Asus DiGiMatrix AB-V10 User manual

®
Quick Start Guide
E1670

2 Quick Start Guide
Front panel features
NOTE. The illustrations in this guide are for reference only. For detailed
information on your system’s specifications, refer to the user guide.
Internal
— VOLUME +
System power button
LED panel
Power LED
HDD LED
Card reader LED
System volume
dial
NEXT button
PREVIOUS button
STOP button
PLAY/PAUSE button
Audio DJ power button
Remote sensor
— VOLUME +
Optical S/PDIF port
4-pin IEEE 1394 port
6-pin IEEE 1394 port
Headphone port
Mic port
SM
®
card slot
SD
™
/MMC card slot
USB ports
Slim optical drive
Drive activity LED
STOP/EJECT button
Emergency eject pinhole
MS
®
/MS Pro™ card slot
CF
®
/Microdrive™ card slot
External

3
ASUS DiGiMatrix (AB-V10)
1. Standby power LED
2. HDD power plug
(to HDD power connector)
3. IDE cable (to HDD
connector)
4. Chassis fan
5. CPU fan
6. DIMM sockets
7. HDD metal tray
8. Optical drive shield
Mic port
Line Out port
Line In port
Antenna port
PS/2 mouse port
Gigabit LAN port
Ethernet LAN port
Video In port
Cable TV connector
DC In socket
DC Out socket
VGA port
DVI port
HDTV/TV port
USB ports
PS/2 keyboard port
1
23
4
5
6
7
8
Rear panel features
Internal components
Secondary IDE
connector

4 Quick Start Guide
2
1
3
Hand slot
2
1
4
5
3
7
6
Removing the top cover
Installing a hard disk drive
Slide the metal
cover toward
the rear panel
Disengage the side
hooks from the HDD
tray and optical drive
shield
Insert the tray metal tacks into the
drive screw holes (two on the side
and two at the bottom)
Align the side hooks with
the tray rail and optical
drive shield. Slide the
metal cover toward the
front panel until it fits in
place

5
ASUS DiGiMatrix (AB-V10)
1
2
5
6
7
8
34
9
10
Installing a CPU
Unlock the socket by pressing the
lever sideways then lifting it up to a
90° angle
Disconnect the CPU fan cable Remove the
bracket screw
CAUTION! Make sure that the gold mark on the CPU matches the base
of the socket lever. The CPU fits only in one correct orientation. DO NOT
force the CPU into the socket to prevent bending the pins and damaging
the CPU
Disconnect the
chassis fan cable
Re-install the chassis fan and
heatsink assembly
Re-install the CPU fan

6 Quick Start Guide
Fit the top cover tabs
with the chassis rail and
the front panel cover
tabs
Tabs
2
3
13
4
4
CAUTION! A DDR DIMM is keyed with a notch so that it fits in only one
direction. DO NOT force a DIMM into a socket to avoid damaging the
DIMM.
1
12
3
Installing a DIMM
3
Press the retaining
clips outward
Align a DIMM on the socket such
that the notch on the DIMM
matches the break on the socket
Firmly insert the DIMM to
the socket until the
retaining clips snap back
in place and the DIMM is
properly seated.
Replacing the top cover

7
ASUS DiGiMatrix (AB-V10)
Power adapter and cable
3
1
2
Audio/Video cable
Radio antenna
1
2
Connecting cables
Antenna
port
Power cable
Power outlet
Power adapter
DC in power plug
DC in socket
Audio/Video
cable plug S-Video
port
HDTV cable
NOTE. You may also connect a regular TV set using the HDTV cable by
connecting the blue jack to the video input port of the TV set. The TV set
only receives video signals from the DiGiMatrix system.
2
HDTV cable plug
HDTV
port
HDTV
RCA
input
ports
1
Video out cable
1
2
Audio out cable
Audio I/O
ports

8 Quick Start Guide
Connecting external devices
To the front panel
To the rear panel
PS/2 KB
PS/2 Mouse
Line OutLine In Mic RJ-45
VGA USB MouseDVI
DiGiMatrix subsystem
Cable TV
— VOLUME +
Mic
Headphone
HDD
Scanner
Camera
Audio Devices
