Asterisk AsReader ASR-032W User manual
Copyright © Asterisk Inc. All Rights Reserved.
AsReader ® is registered trademarks of Asterisk Inc.
Other company and product names are generally trademarks or registered trademarks of their
respective companies.
Wired BOX-Type RFID
User Manual
ASR-032W
Wired BOX-Type RFID User Manual
ASTERISK, INC.
1
Contents
1About Wired BOX-Type RFID 3
1.1. Introduction 3
1.2. Safety Instructions (Please be sure to comply) 5
1.3. Product Pictures 7
1.4. System Configuration 8
1.5. Product specification 9
2Connect Devices 10
2.1. Connect Antennas 10
2.2. Connect HID Device 11
2.3. Connect Printer 11
2.4. Connect Cash Drawer 12
2.5. Connect iOS Device 13
2.6. Connect PoE Power Supply 13
2.7. Power On/Power Off 14
3App Operation Instructions 15
3.1. Connect Wired BOX-Type 15
3.2. Network Configuration 18
3.3. Basic Settings 22
3.4. Read RFID Tags 23
3.5. Scan Barcodes 25
3.6. Print 26
3.6.1 Printer Setting 26
3.6.2 Print Receipts 27
3.7. Open Cash Drawer 28
3.8. RFID Settings 29
3.8.1. Output Power 30
3.8.2. On/Off Time 31
3.8.3. Session 32
3.8.4. Update Registry 33
Wired BOX-Type RFID User Manual
ASTERISK, INC.
3
1About Wired BOX-Type RFID
1.1.Introduction
Thank you for purchasing Wired BOX-Type RFID ASR-032W.
This manual describes the considerations for using Wired BOX-Type RFID ASR-032W
(hereinafter referred to as Wired BOX-Type or the AsReader). Please read the manual
carefully and keep it as long as you have the device.
The Wired BOX-Type can be powered by PoE power supply or PoE switch. And it
charges the iOS device and provides wired network for it at the same time. In addition,
the Wired BOX-Type can also read UHF RFID tags. It can also be connected to multiple
external USB devices (barcode scanners, and printers, etc.), and these functions can be
controlled with iOS devices.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
4
If you have any comments or questions about this manual, please contact us through the
following ways.
Asterisk Inc.
Shin-Osaka Dainichi Bldg. 201, 5-6-16 Nishinakajima, Yodogawa-ku, Osaka-city,
532-0011, Osaka, JAPAN
TEL: +81 (0) 50 5536 8733
★The copyright of this manual belongs to the our company. Without the permission of the
company, no reproduction, reprinting, modification or translation into other languages is
allowed.
★The contents of this manual are subject to change without prior notice. In addition, the
images in this manual are all reference images and may be different from the actual
product.
★In order not to damage your property and life safety, please read this manual carefully
before using this device. We will not be responsible for any loss caused by
non-compliance with this manual.
★We are not responsible for any damage caused by natural disasters, such as
earthquake, lightning, wind, flood, fire outside our responsibility, third party behavior,
other accidents, intentional or negligent, abuse or other improper use.
★If the damage is caused by falling or collision as determined by our company, the
maintenance fee will be charged even within the warranty period.
★We will take appropriate measures to ensure that our products do not infringe other
patents, but we are not responsible for any patent infringement caused by any of the
following (1) to (3).
(1) Used in combination with components, products, equipment, data processing systems
or software outside our company.
(2) Our products are used in unexpected ways.
(3) Modification of our products by any person or company other than our company.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
5
1.2.Safety Instructions (Please be sure to comply)
Please read the following instructions carefully to prevent injury, malfunction, fire, etc.
Warning
Do not attempt to disassemble, modify or repair the AsReader yourself, otherwise it may
cause malfunction, fire or electric shock. We will not be held responsible for any problems that
may occur with the AsReader, PC, smart devices, etc. due to modifications.
If you notice any abnormalities such as smoke, abnormal odor, or strange noise coming from
the AsReader during use, stop using it immediately. Continued use may cause fire or electric
shock.
Do not drop or throw the AsReader and subject it to strong impact. It may cause damage, fire,
electric shock, or malfunction. It may also cause injury. If the AsReader is damaged by
dropping and the inside of the AsReader is exposed, do not touch the exposed part with your
hands, because there is a risk of electric shock or injury on the damaged part.
Do not allow metal or other objects to come into contact with the terminals of each connector.
Doing so may cause a large current to flow, resulting in overheating, fire, or damage to the
device.
Do not get the AsReader wet with water. Doing so may result in fire or electric shock. If foreign
matter or water should get inside the AsReader, unplug the power cable immediately.
Do not use the AsReader with the power supply voltage other than the specified. Doing so
may result in damage to the equipment or an accidental fire.
When constructing a system that may affect human life, such as the management of
chemicals using the AsReader, please pay close attention to redundancy and safety design
so that even if the data is incorrect, there is no possibility of affecting human life.
The AsReader is an RFID reader that uses UHF radio waves with an output power of 250mW.
Therefore, depending on the application and location of use, it may affect medical equipment.
In order to minimize this effect, the following must be strictly observed during operation.
1.The AsReader operators should keep the AsReader no closer than 22cm from the site
where the implantable medical device will be installed.
2.The person wearing the implantable medical device should not come within 22cm of the
AsReader.
When taking the AsReader overseas, please consult with us in advance, as it is necessary to
comply with the laws and regulations of each country and region.
Caution
Wired BOX-Type RFID User Manual
ASTERISK, INC.
6
Since each country or region has different regulations regarding radio waves, it is necessary
to comply with the respective regulations. Modification of the AsReader is prohibited, and
violations may result in penalties according to the regulations of each country or region.
Use the PoE power supply specified in this manual when connecting the AsReader. Use of
non-standard PoE power supply may cause the AsReader failure or malfunction.
Please refer to local regulations when you recycle this device.
If you notice any abnormalities, please discontinue use and contact your distributor
immediately.
Do not use, store, or leave the AsReader in hot places (eg. by the fire, near a heater, in direct
sunlight, in a car in hot weather). It may cause rupture, malfunction, fire or injury.
Do not place the AsReader on an unstable surface such as a wobbly table or a tilted place. It
may fall and cause damage to the crisis or injury.
How to Care for the Device
Always keep your AsReader clean. If the AsReader gets dirty, wipe it with a soft, dry cloth.
Use of volatile solvents such as thinner or benzene may cause deterioration or
discoloration of the AsReader.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
7
1.3.Product Pictures
FIG. 1-3-1 Product appearance (front)
FIG. 1-3-2 Product appearance (back)
Wired BOX-Type RFID User Manual
ASTERISK, INC.
8
1.4.System Configuration
To build a system using the Wired BOX-Type, the following hardware and software are
required in addition to the Wired BOX-Type itself. Some hardware requirements may vary
depending on the power supply used and the type of communication.
Fig. 1-4-1 Connection Image
In addition to the above hardware, an application for the iOS device is required to use the
Wired BOX-Type. You can develop your own application for the iOS device using the
SDK that we provide free of charge. You can download the SDK from our website.
https://asreader.com/products/asr-032w/
You can refer to the SDK manual and sample code that can also be downloaded from our
website to develop your application.
RFID antenna
（sold separately)
RFID antenna cable
（sold separately)
Lightning cable
PC（sold separately)
iOS device（sold separately)
PoE power supply
（sold separately)
Ethernet cable
（sold separately)
USB cable
（sold separately)
Printer
（sold separately)
Barcode reader
（sold separately)
Cash drawer
（sold separately)
Wired BOX-Type RFID User Manual
ASTERISK, INC.
9
1.5.Product specification
Model
ASR-032W
RFID
Spec
ISO 18000-63 (Old 18000-6C) / EPC global Class 1 Gen 2
Radio
frequency
902 ~ 928MHz (US)
865 ~ 868MHz (EU)
Output
Max 500mW 27dBm
Antenna port
SMA male x8
Output can be set for each port.
Functions
Inventory
Power Source
Input
·RJ45 x1 PoE (IEEE802.3at compliant)
* Be sure to use the following specifications for the PoE
hub/injector and Ethernet cable to be used.
Ethernet cable: Category 5e or higher
PoE hub/injector: IEEE802.3at compliant
Output
·USB-C x1: 12.5W *for charging iOS devices
·USB 2.0 Type-A x4: 2500mW (4 ports in total)
*In case of connecting a device that requires more than
the specified input, connect it via a self-powered USB hub.
Communication
interface
Ethernet
RJ45
USB-C
To plug in the dedicated lightning cable or USB Type-C
cable for connecting an iOS device.
A dedicated SDK for iOS app development will be
provided.
USB 2.0
Type-A x4
To connect HID communication devices such as barcode
scanners and ESC/POS compatible printers.
Console
Port for maintenance (not available for customer use).
Appearance
Dimensions
(W)x(D)x(H)
220 × 145 × 29 mm
Weight
Approx. 530g
Material
Aluminum
Color
Black
LED
Indicator
Power LED –Red
System LED –Orange
Network LED –Green
Data transmitting LED - Green
Environment
Operation
temp.
-10～45 ˚C, 20～85 % RH
Storage
temp.
-20～60 ˚C, 10～95 % RH
Certifications
(TBD)
TELEC
Apple MFi
CE
RoHS
Accessories
Dedicated lightning cable or USB Type-C cable
The specifications of this product are subject to change without notice.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
10
2Connect Devices
2.1.Connect Antennas
Please connect the RF cable of the antenna to the antenna interface of Wired BOX-Type
(See FIG. 1-3-1①). It can connect up to 8 antennas. Tighten the screw of the connector
without loosening it. If the connector is loose, reading performance will be degraded.
The RFID antenna and the antenna cable are sold separately.
Please contact your local distributor for the RFID antennas and antenna cables that can
be connected. Connecting RFID antennas and cables other than those specified for our
products is a violation of the Radio Law and will be punished by law.
FIG. 2-1-1 Connect antennas
Wired BOX-Type RFID User Manual
ASTERISK, INC.
11
2.2.Connect HID Device
Please connect the HID device via USB Type-A interface to Wired BOX-Type (see FIG.
1-3-2⑨), such as barcode scanner. The total power output from the four USB ports of the
Wired BOX-Type is 2500mW(5V/500mA). If you wish to connect a device that requires
more power than this, please connect the Wired BOX-Type and the relevant device via a
self-powered USB hub.
FIG.2-2-1 Connect barcode scanner
2.3.Connect Printer
Please connect the printer to Wired BOX-Type via USB Type-A interface (see FIG.
1-3-2⑨) and connect the printer to power supply. The printer needs to be compatible with
ESC/POS.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
12
FIG. 2-3-1 Connect printer
2.4.Connect Cash Drawer
After you connect the printer to the Wired BOX-Type, please connect the cash drawer to
the printer. The cash drawer is controlled through the printer.
FIG. 2-4-1 Connect cash drawer
Wired BOX-Type RFID User Manual
ASTERISK, INC.
13
2.5.Connect iOS Device
Please connect the attached Lightning cable or USB Type-C cable to the USB-C port on
the Wired BOX-Type and connect it to your iOS device (see FIG. 1-3-1②).
FIG. 2-5-1 Connect iOS device
2.6.Connect PoE Power Supply
1. Please connect the PoE power supply and Wired BOX-Type with an Ethernet cable
(RJ45 interface, see FIG. 1-3-2③).
2. Please connect the PoE power supply and the router with an Ethernet cable (RJ45
interface).
Please use an IEEE 802.3at PoE power supply.
Use a UTP cable of category 5e or higher for the Ethernet cable to be connected.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
14
FIG. 2-6-1 Connect PoE power supply
2.7.Power On/Power Off
Power on method: Power on the PoE power supply after device connection is
completed. Once all four LEDs on the Wired BOX-Type are turned on, it means the
device has been turned on successfully.
FIG. 2-7-1 Wired BOX-Type power on
Power off method: Power off the PoE injector. Or disconnect the Wired BOX-Type from
the PoE injector.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
15
3App Operation Instructions
3.1.Connect Wired BOX-Type
Connect:
Go to the Wired BOX-Type app and tap "Setting" to enter the Setting page.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
16
FIG. 3-1-1 Enter the Setting page
Select TCP or MQTT protocol communication on the Setting page, and then tap “Search”.
FIG. 3-1-2 Search for Wired BOX-Type
It displays the IP address of the Wired BOX-Type.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
17
FIG. 3-1-3 Wired BOX-Type IP address
Tap the IP address in the figure above. If the "Connect" button changes into "Disconnect",
the connection is successful, and each function button becomes active.
FIG. 3-1-4 The connection is successful
When the cable connected to the iOS device is unplugged and plugged in, the connection
between the iOS device and the Wired BOX-Type will be disconnected and automatically
reconnected. It may take more than 10 seconds to reconnect.
Disconnect:
Tap “Disconnect” to disconnect from the Wired BOX.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
18
FIG. 3-1-5 Disconnect
3.2.Network Configuration
The function of this page is to configure the IP address of Wired BOX-Type, which
supports setting static IP or dynamic IP.
FIG. 3-2-1 Network
Tap "Network" on the homepage of the app to enter the Network Setting page, and start
searching for Wired BOX-Type.
Wired BOX-Type RFID User Manual
ASTERISK, INC.
19
FIG. 3-2-2 Search for Wired BOX-Type
It displays the IP address of the Wired BOX-Type.
FIG. 3-2-3 IP address
Tap the searched IP address, and "DHCP" will be automatically selected if the current
Wired BOX-Type is set to Dynamic IP, and "Static IP" will be automatically selected if it is
static. The factory default of Wired BOX-Type is dynamic IP.
Table of contents
