Asus VivoMini VM65N User manual

VivoMini VM65 Series
User Manual

COPYRIGHT INFORMATION
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form or by any means, except documentation kept by the purchaser for
backup purposes, without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS,
ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN
IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered
trademarks or copyrights of their respective companies, and are used only for identication or
explanation and to the owners’ benet, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright © 2016 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’ part or other liability, you
are entitled to recover damages from ASUS. In each such instance, regardless of the basis
on which you are entitled to claim damages from ASUS, ASUS is liable for no more than
damages for bodily injury (including death) and damage to real property and tangible
personal property; or any other actual and direct damages resulted from omission or failure of
performing legal duties under this Warranty Statement, up to the listed contract price of each
product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in
contract, tort or infringement under this Warranty Statement.
This limit also applies to ASUS’suppliers and its reseller. It is the maximum for which ASUS, its
suppliers, and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-
PARTY CLAIMS AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS
OR DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC
CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS
SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at https://www.asus.com/support/
First Edition
January 2016
E11190

VivoMini VM65 Series
3
Contents
About this manual ............................................................................................. 4
Conventions used in this manual ............................................................... 4
Typography......................................................................................................... 4
Package contents............................................................................................... 5
Getting to know your VivoMini 7
Features ................................................................................................................. 8
Front panel.......................................................................................................... 8
Left side ............................................................................................................... 9
Rear panel .........................................................................................................10
Using your VivoMini 13
Getting started..................................................................................................14
Connect the AC power adapter to your VivoMini...............................14
Connect a display panel to your VivoMini.............................................16
Connect the USB cable from keyboard or mouse ..............................17
Turn on your VivoMini...................................................................................18
Turning your VivoMini off..............................................................................19
Putting your VivoMini to sleep....................................................................19
Entering the BIOS Setup ................................................................................19
Quickly enter the BIOS..................................................................................20
Memory upgrade 21
Upgrading memory modules......................................................................22
Appendix 29
Safety information ...........................................................................................30
Setting up your system.................................................................................30
Care during use...............................................................................................30
Regulatory notices...........................................................................................32
ASUS contact information ............................................................................38

4
VivoMini VM65 Series
About this manual
This manual provides information about the hardware and software
features of your PC, organized through the following chapters:
Chapter 1: Getting to know your VivoMini
This chapter details the hardware components of your VivoMini.
Chapter 2: Using your VivoMini
This chapter provides you with information on using your
VivoMini.
Chapter 3: Memory upgrade
This chapter provides you with information on how to upgrade
the memory modules of your VivoMini.
Appendix
This section includes notices and safety statements your VivoMini.
Conventions used in this manual
To highlight key information in this manual, some text are presented
as follows:
IMPORTANT! This message contains vital information that must be
followed to complete a task.
NOTE: This message contains additional information and tips that
can help complete tasks.
WARNING! This message contains important information that must
be followed to keep you safe while performing certain tasks and
prevent damage to your VivoMini's data and components.
Typography
Bold text Indicates a menu or an item to select.
Italic This indicates sections that you can refer
to in this manual.

VivoMini VM65 Series
5
Package contents
NOTES:
• Actualproductspecicationsandpackagecontentsmay
vary with your VivoMini’s model type or with country or
region.
• Ifthedeviceoritscomponentsfailormalfunctionduring
normal and proper use within the warranty period, bring the
warranty card to the ASUS Service Center for replacement of
the defective components.
Your VivoMini package contains the following items:
VivoMini VM Series
Power cable*
Technical documentations
AC power adapter*

6
VivoMini VM65 Series

1
Getting to know your VivoMini

8
VivoMini VM65 Series
Features
Front panel
Top cover
The removable top cover allows you access to the hard disk
drive and the memory modules.
IMPORTANT! Before removing the top cover, turn o
your VivoMini and unplug the power cable.
Audio speakers
Your VivoMini uses SonicMaster technology to provide hi-
sound quality, with richer bass sounds, straight from the
built-in audio speakers.
Drive activity indicator
This indicator lights up when your VivoMini is accessing the
internal storage drive.

VivoMini VM65 Series
9
Left side
Air vents
The air vents on the left side allow cooler air to enter your
VivoMini chassis.
IMPORTANT! For optimum heat dissipation and air
ventilation, ensure that the air vents are free from
obstructions.

10
VivoMini VM65 Series
Power button
The power button allows you to turn the VivoMini on or
o. You can also press the power button once to put your
VivoMini to sleep mode.
Memory card slot
The built-in memory card reader enables your PC to read
and write data to and from MMC/SD/SDHC/SDXC cards.
Top cover lock latch + Kensington security slot
The top cover lock latch fastens the top cover on your
VivoMini.
The Kensington security slot allows you to secure your
VivoMini using Kensington® security products.
USB 3.0 ports
These Universal Serial Bus 3.0 (USB 3.0) ports provide a
transfer rate of up to 5 Gbit/s and are backward compatible
with USB 2.0.
Rear panel

VivoMini VM65 Series
11
DisplayPort port
Use this port to connect your ViVoMini to a DisplayPort or
VGA, DVI, or HDMI external display.
LAN port
The 8-pin RJ-45 LAN port supports a standard Ethernet
cable for connection to a local network.
Headphone/Audio Out jack
The stereo headphone jack is used to connect the system’s
audio out signal to amplied speakers or headphones.
Microphone jack
The microphone jack is designed to connect the
microphone used for video conferencing, voice narrations,
or simple audio recordings.
Digital audio out port (S/PDIF optical)
The Sony/Philips Digital Interface (S/PDIF) optical out port
allows you to transfer digital audio from your VivoMini into
an amplier or your TV.
USB 3.0 ports
These Universal Serial Bus 3.0 (USB 3.0) ports provide a
transfer rate of up to 5 Gbit/s and are backward compatible
with USB 2.0.
USB 3.1 ports (on selected models)
The USB 3.1 (Universal Serial Bus 3.1) port provides a transfer
rate up to 10 Gbit/s and is backward compatible to USB 2.0.
NOTE: Transfer rate of this port may vary per model.

12
VivoMini VM65 Series
HDMI port
The HDMI (High Denition Multimedia Interface) port
supports a Full-HD device such as an LCD TV or monitor to
allow viewing on a larger external display.
Rear air vents
The air vents on the rear allow warm air to exit the
VivoMini.
IMPORTANT! For optimum heat dissipation and air
ventilation, keep the air vents at least 10cm away
from any obstructions.
Power input (DC 19V)
The supplied power adapter converts AC power to DC
power for use with this jack. Power supplied through this
jack supplies power to the PC. To prevent damage to the
PC, always use the bundled power adapter.
WARNING! The power adapter may become warm to
hot when in use. Do not cover the adapter and keep
it away from your body.

2
Using your VivoMini

14
VivoMini VM65 Series
Getting started
Connect the AC power adapter to your VivoMini
To connect the AC power adapter to your VivoMini:
A. Connect the AC power cord to the AC/DC adapter.
B. Plug the AC power cord into a 100V~240V power source.
C. Connect the DC power connector into your VivoMini’s power
(DC) input port.
NOTE: The power adapter may vary in appearance, depending on
models and your region.

VivoMini VM65 Series
15
NOTE:
Power adapter information:
• Inputvoltage:100-240Vac
• Inputfrequency:50-60Hz
• Ratingoutputcurrent:3.42A(65W)or4.74A(90W)(variesper
model)
• Ratingoutputvoltage:19V
IMPORTANT!
• WestronglyrecommendthatyouuseonlytheACpower
adapter and cable that came with your VivoMini.
• Westronglyrecommendthatyouuseagroundedwall
socket while using your VivoMini.
• Thesocketoutletmustbeeasilyaccessibleandnearyour
VivoMini.
• TodisconnectyourVivoMinifromitsmainpowersupply,
unplug your VivoMini from the power socket.

16
VivoMini VM65 Series
Connect a display panel to your VivoMini
You can connect a display panel or projector to your VivoMini that
has the following connectors:
• HDMIconnector
• DisplayPortconnector
• VGAconnector(usewithaDisplayPorttoVGAadapterorHDMI
to VGA adapter)
• DVIconnector(usewithanHDMItoDVIadapter)
NOTE: The HDMI to DVI adapter, DisplayPort to VGA adapter, or HDMI
to VGA adapter are each sold separately.
To connect a display panel to your VivoMini:
Connect a display cable either to the HDMI or DisplayPort port.
Connecting display via HDMI port
Connecting display via DisplayPort port

VivoMini VM65 Series
17
Connect the USB cable from keyboard or mouse
You can connect generally any USB keyboard and mouse to your
VivoMini. You can also connect a USB dongle for a wireless keyboard
and mouse set.
To connect a keyboard and mouse to your VivoMini:
Connect the USB cable from your keyboard and mouse to any of the
USB 3.0 ports of your VivoMini.
Connecting keyboard or mouse via USB 3.0 port

18
VivoMini VM65 Series
Turn on your VivoMini
Press the power button to turn on your VivoMini.

VivoMini VM65 Series
19
Turning your VivoMini off
If your VivoMini is unresponsive, press and hold the power button
for at least four (4) seconds until your VivoMini turns o.
Putting your VivoMini to sleep
To put your VivoMini on Sleep mode, press the Power button once.
Entering the BIOS Setup
BIOS (Basic Input and Output System) stores system hardware
settings that are needed for system startup in the VivoMini.
In normal circumstances, the default BIOS settings apply to most
conditions to ensure optimal performance. Do not change the
default BIOS settings except in the following circumstances:
• Anerrormessageappearsonthescreenduringthesystem
bootup and requests you to run the BIOS Setup.
• Youhaveinstalledanewsystemcomponentthatrequiresfurther
BIOS settings or update.
WARNING! Inappropriate BIOS settings may result to instability
or boot failure. We strongly recommend that you change the BIOS
settings only with the help of a trained service personnel.

20
VivoMini VM65 Series
Quickly enter the BIOS
To quickly enter the BIOS:
• Pressthepowerbuttonforatleastfour(4)secondstoshutdown
your VivoMini, then press the power button again to turn your
VivoMini back on, then press <F2> or <Del> during POST.
• WhenyourPCiso,disconnectthepowercordfromyour
VivoMini’s power connector. Reconnect the power cable and
press the power button to turn on your VivoMini. Press <F2> or
<Del> during POST.
NOTE: POST (Power-On Self Test) is a series of software controlled
diagnostic tests that run when you turn on your PC.
