Guide to SATA Hard Disks
Installation and RAID Configuration
1. Guide to SATAHardDisks Installation ……………..2
1.1 SerialATA(SATA) HardDisks Installation …… 2
1.2 MakingAn SATADriverDiskette ……………… 3
2. Guide toRAID Configurations
(RAID 0 / RAID 1 / JBOD) …………………………. . 4
2.1 Introduction of RAID …………………………… 4
2.2 RAIDConfigurationPrecautions……………… 5
2.3 RAID0Configuration…………………………… 6
2.4 RAID1Configuration…………………….…….13
2.5 JBODConfiguration…………………………… 19
3. Guide to Windows 2000 /
Windows XP Installation …………………………...23

2
1. Guide to SATA Hard Disks Installation
1.1 Serial ATA (SATA) Hard Disks Installation
This motherboard adopts SiS 965L south bridge chipset that supports Serial
ATA (SATA) hard disks. You may install SATA hard disks in this motherboard
for internal storage devices. This section will guide you to install the SATA
hard disks.
STEP1: Install the SATA hard disks into the drive bays of your chassis.
STEP2: Connect one end of the SATA data cable to the motherboard’s
primary SATA connector (SATA1).
STEP3: Connect the other end of the SATA data cable to the primary SATA
hard disk.
STEP4: Connect the SATA power cable to the SATA hard disk. If you just
want to install only one SATA HDD, the installation process is
complete at this step. If you want to install two SATA HDDs or you
want to use RAID function, please continue to do the following
steps.
STEP5: Connect one end of the second SATA data cable to the
motherboard’s secondary SATA connector (SATA2).
STEP6: Connect the other end of the SATA data cable to the secondary
SATA hard disk.
STEP7: Connect the SATA power cable to the SATA hard disk.

3
1.2 Making An SATA Driver Diskette
If you want to install Windows 2000 or Windows XP on SATA HDDs, you will
need to make an SATA driver diskette before you start the OS installation.
How to make an SATA driver diskette?
STEP1: Insert the ASRock Support CD into your optical drive to boot your
system. (DoNOT insert any floppy diskette into the floppy drive at
this moment!)
STEP2: During POST at the beginning of system boot-up, press <F11>
key, and then a window for boot devices selection appears. Please
select CD-ROM as the boot device.
STEP3: When you see the message on the screen, “Do you want to
generate Serial ATA driver diskette [YN]?”, press <Y>.
STEP4: Then you will see these messages,
Please insert a diskette into the floppy drive.
WARNING! Formatting the floppy diskette will
lose ALL data in it!
Start to format and copy files [YN]?
Please insert a floppy diskette into the floppy drive, and press
<Y>.
STEP5: The system will start to format the floppy diskette and copy SATA
drivers into the floppy diskette.
Once you have the SATA driver diskette ready, you may start to install
Windows 2000 / Windows XP on your system directly without setting the
RAID configuration on your system, or you may start to use “SiS RAID BIOS
Setting Utility” to set RAID 0 / RAID 1 / JBOD configuration before you install
the OS. You may also set the RAID configuration by using “SiS RAID Utility
for Windows” in Windows environment. Please refer to the document in the
Support CD, “Guide to SiS RAID Utility for Windows”, which is located in the
folder at the following path:
.. \ RAID Utility for Windows

4
2. Guide to RAID Configurations
(RAID 0 / RAID 1 / JBOD)
2.1 Introduction of RAID
This motherboard adopts SiS 964 south bridge chipset that integrates RAID
controller supporting RAID 0 / RAID 1 / JBOD function with two independent
Serial ATA (SATA) channels. This section will introduce the basic knowl-
edge of RAID, and the guide to configure RAID 0, RAID 1, and JBOD settings.
RAID
The term “RAID” stands for “Redundant Array of Independent Disks”, which
is a method combining two or more hard disk drives into one logical unit. For
optimal performance, please install identical drives of the same model and
capacity when creating a RAID set.
RAID 0 (Data Striping)
RAID 0 is called data striping that optimizes two identical hard disk drives to
read and write data in parallel, interleaved stacks. It will improve data ac-
cess and storage since it will double the data transfer rate of a single disk
alone while the two hard disks perform the same work as a single drive but
at a sustained data transfer rate.
WARNING!!
Although RAID 0 function can improve the access performance,
it does not provide any fault tolerance. Hot-Plug any HDDs of the
RAID 0 Disk will cause data damage or data loss.
RAID 1 (Data Mirroring)
RAID 1 is called data mirroring that copies and maintains an identical image
of data from one drive to a second drive. It provides data protection and
increases fault tolerance to the entire system since the disk array manage-
ment software will direct all applications to the surviving drive as it contains
a complete copy of the data in the other drive if one drive fails.

5
JBOD
JBOD (Just a Bunch of Drives) is also called data spanning. It will expands
the capacity of your drive and results in a useable total capacity since it will
make several hard disk types configured as a single hard disk, and the hard
drives are simply hooked up in series. However, JBOD will not increase any
performance or data security.
2.2 RAID Configurations Precautions
1. Please use two new drives if you are creating a RAID 0 (striping) array
for performance. It is recommended to use two SATA drives of the same
size. If you use two drives of different sizes, the smaller capacity hard
disk will be the base storage size for each drive. For example, if one
hard disk has an 80GB storage capacity and the other hard disk has
60GB, the maximum storage capacity for the 80GB-drive becomes 60GB,
and the total storage capacity for this RAID 0 set is 120GB.
2. You may use two new drives, or use an existing drive and a new drive
to create a RAID 1 (mirroring) array for data protection (the new drive
must be of the same size or larger than the existing drive). If you use
two drives of different sizes, the smaller capacity hard disk will be the
base storage size. For example, if one hard disk has an 80GB storage
capacity and the other hard disk has 60GB, the maximum storage capac-
ity for the RAID 1 set is 60GB.
3. Please verify the status of your hard disks before you set up your new
RAID array.
Please carefully read the following list of limita-
tions of “SiS SATA Driver” and “SiS RAID BIOS
Setting Utility” before you use the RAID function.
Limitations of “SiS SATA Driver” and “SiS RAID
BIOS Setting Utility”
1. “SiS RAID Utility for Windows” are only available for Windows
XP / Windows 2000. There is no RAID utility supporting Win-
dows 98 SE and Windows ME.
2. “SiS SATA driver/utility/BIOS” may be updated occasionally.
Please visit ASRock website for the latest driver update.
ASRock website: http://www.asrock.com

6
2.3 RAID 0 Configuration
This section will guide you to configure RAID0. To set RAID0 configuration,
please follow the instruction below to use “SiS RAID BIOS Setting Utility”.
NOTE
In the following instruction, the term “Disk 1” refers to the SATA
hard disk that you connect to “SATA1” connector on your
motherboard; the term “Disk 2” refers to the SATA hard disk that
you connect to “SATA2” connector on your motherboard.
STEP1: Boot-up your computer.
STEP2: Press <Ctrl-S> key to enter “SiS RAID BIOS Setting Utility”
STEP3: Press <R> key to enter RAID setup utility and start to create array.
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
[R] : Enter Raid setup utility
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *

7
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
Press[A]keytocreateRAID
[Q] : Exit current menu
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
Location Model Capacity Mode RAID Type
* Current Created Raid *
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID Type: <1> JBOD <2> RAID 0 <3> RAID 1: 2
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP4: Press <A> key to create array.
STEP5: Press <2> and <Enter> to select RAID 0.

8
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID 0
<1> Auto Create <2> Manual Create: 2
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID 0
Block Size:
[Q] : Exit current menu
<1>16K <2>32K <3>64K <4>128K <5>256K: 3
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP6: Press <1> or <2> to select Create options. If you select <1> “Auto
Create”, “Disk 1” will be the Source disk. If you select <2> “Manual
Create”, the first selected disk will be the Source disk.
WARNING!!
The SOURCE disk should be correctly selected,
otherwise, the inside data will be cleared after
RAID 0 created.
STEP7: If you select <2> “Manual Create” in STEP 6, then the following
screen will appear. Please press <1>-<5> keys and <Enter> to
select Block Size. (Default : 64K)

9
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID 0
Use to select and press <Enter> to confirm
The disk you select first will be the SOURCE disk
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP8: Use < > and < > keys to select disk, and press <Enter> to confirm
your selection. Please note that the disk you select first will be the
SOURCEdisk.

10
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID 0
Split the SOURCE (Disk 1) data to RAID disks ? N
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP9: Press <Q> to escape the current setup menu. Then you will see
the following message: “Split the SOURCE (Disk 1) data to RAID
disks? N” If you press <N> and <Enter>, it will Create Stripe only.
If you press <Y> and <Enter>, it will split the data on source disk
to RAID disks.
NOTE
If both SATA disks are empty, or you don’t need
the data any more, you should select <N> to save
your time. If you want to keep the data of the
source disk, you should select <Y>. This split ac-
tion may take several hours depending on the size
of your HDD.

11
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
[Q] : Exit current menu
Press[D]keytodeleteRAID
RAID 0: Disk1 Disk 2
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
[R] : Enter Raid setup utility
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
RAID 0: Disk1 Disk 2
* Current Created Raid *
STEP10: Press <Enter> to escape the current menu. Then the following
screen will appear.
STEP 11: Press <Q> again to escape the setup Utility.

12
Disk Status
Pri_Master XXXXXX XXXXXX XXXX XXXXXXX
Sec_Master XXXXXX XXXXXX XXXX XXXXXXX
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
[R]:E
[Q]:E
Do You Want To Save changes ? N
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
RAID 0: Disk1 Disk 2
* Current Created Raid *
STEP12: Then you will see the confirming message: “Do You Want to Save
Changes? N” Please press <Y> and <Enter> to save changes.
STEP13: Once the array has been created, you will need to FDISK and
format the array as if it were a new single hard drive.

13
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
[R] : Enter Raid setup utility
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
2.4 RAID 1 Configuration
This section will guide you to configure RAID1. To set RAID 1 configuration,
please follow the instruction below to use “SiS RAID BIOS Setting Utility” for
the setting of RAID 1 configuration.
NOTE
In the following instruction, the term “Disk 1” refers to the SATA
hard disk that you connect to “SATA1” connector on your
motherboard; the term “Disk 2” refers to the SATA hard disk that
you connect to “SATA2” connector on your motherboard.
STEP1: Boot-up your computer.
STEP2: Press <Ctrl-S> key to enter “SiS RAID BIOS Setting Utility”
STEP3: Press <R> key to enter RAID setup utility and start to create array.

14
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
Press[A]keytocreateRAID
[Q] : Exit current menu
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
Location Model Capacity Mode RAID Type
* Current Created Raid *
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID Type: <1> JBOD <2> RAID 0 <3> RAID 1: 3
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP4: Press <A> key to create array.
STEP5: Press <3> and <Enter> to select RAID 1.

15
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID 1
<1> Auto Create <2> Manual Create: 2
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP6: Press <1> or <2> to select Create options. If you select <1> “Auto
Create”, “Disk 1” will be the SOURCE disk, and the “Disk 2” will be
the MIRROR disk. If you select <2> “Manual Create”, the first se-
lected disk will be the SOURCE disk, and the next selected disk will
be the MIRROR disk.
WARNING!!
The SOURCE disk should be correctly selected,
otherwise, the inside data will be cleared after
RAID 1 created.

16
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID 1
Use to select and press <Enter> to confirm
The disk you select first will be the SOURCE disk
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP7: Use < > and < > keys to select disk, and press <Enter> to confirm
your selection. Please note that the disk you select first will be the
SOURCEdisk.

17
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID 1
Duplicate the SOURCE (Disk 1) data to RAID disks ? N
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP8: Then you will see the following message: “Duplicate the SOURCE
(Disk 1) data to RAIDdisks?N”. If you press <N> and <Enter>, it will
Create Mirror only. If you press <Y> and <Enter>, it will duplicate
the data on source disk to RAID disks.
NOTE
If both SATA disks are empty, or you don’t need
the data any more, you should select <N> to save
your time. If you want to keep the data of the
SOURCE disk, you should select <Y>. This mirror
action may take several hours depending on the
size of your HDD.

18
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
[R] : Enter Raid setup utility
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
RAID 1: Disk1 Disk 2
* Current Created Raid *
Disk Status
Pri_Master XXXXXX XXXXXX XXXX XXXXXXX
Sec_Master XXXXXX XXXXXX XXXX XXXXXXX
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
[R]:E
[Q]:E
Do You Want To Save changes ? N
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
RAID 1: Disk1 Disk 2
* Current Created Raid *
STEP9: Press <Q> to escape the setup menu.
STEP10: Before you escape the setup Utility, you will see the confirming
message: “Do You Want to Save Changes? N” Please press <Y>
and <Enter> to save changes.
STEP11: Once the array has been created, you will need to FDISK and
format the array as if it were a new single hard drive.

19
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
[R] : Enter Raid setup utility
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
2.5 JBOD Configuration
This section will guide you to configure JBOD. To set JBOD configuration,
please follow the instruction below to use “SiS RAID BIOS Setting Utility” for
the setting of JBOD configuration.
NOTE
In the following instruction, the term “Disk 1” refers to the SATA
hard disk that you connect to “SATA1” connector on your
motherboard; the term “Disk 2” refers to the SATA hard disk that
you connect to “SATA2” connector on your motherboard.
STEP1: Boot-up your computer.
STEP2: Press <Ctrl-S> key to enter “SiS RAID BIOS Setting Utility”
STEP3: Press <R> key to enter RAID setup utility and start to create array.

20
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
Press[A]keytocreateRAID
[Q] : Exit current menu
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
Location Model Capacity Mode RAID Type
* Current Created Raid *
Disk Status
[B] : Select Boot Disk
[R] : Enter Raid setup utility
[Q] : Exit the menu
Location Model Capacity Mode RAID Type
Pri_Master XXXXXX XXXXXX XXXX XXXXXXX
Sec_Master XXXXXX XXXXXX XXXX XXXXXXX
Pri_Master XXXXXX XXXXXX XXXX XXXXXXX
Sec_Master XXXXXX XXXXXX XXXX XXXXXXX
The selected boot disk is marked by "*"
SiS RAID BIOS Setting Utility
Copyright (c) 2003-2005. Silicon Integrated Systems Corp | www.sis.com
RAID Setup
RAID Type: <1> JBOD <2> RAID 0 <3> RAID 1: 1
[Q] : Exit current menu
Location Model Capacity Mode RAID Type
Disk 1 XXXXXX XXXXXX XXXX XXXXXXX
Disk 2 XXXXXX XXXXXX XXXX XXXXXXX
* Current Created Raid *
STEP4: Press <A> key to create array.
STEP5: Press <1> and <Enter> to select JBOD.
