aspenhome I91-332 User manual

07-20-2017
Page1/1
ITEMNO:I91-332DoorBookcase
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference. FORINDOORUSEONLY
FUNCTIONALITY INSTRUCTION
I91-333OpenBookcase
I91-332 I91-333
COMPONENTS LIST:I91-332/333
No. Description Sketch Quantity
1LeftCrownMolding 1PC
2RightCrownMolding 1PC
3LeftMiddle Molding 1PC
4Right Middle Molding 1PC
5LeftBottomMolding 1PC
6RightBottomMolding 1PC
STEP2:Attachthe
moldingstocase.
Ifyouprefertoadjusttheshelf
location,removethescrewsand
moveshelfbracketstothe
desiredlocation.Thensecurethe
bracketstoshelfwithscrews.
Adjustablewood shelves
Leveler on base
Adjusttheleveler
whennecessary
RemovableMoldings
Magnet
Moldings
LocatingDowel
Hiddendrawer
HARDWARELIST:I91-332/333
No. Description Sketch Quantity
AUbracket 1PC
BWoodScrew 2PCS
STEP1:Lineupthefront
ofbookcasesthenusing the
Ubracket(A)withscrew
(B)toadjacentbookcase.
BA

10-23-2017
Page1/3
ITEMNO:I91-344Peninsula Desk
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
HARDWARELIST:I91-344
No. Description Sketch Quantity
ABolt1/4"*1-1/4" 3PCS
BBolt1/4"*1-1/2" 2PCS
CLockWasher1/4" 5PCS
DFlatWasher1/4"*3/4" 5PCS
EAllenWrench4MM 1PC
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
FORINDOORUSEONLY
COMPONENTS LIST:I91-344
No. Description Sketch Quantity
1DeskTop 1PC
2Pedestal 1PC
FUNCTIONALITY INSTRUCTION
OPTION1LeftPeninsulaDesk OPTION2RightPeninsula Desk
I91-344 I91-344
I91-333 I91-333
Locking file drawer hold
letter or legal size files
Removethewoodscrewsonthesideofdrawer box
toremovetherodloopsandfilerodsifnecessary.
Pressheretorelease
Hook latch
Metal plate
Leveler on base
Adjusttheleveler
whennecessary
Floatingpanel
Flipdowndrawer

07-20-2017
Page2/3
ITEMNO:I91-344Peninsula Desk
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
OPTION1LeftPeninsulaDesk
STEP1:Removethedrawerfromthebookcase,
Attachtheassemblydesktothebookcasebyusing
3bolts(A)2bolts(B),lockwashers(C), flat
washers(D).
Note:Requiresonepersonholding the top panel
whileanotherpersonsecuresboltstodesktop.
Bookcase
Desktop A
C
D
E
OPTION2RightPeninsula Desk
STEP1:Removethedrawersfromthepedestal:Fullyextendthedrawer,thenpresstheplastictabdownontheright
andupontheleftatthesametimeasshownbelow.Whileholdingthetabspresseddown/up,pullthedrawer out.
PlasticTab
STEP2:Takethemiddledraweroff.Remove16bolts,
lockwashersandflatwashersfromdrawer frame
pedestal and end connector to the desktop. Removethe
drawerframeandconnectormovetotheoppositeside of
thedeskandreversethepedestal. End Connector
DrawerFrame
pedestal
B
C
DE

07-20-2017
Page3/3
ITEMNO:I91-344Peninsula Desk
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ah
STEP3:Attachdrawerframe,pedestalandendconnectorto
backpanelbyusingbolts(16pcs),lockwashersandflatwashers.
STEP5:Replaceallofthedrawersinpedestal:Fullyextend
theslidesfromthecase.Thenaligntheslidesonthedrawer to
theslidesonthecaseasshown.Pushthedrawerbackin. You
mayhavetoslidethedrawerinandoutseveraltimesinorder
toproperlyaligntheballbearings.
Bookcase
Desktop
A
C
D
E
STEP4:Removethedrawerfromthebookcase,
Attachtheassemblydesktothebookcasebyusing
3bolts(A)2bolts(B),lockwashers(C), flat
washers(D).
Note:Requiresonepersonholding the top panel
whileanotherpersonsecuresboltstodesktop.
BCD
E
