Astria Alpha32ZEN User manual

Installation and Operation Instructions
Unvented (Vent-Free) Radiant Faced and Louvered
Fireplace System with Logs and Thermostat Blower
P/N 126878-01 REV. B 05/2017
Models
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation
section on Page 7 of this manual.
PFS
®
US
Report No. F12-047
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Alpha32ZEN
Alpha32ZEP
Alpha36ZEN
Alpha36ZEP
BisonMtn18
For use with log set (required option)
P126878-01

Astria.us.com 126878-01B2
TABLE OF CONTENTS
Safety .................................................................. 2
Product Identification........................................... 4
Local Codes......................................................... 5
Unpacking............................................................ 5
Product Features................................................. 6
Air For Combustion and Ventilation..................... 7
Installation ........................................................... 9
Operation........................................................... 23
Inspecting Burners............................................. 30
Cleaning and Maintenance................................ 31
Wiring Diagram.................................................. 32
Specifications .................................................... 33
Troubleshooting................................................. 34
Replacement Parts............................................ 41
Service Hints ..................................................... 41
Technical Service............................................... 41
Accessories....................................................... 41
Parts.................................................................. 42
Warranty............................................................ 47
SAFETY
Carbon Monoxide Poisoning: Early signs
of carbon monoxide poisoning resemble the
flu, with headaches, dizziness, or nausea. If
you have these signs, the heater may not be
workingproperly.Getfreshair at once!Have
heater serviced. Some people are more af-
fectedby carbonmonoxide thanothers.These
include pregnant women, people with heart or
lung disease or anemia, those under the influ-
ence of alcohol, and those at high altitudes.
Natural and Propane/LP Gas: Natural and
propane/LP gases are odorless. An odor-
making agent is added to the gas. The odor
helps you detect a gas leak. However, the
odor added to the gas can fade. Gas may be
present even though no odor exists.
Make certain you read and understand all
warnings. Keep this manual for reference.
It is your guide to safe and proper operation
of this heater.
WARNING: FIRE, EXPLOSION, AND ASPHYXIATION HAZARD
Improperadjustment,alteration,service,maintenance,orinstallationofthis
heater or its controls can cause death or serious injury.
Read and follow instructions and precautions in User’s Information Manual
provided with this heater.
WARNING: This is an unvented
gas-firedheater.Itusesair(oxygen)
fromtheroominwhichitisinstalled.
Provisionsforadequatecombustion
andventilationairmustbeprovided.
Refer to Air for Combustion and
Ventilation section on Page 7 of
this manual.
Thisappliancemaybeinstalledinan
aftermarket,* permanently located,
manufactured(mobile)home,where
not prohibited by local codes.
This appliance is only for use with
the type of gas indicated on the
rating plate. This appliance is not
convertibleforusewithothergases.
* Aftermarket: Completion of sale, not for
purpose of resale, from the manufacturer
WARNING:Thisproductcontains
and/or generates chemicals known
to the state of California to cause
cancer or birth defects or other re-
productive harm.
DANGER: Carbon monoxide
poisoning may lead to death!
WARNING:Vent-freeproductsare
prohibitedforbedroomandbathroom
installation in the Commonwealth of
Massachusetts.

Astria.us.com
126878-01B 3
SAFETY
Continued
IMPORTANT: Read this owner’s
manual carefully and completely
beforetryingtoassemble,operateor
service this fireplace. Improper use
of this fireplace can cause serious
injury or death from burns, fire, ex-
plosion,electricalshockandcarbon
monoxide poisoning.
WARNING: Any change to this
heater or its controls can be dan-
gerous.
WARNING: Do not use a blower
insert,heatexchangerinsertorother
accessorynotapprovedforusewith
this heater.
Due to high temperatures, the ap-
pliance should be located out of
traffic and away from furniture and
draperies.
Do not place clothing or other flam-
mable material on or near the appli-
ance. Never place any objects on
the heater.
Fireplace front and screen become
very hot when running fireplace.
Keep children andadults away from
hotsurfacestoavoidburnsorcloth-
ing ignition. Fireplace will remain
hot for a time after shutdown.Allow
surfaces to cool before touching.
Young children should be carefully
supervisedwhentheyareinthesame
room with the appliance. When us-
ingthehand-heldremoteaccessory,
keepselectorswitchintheOFFposi-
tiontopreventchildrenfromturning
on burners with remote.
Youmustoperatethisheaterwiththe
fireplace screen and hood in place
before running heater. The fireplace
screenshallhaveopeningsforintro-
duction of combustion air.
Keep the appliance area clear and
free from combustible materials,
gasolineandotherflammablevapors
and liquids.
WARNING: Do not allow fans
to blow directly into the fireplace.
Avoid any drafts that alter burner
flame patterns. Ceiling fans can
create drafts that alter burner flame
patterns.Alteredburnerpatternscan
cause sooting.
WARNING: Do not place log
scraps or volcanic stone on burner.
Solid-fuels shall not be burned in a
fireplaceinwhichanunventedroom
heater is installed.
2. Do not place propane/LP supply tank(s)
inside any structure. Locate propane/
LP supply tank(s) outdoors (propane/LP
only).
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touchany electrical switch; donot
use any phone in your building
1. WARNING: Thisappliance is onlyfor
use with the type of gas indicated on
the rating plate.This appliance isnot
convertible for use with other gases.
Installation and repair should be
done by a qualified service person.
The appliance should be inspected
before use and at least annually by
aprofessionalserviceperson.More
frequent cleaning may be required
duetoexcessivelintfromcarpeting,
beddingmaterial,etc.Itisimperative
thatcontrolcompartments,burners,
and circulating air passageways of
the appliance be kept clean.

Astria.us.com 126878-01B4
SAFETY
Continued
• immediately call your gas supplier from
aneighbor’sphone.Followthegassup-
plier’s instructions
• if you cannot reach your gas supplier,
call the fire department
4. This fireplace shall not be installed in a
bedroom or bathroom.
5. Do not use this fireplace as a wood-burn-
ing fireplace. Use only the logs provided
with the fireplace.
6. Do not add extra logs or ornaments such
as pine cones, vermiculite, or glowing
embers. Using these added items can
cause sooting. Do not add volcanic stone
around base. Volcanic Stone and debris
couldfallintothe control area of fireplace.
7. This fireplace is designed to be smoke-
less. If logs ever appear to smoke, turn
off fireplace and call a qualified service
person.
NOTE: During initial operation, slight
smokingcouldoccur duetolog curing and
fireplaceburning manufacturing residues.
8. To prevent the creation of soot, follow the
instructionsinCleaning andMaintenance,
Page 31.
9. Before using furniture polish, wax, carpet
cleaner, or similar products, turn heater
off.If heated, the vapors from these prod-
ucts may create a white powder residue
within burner box or on adjacent walls or
furniture.
10. Thisfireplaceneedsfreshair ventilationto
runproperly.Thisfireplacehasan Oxygen
Depletion Sensing (ODS) safety shutoff
Figure 1 - Log Base Assembly
PRODUCT IDENTIFICATION
Log Set
Base
Assembly
Front
Burner
Remote
Control
Figure 2 - Fireplace
Cont.
SM TW T FS
AM
PM
ROOM
SET
P1
A
P1
P2
P2
Pilot
:
ON THERMO OFF
°
u
°
PROGRAM
MODE/SET
Top Outer Casing
Top panel
Assembly
Fireplace
Hood
Bottom Panel
Assembly
Screen
Assembly
Magnet
Left Side
Right
Side
Front
system.TheODSshutsdown thefireplace
if not enough fresh air is available.
See Air for Combustion and Ventilation,
Page 7.Iffireplace keepsshuttingoff,see
Troubleshooting, Page 34.
11. Do not run fireplace
• where flammable liquids or vapors are
used or stored.
• under dusty conditions.
12. Do not use this fireplace to cook food or
burn paper or other objects.
13. Do not use fireplace if any part has been
under water. Immediately call a qualified
service technician to inspect the room
fireplace and to replace any part of the
controlsystem and any gas control which
has been under water.
14. Turn off and unplug fireplace and let
cool before servicing. Only a qualified
service person should service and repair
fireplace.
15. Operating fireplace above elevations of
4,500 feet could cause pilot outage.
16. Do not operate fireplace if any log is
broken. Do not operate fireplace if a log
is chipped (dime-sized or larger).
17. Toprevent performance problems, do not
usepropane/LPfuel tank of lessthan100
lbs. capacity (propane/LP only).
18. Provide adequate clearances around air
openings.
19. The screen or any other part removed
for servicing must be replaced prior to
operating this heater.

Astria.us.com
126878-01B 5
LOCAL CODES
UNPACKING
2. Locate two screws above top corners of
the fireplace screen. Remove and discard
thesescrews.Push the bottom corners of
thescreeninandrelease.The screenwill
pop out at the bottom. Grasp the bottom
of the screen, lift the screen up and pull
out to remove.
3. Remove protective packaging applied to
logs, log base assembly, and fireplace.
4. Remove fireplace hood from carton
inserts.
5. Checkall items for any shipping damage.
Ifdamaged,promptly inform dealerwhere
you purchased the fireplace.
Install and use firebox with care. Follow all
local codes. In the absence of local codes,
usethelatest editionofThe NationalFuelGas
Code ANS Z223.1/NFPA 54*. Firebox must
be electrically grounded in accordance with
the National Electrical Code, ANS/NFPA70
(latest edition).
NOTE: Where listed vented decorative logs
are required, thermostat operation is not
permitted.
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS
These appliances are approved for installation in the US state of Massachusetts if the fol-
lowing additional requirements are met:
• Un-vented Room Heaters shall be installed in accordance with 527 CMR 30.
• Installation and repair must be done by a plumber or gas fitter licensed in the Common-
wealth of Massachusetts.
• Theflexiblegasline connector used shall notexceed36inches(92centimeters) in length.
• The individual manual shut-off must be a T-handle type valve.
• Unvented appliances may NOT be installed in bedrooms or bathrooms.
• A working smoke detector must be installed in the area where vent-free appliances are
installed.
Seller of unvented propane or natural gas-fired supplemental room heaters shall provide
to each purchaser a copy of 527 CMR 30 upon sale of the unit.
*Available from:
American National Standards Institute, Inc.
25 West 43rd Street, 4th floor
New York, NY 10036
National Fire Protection Association, Inc.
1 Batterymarch Park
Quincy, MA 02169-7471
CAUTION:Donotremovethe
dataplatesattachedtotheheater
base assembly. The data plates
contain important warranty and
safety information.
1. With utility knife, cut the carton all the way
around above the staples on the bottom
tray. Lift the carton off the heater. Remove
packing.
NOTE: The hood is located in the packing
on the right hand side of the heater front.
Lift the heater off the bottom tray.

Astria.us.com 126878-01B6
PRODUCT FEATURES
OPERATION
This vent-free fireplace is clean burning. It
requires no outside venting. There is no heat
loss out a vent or up a chimney. Heat is gen-
erated by both realistic flames and glowing
embers. When used without the blower, the
fireplace requires no electricity making it ideal
for emergency backup heat.
SAFETY DEVICE
This fireplace has a pilot with an Oxygen
Depletion Sensing (ODS) safety shutoff
system. The ODS/pilot is a required feature
for vent-free room heaters. The ODS/pilot
system shuts off the fireplace if there is not
enough fresh air.
ELECTRONIC IGNITION SYSTEM
This heater has an electronic igniter to light
the fireplace's fuel supply.
BLOWER ASSEMBLY
Thisfireplaceincludesablowerassembly.The
blower operates thermostatically and features
avariablespeedcontrol.Theblowercirculates
heated air from the fireplace into the room.

Astria.us.com
126878-01B 7
Unusually tight construction is defined as
construction where:
a. walls and ceilings exposed to the out-
side atmosphere have a continuous
water vapor retarder with a rating of one
perm (6 x 10-11 kg per pa-sec-m2) or less
with openings gasketed or sealed and
b. weather stripping has been added on
openable windows and doors and
c. caulking or sealants are applied to
areas such as joints around window
and door frames, between sole plates
and floors, between wall-ceiling joints,
between wall panels, at penetrations for
plumbing, electrical, and gas lines, and
at other openings.
If your home meets all three criteria above,
you must provide additional fresh air. See
Ventilation Air From Outdoors, Page 9.
Ifyourhome doesnotmeet all three criteria
above, proceed to Determining Fresh-Air
Flow For Heater Location.
Confined and Unconfined Space
The National Fuel Gas Code, ANSI Z223.1/
NFPA54 allows two methods for determining
whether the space in which the heater is being
installed is confined or unconfined space. The
standardmethoddefinesaconfinedspaceasa
space whose volume is less than 50 cubic feet
per1,000Btuperhour(4.8m3perkw)oftheag-
gregateinputratingofall appliancesinstalledin
thatspaceandanunconfinedspaceasaspace
whose volumeis notless than50 cubic feetper
1,000 Btu per hour (4.8 m3per kw) of the ag-
gregateinputratingofall appliancesinstalledin
thatspace.Roomscommunicatingdirectlywith
thespaceinwhichtheappliancesareinstalled*,
through openings not furnished with doors, are
considered a part of the unconfined space.
Where the air infiltration rate of a structure is
known,theKnownAir Infiltration RateMethod
may be used. Follow The National Fuel Gas
Code, ANSI Z223.1/NFPA 54 to use this
method to determine if the space is confined
or unconfined.
* Adjoining rooms are communicating only if
therearedoorless passagewaysorventilation
grills between them.
DETERMINING FRESH-AIR FLOW
FOR FIREPLACE LOCATION
Determining if You Have a Confined or
Unconfined Space Using the Standard
Method
AIR FOR COMBUSTION AND VENTILATION
Today’s homes are built more energy efficient
thanever.Newmaterials,increasedinsulation,
and new construction methods help reduce
heat loss in homes. Homeowners apply
weather strip and caulk around windows and
doors to keepthe cold air out andthe warm air
in. During heating months, homeowners want
their homes as airtight as possible.
While it is good to make your home energy
efficient, your home needs to breathe. Fresh
air must enter your home.All fuel-burning ap-
pliancesneedfreshairforproper combustion
and ventilation.
Exhaust fans, some fireplaces, clothes dryers
and some fuel-burning appliances draw air
from the house to operate. You must provide
adequate fresh air for these appliances. This
will ensure proper venting of vented fuel-
burning appliances.
PROVIDING ADEQUATE
VENTILATION
Thefollowingareexcerptsfrom National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation.
All spaces in homes fall into one of the three
following ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on Pages 7–9 will help you
classify your space and provide adequate
ventilation.
Unusually Tight Construction
The air that leaks around doors and windows
may provide enough fresh air for combustion
and ventilation. However, in buildings of un-
usually tight construction, you must provide
additional fresh air.
WARNING: This heater shall not
be installed in a room or space un-
less the required volume of indoor
combustion air is provided by the
method described in the National
Fuel Gas Code, ANSI Z223.1/NFPA
54, the International Fuel Gas Code,
or applicable local codes. Read the
following instructions to ensure
properfreshair for this and other fuel-
burning appliances in your home.

Astria.us.com 126878-01B8
Use this work sheet to determine if you have
a confined or unconfined space.
Space: Includesthe roomin whichyouwill install
fireplace plus any adjoining rooms with door-
less passageways or ventilation grills between
the rooms.
1. Determine the volume of the space (length
x width x height).
Lengthx Width xHeight =__________cu. ft.
(volume of space)
Example:Space size 20 ft. (length) x 16 ft.
(width) x 8 ft. (ceiling height) = 2,560 cu. ft.
(volume of space)
If additional ventilation to adjoining room
is supplied with grills or openings, add the
volume of these rooms to the total volume
of the space.
2. Multiply the space volume by 20 to determine
the maximum Btu/Hr the space can support.
________ (volume of space) x 20 = (Maxi-
mum Btu/Hr the space can support)
Example:2,560 cu. ft. (volume of space) x
20 = 51,200 (maximum Btu/Hr the space can
support)
3. Add the Btu/Hr of all fuel burning appliances
in the space.
Vent-free fireplace _________Btu/Hr
Gas water heater* _________Btu/Hr
Gas furnace _________Btu/Hr
Vented gas heater _________Btu/Hr
Gas fireplace logs _________Btu/Hr
Other gas appliances* +________ Btu/Hr
Total =________Btu/Hr
* Do not include direct-vent gas appliances.
Direct-vent draws combustion air from the
outdoors and vents to the outdoors.
Example:
Gas water heater _____________Btu/Hr
Vent-free fireplace+ ___________ Btu/Hr
Total =____________Btu/Hr
4. Compare the maximum Btu/Hr the space
can support with the actual amount of Btu/
Hr used.
_______ Btu/Hr (maximum the space can
support)
_______ Btu/Hr (actual amount of Btu/Hr
used)
Example:51,200 Btu/Hr (maximum the
space can support)
73,000 Btu/Hr (actual amount of
Btu/Hr used)
The space in the example is a confined space
because the actual Btu/Hr used is more than the
maximum Btu/Hr the space can support. You
must provide additional fresh air. Your options
are as follows:
AIR FOR COMBUSTION AND VENTILATION
Continued
40,000
33,000
73,000
Figure 3 - Ventilation Air from Inside
Building
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills Into
Adjoining
Room,
Option 1
12"
12"
A. Rework worksheet, adding the space of an
adjoiningroom.Iftheextraspaceprovidesan
unconfined space, remove door to adjoining
room or addventilation grills betweenrooms.
See Ventilation Air From Inside Building.
B. Vent room directly to the outdoors. See
Ventilation Air From Outdoors Page 9.
C. Install a lower Btu/Hr fireplace, if lower Btu/
Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maxi-
mum Btu/Hr the space can support, thespace is
anunconfined space.You willneed noadditional
fresh air ventilation.
WARNING: If the area in which
the heater may be operated does not
meet the required volume for indoor
combustion air, combustion and
ventilation air shall be provided by
one of the methods described in the
NationalFuel Gas Code,ANSIZ223.1/
NFPA 54, the International Fuel Gas
Code, or applicable local codes.
VENTILATION AIR
Ventilation Air From Inside Building
This fresh air would come from an adjoining
unconfined space. When ventilating to an
adjoiningunconfinedspace,youmust provide
twopermanent openings:onewithin 12"ofthe
ceiling and one within 12" of the floor on the
wall connecting the two spaces (see options
1and2,Figure 3).You can alsoremovedoor
into adjoining room (see option 3, Figure 3).

Astria.us.com
126878-01B 9
INSTALLATION
CAUTION:Thisfireplacecre-
ates warm air currents. These
currents move heat to wall sur-
facesnexttofireplace.Installing
fireplace next to vinyl or cloth
wall coverings or operating
heater where impurities (such
as, but not limited, to tobacco
smoke,aromaticcandles,clean-
ingfluids,oilorkerosenelamps,
etc.)intheairexist,maydiscolor
walls or cause odors.
NOTE: Your fireplace is designed to be
used in zero clearance installations. Wall
or framing material can be placed directly
against any exterior surface on the rear,
sides, or top of your fireplace, except where
standoff spacers are integrally attached.
Where standoff spacers are attached to your
fireplace, combustible material (studs and
wall board) may be place on top and above
the top of the standoffs.
Usethe dimensionsshownforroughopenings
to create the easiest installation. See Built-In
Fireplace Installation, Page 12.
IMPORTANT:Vent-free heatersaddmoisture
totheair.Althoughthis is beneficial, installing
fireplace in rooms without enough ventilation
air may cause mildew to form from too much
moisture.SeeAir forCombustionandVentila-
tion, Page 7.
IMPORTANT:Makesurethefireplaceislevel.If
fireplaceisnotlevel,logsetwillnotworkproperly.
Figure 4 - Ventilation Air from Outdoors
Outlet
Air
Ventilated
Attic
Outlet
A
ir
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two perma-
nent openings: one within 12" of the ceiling
andonewithin12"ofthefloor. Connect these
items directly to the outdoors or spaces open
to the outdoors. These spaces include attics
and crawl spaces. Follow the National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation for required size
of ventilation grills or ducts.
IMPORTANT: Do not provide openings
for inlet or outlet air into attic if attic has a
thermostat-controlled power vent. Heated air
entering the attic will activate the power vent.
NOTICE: This appliance is in-
tended for supplemental heat-
ing. Use this heater along with
yourprimaryheatingsystem.Do
notinstallthisheaterasyourpri-
mary heat source. If you have a
centralheatingsystem,youmay
run system’s circulating blower
whileusingheater.Thiswillhelp
circulatetheheatthroughoutthe
house. In the event of a power
outage, you can use this heater
as your primary heat source.
WARNING: A qualified ser-
vice person must install fire-
place. Follow all local codes.
WARNING: Never install the
fireplace
• in a bedroom or bathroom
• in a recreational vehicle
• where curtains, furniture,
clothing, or other flammable
objects are less than 36" from
the front and 42" from the top
of fireplace. For side clear-
ances see Figure 8, Page 11
• in high traffic areas
• in windy or drafty areas
AIR FOR COMBUSTION AND VENTILATION
Continued

Astria.us.com 126878-01B10
Figure 5 - Installing Hood
Screw
Hood
Rail
INSTALLATION
Continued
Figure 6 - Assembling Perimeter Trim
Side Trim
Slot
Mitered
Edge
Slot
Shim
Set Screws
Adjusting
Plate
Assembled
Trim
Top
Trim
Figure 7 - Attaching Perimeter Trim to
Fireplace
Trim
Hanging
Screws
Hanging
Notches
on Trim
Mitered
Edge
ASSEMBLING AND ATTACHING
OPTIONAL PERIMETER TRIM
(Included with Mantel Accessory)
IMPORTANT: Ifyouarerecessingthefirebox
in a wall, do not attach trim at this time. See
Built-In Fireplace Installation,Page 12.
NOTE: These instructions show assembling
and attaching trim to fireplace.
CHECK GAS TYPE
Use the correct gas type (natural or propane/
LP)foryourfireplace. If your gas supplyisnot
correct, do not install fireplace. Call dealer
where you purchased fireplace for proper
type fireplace.
WARNING:Thisapplianceis
equippedfornaturalorpropane/
LP gas but not both. Gas type is
indicated on rating plate. Field
conversion is not permitted.
ELECTRICAL HOOKUP
This fireplace includes a blower which must
be connected to either a wall receptacle or
theelectricalreceptaclethatisincludedwithin
the fireplace. If the receptacle included with
the fireplace is to be used, it must be wired
to a 120 volt supply by a certified electrician.
INSTALLING HOOD
Installhoodto railalreadyinstalledin fireplace
as shown in Figure 5. Use 3 Phillips screws
provided.
1. Remove packaging from three pieces
of trim.
2. Locate four screws, two adjusting plates
with set screws, and two shims in the
hardware packet.
3. Alignshimunderadjusting plateasshown
in Figure 6.
4. Slide one end of adjusting plate/shim
in slot on mitered edge of top trim (see
Figure 6).
5. Slide other end of adjusting plate/shim
in slot on mitered edge of side trim (see
Figure 6).
6. While firmly holding edges of trim to-
gether, tighten both set screws on the
adjusting plate with slotted screwdriver.
7. Repeat steps 1 through 6 for other side.
8. Tighten trim hanging screws (#10 x 6.25
shoulder) into holes in cabinets. Place
the assembled trim onto fireplace cabi-
net. Align hanging notches on trim with
hanging screws on side of fireplace (see
Figure 7).Pushtrim firmly intoplace,slid-
inghanging notchesoverhanging screws.

Astria.us.com
126878-01B 11
INSTALLATION
Continued
2. Installaproperly grounded,120volt three-
prongelectricaloutletat fireplace location
if an outlet is not there. If possible, locate
outletsocabinetmantelwillcoveritwhen
installed (see Figure 9).
3. Installgaspiping tofireplacelocation.This
installation includes an approved flexible
gas line (if allowed by local codes) after
the equipment shutoff valve. The flexible
gas line must be the last item installed on
the gas piping. See Installing Gas Piping
to Fireplace Location, Page 14.
4. Placehearthbaseaccessoryagainstwallat
installation location. Cut an access hole in
hearthtoptorunflexiblegaslinetofireplace
(seeFigure 9).Make sureto locate access
hole so cabinet mantel will cover it when
installed.
NOTE:You can secure base to floor using
woodscrews.Countersinkscrewheadsand
putty over.
5. Route flexible gas line through access
hole in hearth base.
6. Center cabinet mantel on hearth base (see
Figure 10, Page 12). Make sure mantel is
flush against wall.
7. Placecardboardorother protective mate-
rial on top of hearth base. Carefully set
fireplaceonprotectivematerial, with back
of fireplace inside mantel opening.
8. Attach flexible gas line from fireplace gas
regulator to gas supply. See Connecting
Fireplace to Gas Supply, Page 15.
9. Route blower electrical cord through ac-
cess holes in either side of fireplace.
CONVENTIONAL FIREPLACE
INSTALLATION
Conventional installation of this fireplace
involves installing fireplace along with the
corner, face, or cabinet mantel with hearth
baseaccessoriesagainst awallinyour home.
Followtheinstructionsinthis section to install
the fireplace in this manner.
1. Assemble cabinet mantel, hearth base,
and trim accessories. Assembly instruc-
tions are included with each accessory.
Figure 9 - Placing Hearth Base
Accessory Against Wall
Electrical Outlet
Hearth Base
Rigid Pipe and Gas
Shutoff Valve
Gas Line
Access Hole
INSTALLATION CLEARANCES
WARNING: Maintain the
minimum clearances. If you can,
provide greater clearances from
floor, ceiling, and adjoining wall.
Carefully follow the instructions below. This
will ensure safe installation.
MinimumClearancesForSideCombustible
Material, Side Wall, and Ceiling
A. Clearances from the side of the fireplace
cabinet to any combustible material and
wall should follow diagram in Figure 8.
Example:Theface ofamantel, bookshelf,
etc. is made of combustible material and
protrudes 3 1/2" from the wall. This com-
bustiblematerialmustbe4" from the side
of the fireplace opening (see Figure 8).
B. Clearances from top of fireplace opening
to ceiling should not be less than 42".
MINIMUM CLEARANCE TO
COMBUSTIBLE MATERIALS
Top 0", Left and Right Sides 16",
Bottom and Rear 0", Front 36"
*Minimum 16" from Side Wall
Figure 8 - Minimum Clearance for
Combustible to Wall
*
Example
Maintain adequate clearances for accessibility for purposes
of servicing and proper operation.

Astria.us.com 126878-01B12
Figure 10 - Installing Cabinet Mantel
Cabinet
Mantel
Figure 11 - Location of Nailing Flange
Nailing
Flange
10. Carefullyinsertfireplaceintocabinetmantel.
Be careful not to scratch or damage hearth
base, cabinet mantel, or any laminate trim
onhearthbase.Removeprotectivematerial
from top of hearth base and from front of
fireplace (if any).
NOTE: You can secure fireplace to hearth
or floor. Remove burner assembly. Locate
screw holes in bottom of base. Tighten
wood screws through these holes and into
hearth or floor. Replace burner assembly.
11. Check all gas connections for leaks. See
Checking Gas Connections, Page 16.
INSTALLATION
Continued
Figure 12 - Inserting Fireplace Into
Cabinet Mantel
BUILT-IN FIREPLACE
INSTALLATION
Built-in installation of this fireplace involves
installing fireplace into a framed-in enclosure.
Thismakesthefrontoffireplaceflushwithwall.
If installing a mantel above the fireplace, you
must follow the clearances shown in Figure
16, Page 13. Follow the instructions below to
install the fireplace in this manner.
1. Frameinroughopening.Usedimensions
showninFigure 13 for theroughopening.
If installing in a corner, use dimensions
shown in Figure 14, Page 13, Figure 13,
for the rough opening.
Figure 13 - Rough Opening for Installing
in Wall
Rough Opening Dimensions for Built-in
Installation
Model Front Width
(Inside to Inside) Height Depth
32" 34 7/8" 36 3/4" 16 1/4"
36" 41 1/2" 40 1/2" 20 3/4"
Depth
(Minimum)
Width
(Inside to Inside)
Height

Astria.us.com
126878-01B 13
INSTALLATION
Continued
2. Install gas piping into fireplace location.
Thisinstallation includesanapprovedflex-
iblegasline(ifallowedbylocalcodes)after
the equipment shutoff valve. The flexible
gas line must be the last item installed on
the gas piping. See Installing Gas Piping
to Fireplace Location, Page 14.
3. Carefully set fireplace in front of rough
opening with back of fireplace inside wall
opening.
4. Carefully insert fireplace into rough
opening.
5. Attach flexible gas line to gas supply.
SeeConnectingFireplacetoGasSupply,
Page 15.
6. Attach fireplace to wall studs using nails
or wood screws through holes in nailing
flange (see Figure 15).
Figure 14 - Rough Opening for Installing
in Corner
Figure 15 - Attaching Fireplace to Wall
Studs
Nailing
Flange
Nails or
Wood
Screws
Figure 16 - Minimum Mantel Clearances
for Built-In Installation
7. Check all gas connections for leaks. See
Checking Gas Connections, Page 16.
8. Plug electrical cord into electrical outlet.
9. Installtrimafter finalfinishingand/orpaint-
ing of wall (see Figure 7, Page 10).
IMPORTANT: When finishing your firebox,
combustible materials such as wall board,
gypsum board, sheet rock, drywall, plywood,
etc.may bebuttedup nexttothe sidesandtop
of the firebox. Combustible materials should
never overlap the firebox front facing.
WARNING: Do not allow any
combustiblematerialstooverlap
the firebox front facing.
IMPORTANT: Noncombustiblematerialssuch
asbrick,tile,etc. may overlap thefrontfacing,
but should never cover any necessary open-
ings like louvered slots or screen assembly.
WARNING: Do not allow
noncombustible materials to
cover any necessary openings
like louvered slots.
WARNING:Useonlynoncom-
bustiblemortaroradhesiveswhen
overlapping the front facing with
noncombustible facing material.
* THESE DIMENSIONS ALLOW FOR
MINIMUM CLEARANCES TO A 45°
PROJECTED SIDE WALL
HOWEVER, CLEARANCES TO
PROJECTED MANTEL TRIMS AND
FACINGS ARE ALLOWED WITHIN
A MINIMUM OF 16" TO A
PERPENDUCULAR WALL AS
SHOWN IN FIGURE 5, ON PAGE 10
55 5/8"
39 3/8"
34 1/2"
27 3/4"
0" CLEARANCE
*10 1/2"*10 1/2"
*14 1/2"
50 3/8"
71 1/4"
35 5/8"
*14 1/2"
41 1/2"
0" CLEARANCE
0" CLEARANCE
FOR 32" MODELS
FOR 36" MODELS
FOR 42" MODELS
Figure
a
Figure
b
Supplied
Firebox Hood
Must Be Used
at All Times
Wire-mesh
Screen
Firebox
Noncombustible
Material May
Project Off this
Surface above
the Firebox Hood
Mantel Shelf
Note: Any portion of the
mantel shelf must NOT
extend beyond this profile.
12" 16" 20"
1
1
/ 2 "
6
3
/ 4 "
12"
Note: All vertical
measurements are
from top of fireplace
hood opening to
bottom of mantel shelf.
These minimum
clearances replace any
other recommended
clearances supplied
with your ANSI Z21.11.2
approved gas logs.
Wall board or facing
material (above
firebox) may be of
combustible material,
including decorative
mantel ornaments or
other similar projec-
tions off of the facing
material.
Framing
Material
such

Astria.us.com 126878-01B14
INSTALLATION
Continued
WARNING: Never connect
natural gas fireplace to private
(non-utility) gas wells. This
gas is commonly known as
wellhead gas.
Installation Items Needed
Before installing fireplace, make sure you
have the items listed below.
• external regulator for propane/LP unit only
(supplied by installer)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve *
• test gauge connection *
• sediment trap (optional)
• tee joint
• pipe wrench
• approvedflexiblegas line withgasconnec-
tor(ifallowed bylocalcodes) (notprovided)
* A equipment shutoff valve with 1/8" NPT
tap is an acceptable alternative to test gauge
connection.
For propane/LP units, the installer must
supply an external regulator. The external
regulator will reduce incoming gas pressure.
You must reduce incoming gas pressure to
between 11" and 14" of water. If you do not
reduceincominggas pressure, heaterregula-
tordamagecouldoccur. Install external regu-
lator with the vent pointing down as shown in
Figure 17, Page 15. Pointing the vent down
protects it from freezing rain or sleet.
CAUTION: Use only new,
black iron or steel pipe. Inter-
nally-tinned copper tubing may
be used in certain areas. Check
your local codes. Use pipe of
1/2"diameterorgreatertoallow
proper gas volume to fireplace.
If pipe is too small, undue loss
of volume will occur.
Mantel Clearances for Built-In
Installation
If placing mantel above built-in fireplace, you
mustmeetminimum clearancebetweenman-
tel shelf and top of fireplace opening.
NOTICE:Ifyourinstallationdoes
not meet the minimum clear-
ances shown, you must do one
of the following:
• raise the mantel to an accept-
able height
• remove the mantel
NOTICE: Surface temperatures
of adjacent walls and mantels
become hot during operation.
Walls and mantels above the
firebox may become hot to
the touch. If installed properly,
these temperatures meet the
requirement of the national
product standard. Follow all
minimum clearances shown in
this manual.
INSTALLING GAS PIPING TO
FIREPLACE LOCATION
WARNING: This appliance
requires a 1/2" NPT (National
Pipe Thread) inlet connection.
WARNING: A qualified
service person must connect
fireplace to gas supply. Follow
all local codes.
CAUTION: Never connect
propane/LP fireplace directly
to the propane/LP supply. This
fireplace requires an external
regulator (not supplied). Install
the external regulator between
the fireplace and propane/LP
supply.

Astria.us.com
126878-01B 15
Installationmustinclude anequipmentshutoff
valve, union, and plugged 1/8" NPT tap. Lo-
cateNPTtap withinreachfortestgaugehook
up. NPT tap must be upstream from fireplace
(see Figure 18).
IMPORTANT: Install equipment shutoffvalve
in an accessible location. The equipment
shutoff valve is for turning on or shutting off
the gas to the appliance.
Check your building codes for any special
requirements for locating equipment shutoff
valve to fireplaces.
Apply pipe joint sealant lightly to male NPT
threads.This willpreventexcesssealantfrom
going into pipe. Excess sealant in pipe could
result in clogged fireplace valves. Never use
sealant on flare threads.
WARNING: Use pipe joint
sealantthatisresistanttoliquid
petroleum (LP) gas.
We recommend that you install a sediment
trap in supply line as shown in Figure 18.
Locate sediment trap where it is within reach
for cleaning. Install in piping system between
fuel supply and fireplace. Locate sediment
trap where trapped matter is not likely to
freeze. A sediment trap traps moisture and
contaminants. This keeps them from going
into fireplace gas controls. If sediment trap
is not installed or is installed wrong, fireplace
may not run properly.
INSTALLATION
Continued
Figure 17 - External Regulator on
Propane/LP Supply Tank with Vent
Pointing Down
External
Regulator Propane/LP
Supply Tank
Vent Pointing Down
CONNECTING FIREPLACE TO GAS
SUPPLY
Installation Items Needed
• 5/16" hex socket wrench or nut-driver
• Phillips screwdriver
• sealant (resistant to propane/LP gas, not
provided)
1. Remove fireplace screen. Remove two
screws that hold fireplace screen in place
for shipping. These screws are located
near top of screen. Discard screws. Push
the bottom corners of the screen in and
release. The screen will pop out at the
bottom. Grasp the bottom of the screen,
lift the screen up and pull out to remove.
2. Remove screws that attach log base as-
sembly to fireplace (see Figure 19, Page
16). Carefully lift up log base assembly
and remove from fireplace (see Figure
19, Page 16).
3. Route gas line (provided by installer)
fromequipmentshutoffvalve to fireplace.
Routeflexiblegas supplylinethroughone
of the access holes.
4. Attach the flexible gas line to gas supply
(see Figure 20, Page 16). Check tight-
ness of flexible gas line attached to gas
regulator of fireplace (see Figure 20,
Page 16).
5. Check all gas connections for leaks. See
Checking Gas Connections, Page 16.
**Minimuminlet pressure for purposeofinput
adjustment.
Figure 18 - Gas Connection
3" Minimum
Natural Gas
From Gas
Meter
(5" W.C.** to
10.5" W.C.
Pressure)
Propane/LP
From External
Regulator
(11" W.C.**
to 14" W.C.
Pressure)
Sediment Trap
Cap Pipe Tee
Nipple Joint

Astria.us.com 126878-01B16
INSTALLATION
Continued
Figure 19 - Removing Log Base
Assembly From Fireplace
Figure 20 - Attaching Flexible Gas Lines
Together
Flexible Gas Line
from Fireplace Gas
Regulator
To Fireplace Gas
Regulator Equipment Shutoff
Valve Provided by
Installer Propane/LP
To External
Regulator
Natural Gas
To Gas Meter
6. Replace log base assembly back into
fireplace. Feed flexible gas line into fire-
place base area while replacing log base
assembly. Make sure the entire flexible
gas line is in fireplace base area. Reat-
tach log base assembly to fireplace with
screws removed in step 2, Page 15.
CAUTION: Do not pick up
log base assembly by burner.
Thiscoulddamageburner.Only
handle base by grates.
NOTICE: Most building codes
do not permit concealed gas
connections. A flexible gas line
is provided to allow accessibility
fromthefireplace(seeFigure20).
The flexible gas supply line con-
nection to the equipment shutoff
valve should be accessible.
CHECKING GAS CONNECTIONS
WARNING:Testallgaspiping
and connections, internal and
external to unit, for leaks after
installing or servicing. Correct
all leaks at once.
WARNING: Never use an
open flame to check for a leak.
Applyanoncorrosiveleakdetec-
tion fluid to all joints. Bubbles
forming show a leak. Correct all
leaks at once.
CAUTION: Make sure exter-
nal regulator has been installed
betweenpropane/LPsupplyand
fireplace. See guidelines under
Connecting Fireplace to Gas
Supply, Page 15.
PRESSURE TESTING GAS SUPPLY
PIPING SYSTEM
Test Pressures In Excess Of 1/2 PSIG
(3.5 kPa)
1. Disconnect fireplace with its main gas
valve(controlvalve)andequipmentshut-
off valve from gas supply piping system.
Pressures in excess of 1/2 psig (3.5 kPa)
will damage fireplace regulator.
2. Capoffopenendof gaspipewhere equip-
ment shutoff valve was connected.
3. Pressurizesupplypipingsystem by either
opening propane/LP supply tank valve
for propane/LP gas or opening main gas
valve located on or near gas meter for
natural gas, or using compressed air.
4. Checkalljointsofgassupplypipingsystem.
Apply noncorrosive leak detection fluid to
all joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Reconnect fireplace and equipment
shutoff valve to gas supply. Check recon-
nected fittings for leaks.

Astria.us.com
126878-01B 17
Test Pressures Equal To or Less Than
1/2 PSIG (3.5 kPa)
1. Close equipment shutoff valve (see
Figure 21).
2. Pressurizesupplypipingsystem by either
opening propane/LP supply tank valve
for propane/LP gas or opening main gas
valve located on or near gas meter for
natural gas, or using compressed air.
3. Check all joints from gas meter to equip-
ment shutoff valve for natural gas or pro-
pane/LPsupply toequipment shutoffvalve
for propane/LP (see Figures 22 and 23).
Apply noncorrosive leak detection fluid to
all joints. Bubbles forming show a leak.
4. Correct all leaks at once.
INSTALLATION
Continued
Figure 21 - Equipment Shutoff Valve
Figure 23 - Checking Gas Joints for
Propane/LP Gas
Propane/LP
Supply Tank
Figure 22 - Checking Gas Joints for
Natural Gas
Gas Control Valve
Equipment Shutoff Valve
Equipment
Shutoff
Valve
Gas Meter
Gas Control Valve
Open
Closed
Equipment
Shutoff
Valve
PRESSURE TESTING FIREPLACE GAS
CONNECTIONS
1. Open equipment shutoff valve (see Fig-
ure 21).
2. Open main gas valve located on or near
gas meter for natural gas or open pro-
pane/LP supply tank valve.
3. Make sure control knob of fireplace is in
the OFF position.
4. Check all joints from equipment shutoff
valvetogas controlvalve(seeFigures 22
or 23).Applynoncorrosiveleakdetection
fluid to all joints. Bubbles forming show a
leak.
5. Correct all leaks at once.
6. Light fireplace (see Operation, Page 23).
Check all other internal joints for leaks.
7. Turn off fireplace (see To Turn Off Gas to
Appliance, Page 23).
POWER SUPPLY AND BATTERY
INSTALLATION
It is helpful to have a flashlight so you can
see the connections as described below. Lo-
cate the battery power supply. It is the black
box with the red and black wires. Locate the
control module (see Figure 24). Connect the
battery power supply to the control module
by plugging the battery power supply to the
matingreceptacleonthecontrolmodule.The
receptacle is located on the side of the black
control module next to the word “SUPPLY”
which is molded in the control module’s black
housing (see Figure 24). Be certain to push
the plug fully into the receptacle. Install bat-
teries in the battery power supply and hand
held remote control.
Figure 24 - Control Module
S1 Button
Connect Battery Plug Here

Astria.us.com 126878-01B18
INSTALLATION
Continued
TOUCH PAD INSTALLATION
Locate the touch pad wire harness and the
touch pad control (see Figure 25). They are
shipped from the factory in the clear plastic
bag with your owner’s manual. Connect the
black plastic connectors together as shown
in Figure 26. Connect the remaining end
with the white plastic connector to the control
module in the socket marked TOUCH LED
(see Figure 27).
NOTE: The touch pad includes a red LED
display light. If the LED remains on, the black
plug is connected upside down. You must
unplug the touch pad control from the touch
pad wire harness, turn over, and reconnect.
Figure 26 - Touch Pad Control Cable
Figure 25 - Touch Pad Wire Harness and
Touch Pad Control
Figure 27 - Connecting end of Touch Pad
Cable
Touch Pad Wire
Harness
Touch Pad Control
INSTALLING LOGS
WARNING:Failuretoposition
thepartsinaccordancewiththese
diagrams or failure to use only
parts specifically approved with
thisheatermayresultinproperty
damage or personal injury.
CAUTION: Do not remove
the data plates attached to the
heater base assembly. The data
plates contain important safety
and warranty information.
1. Place fiber ramp log in center of chassis
as shown in Figure 28. The fiber ramp
log can be identified by the shape and
much lighter weight when compared to
the other logs. The log must sit flat on the
blacksheet metaland behindtheleftmetal
tab as shown. Make sure the side marked
''BOTTOM'' is setting down.
2. Placefrontleftandfrontrightlogsasshown
in Figure 29.
Figure 28 - Installing Fiber Ramp Log
Ramp Log
Metal
Tab
Figure 29 - Installing Left/Right Front Logs
Left Front
Log
Right Front Log

Astria.us.com
126878-01B 19
INSTALLATION
Continued
Figure 30 - Installing Left Ember Bed Log
Left Ember
Bed Log
3. Place left ember bed log as shown in
Figure 30. The log has groove on one
side that sets on the ember bed pan. The
back side of this log needs to rest against
thefrontofthe base assembly.Makesure
the flame from the ember pan does not
touch the ember bed log.
4. TheAlpha32 andAlpha36 use two different
rightemberbedlogs. TheAlpha32rightem-
ber bed log is installed in the same manner
as the log in step 3 above but on the right
side. TheAlpha36 right ember bed log has
a hole in the bottom that sets on the grate
fingerandtheotherendrestonthefireplace
floor, place log as shown in Figure 31. The
back side of this log needs to rest against
the front of the base assembly, make sure
theflamefromtheemberpandoesnottouch
the ember bed log.
Figure 31 - Installing Right Ember Bed Log
5. The left middle log has a groove on the
bottom to sit on the chassis and has to sit
on the tab on the back of the left front log
as shown in Figure 32.
6. The right middle log has a groove on the
bottom to sit on the chassis and has to sit
onthetabonthebackoftherightfront.The
rightmiddlelog shouldhavea recessarea
that fits around the ramp log as shown in
Figure 33.
Alpha36 Right
Ember Bed Log
Hole
Underneath
Grate Prong
Figure 32 - Installing Left Middle Log
Left Middle
Log
Figure 33 - Installing Right Middle Log
Right Middle
Log
7. The rear middle log should fit between the
ramp log and the rear burner. The left and
right middle logs have recessed areas for
the rear middle log to sit into (See Figure
34, Page 20). Be careful not to push the
rear burner out of position while installing
this log.
8. Rest rear log in back corner sections of
chassis assembly as shown in Figure 35,
Page 20.
9. Place the left top log onto the rear log and
the left middle log. Make sure to place the
projection on the bottom of the left top log
intothe recessedareasontherearandleft
middle logs (see Figure 36).

Astria.us.com 126878-01B20
INSTALLATION
Continued
Rear
Middle Log
Figure 34 - Installing Rear Middle Log
Figure 35 - Installing Rear Log
Rear Log
Figure 36 - Installing Left Top Log
Figure 37 - Installing Middle Crossover Log
Rear Log
Left Top Log
Left
Middle
Log
Middle
Crossover
Log
Figure 38 - Installing Top Rear Log
Top Rear
Log Rear Log
10. Restthemiddlecrossoverlogontotheright
middlelogandtheleftfrontlog(seeFigure
37). Make sure to match the projection on
the bottom of the crossover log with the
recess area in the right middle log and the
left front log.
11. Place the top rear log onto the rear log as
shown. The rear log has a projection that
will fit into the recess area on the bottom
of the top rear log (see Figure 38).
