Asus AAEON AEC-6613 User manual

Last Updated: December 31, 2015
AEC-6613
Fanless Embedded Box PC
User‟s Manual 4th Ed
All manuals and user guides at all-guides.com
all-guides.com

Preface II
Fanless Embedded Box PC AEC-6613
Copyright Notice
This document is copyrighted, 2015. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.
All manuals and user guides at all-guides.com

Preface III
Fanless Embedded Box PC AEC-6613
Acknowledgement
All other products‟ name or trademarks are properties of their respective owners.
Microsoft Windows is a registered trademark of Microsoft Corp.
Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel Corporation
Core, Atom are trademarks of Intel Corporation
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines
Corporation.
All other product names or trademarks are properties of their respective owners.
All manuals and user guides at all-guides.com

Preface IV
Fanless Embedded Box PC AEC-6613
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
BOXER-6613
1
Phoenix power connector
1
Screw package
1
Heat spreader
1
Wall mount brackets
2
Product CD with User‟s Manual (in pdf) and drivers
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.
All manuals and user guides at all-guides.com

Preface V
Fanless Embedded Box PC AEC-6613
About this Document
This User‟s Manual contains all the essential information, such as detailed descriptions
and explanations on the product‟s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver
installation instructions (if any), to facilitate users in setting up their product.
Users may refer to the AAEON.com for the latest version of this document.
All manuals and user guides at all-guides.com

Preface VI
Fanless Embedded Box PC AEC-6613
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. All cables and adapters supplied by AAEON are certified and in accordance with
the material safety laws and regulations of the country of sale. Do not use any
cables or adapters not supplied by AAEON to prevent system malfunction or
fires.
3. Make sure the power source matches the power rating of the device.
4. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
5. Always completely disconnect the power before working on the system‟s
hardware.
6. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
7. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
8. Always disconnect this device from any AC supply before cleaning.
9. While cleaning, use a damp cloth instead of liquid or spray detergents.
10. Make sure the device is installed near a power outlet and is easily accessible.
11. Keep this device away from humidity.
12. Place the device on a solid surface during installation to prevent falls
13. Do not cover the openings on the device to ensure optimal heat dissipation.
14. Watch out for high temperatures when the system is running.
15. Do not touch the heat sink or heat spreader when the system is running
16. Never pour any liquid into the openings. This could cause fire or electric shock.
All manuals and user guides at all-guides.com
all-guides.com

Preface VII
Fanless Embedded Box PC AEC-6613
17. As most electronic components are sensitive to static electrical charge, be sure
to ground yourself to prevent static charge when installing the internal
components. Use a grounding wrist strap and contain all electronic components
in any static-shielded containers.
18. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
19. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE‟S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.
All manuals and user guides at all-guides.com

Preface VIII
Fanless Embedded Box PC AEC-6613
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept
any interference received including interference that may
cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer‟s instructions and your local government‟s
recycling or disposal directives.
Attention:
Il y a un risque d‟explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu‟avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et
les directives gouvernementales de recyclage.
All manuals and user guides at all-guides.com

Preface IX
Fanless Embedded Box PC AEC-6613
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON Embedded Box PC/ Industrial System
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
○
○
○
○
○
○
外部信号
连接器及线材
○
○
○
○
○
○
外壳
○
○
○
○
○
○
中央处理器
与内存
○
○
○
○
○
○
硬盘
○
○
○
○
○
○
电源
○
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、电源为选购品。
All manuals and user guides at all-guides.com

Preface X
Fanless Embedded Box PC AEC-6613
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
AAEON Embedded Box PC/ Industrial System
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components
○
○
○
○
○
○
Wires &
Connectors
for External
Connections
○
○
○
○
○
○
Chassis
○
○
○
○
○
○
CPU & RAM
○
○
○
○
○
○
Hard Disk
○
○
○
○
○
○
PSU
○
○
○
○
○
○
O：The quantity of poisonous or hazardous substances or elements found in each of the
component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least one of the
component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this product is applicable under normal
usage only
All manuals and user guides at all-guides.com

Preface XI
Fanless Embedded Box PC AEC-6613
Table of Contents
Chapter 1 - Product Specifications........................................................................................1
1.1 Specifications............................................................................................................ 2
Chapter 2 –Hardware Information .......................................................................................4
2.1 Dimensions............................................................................................................... 5
2.2 Jumpers and Connectors .................................................................................... 11
2.3 List of Jumpers ....................................................................................................... 13
2.4 List of Connectors ................................................................................................. 14
2.4.1 COM2 Port #4 (CN16)................................................................. 16
2.4.2 COM2 Port #3 (CN18)................................................................. 16
2.4.3 COM2 Port #2 (CN20)................................................................. 16
2.4.4 RCOM Port #1 (CN33)................................................................. 17
2.5 CFast™ Card Installation ...................................................................................... 18
2.6 Hard Disk Drive Installation (Model A1M/A2M) ............................................. 19
2.7 SDRAM Installation ............................................................................................... 22
2.8 DIN Rail Installation............................................................................................... 26
2.9 Wallmount Kit Installation.................................................................................... 27
Chapter 3 - AMI BIOS Setup................................................................................................28
3.1 System Test and Initialization .............................................................................. 29
3.2 AMI BIOS Setup..................................................................................................... 30
3.3 Setup Submenu: Main.......................................................................................... 31
3.4 Setup Submenu: Advanced ................................................................................ 32
3.4.1 Advanced: ACPI Settings............................................................. 34
3.4.2 Advanced: CPU Computing ....................................................... 35
3.4.3 Advanced: SATA Configuration.................................................. 36
3.4.4 Advanced: USB Configuration ................................................... 37
3.4.5 Advanced: Super IO Configuration........................................... 39
All manuals and user guides at all-guides.com
all-guides.com

Preface XII
Fanless Embedded Box PC AEC-6613
3.4.5.1 Super IO Configuration: Serial Port 2 Configuration. 40
3.4.6 Advanced: Smart Fan Function.................................................. 42
3.4.7 Advanced: H/W Monitor............................................................. 43
3.5 Setup submenu: Chipset...................................................................................... 44
3.5.1 Chipset: Host Bridge .................................................................... 45
3.5.1.1 Chipset: IGD Configuration............................................. 46
3.5.2 Chipset: South Bridge.................................................................. 47
3.5.2.1 South Bridge: TPT Devices.............................................. 48
3.6 Setup submenu: Boot........................................................................................... 49
3.6.1 Boot: BBS Priorities....................................................................... 50
3.7 Security.................................................................................................................... 51
3.7.1 Security: HDD Security................................................................. 53
3.8 Setup submenu: Save & Exit............................................................................... 55
Chapter 4 –Drivers Installation ...........................................................................................56
4.1 Product CD/DVD................................................................................................... 57
Appendix A - Watchdog Timer Programming...................................................................59
A.1 Watchdog Timer Programming ......................................................................... 60
A.2ITE8783 Watchdog Timer Initial Program........................................................ 64
Appendix B - I/O Information..............................................................................................69
B.1 I/O Address Map................................................................................................... 70
B.2 1st Memory Address Map.................................................................................... 72
B.3 IRQ Mapping Chart .............................................................................................. 73
B.4 DMA Channel Assignments ................................................................................ 75
Appendix C –AHCI Settings .................................................................................................76
C.1 Setting AHCI........................................................................................................... 77
All manuals and user guides at all-guides.com

Fanless Embedded Box PC AEC-6613
Chapter 1
Chapter 1 - Product Specifications
All manuals and user guides at all-guides.com

Chapter 1 –Product Specifications 2
Fanless Embedded Box PC AEC-6613
1.1 Specifications
System
CPU
Intel®AtomTM D2550 1.86 GHz
Memory
DDR3 800/1066 SODIMM x 1, up to 4 GB)
VGA
VGA x 1 (optional 2nd VGA)
Ethernet
Gigabit Ethernet, RJ-45 connector x 2
Hard Disk Storage
2.5” SATA HDD Bay x 1
Expansion
MiniCard Slot x 1
LCD/CRT Controller
Integrated in Processor, shared system
memory by Intel® DVMT Technology
Solid Storage Disk
CFastTM slot x 1 (w/ cover protection)
Serial Port
RS-232/422/485 x 1, RS-232 x 3 (optional x 2)
USB
USB 2.0 x 4
System Control
Power ON/OFF
LED Indicator
Power LED x 1, Hard disk active LED x 1,
CFast™ slot x 1, Antenna hole x 2
OS Support
Windows® 7
Windows® XP
Linux Fedora Core,
Mechanical
Construction
Aluminum Alloy Chassis
Color
Dark Gray
Mounting
Wall mounted
Dimension (W x H x D)
212.15 x 78.88 x 107 mm
(8.35 x 3.1 x 2.25”)
Gross Weight
3.8 kg (8.36 lb)
All manuals and user guides at all-guides.com

Chapter 1 –Product Specifications 3
Fanless Embedded Box PC AEC-6613
Net Weight
2.16 kg (4.75 lb)
Environmental
Operating Temperature
No Airflow:
0 ~ 50°C (32 ~ 122°F) - HDD
0 ~ 55°C (32 ~ 131°F) - CFast™ Card
Ambient with Airflow:
0 ~ 55°C (32 ~ 131°F) - HDD
0 ~ 60°C (32 ~ 140°F) - CFast™ Card
Storage Temperature
-20 ~ 70°C (-4 ~ 158°F)
Storage Humidity
5 ~ 95% @ 40°C, non-condensing
Anti-Vibration
5 Grms/ 5~500Hz/ random operation –CFast™
1 Grms / 5~500Hz/ random operation –HDD
Anti-Shock
50 G peak acceleration (11msec. duration) –
CFast™
20 G peak acceleration (11msec. duration) –HDD
EMC
CE/FCC Class A
Power
Power Supply
DC power input 12V/ DC 9-30V w/ 3-pin
terminal block
All manuals and user guides at all-guides.com

Fanless Embedded Box PC AEC-6613
Chapter 2
Chapter 2 –Hardware Information
All manuals and user guides at all-guides.com
all-guides.com

Chapter 2 –Hardware Information 5
Fanless Embedded Box PC AEC-6613
2.1 Dimensions
Model A1
CFast
-- +
12V
DC
All manuals and user guides at all-guides.com

Chapter 2 –Hardware Information 6
Fanless Embedded Box PC AEC-6613
Model A1M
CFast
All manuals and user guides at all-guides.com

Chapter 2 –Hardware Information 7
Fanless Embedded Box PC AEC-6613
Model A2
CFast
-- +
12V
DC
All manuals and user guides at all-guides.com

Chapter 2 –Hardware Information 8
Fanless Embedded Box PC AEC-6613
Model A2M
CFast
All manuals and user guides at all-guides.com
