ASROCK 13.3" Side Panel Kit User manual

Before You Begin
• PleasemakesureyourPCcasecontainsatransparenttemperedglassside
panel,withenoughspacetomounttheeDPpanel.Usethemicrober
clothtowipethepanelcleanandidentifythelocationyouwanttomount
yourscreen.
Note: e transparency of your side panel may aect the display quality of your eDP panel.
• MakesurethemotherboardofyoursystemcomeswithaneDPconnector.
PleasevisitASRock'swebsiteforthesupportedmotherboardswitheDP
interface.
Installation Procedure
e illustrations in this guide are for reference purposes only and may not exactly match the model
you purchase.
1. Gentlylithe13.3"eDPscreenpanel,alongwiththetwolongbrackets,from
thebox.RemovethebracketsfrombothsidesoftheeDPpanel.
A
B
2. Takeouttwomountingbracketsandtworetainingrubberstripsfromthe
box.Botharerequiredforeithertheverticalorthehorizontaldisplay.

Bracket
Bracket
eDP Panel
Rubber Rubber
Bracket
eDP Panel
Rubber
Rubber
Bracket
3. Takeonebracket.Peeltheblueplasticlinero.Donottouchtheadhesive
surface.
Black Strip
Blue Plastic Liner

4. PastethebrackettothedesiredlocationontheinternalsideofthePCside
panel.Pressandholdthebracketforafewsecondstoensureadhesion.Be
suretoleaveenoughspaceabove,allowingtheeDPpaneltobeplaced.
Transparent Side Panel
Free Space
*15G062394001AK*
P/N:15G062394001AKV1.1
WithASRock13.3"SidePanelKit,youcaneasilybuildaLCDdisplayinside
yourPCcase,whichprovidesyouwithasubscreenformonitoringPCstatus
orallowsyoutosendmessages,watchvideosordostreamingatthesametime.
isIPSpanelequippedwitheDPinterfacereducespowerconsumptionand
meanwhiledeliversgreatviewingexperience.
Package Contents
Horizontal DisplayVertical Display
ATTENTION! Two brackets are not clung to the panel. Beware of
dropping the panel when you remove them.
Note: For vertical display, we suggest you rotate the PC side panel 90 degrees during installation.
Once the eDP panel is securely attached with the brackets and the rubber strips, rotate the PC
side panel back to normal postion.
Specication
• PanelSize(inch):13.3
• AspectRatio:16:9
• DisplayViewingArea(HxV):
93.76x165.24
• DisplaySurface:Anti-Glare
• BacklightType:LED
• PanelType:IPS
• PixelPitch:0.153mm
• Resolution:1920x1080
• Brightness(Typ.):300cd/m2
• ContrastRatio(Typ.):800:1
• DisplayColors:16.7M(8bit)
• RefreshRate(Max):60Hz
• Dimension(WxHxD):
300.3x177.6x2.3mm
*For the updated and more information, please visit www.asrock.com.
Note: Do not peel o the black strip behind the blue plastic liner. e black strip allows you to
easily remove the bracket.
Dimensions of the 13.3” eDP Panel
with Brackets and Rubbers Installed
320.26mm
193.01mm
13.3"eDPPanel
2xBrackets 2xRubberStrips
eDPCable 5xCableClips

8. Peelothepaperlinersfromtherubberstrips.Donottouchtheadhesive
surface.PastetherubberstripscloselyalongtheedgesoftheeDPpanel,so
thattheeDPpanelissecurelyframedandwon'tshiorslide.
eDP Panel Rubber
Rubber
9. ConnectthesmallerendoftheeDPcabletotheeDPpanel.
Todoso,openthecoverontheip-lockconnector.Insertitintothe
connectoronthebackoftheeDPpanel.enclosethecoveronthe
connectortosecureitinplace.
A
B

10.Connecttheotherendofthecabletothe40-pineDPconnectoronthe
motherboard.
Note: For easier cable routing, we sugguest you rst connect the eDP cable to your motherboard
before installing the motherboard into the case.
11.Youcanusethecableclipstomanageyourcable.It'sdone.
5. InstalltheotherbracketonthetopedgeoftheeDPpanel.Makesurethe
screenisfacingthesamesideasthesticker.
Pleasenotethedirectionasshownbelow.
Screen Side
Top Edge
Bottom Edge
(with silver mylar)
6. Peeltheblueplasticlinero.Donottouchtheadhesivesurface.
Note: Do not peel o the black strip behind the blue plastic liner.
7. HoldthesidesoftheeDPpanelassembly.Obliquelyinsertitintothegroove
ofthebottombracket.encarefullypushittowardtheglasspaneluntilthe
topbracketisrmlyadhered.
A
B
Screen Side
Ifyouinstallthemcorrectly,fromthescreenside,thesilvermylaratthe
bottomoftheeDPpanelwillbefullycoveredbythebracket.

eDP Panel eDP Panel
silver mylar
(Screen Side) (Screen Side)
ATTENTION! Do not paste the rubber strip onto the black strip at
the bracket end, so you can grasp and stretch the black strip to easily
remove the bracket when needed.
ATTENTION! Note the direction when you paste the bracket.
Before using your side panel, please set “Primary Graphics Adapter” to “Onboard” in
the BIOS settings to ensure the display work properly. To do so, please go to “Advanced”
> “Chipset Conguration” and set “Primary Graphics Adapter” to “Onboard”. en
save the settings and restart the system.
RubberRubber
Black Strip (on the bracket)
