ASP Allegro Specification sheet

Operation and installation manual - ASP Allegro
Allegro

1
1 Scope of delivery 2
2 General warnings / Notes on safety 2
3 Unpacking the unit 5
4 Function, technology 5
5 General information 6
6 Installation 6
7 Connecting the inverter 7
8 Information´s for operation 8
9 Status LED-display 9
10 Fault clearance 12
11 Warranty (short form) 13
12 Technical Data ASP Allegro 08/12 13
Technical Data ASP Allegro 10/24 14
13 Glossary 15
Table of content

2
1 Scope of delivery
• ASP Allegro
• Operation and installation manual
• AC connector
2 General warnings / Notes on safety
Congratulations on your purchase of a ASP Allegro sinewave inverter. You’ve become the owner
of the nest engineered, highest quality sinewave inverter. We have dedicated our products, our
services and ourselves to the satisfaction of every customer.
This manual for installation and operation contains important information’s about this unit. Please
familiarise yourself with all the information’s contained in these instructions before installing and
operating this unit. This will help you to acquaint yourself properly with this unit and make full use of
its advanced technical features under all operating conditions.
Should you encounter problems while installing or running this unit, please contact the dealer you
purchased the unit from or a dealer authorised by asp ag.
Improper assembly, installation and maintenance may impair the safety and function of this unit. For
this reason make sure that you understand all the information’s in this manual before beginning the
assembly and installation procedure.
Safety Symbols
Safety symbols mark passages in the text, which you absolutely need to read and consider.
• Consider these warnings
• Behave in such cases particularly carefully
• Inform other users about these dangers
Warning of dangerous electrical voltage
Ignoring this warning can lead to heavy bodily injury or to death.
Warning of a danger
Ignoring this warning can lead to heavy bodily injury or to damage.
Warning of hot surface
Ignoring this warning can lead to burns or to damage.
© Copyright – asp ag advanced solar products - All rights reserved.
This manual accompanies our equipment for use by the end users. The technical instructions and illustrations contained in this manu-
al are to be treated as condential and no part may be reproduced without the prior written permission of asp ag advanced solar pro-
ducts Service engineers and end users may not divulge the information contained herein or use this manual for purposes other than
those strictly connected with correct use of the equipment. All information and specications are subject to change without notice.

3
Safety Instructions
• In principle the general regulations for security and accident prevention are valid for operating
and handling the inverter.
• The equipment was built and examined in accordance with the safety regulations for electri-
cal devices. In order to guarantee a safe handling, the safety instruction must be considered,
which are contained in this manual.
• For any works on equipment and electrical connections the national and regional regulations
are valid concerning grounding, protective ground and lightning protection.
• Any Work on equipment and electrical connections may be carried out only by electrical spe-
cialists. An electrical specialist has the necessary technical training and knowledge to avoid
dangers by electricity.
Warning! In this unit potential differences of up to 1000V occur during operation and
can result in death or serious bodily injury. Use extreme caution while operating and
always observe precautions as: The unit must be connected by a professional elec-
trician only.
Only specially trained maintenance and service personnel are permitted to test and repair this unit.
These personnel further must be familiar with this manual and all domestic regulations.
Safe handling of this inverter is only ensured by correct installation and mounting
according to regional valid regulations. Carefully follow the lightning protection regu-
lations!
Any work performed on this unit, its installation and electrical connection must be carried out in com-
pliance with national electric codes and local regulations, which may deviate from those contained
herein. Refer to responsible authorities for relevant information’s.
No AC-generator or power supply is allowed to connect to this unit. Connecting
mains power, AC-Generator or any other inverter to AC-output will damage the
unit immediately. Excess voltage applied to the inputs and outputs may result in
destruction of the unit. Charging the battery with a dynamo while the inverter is
connected to the battery, the inverter may be damaged. Please ask your dealer
if you have any questions.
Take care of regulations for lightning protection. The unit is tested by the manufacturer and it is not
allowed to change anything! Without a written permission of asp ag advanced solar products you
will lose warranty if you repair the unit. Please refer to the warranty information’s.
Operate the device only when all factory-supplied covers are available and in place.
Temperatures at the enclosure of the device may be as high as 80 degrees C during
operation. Obstruction of the ventilation of the unit may result in overheating and
thus in failure of the unit. Always keep the unit and the ventilation slots clean. Do not
cover up or place any item on ventilation holes or cooling components.
Please note the permissible ambient conditions for operating the unit.
Automatic restart of the unit may occur after fault clearance.
Please note that also under standby operation, 230V test voltage pulses are present at the inverter
AC-output. The inverter is still ready to run. To be sure that the unit is completely switched off, you
have to switch the main circuit breaker in OFF-position or disconnect the battery.

4
Warning! Inbuilt, large electrolytic capacitors will hold DC-voltage for extended peri-
ods. Do not use any measuring equipment damaged or defective.
Contact with energised parts can result in serious or fatal injury. Please note that,
even under excessively light load or in stand by operation, high voltage can be pre-
sent at the AC-output.
Limitation of liability
Since neither the observance of these instructions for installation and operation, nor the conditions
and methods of installation, operation, utilisation and maintenance of the unit can be supervised by
asp ag advanced solar products, we don’t assume any responsibility or liability for loss, damage or
costs arising from using this unit or in any way connected with faulty installation, improper opera-
tion or incorrect utilisation and maintenance. Furthermore we don’t assume any responsibility for
infringement of patent rights or violations of the rights of third parties arising from the utilisation of
this unit. We reserve the right to make product changes, change technical specications or these
instructions without prior notice.
Important: Please be informed that units without CE-declaration can only be used on your own
liability in Europe countries. If you have a unit without CE please contact your local dealer.
WARNING! Unauthorised repairs and operation of this device for any use other than that for which it
was intended will result in loss of warranty. If you have problems with the unit asp ag advanced solar
products will provide you with the authorisation necessary to return or repair a unit.
Environmental protection
Recycling raw materials instead of waste disposal. This unit is built from valuable
materials and is easy to recycle. The unit, accessories and packaging should be
sorted for environment-friendly recycling. Please keep packaging for retransport
the inverter later. To prevent damage during transport we have to use and bill you
a new packaging if we receive the unit not with original packaging.
Maintenance and Spare parts
This unit is maintenance-free.
Proper functioning of the unit and electrical connections must be inspected at regular intervals - we
recommend once a year - by trained electrical specialists. The routine inspection should include the
entire electrical system. Should malfunctions of the unit occur despite these inspections, the unit
must be returned to the manufacturer for repair. Original spare parts are only available from asp ag
advanced solar products. asp ag will provide you with the authorisation necessary to return a unit
for repair. Before you call please prepare you for the following questions: Type of unit, DC-voltage,
manufacturing date, date of purchase, kind of fault, connected loads.

5
3 Unpacking the unit
Please check if the unit has no visible damage. If the unit is damaged you must inform your dealer
within 3 days after receiving the unit.
4 Function, technology
This inverter is designed to convert DC-battery voltage (direct voltage) to 230V AC (sinusoidal al-
ternating voltage). Voltage controlled, the inverter provides a stabilised, crystal-accurate alternating
230V/50Hz voltage (different voltages and frequencies refer to the indication label). With a sine-
wave inverter almost any type of electric consumer may be connected as for example energy saving
lights, uorescent tubes, computers, Radio- and HIFI-equipment and other household appliances,
freezers, pumps, motors etc. Due to a high degree built-in safety, excellent dynamic response, a
surge-proof and overload-proof output, it is very simple to operate a broad range of applications.
The „heart“ of the inverter is a very powerful RISC-microprocessor of the latest generation. This
microprocessor is responsible for the real time computing of the output sine-wave shape, for the
process control of the output voltage, for the supervision of the battery (dynamic) and the inverter
temperature. The power stage features modern Power Mosfet transistors. These transistors are the
key to the high partial-load efciency and superb overload capability. The power transistors are pro-
tected by independent intelligent protection circuits. The inverter is further more protected against
DC-over voltage (static) and short circuit on AC-output. The battery input side is equipped with a
thermal/magnetic circuit breaker to protect of your system.
FET Control
FET - bridge PWM Filter Transformer
AC-low AC-high
AC Line
Uac, Fac
Udc, Idc, Pdc
Microprocessors
MPPT
FET drives
Startup logic
Temp. supervision
Data output/Remote ON,OFF
Batterie
+
RS 232
LED-Display
10M
10M
Input
capacitors
and DC-Filter
+
_
Thermisch/Magnetischer
Schutzschalter
AC-Filter
Block daigram

6
6 Installation
Safety Instructions
5 General information
Always check the power draw of your appliances. Electrical equipment as motors, pumps, compres-
sors etc. need more power while starting up. Start up power draw can be much higher than Pnom.
For these applications the inverter is able to supply up to 300% surge power for a short time. Be
careful if you use pumps. Power declaration on pumps is normally not the electrical input power of
the pump! The inverter switches off automatically if surge power is too high. If ambient temperature
is higher than 20° C, Pnom and overload capability of the inverter will be reduced. Due to reduced
cooling capacity, Pnom of the inverter is reduced if operation altitude is above 900m ASL. Reduction
of Pnom is approx. 1.5% per every additional 100m more altitude. Example: If a 1000VA inverter is
installed as high as 2500m ASL maximal Pnom will be at 780VA only! If you use more power, over-
heating and associated premature disconnection of the inverter must be anticipated. If you use the
inverter under above conditions we recommend using a well over dimensioned inverter.
• Be sure the points demanded under „safety regulations“ are obeyed.
• Install the unit in a dry place. The unit is not designed for outdoor use.
• Adequate ventilation. Keep min. 10cm distance to other objects (except mounting
side). Do not cover heat sink!
The selection of a safe location for installing the inverter depends on the following criteria:
• Check indication label for correct DC-Voltage and AC-Voltage.
• The inverter can be used in any position.
• Protection from unauthorised access in particular of children’s.
• Dry, dust free surroundings (max. 95% humidity, not condensing).
• Short distance between battery and inverter. Use a grounded metal pipe to reduce RFI emissi-
on and to prevent surroundings of re. The inverter should not be mounted in the same room
as the batteries are (gas of the batteries during charging).
• Adequate ventilation. Keep min. 10cm distance to other objects (except mounting side).
• Battery capacity must be at least 200Ah. Using a smaller battery may reduce performance of
the unit.
• If other DC-units are installed at the same battery, contact your dealer for more information’s
• Protection of inverter and battery from the effects of water.
• Temperature range –25°C to +50 degrees C.
• Only specially trained maintenance and service personnel are permitted to test this unit. These
personnel further must be familiar with this manual and all domestic regulations before instal-
ling this unit.

7
ON
OFF
DC-BATTERY +DC-BATTERY -
Transformer
4 x mounting hole
7 Connecting the inverter
Safety Instructions
• Be sure the points demanded under „safety regulations“ are obeyed.
• Check whether the intended solar generator voltage corresponds properly with
the type-label on the unit itself.
• Any electrical connections must be carried out by an electrical specialist.
• The large input capacitors may still be charged even if DC-cables are disconnec-
ted and DC-switches are in OFF position!
The DC-circuit breaker must be turned to OFF-Position. Note: Inbuilt, large capacitors will hold DC-
Voltage for extended periods. They still can have DC-Voltage even when the switch is in off position
and the DC-Cables are disconnected from the battery! First make AC-Connections. Connect your
load with enclosed connector to the inverters AC-Output. An additional AC-Circuit breaker (size re-
fer to datasheet) has to be installed. We recommend installing an earth leakage protector for protec-
tion of personnel. Please observe domestic regulations when making connections! To connect the
Battery to the inverter uses a wire with minimum cross section of 25mm2. An additional DC-breaker
must be installed direct at the battery. Before connecting the cables to the battery make sure that
the polarity is correct! Applying of wrong polarity may damage the inverter.
NOTE: Please exercise extreme care when connecting the unit to a battery. Otherwise the inverter
or the battery could be damaged!

8
Take care of correct grounding of the inverter and your equipment that is connected to the inverter!
We recommend using an earth cable with minimum cross section of 10mm2to ground the inverter.
This will help to protect your unit in case of lightning. Be sure to meet all regulations about lightning
protection! Check again to make sure all cables are securely connected. Switch on the DC-Circuit
breaker. The inverter is now ready to operate.
8 Information’s for operation
Security advices
• Be sure that all demands written in the topic „safety regulations“ are kept.
• If DC voltage is out of range longer then 5 sec., the inverter switches off auto-
matically, LED indication “LOW BATERY” ashes red. Caution: As soon as DC
voltage is back in tolerance the inverter switches automatically on again.
• If AC voltage is out of range, LED indication “AC-OUTPUT” turns to red. The
inverter switches off automatically and indication “AC-OUTPUT” ashes red.
Caution: After approx. 20 sec. the inverter tries to switch on automatically again.
• Each time a fault occurs, the inverter restarts automatically after 20 seconds or if
the parameters (for example temperature) are back in normal conditions after a
fault. Time before the unit starts again can be from a few seconds to a few hours!
Always switch off the unit if you work at your system or electric consumer.
• For any manipulations and works on the electrical facility or AC-load, always
cut off the inverter from the battery (turn DC-switch rsp. circuit breaker to OFF
position).
• Inverter heat sink may be very hot, do not touch surface to reduce the risk of
burns.
Protect your inverter from rain. The unit is not designed to be used outdoor.
The DC-input breaker should be in „ON“-position all the time. In case of an error it will switch of
automatically. If the inverter is switched off (by turning the potentiometer fully counter clockwise) it
still needs app. 25mA from the battery. The inverter is electronically short circuit protected at the AC-
Output. DC input of the inverter is monitored for over voltage and under voltage. The upper limit is
static. If DC-Voltage is too high the inverter will switch off. Automatic restart follows after DC-Voltage
is in the normal range. The lower limit is dynamic (cut off voltage is lower if a big load is in use). This
allows an optimal use of the battery capacity and protects your battery during small load operation.
Important: If the inverter has switched off automatically it still needs very little power from the
battery!
Important: Always before you switch on the circuit breaker you must switch off the load.
The fan is controlled by temperature and power needed. It is helping to reduce problems of over-
heating.
