Assured Automation FireBag User manual

FireBag®
Use & Care Manual
1-800-899-0553
assuredautomation.com
1. INTRODUCTION
The FireBag automatically turns off gas
supply in the event of fire, preventing
explosions and the spreading of fire.
When outside temperature reaches
203˚F to 212˚F (95˚C to 100˚C) the metal
alloy that keeps plug and cartridge
together melts and the spring pressure
pushes the plug against the gas opening
to close it completely.
No fire or heat detectors are required to
automatically intercept gas flow.
2. GENERAL SPECIFICATIONS
Thermal safety device, FireBag, as a
connection or with integrated interceptor
valve (GT2, G4T or R4T).
ASSEMBLING IS TO BE EXECUTED BY
AUTHORIZED COMPANIES ONLY.
Before installation read and follow the
installation instructions.
3. USAGE
The thermal safety device, FireBag,
shuts off automatically the flow of gas
in the instance of fire and is certified for
natural gas, city gas, and fluid gas I (in
gas form). It is manufactured according
to DIN 3586 Standard.
FB2010© Assured Automation 2010
Technical Specifications
•Maximum Pressure: 72.5 PSI (NPT),
232 PSI (Flanged)
• Temperature Range: -4˚F to 176˚F
• Set-off Temperature: 203˚F to 212˚F
• Shut-off time: < 60 sec.
•Heat Resistance: 1,697˚F for 60 minutes
at 72.5 PSI (NPT)
4. INSTALLATION
1. Before installation, check that the device
has not gone off (check the integrity of
the shut-off device and the gas flow).
2. Protect the valve against dirt before
usage and during the installation.

4. It is suggested to choose an installation
place where nothing can disturb the
function of the FireBag thermal safety
device.
5. Use the correct wrench when installing.
6. Check the tightness of the valve and its
connection after installation.
7. When installed, do not paint or cover
the safety device.
Caution: Make sure the materials of
the plant and its related connections
can handle the specified thermal
load before installing the safety device
to guarantee proper functioning.
5. MAINTENANCE
The FireBag does not need maintenance.
A complete valve (or complete connection)
is to be replaced whenever the thermal
safety device goes off.
6. CERTIFICATIONS
• AGA ANSI Z21.15-CGA 9.1-M97
(certain models)
• CGA ANSI Z21.15-CGA 9.1-M97
(certain models)
• DIN 3586 thermo activated safety
device for gas applications
• European UNI EN 1775 Standard for
indoor gas installations
• European Directive 90/396/CEE
certification for durability in mechanical
or thermal stress
• German DVGW TRGI 86/96 Standard
for thermo activated locking systems on
gas heaters, water heaters & domestic
gas fittings
• German Standard Muster-
Feuerverordnung (FeuVo v. 02/95 -
edition 09/97) for thermo activated
devices
• Italian UNI 7129 Ed 2001 Standard for
fire protection and gas supply line
components
Assured Automation declines any
responsibility for faulty usage or
false interpretation of the above
installation directions.
FireBag thermal
safety device
Flow
3. Installation position can be freely
chosen, but look carefully at gas flow
direction (as indicated by the arrow on
the valve body).
Flow Diagram
