Asus T3-M3N8200 User manual

T-Series
M3N8200
ASUS PC (Desktop Barebone)
T3-M3N8200 T4-M3N8200
(Only some models have the Time and IR LED
display.)

ii
Copyright © 2008 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E3546
First Edition
February 2008

iii
Table of contents
Notices......................................................................................................... vi
Safety information ..................................................................................... vii
About this guide ....................................................................................... viii
System package contents........................................................................... x
Chapter 1: System introduction
1.1 Welcome! ...................................................................................... 1-2
1.2 Front panel (external and internal)............................................. 1-2
1.3 Rear panel..................................................................................... 1-5
1.4 Internal components.................................................................... 1-7
Chapter 2: Basic installation
2.1 Preparation ................................................................................... 2-2
2.2 Before you proceed ..................................................................... 2-2
2.3 Removing the cover..................................................................... 2-3
2.4 Power supply unit ........................................................................ 2-4
2.5 CPU installation............................................................................ 2-5
2.5.1 Overview ......................................................................... 2-5
2.5.2 Installing CPU ................................................................. 2-5
2.5.3 Installing the heatsink and fun ........................................ 2-7
2.6 Installing a DIMM.......................................................................... 2-9
2.6.1 Memory congurations.................................................... 2-9
2.6.2 DIMM installation ...........................................................2-11
2.7 Installing an expansion card..................................................... 2-12
2.7.1 Expansion slots............................................................. 2-12
2.7.2 Expansion card installation ........................................... 2-13
2.8 Installing an optical drive.......................................................... 2-14
2.9 Installing a Serial ATA disk drive .............................................. 2-15
2.10 Reinstalling the power supply unit........................................... 2-16
Voltage selector............................................................................ 2-16
2.11 Replacing the cover................................................................... 2-17
Chapter 3: Starting up
3.1 Installing an operating system ................................................... 3-2
3.2 Powering up.................................................................................. 3-2

iv
Table of contents
3.3 Support CD information .............................................................. 3-3
3.3.1 Running the support CD ................................................. 3-3
3.3.2 Drivers menu................................................................... 3-4
3.3.3 Utilities menu .................................................................. 3-5
3.3.4 ASUS contact information............................................... 3-6
Chapter 4: Motherboard info
4.1 Introduction .................................................................................. 4-2
4.2 Motherboard layout...................................................................... 4-2
4.3 Jumpers ........................................................................................ 4-3
4.4 Connectors ................................................................................... 4-5
Chapter 5: BIOS setup
5.1 Managing and updating your BIOS ............................................ 5-2
5.1.1 ASUS EZ Flash utility...................................................... 5-3
5.1.2 AFUDOS utility................................................................ 5-4
5.1.3 ASUS CrashFree BIOS 2 utility ...................................... 5-6
5.1.4 ASUS Update utility ........................................................ 5-8
5.2 BIOS setup program .................................................................. 5-11
5.2.1 BIOS menu screen........................................................ 5-12
5.2.2 Menu bar....................................................................... 5-12
5.2.3 Navigation keys............................................................. 5-12
5.2.4 Menu items ................................................................... 5-13
5.2.5 Sub-menu items............................................................ 5-13
5.2.6 Conguration elds ....................................................... 5-13
5.2.7 Pop-up window ............................................................. 5-13
5.2.8 Scroll bar....................................................................... 5-13
5.2.9 General help ................................................................. 5-13
5.3 Main menu .................................................................................. 5-14
5.3.1 System Time ................................................................ 5-14
5.3.2 System Date ................................................................ 5-14
5.3.3 IDE Conguration.......................................................... 5-14
5.3.4 Primary and SATA IDE Master/Slave ............................ 5-15
5.3.5 System Information ....................................................... 5-17
5.4 Advanced menu ......................................................................... 5-17

v
Table of contents
5.4.1 Jumperfree Conguration ............................................. 5-18
5.4.2 CPU Conguration ........................................................ 5-20
5.4.3 Chipset.......................................................................... 5-21
5.4.4 Onboard Devices Conguration.................................... 5-25
5.4.5 USB Conguration ........................................................ 5-26
5.5 Power menu................................................................................ 5-27
5.5.1 Suspend Mode ............................................................. 5-27
5.5.2 Repost V ideo on S3 Resume ...................................... 5-27
5.5.3 ACPI Version Feature .................................................. 5-27
5.5.4 ACPI APIC Support....................................................... 5-27
5.5.5 APM Conguration........................................................ 5-28
5.5.6 Hardware Monitor ......................................................... 5-29
5.6 Boot menu .................................................................................. 5-30
5.6.1 Boot Device Priority ...................................................... 5-30
5.6.2 Boot Settings Conguration .......................................... 5-30
5.6.3 Security ......................................................................... 5-32
5.7 Tools menu ................................................................................. 5-34
5.7.1 ASUS EZ Flash 2.......................................................... 5-34
5.7.2 LED Poster Conguration ............................................. 5-34
5.7.3 AL NET2........................................................................ 5-35
5.7.4 ASUS O.C. Prole......................................................... 5-36
5.8 Exit menu.................................................................................... 5-37
Appendix
A.1 Power supply specications.......................................................A-1
A.2 Debug code table .........................................................................A-1
A.3 Using the Remote Control (Optional).........................................A-3

vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
Macrovision Corporation Product Notice
This product incorporates copyright protection technology that is protected by
U.S. patents and other intellectual property rights. Use of this copyright protection
technology must be authorized by Macrovision, and is intended for home and other
limited viewing uses only unless otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.

vii
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that the power
cables for the devices are unplugged before the signal cables are connected.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied
service technician or your retailer.
Operation safety
• Before installing devices into the system, carefully read all the documentation
that came with the package.
• Before using the product, ensure that all cables are correctly connected and
the power cables are not damaged. If you detect any damage, contact your
dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in
any area where it may become wet. Place the product on a stable surface.
• When using the product, do not block any air inlet/outlet in the chassis.
• The maximum environmental temperature is 35ºC.
• If you encounter technical problems with the product, contact a qualied
service technician or your retailer.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
VORSICHT: Explosionsgetahr bei unsachgemäßen Austausch der Batterie.
Ersatz nur durch denselben oder einem vom Hersteller empfohlenem
ähnljchen Typ. Entsorgung gebrauchter Batterien nach Angaben des
Herstellers.
LASER PRODUCT WARNING
CLASS 1 LASER PRODUCT

viii
About this guide
Audience
This guide provides general information and installation instructions about ASUS
T-Series M3N8200 barebone system. This guide is intended for experienced users
and integrators with hardware knowledge of personal computers.
How this guide is organized
This guide contains the following parts:
1. Chapter 1: System introduction
This chapter gives a general description of ASUS T-Series M3N8200. The
chapter lists the system features, including introduction on the front and rear
panel, and internal components.
2. Chapter 2: Basic installation
This chapter provides step-by-step instructions on how to install components
in the system.
3. Chapter 3: Starting up
This chapter helps you power up the system and install drivers and utilities
from the support CD.
4. Chapter 4: Motherboard information
This chapter gives information about the motherboard that comes with the
system. This chapter includes the motherboard layout, jumper settings, and
connector locations.
5. Chapter 5: BIOS information
This chapter tells how to change system settings through the BIOS Setup
menus and describes the BIOS parameters.
6. Appendix
The Appendix includes the power supply unit specication for this system.

ix
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.
Where to nd more information
Refer to the following sources for additional information and for product and
software updates.
1. ASUS Websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to the ASUS contact information.
2. Optional Documentation
Your product package may include optional documentation, such as warranty
yers, that may have been added by your dealer. These documents are not
part of the standard package.

x
System package contents
Check your T-Series M3N8200 system package for the following items.
If any of the items is damaged or missing, contact your retailer immediately.
Item description
1. ASUS T-Series M3N8200 barebone system with
• ASUS motherboard
• 250 W PFC power supply unit
• Front I/O card
• 6-in-1 storage card reader
2. Cables
• AC power cord
• ATA cable
• Serial ATA cable
• Serial ATA power cable
3. Support CD
4. Installation Manual
5. Optional items
• Telephone Adapter card
• Remote control

Chapter 1
System introduction
This chapter gives a general
description of ASUS T-Series
M3N8200. The chapter lists the system
features including introduction on
the front and rear panel, and internal
components.
T3-M3N8200 T4-M3N8200
(Only some models have the Time
and IR LED display.)

1-2 Chapter 1: System introduction
1.1 Welcome!
Thank you for choosing ASUS T-Series M3N8200!
ASUS T-Series M3N8200 is an all-in-one barebone system with a versatile home
entertainment feature.
The system comes in a stylish mini-tower casing, and powered by the ASUS
motherboard that supports the AMD Athlon™ 64 X2/Athlon™ 64/Athlon™ FX/
Sempron™ processor. in the AM2 socket with 800/1000 MHz FSB and up to 8GB
system memory.
With audio functions, extensive connectivity, and Gigabit LAN capability, T-Series
M3N8200 is designed for the sophisticated.
With these and many more, T-Series M3N8200 denitely delivers the cutting edge
technology for your computing and multimedia needs!
1.2 Front panel (external and internal)
The front panel includes the system and audio control buttons, system LEDs, and
LED panel.
The optical drive(s), storage card reader slots, and several I/O ports are located
inside the front panel doors.
T4 Series
2
14
6
4
5
3
11
7
8
9
10
12
13
14

1-3ASUS T-Series M3N8200
1. Drive door. Open this door to access the disk drive.
2. Front panel I/O door. Open the front panel to show the input/output ports.
3. Time and IR LED display (optional)
4. Eject button . Press this button to eject the optical drive bay.
5. Power button . Press this button to turn the system on.
6. HDD LED . This LED lights up when data is being read from or written to
the hard disk drive.
7. CompactFlash®/Microdrive™ card slot . This slot is for a
CompactFlash®/Microdrive™ storage card.
8. Memory Stick®/Memory Stick Pro™ card slot. This slot is for a Memory
Stick®/Memory Stick Pro™ storage card.
9. USB 2.0 ports
2.0
. These Universal Serial Bus 2.0 (USB 2.0) ports are
available for connecting USB 2.0 devices such as a mouse, printer, scanner,
camera, PDA, and others.
10. Secure Digital™/MultimediaCard slot . This slot is for a Secure
Digital™/MultimediaCard storage card.
11. W/R LED .This LED lights up when data is being read from or written to
the card reader.
12. Microphone port . This Mic (pink) port connects a microphone.
13. Headphone port . This port connects a headphone with a stereo mini-
plug.
14. 4-pin IEEE 1394a port . This port provides high-speed connectivity for
IEEE 1394a-compliant audio/video devices, storage peripherals, and other
PC devices.

1-4 Chapter 1: System introduction
16
15
17
18
19
15. Drive door. Open this door to access the disk drive.
16. Power button . Press this button to turn the system on.
17. HDD LED . This LED lights up when data is being read from or written to
the hard disk drive. (for BlackBezel)
18. HDD LED . This LED lights up when data is being read from or written to
the hard disk drive. (for Silver Bezel)
19. Front panel I/O door. Push down this door to show the input/output ports.
20. CompactFlash®/Microdrive™ card slot . This slot is for a
CompactFlash®/Microdrive™ storage card.
21. Memory Stick®/Memory Stick Pro™ card slot. This slot is for a Memory
Stick®/Memory Stick Pro™ storage card.
22. USB 2.0 ports
2.0
. These Universal Serial Bus 2.0 (USB 2.0) ports are
available for connecting USB 2.0 devices such as a mouse, printer, scanner,
camera, PDA, and others.
23. Secure Digital™/MultimediaCard slot . This slot is for a Secure Digital™/
MultimediaCard storage card.
24. Eject button. Press this button to eject the optical drive bay.
25. Microphone port . This Mic (pink) port connects a microphone.
26. Headphone port . This port connects a headphone with a stereo mini-
plug.
27. 4-pin IEEE 1394a port . This port provides high-speed connectivity for
IEEE 1394a-compliant audio/video devices, storage peripherals, and other
PC devices.
24
20
21
22
23
25
26
27
T3 Series

1-5ASUS T-Series M3N8200
1.3 Rear panel
The system rear panel includes the power connector and several I/O ports that
allow convenient connection of devices.
28. Expansion slot covers. Remove these covers when installing expansion
cards.
29. Expansion slots. Use this slot when installing expansion card.
30. Rear surround speakers. This port connects to a high-denition six-channel
speaker.
31. Side surround speakers.This port connects to a high-denition six-channel
speaker.
32. Microphone port . This Microphone (pink) port connects a microphone.
In 4/6-channel mode, the function of this port becomes Low Frequency
Enhanced Output/Center.
33. HDMI port. This port is for a High-Denition Multimedia Interface (HDMI)
connector, and is HDCP compliant allowing playback of HD DVD, Blu-Ray
and other protected content
34. PS/2 mouse port . This green 6-pin connector is for a PS/2 mouse.
35. COM port . This port connects a mouse, modem, or other devices that
conforms with serial specication.
36. PS/2 keyboard port . This purple 6-pin connector is for a
PS/2 keyboard.
37. USB 2.0 ports
2.0
. These Universal Serial Bus 2.0 (USB 2.0) ports are
available for connecting USB 2.0 devices such as a mouse, printer, scanner,
camera, PDA, and others.
29
30
31
32
33
34
35
36
37
39
40
41
42
43
44
45
46
47
48
28
49
38

1-6 Chapter 1: System introduction
38. LAN (RJ-45) port . This port allows Gigabit connection to a Local Area
Network (LAN) through a network hub.
39. Chassis vent. This vent is for the fan that provides ventilation inside the
system chassis.
40. Expansion card lock. This lock secures installed expansion cards. See
page 2-13 for details.
41. Center & woofer speakers. This port connects the center/subwoofer
sspeakers.
42. Line In port . This Line In (light blue) port connects a tape player or
other audio sources. In 6-channel mode, the function of this port becomes
Surround output.
43. Line Out port . This Line Out (lime) port connects a headphone or a
speaker. In 4/6-channel mode, the function of this port becomes Front
Speaker Out.
44. Coaxial S/PDIF Out port. This port connects an external audio output device
via a coaxial S/PIF cable.
45. Voltage selector. This switch allows you to adjust the system input voltage
according to the voltage supply in your area.
46. Power connector. This connector is for a power cable and plug.
47. Power switch. This switch allows you to turn your PC on/off..
48. VGA port . This port connects a VGA monitor.
49. 6-pin IEEE 1394a port . This port provides high-speed connectivity for
IEEE 1394a-compliant audio/video devices, storage peripherals, and other
PC devices.

1-7ASUS T-Series M3N8200
1. ASUS motherboard
2. AM2 socket
3. DIMM sockets
4. Serial ATA connectors
5. PCI Express™ x16 slot for discrete graphics
card
6. PCI slot
7. Expansion card slot
8. Power supply unit
1.4 Internal components
The illustration below is the internal view of the system when you remove the top
cover and the power supply unit. The installed components are labeled for your
reference. Proceed to Chapter 2 for instructions on installing additional system
components.
1
2
3
4
5
6
7
8
The illustration shows an open chassis lifted at a 90oangle.

1-8 Chapter 1: System introduction

T3-M3N8200 T4-M3N8200
(Only some models have the Time
and IR LED display.)
Chapter 2
This chapter provides step-by-step
instructions on how to install
components in the system.
Basic installation

2-2 Chapter 2: Basic installation
R
M3N18L
M3N18L Onboard LED
SB_PWR
ON
Standby
Power
OFF
Powered
Off
2.1 Preparation
Before you proceed, ensure that you have all the components you plan to install in
the system.
Basic components to install
1. Central Processing Unit (CPU)
2. DDR2 Dual Inline Memory Module (DIMM)
3. Expansion card(s)
4. Hard disk drive
5. Optical drive
Tool
Philips (cross) screw driver
The motherboard comes with an onboard standby power LED. This LED lights
up to indicate that the system is ON, in sleep mode or in soft-off mode, and not
powered OFF. Unplug the power cable from the power outlet and ensure that the
standby power LED is OFF before installing any system component.
• Use a grounded wrist strap or touch a safely grounded object or a metal
object, such as the power supply case, before handling components to
avoid damaging them due to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic
pad or in the bag that came with the component.
2.2 Before you proceed
Take note of the following precautions before you install components into the
system.
