astra telematics AT110V5 User manual

AT110V5 Advanced Vehicle Tracking Device
User Guide
Version: 5.0
Date: September 2018

Abbreviations
ADC Analogue to Digital Converter
ASCII American Standard Code for Information Interchange (computer character set)
BLE Bluetooth Low Energy
BT Bluetooth (Classic)
CAN Controller Area Network
DC Direct Current
FET Field Effect Transistor
GIS Geographic Information System
GPRS General Packet Radio Service (part of GSM)
GPS Global Positioning System
GNSS Global Navigation Satellite System
GSM Global System for Mobile communication
IP Internet Protocol (part of TCP/IP)
LED Light Emitting Diode
MEMS Micro Electro-Mechanical System
NMEA National Marine Electronics Association (defined a GPS output format)
OTA Over the Air (remote configuration of devices)
PC Personal Computer
PCB Printed Circuit Board
PDU Protocol Description Unit (describes a binary SMS format)
RFID Radio Frequency Identification
SIM Subscriber Identity Module
SMS Short Message Service
SMSC Short Message Service Centre
SV Satellite Vehicle
TCP Transmission Control Protocol (part of TCP/IP)
UDP User Datagram Protocol
UMTS Universal Mobile Telecommunication Service
WGS84 World Geodetic System 1984 (global co-ordinate system used by GPS)

Product Overview
The AT110 is a highly featured vehicle tracking device, housed in a sturdy aluminium enclosure
with external GNSS/GSM/UMTS antennas. The AT110 incorporates the very latest technology,
including the latest Cortex M3 ARM processor, ublox SARA-U2 penta-band 3G (GSM/UMTS)
communication module and ublox EVA-M8M GNSS, supporting GPS, GALILEO, GLONASS &
BeiDou navigation systems. The AT110 operates from an external voltage source in the range 5
to 50V and has an internal 950mAh back-up battery which allows operation for approx. 10 hours
in continuous mode, or 10 days in low-power mode. Basic 3 wire (power and ignition)
connections are made using a simple 3 way connector and cable assembly. More advanced
features are available by using the 36 way data connector.
Features
The main features of the AT110 are highlighted below:
•Compact matchbox sized dimensions
•Cortex M3 ARM Processor
•ublox EVA-M8M GNSS, 72 channel, -164dBm sensitivity
•supporting GPS, GALILEO, GLONASS and BeiDou navigation systems
•ublox SARA-U2 penta-band 3G UMTS/HSPA global communications module
•Low power consumption (near zero current drain when vehicle ignition is off)
•3 axis accelerometer (2/8g)
•CANBus interface with FMS and OBD support
•6 digital inputs
•5 digital outputs
•1-wire Dallas interface
•2 ADC inputs
•2 RS232 Ports
•Internal back-up battery, lithium, 950mAh
•Configuration by RS232, SMS or TCP/UDP
•Fast and reliable over the air firmware update
•Modular communication protocol X
•Pass through data mode
•SDK available for rapid development of client customised applications
•Approved to: TBC

Technical Specifications
1
UMTS/HSPA Communications: 800/850/900/1900/2100 MHz
GSM/GPRS Communications: 850/900/1800/1900 MHz
GSM Antenna: external
GPS Antenna: external
GPS Receiver: EVA-M8M
L1 receiver: 72 channels
Position accuracy: 2.5m CEP
Receiver sensitivity: -164dBm (tracking)
TTFF: Cold start 26 sec
Hot start 1 sec
Input voltage: 6 –50 volts DC
Internal Battery: 3.7V, 950mAh
Battery Life: 10 hours continuous operation
10 days operation in low-power mode (hourly update)
Data transfer modes: GPRS / UMTS 3G (TCP or UDP)
Inputs/outputs: 4 digital pull-up inputs
2 digital pull-down inputs
5 digital outputs (MOSFET low-side switches)
2 ADC inputs (0-5V and 0-15V range)
CANBus / FMS 2.0 / OBD2
2 RS232 serial ports
Current consumption, max: 300mA @ 13.8 VDC (battery charging at max. rate)
Current consumption, average: 25mA @ 13.8 VDC (typical)
Current consumption, sleep: < 100uA
Dimensions: 85 x 47 x 15 mm (3.3” x 2.0” x 0.6”)
Weight: 180g
Temperature:
Operating -20 to +85C
Storage -30 to +85C
Connectors:
GPS SSMB
GSM MCX
Data Hirose ST40X-36S, 36 way
Power JST PHR-3 (3 way plug)
SIM: micro SIM (3FF), push-push style
Product Approvals: TBC
1
Specifications may change without notice.

Hardware Description
Dimensions
SIM installation
Note: fitting the SIM will trigger the AT110 to power up.
The AT110 must be fitted with a SIM card (micro SIM, format 3FF) to allow access to a
GSM/GPRS/UMTS network services. The SIM card is installed in a small slot in the side of the
AT110. Correct orientation of the SIM card is essential for correct operation. Push the SIM card
into the slot until the edge is flush with the AT110 case. To remove the SIM card, simply push it
again, and it will spring out. SIM PIN must be disabled.

Power requirements
The AT110 operates from a DC Voltage between 5 and 50 Volts. We recommend that a
permanent power source is used to supply the AT110. If current drain is of concern, please refer
to the power management section for options to minimise vehicle battery drain when stationary
for long periods.
Fuse Recommendations
Typical current drain is 25mA @ 13.8VDC and 14mA @ 27.6VDC, although maximum peak
current can be around 500mA for very short periods. The AT110 is supplied with a 1.0m power
cable, which is fitted with 1A fuses in the power feeds and ignition sense wires.
Back-up Battery
The AT110 operates from the external voltage source, with an internal back-up battery to allow
continuous operation for short periods without external power. The device will maintain the
battery charge level and seamlessly switch to battery power if the external voltage source fails or
fall outside of the permitted range. Note that the operating temperature range of the AT110 is
reduced when the battery option is fitted (see Specifications section). Please also note the
handling precautions for lithium polymer batteries as outlined in the AT110 Installation Guide.
Powering up your AT110
Fitting the SIM acts as the on/off switch. Your AT110 will power up as soon as the SIM is
inserted.
LED Indicators
The AT110 has 2 external status LEDs, which indicate GPS/GNSS status and GSM/UMTS network
status, as per the description below:
GPS/GNSS STATUS (GREEN):
ON CONTINUOUSLY device is powered-up and is searching for first location fix
FAST DOUBLE FLASH good fix received, typically 1Hz flash (once per second)
OFF device currently has no location fix
GSM/UMTS STATUS (BLUE):
OFF no network service
100mS ON / 2S OFF Registered on home network 2G service
DOUBLE 50mS ON / 2 SEC OFF Registered on home network 3G service
DOUBLE 100mS ON / 2 SEC OFF Registered on roaming network 2G service
50mS ON / 50mS OFF Registered on roaming network 3G service
ON CONSTANTLY device is currently transmitting data on home network
800mS ON / 200mS OFF device is currently transmitting data on roaming network

Interconnections
For basic installations, the 3 wires provided on the standard power cable are all that is
necessary, these provide power and ignition input (digital 1) using a 3 way cable which mates
with the 3 way power header on the AT110 device.
AT110 Power Connections and Colour Code
Pin Number
Application
Wire Colour
1
Supply Voltage, 5 –50 VDC
RED
2
GND
BLACK
3
IGNITION Input (digital input 1)
WHITE
Other connections to the AT110 are provided by a single 36 way cable assembly (see below).
AT110 Data Connector Applications and Colour Code
Pin Number
Application
Wire Colour
1
GND
black
2
RS232-TX1
green
3
RS232-TX2
green/white
4
GND
black/white
5
RS232-RX1
blue
6
RS232-RX2
blue/white
7
JTAG (for SDK users only)
brown/white
8
JTAG (for SDK users only)
orange/white
9
JTAG (for SDK users only)
purple/white
10
JTAG (for SDK users only)
orange/black
11
JTAG (for SDK users only)
yellow/black
12
JTAG (for SDK users only)
green/black
13
3.3V output (regulated), 250mA fused
red/white
14
Digital output 1
gray/black
15
GND
pink/black
16
Digital output 2
pink/red
17
Digital output 5
pink/yellow
18
auxilliary output 5-50 VDC*, 250mA fused
red*
19
4.5V output (unregulated), 250mA fused
red/black
20
RESERVED
pink/white
21
RESERVED
pink/blue
22
Digital output 3
light blue/black
23
Digital output 4
light blue/yellow
24
CANH
light blue/green
25
CANL
light blue/blue
26
GND
gray/red
27
ADC1 (0-5V)
pink
28
ADC2 (0-15V)
light green
29
GND
light blue/red
30
1-wire / iButton / temperature probe
light blue
31
Digital input 1 –Ignition
white
32
Digital input 2 –Panic
gray
33
Digital input 3
purple
34
Digital input 4
yellow
35
Digital input 5 (pull-down)
orange
36
Digital input 6 (pull-down) –Private mode
brown
*this is an output to power external accessories, not to be used to supply power to the device

Digital Inputs
Digital inputs 1 to 4 are normally low and can be connected directly to 12/24V vehicle circuits.
Digital inputs 5 and 6 are normally high, for use in pull-down applications. Simply switch to GND
to activate these inputs.
Note: damage may be caused to the AT110 device if a voltage source is applied to digital inputs
5 and 6.
Digital Outputs
The AT110 is capable of switching 5 different loads using digital outputs 1–5, implemented with
MOSFET low-side switches. These must be used to switch the GND side of the load.
Digital outputs 1-5 are capable of handling loads of up to 30V, 0.5A maximum. The digital
output switches are protected by internal fuses, rated at 0.63A. The fuses are not user-
replaceable, and are not covered by warranty, hence any replacements are chargeable. An
external fuse, rated at 0.5A will avoid internal damage to the AT110 device.
Analogue to Digital Converter (ADC) Inputs
ADC1 can be used to measure analogue voltages up to 5.0V maximum
ADC2 can be used to measure analogue voltages up to 15.0V maximum
External scaling can be used to measure higher voltages if necessary.
Integrated Accelerometer(s)
The AT110 has a built in 3 axis MEMS accelerometer that operates in the range ±2g and is used
to measure driver behaviour (acceleration and braking) during normal driving conditions.
The accelerometer also allows the AT110 to wake from sleep on movement, with configurable
thresholds. Please refer to the MEMS parameter and Power Management section for more
details.
1-wire / iButton / Temperature Probe Interface
This can be used with iButton devices for the purpose of driver ID, or with DS18B20 temperature
probes. Please refer to the appropriate application notes for more details of how to use these
features
CANBus
The AT110has integrated CANBus. Please refer to CANBus and FMS Application Notes for details
of supported protocols and features.
IMPORTANT NOTE: The CANBus pins are ESD protected to 15kV, but can only withstand
a continuous voltage of 12V maximum. These pins must not be used for any other
application to avoid damage to the device.
5-50V, 4.5V and 3.3V Outputs
These are reserved for use with external devices, all are fused at 250mA (non-resetting). The
3.3V regulated output can be used as a reference voltage for external temperature sensors and
used with the ADC1 input.
Device Configuration / Settings
For device configuration and related commands, please refer to the Astra Telematics Command
Reference document, which describes our generic commands, for use with all our devices.
Questions?
If you have any problems, questions, please contact Astra Telematics technical support:
[email protected]
[phone]

Electrical Parameters
Operating Conditions
Parameter
Min
Max
Units
Power Supply Input Voltage
+7
+36
V
Digital Input High Voltage Threshold
+5.0
-
V
Digital Input Low Voltage Threshold
-
+2.0
V
Digital Maximum Voltage
-
+30.0
V
Digital Maximum Current
-
0.5
A
Absolute Maximum Ratings
Parameter
Min
Max
Units
Power Supply Input Voltage
-32
+40
V
Voltage on Digital 1-4 and ADC Inputs
-32
+32
V
Voltage on Digital 5-6 (pull-down)
+3.3
V
Voltage on RS232 RX
-25
+25
V
Voltage on RS232 TX
-13
+13
V
Voltage on CAN RX/TX
-12
+12
V
Voltage on iButton/Dallas Interface
-5
+5
V
Current sunk by MOSFET low side switches
500
mA
Current handling of solid state relay switches
500
mA
Voltage rating of relay and MOSFET switches
+30.0
V
Storage Temperature
-40
+85
°C
Operating Temperature (without battery)
-20
+60
°C
Operating Temperature (with battery)
0
45
°C
Typical Power Consumption
Operating Mode
Current @ 13.8V
Current @ 27.6V
Power Consumption
Fully Operational
25mA
14mA
< 400mW
Battery charging
500mA
275mA
< 7W
Sleep (no battery)
0.5mA
0.3mA
7mW
Sleep (with battery)
< 10uA
< 10uA
0.1mW
Environmental Specifications
Parameter
Specification
Storage temperature
-40 to +85 °C
Operating temperature (no battery)
-20 to +60 °C
Operating temperature (with battery)
0 to +45 °C (note: no charging below 0°C)
Ingress Protection
N/A
Vibration, broadband random
Complies with IEC60068-2-64
Shock
Complies with IEC60068-2-64

AT110-STD (Standard) Kit Contents
Our AT110 standard kit is supplied with a CB110 power / ignition cable and an AE001 combined
GSM-GPS antenna.
CB110 Power / Ignition Cable
This 3-way fused cable is used to connect a permanent voltage source (i.e. power), ground and
an ignition-switched voltage source (i.e. ignition sense) to the AT110 device. The CB001 is fitted
with our standard 4-way power / ignition connector, which mates with a matching connector on
the CB243 cable.
AE001 Combined GSM / GNSS Antenna
The standard AT110 kit includes an AE001 combo antenna, for mounting beneath the vehicle
dashboard, adhesive side down:
Alternatively, we can offer the AE003 glass-mount combo antenna, which is designed for
mounting inside the vehicle windscreen, adhesive side up:

CB113 Plug-and-Play Cable
The 30-way AT110 cable is terminated to suit the CB001 power / ignition cable (above), and also
allows easy connection of our optional accessories. Note that each accessory is fitted with a
unique connector, which matches only one of the available CB113 connectors, hence preventing
incorrect termination. The following optional accessories are available from Astra Telematics and
supported by direct connection to the CB113 cable:
•IB001 iButton driver ID probe
•CB242 OBD cable
•CB002 FMS cable
•CC001 contactless CANBus adapter
•BZ001 buzzer
•CR001 RFID/NFC card reader
•CR002 MIFARE card reader
•TP001 1-wire temperature sensor
•DB001 driver behaviour indicator
For installation information, please refer to our AT110 Installation Guide
