................................58
Connects to ADSL with Floating Public IP Address (PPPoE)..............................................59
C. Intranet + Internet..........................................................................................................61
Connects to Internet with Fixed Public IPAddress..............................................................61
Connects to Internet with Floating Public IPAddress..........................................................63
7. Factory Default..................................................................................................................64
Compatible List of SD Card.....................................................................................................65

3
1. Preface
This device is a 1 channel video transceiver provides function which is a combination of
Video Server and Video Decoder.
As a Video Server, It encodes analogue signals of traditional cameras to digital signals;
user can monitor real-time video via IE browser. It supports H.264, JPEG and MPEG4
(3GPP Only) video compression which provides smooth and high quality video. The video
can be stored in the SD card, and can be playback remotely by Microsoft Windows Media
Player.
As a Video Decoder, user can use this device to decode the video/audio of our network
camera and video server over network, and transfer analogue signals to TVs, CRT
monitors or DVR systems.
The PoE model built-in support for Power over Ethernet allows the video server to receive
both data and power over a single Ethernet cable.
2. Product Specifications
H.264 / MJPEG / MPEG4 (3GPP Only) compression formats. Supports resolution up
to 30/25 fps @ Full D1 (720x480 / 720x576)
H.264 / MJPEG / MPEG4 (3GPP Only) triple streaming.
Decode digital video/audio from remote network devices, and output to analog monitor
or DVR.
Available decode compression format: H.264 / MJPEG / MPEG4.
Available decode resolution: up to Full-D1 (NTSC: 720x480, PAL: 720x576)
Self-Contained HTTP Web Server providing Internet capability for remote access
Wireless network connection (Wireless model)
Built-in PoE splitter, support for Power over Ethernet (PoE model)
Supports SD card for local recording
2-way audio
RS-485 connection for remote Pan/Tilt/Zoom control
Online firmware upgrade
Recorded files compatible with Microsoft Windows Media Player

4
Hardware
CPU / RAM / ROM ARM 9, 32 bit RISC / 256MB / 16MB
Video In (Encode) 1 Analog video input (BNC connector)
Video Out (Decode) 1 Analog video output (BNC connector)
Audio In (Encode) 1Analog video input for encode (RCAconnector)
Audio Out 1 Analog video output (RCA connector) for:
Hear the voice from remote PC user
Output the decoded audio of IP camera (when enable the “Audio
Encode” function)
Audio In / Out 1 Line in/ 1 Line out (RCA connectors)
Digital I/O 2 Digital in / 2 Relay out
RS-485 1, for PTZ control
Power Supply Normal & Wireless model: DC 12V, 1A
PoE model (built-in PoE Splitter):
Use PoE: PoE Injector (IEEE 802.3af)
Or, use Power Adaptor: DC 12V, 1A
Power Consumption Max. 4 Watt
Dimensions W134 x H42 x D107 mm
Network
Ethernet 10/ 100 Base-T
Wireless (Wireless model) 802.11b/g, supports WPA-PSK, WPA2-PSK, WEP 64/ 128 bit
Network Protocol HTTP, TCP/IP, RTP/RTSP, 3GPP, SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP
Video Encoding
Video Resolution NTSC: 720x480, 704x480, 352x240, 176x120
PAL: 720x576, 704x576, 352x288, 176x144
Compression Format H.264 / MJPEG / MPEG-4 (3GPP only)
Frame Rate Up to 30 FPS
Triple Streaming Yes (2 for live view, 1 for 3GPP)
3GPP Yes, Live view with 3G mobile phone
Video Bitrate Adjustment CBR, VBR
Video Adjustment Brightness, Contrast, Hue, Saturation, Sharpness
Image Snapshot Yes
Privacy Mask Yes, 3 different areas
Motion Detection Yes, 3 different areas
Event Trigger Motion Detection, Digital In
Triggered Action Send Email, Send to FTP, Save to SD Card, Relay Out
Pre/ Post Alarm Yes, configurable

5
Remote PTZ Control Yes, via RS-485
Security Password protection
Firmware Upgrade HTTP mode, can be upgraded remotely
Connection Up to 10 clients simultaneously
Audio When “Audio Encode” function is disabled: 2-way
When “Audio Encode” function is enabled: 1-way (receive)
Video Decoding
Video Output Resolution Up to 720x480 (NTSC) / 720x576 (PAL)
Decompression Format H.264 / MPEG-4 / MJPEG
Audio Decoding Yes
Output OSD Yes
Decoded Device IP Camera, Video Server
SD card management
Recording Trigger Motion Detection, Digital In, IP Check, Network Disconnect
Schedule Snapshot with schedule
Video Format Video (AVI), Snapshot (JPEG)
Video Playback Yes
Web browsing requirement
OS Windows 2000, XP, Vista, Windows 7
Web Browser Microsoft IE V7.0 (32-bit) or above, Mozilla Firefox V5.0 or above, Opera V10
or above, Safari V4.0.5 or above, Google Chrome V5.0 or above
Suggested Hardware Intel Core 2 Duo 1.66GHz, RAM: 1GB
Graphic card: 128MB onboard RAM
* Specifications are subject to change without notice

6
3. Product Installation
A. Hardware Installation
Cable Connections
Network Connector:
The RJ-45 connector allows connect the Ethernet cable.
Power Jack:
To connect the included power adapter.
Video Out: The BNC connector allows connect to the analog display to
output decoded analog video for locally monitoring.

Video In: The BNC connector allows connect to the video signal of an
analog camera for encode.

Audio Out: The RCAconnector allows connect to an amplified speaker,
and then hear the voice of:
When “Audio Encode” function is disabled in Configuration
Video/Audio Receiver Setting : you can hear the
voice of the remote PC user.











7
When “Audio Encode” function is enabled in Configuration
Video/Audio Receiver Setting : you can hear the
voice of the decoded IP camera or video server.

Audio In: The RCAconnector allows connect to a microphone or audio
source, the voice will be encoded and
transferred to the remote
site via network.
RS-485 Connector:
This terminal block allows connect to a PTZ device.

Antenna Connector: Available for Wireless model. To connect the included wireless
antenna.

SD Card Slot: Insert a SD card if you want to do the event recording (Video
only) in the video transceiver.
Digital I/O:
Digital In and Relay Out.
1. If you want to use the “Encoder” function, connect the video and audio outputs of
analog camera to “Video In” and “Audio In” connectors. If the analog camera is a PTZ
device, connect the RS-485 for the remote PTZ control.
2. If you want to use the “Decoder” function, connect the “Video Out” connector to an
analog monitor or DVR, and connect the “Audio Out” connector to an amplified
speaker or DVR.
3. Connect the cable of Digital I/O if you want to use this functionality.
4. Connect the wireless antenna for the Wireless model.
5. Connect Ethernet cable for network connection.
6. Connect power adapter to turn on the device.
7. If the device is PoE model, the power adapter is not necessary. The device will get the
power from the PoE injector or PoE switch.
PoE (Power over Ethernet) is a technology that integrates power into a standard LAN
infrastructure. It enables power to be provided to the network device, such as an IP
phone or a network camera, using the same cable as that used for network connection.
It eliminates the need for power outlets at the camera locations. Please follow the
below figure for the connection.

8
8. Set up the network configurations according to the network environment. For further
explanation, please refer to Network Configuration chapter.
9. After finish the configuration for the very first time, if you want to use wireless network,
plug out the Ethernet cable.
I/O Connections
I/O terminal connector – used in application, for e.g., motion detection, event triggering,
alarm notifications. It provides the interface to:
2 sets of Digital Input (Alarm In + GND) – The digital inputs for connecting devices
that can toggle between an open and closed circuit, such as PIRs, door/window
contacts, glass break detectors, etc. When a signal is received the status changes
and the input becomes active.
2 sets of Relay Output (N.O. + COM or N.C. + COM) –The output to Relay switch
of the alarm device such as LEDs, Sirens, etc.
Alarm In Relay Out
PoE Switch or PoE Injector
Ethernet Cable
Data only
Ethernet Cable
Mixed data and power
PoE Network Video Server
To Network

9
Digital Input (Alarm Input)
GND (Ground): Initial status is LOW.
Alarm: Max. 50mA, 12VDC.
Relay output
COM: Common pin.
N.O. (Normally Open): Max. 1A / 24VDC or 0.5A / 125VAC.
N.C. (Normally Close): Max. 1A / 24VDC or 0.5A / 125VAC.
Door/Window
Contacts
