Assurelink Smart Home Care System User manual

Welcome to your Assurelink
Smart Home Care System.
Home, with its comfort and
familiarity, plays a central role in
all our lives. That’s why it’s natural
to want to stay in it for longer.
When it comes to people who love
and care for each other, it’s also
natural to want to stay in the
know, assuring and linking us
to each other. Our system provides
reassurance and support for home
living independence in an easy to
setup, out of the box solution.
For further information please visit
our website www.assurelink.co.uk
where you can nd a copy of
this guide, a Q&A section and
contact details.
WHAT’S IN THE BOX
GATEWAY x1
POWER PLUG x1
For Gateway
MOTION
SENSORS x4
DOOR SENSOR
& MAGNET x2
TEMPERATURE
SENSOR x1
EXTRA STRONG DOOR MAGNET
x2 (If required for door sensors)
www.assurelink.co.uk
[e-mail]
01278 874677
BED PAD
x1
AAA
BATTERIES
TRANSMITTER x1
For Bed Pad
WHAT GOES WHERE
WE ADVISE THAT:
• The motion sensors are setup in the
bathroom, kitchen, living room and
bedroom according to the stickers on them.
• The temperature sensor is placed in a
central area such as the hallway.
• The door sensors are setup on the front
and back doors.
• The bed pad under the sheet on the bed.
• The gateway near the WiFi router.
PETS
We understand that pets can be an
important part of some households.
Their movement will also be detected,
as with other motion sensors, leading
to false readings. To help minimise
this please see the diagram showing
the placing of the sensors.
HOW TO RESET
YOUR GATEWAY
Reset Button
Power Cable
Network Cable
• If your app account does not connect,
ensure the internet and power cables
are connected to gateway
• Use the end of a paperclip to press
the reset button
• Hold for 5 seconds
• Reconnect internet and power
cables after indication lights have
stopped ashing
• Now, you can retry the normal setup
procedures with an existing or new
app account.
SENSOR REACH
Place your sensor above
a shelf or furniture to avoid
the detection of ground
level pets.
DOOR SENSOR
WALL MOUNT x2
NETWORK
CABLE x1
For Gateway
463_PC_Asssurelink_Instructions_Poster_OCT_2019_01.indd 1 18/10/2019 15:40

SMART
HOME
CARE
SYSTEM
INSTALLATION
GUIDE
HOW TO
INSTALL
03 TEMPERATURE
SENSOR
• Insert 2 x AAA batteries
• Install with wall hook and
double-sided tape
• Install in a well-ventilated indoor
location
• To remove, press and pull
double-sided tape out
• Insert 2 x AAA batteries
• Install with wall hook and
double-sided tape
• Install in living room, kitchen,
bathroom and bedroom
• To remove, press and pull
double-sided tape out
• Insert 2 x AAA batteries
• Install main sensor into
wall-mounted case
• Install main sensor at the door’s
opening side
• Install magnet in the door frame –
match the markings on both parts
• Plug transmitter into bed pad
• Switch on transmitter
• Cover transmitter inside side pocket
• Press bed pad for 15 seconds
to activate
• Place bed pad at shoulder or hip level
• Connect network cable
• Connect power cable
01 GATEWAY 02 BED PAD
Signal
Network
Power
Button
Reset Button
Power Cable
Network Cable
On/Off
Transmitter
Connector
Pressure
Sensing Zone
Cover bed pad
with a bed sheet
04 MOTION
SENSOR
05 DOOR
SENSOR
Mounting hole
2 AAA batteries
Wall
Mounting hole
2 AAA batteries
Wall
06 DOWNLOAD ASSURELINK SMART HOME
CARE SYSTEM APP
You can start using Assurelink Smart
Home Care System by just completing
a few steps on your mobile app.
Mounting hole
2 AAA batteries
Wall
Mounting hole
2 AAA batteries
Wall
Max Distance <1cm
Door Frame
Door
(Inside)
Double size magnet
can be used to line up
with the main sensor
OR
Max Distance <1cm
Door Frame
Door
(Inside)
Double size magnet
can be used to line up
with the main sensor
OR
