Asus VIVOMINI VC65 SERIES User manual

VivoMini
VC65 Series
User Manual

COPYRIGHT INFORMATION
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS,
ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN
IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identication or
explanation and to the owners’ benet, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright © 2016 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’ part or other liability, you
are entitled to recover damages from ASUS. In each such instance, regardless of the basis
on which you are entitled to claim damages from ASUS, ASUS is liable for no more than
damages for bodily injury (including death) and damage to real property and tangible
personal property; or any other actual and direct damages resulted from omission or failure of
performing legal duties under this Warranty Statement, up to the listed contract price of each
product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in
contract, tort or infringement under this Warranty Statement.
This limit also applies to ASUS’suppliers and its reseller. It is the maximum for which ASUS, its
suppliers, and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-
PARTY CLAIMS AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS
OR DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC
CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS
SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at https://www.asus.com/support/
Revised Edition V3
January 2016
E11262

VivoMini VC65 Series
3
Contents
About this manual ............................................................................................. 4
Conventions used in this manual ............................................................... 4
Typography......................................................................................................... 4
Package contents............................................................................................... 5
Getting to know your VivoMini
Features ................................................................................................................. 8
Front panel.......................................................................................................... 8
Left side ............................................................................................................... 9
Right side............................................................................................................. 9
Rear panel .........................................................................................................10
Using your VivoMini
Getting started..................................................................................................14
Connect the AC power cord to your VivoMini .....................................14
Connect a display panel to your VivoMini.............................................15
Connect the USB cable from keyboard or mouse ..............................17
Turn on your VivoMini...................................................................................18
Turning your VivoMini off..............................................................................19
Putting your VivoMini to sleep....................................................................19
Entering the BIOS Setup ................................................................................19
Quickly enter the BIOS..................................................................................20
Upgrading your VivoMini
Installing 2.5”hard disk drive / solid state drive....................................22
Upgrading memory modules......................................................................27
Appendix
Safety information ...........................................................................................32
Setting up your system.................................................................................32
Care during use...............................................................................................32
Regulatory notices...........................................................................................34
ASUS contact information ............................................................................40

4
VivoMini VC65 Series
About this manual
This manual provides information about the hardware and software
features of your PC, organized through the following chapters:
Chapter 1: Getting to know your VivoMini
This chapter details the hardware components of your VivoMini.
Chapter 2: Using your VivoMini
This chapter provides you with information on using your
VivoMini.
Chapter 3: Upgrading your VivoMini
This chapter provides you with information on how to upgrade
the memory modules and hard disk drive / solid state drive of
your VivoMini.
Appendix
This section includes notices and safety statements your
VivoMini.
Conventions used in this manual
To highlight key information in this manual, some text are presented
as follows:
IMPORTANT! This message contains vital information that must be
followed to complete a task.
NOTE: This message contains additional information and tips that
can help complete tasks.
WARNING! This message contains important information that must
be followed to keep you safe while performing certain tasks and
prevent damage to your VivoMini's data and components.
Typography
Bold text Indicates a menu or an item to select.
Italic This indicates sections that you can refer
to in this manual.

VivoMini VC65 Series
5
Package contents
Your VivoMini package contains the following items:
Technical documentations
Keyboard (optional)** Mouse (optional)**
Power cord* Driver DVD**
NOTE:
• *Actualproductspecicationsandpackagecontentsmay
vary depending on the model type, country, or region.
• **Theavailabilityandquantityoftheseitemsvarywithyour
VivoMini package.
• Ifthedeviceoranyofitscomponentsfailormalfunction
during normal or proper use and it is still within the warranty
period, bring the device and the warranty card to you
nearest ASUS Service Center.
VivoMini

6
VivoMini VC65 Series

1
Getting to know your VivoMini

8
VivoMini VC65 Series
Features
Front panel
Top cover
The removable top cover allows you access to the hard disk
drive and the memory modules.
IMPORTANT! Before removing the top cover, turn o
your VivoMini and unplug the power cable.
Drive activity indicator
This indicator lights up when your VivoMini is accessing the
internal storage drive.
USB 3.0 port
The USB 3.0 (Universal Serial Bus 3.0) port provides a
transfer rate up to 5 Gbit/s and is backward compatible to
USB 2.0.
Power button
The power button allows you to turn the VivoMini on or
o. You can also press the power button once to put your
VivoMini to sleep mode.

VivoMini VC65 Series
9
Left side
Right side
Air vents
The air vents allow air to enter your VivoMini chassis.
IMPORTANT! For optimum air ow, ensure that the
air vents are free from obstructions.
Air vents
The air vents allow air to exit your VivoMini chassis.
IMPORTANT! For optimum heat dissipation and air
ventilation, ensure that the air vents are free from
obstructions.
Memory card slot
This built-in memory card reader slot supports MMC, SD,
SDHC, and SDXC card formats.

10
VivoMini VC65 Series
USB 3.0 port
The USB 3.0 (Universal Serial Bus 3.0) port provides a
transfer rate up to 5 Gbit/s and is backward compatible to
USB 2.0.
NOTE: On selected models these ports are USB 2.0
ports.
Top cover lock latch + Kensington® security slot
The top cover lock latch fastens the top cover on your
VivoMini.
The Kensington® security slot allows you to secure your
VivoMini using Kensington® compatible VivoMini security
products.
DisplayPort
The DisplayPort sends high-performance digital output
from your VivoMini to a display device such as an LCD TV or
HD monitor.
Rear panel

VivoMini VC65 Series
11
LAN port
The 8-pin RJ-45 LAN port supports a standard Ethernet
cable for connection to a local network.
Serial (COM) connector
The 9-pin serial (COM) connector allows you to connect
devices that have serial ports such as mouse, modem, or
printers.
Power (AC) input port
Insert the power cord into this port to supply power to
your VivoMini.
Headphone jack
This port allows you to connect amplied speakers or
headphones.
Microphone jack
The microphone jack is designed to connect to a
microphone used for video conferencing, voice narrations,
or simple audio recordings.
VGA port
This port allows you to connect your VivoMini to an
external display.
USB 3.0 port
The USB 3.0 (Universal Serial Bus 3.0) port provides a
transfer rate up to 5 Gbit/s and is backward compatible to
USB 2.0.
HDMI port
The HDMI (High Denition Multimedia Interface) port
supports a Full-HD device such as an LCD TV or monitor to
allow viewing on a larger external display.

12
VivoMini VC65 Series
Air vents
The air vents allow air to enter your VivoMini chassis.
IMPORTANT! For optimum air ow, ensure that the
air vents are free from obstructions.

2
Using your VivoMini

14
VivoMini VC65 Series
Getting started
Connect the AC power cord to your VivoMini
To connect the AC power cord to your VivoMini:
A. Connect the AC power cord to the AC-IN port.
B. Plug the AC power cord into a 100V~240V power source.
IMPORTANT!
• WestronglyrecommendthatyouuseonlytheACpower
cord that came with your VivoMini.
• Westronglyrecommendthatyouuseagroundedwall
socket while using your VivoMini.
• Thesocketoutletmustbeeasilyaccessibleandnearyour
VivoMini.
• TodisconnectyourVivoMinifromitsmainpowersupply,
unplug your VivoMini from the power socket.
• Poweradapterinformation:
- Rating: 100~240V~, 50-60Hz, 1.5A

VivoMini VC65 Series
15
Connect a display panel to your VivoMini
You can connect a display panel or projector to your VivoMini that
has the following connectors:
• HDMIconnector
• DisplayPortconnector
• VGAconnector
• DVIconnector(usewithanHDMI/DisplayPort/VGAtoDVI
adapter)
NOTE: The HDMI to DVI adapter, DisplayPort to DVI adapter, or VGA to
DVI adapter are each sold separately.
To connect a display panel to your VivoMini:
Connect a display cable either to the HDMI, DisplayPort or VGA port.
Connecting display via HDMI port
Connecting display via DisplayPort port

16
VivoMini VC65 Series
Connecting display via VGA port

VivoMini VC65 Series
17
Connect the USB cable from keyboard or mouse
You can connect generally any USB keyboard and mouse to your
VivoMini. You can also connect a USB dongle for a wireless keyboard
and mouse set.
To connect a keyboard and mouse to your VivoMini:
Connect the USB cable from your keyboard and mouse to any of the
USB ports of your VivoMini.
Connecting keyboard or mouse via USB port

18
VivoMini VC65 Series
Turn on your VivoMini
Press the power button to turn on your VivoMini.

VivoMini VC65 Series
19
Turning your VivoMini off
If your VivoMini is unresponsive, press and hold the power button
for at least four (4) seconds until your VivoMini turns o.
Putting your VivoMini to sleep
To put your VivoMini on Sleep mode, press the Power button once.
Entering the BIOS Setup
BIOS (Basic Input and Output System) stores system hardware
settings that are needed for system startup in the VivoMini.
In normal circumstances, the default BIOS settings apply to most
conditions to ensure optimal performance. Do not change the
default BIOS settings except in the following circumstances:
• Anerrormessageappearsonthescreenduringthesystem
bootupandrequestsyoutoruntheBIOSSetup.
• Youhaveinstalledanewsystemcomponentthatrequiresfurther
BIOS settings or update.
WARNING! Inappropriate BIOS settings may result to instability
or boot failure. We strongly recommend that you change the BIOS
settings only with the help of a trained service personnel.

20
VivoMini VC65 Series
Quickly enter the BIOS
ToquicklyentertheBIOS:
• Pressthepowerbuttonforatleastfour(4)secondstoshutdown
your VivoMini, then press the power button again to turn your
VivoMini back on, then press <F2> or <Del> during POST.
• WhenyourPCiso,disconnectthepowercordfromyour
VivoMini’s power connector. Reconnect the power cable and
press the power button to turn on your VivoMini. Press <F2> or
<Del> during POST.
NOTE: POST (Power-On Self Test) is a series of software controlled
diagnostic tests that run when you turn on your PC.
