Cinzone DA-1000 User manual

Intel® Atom™ or Celeron® Processor
Affordable Fanless Embedded Computer
DA-1000
Fanless Computing Solution
DOC No: DA-20170515002_R1.31

DA-1000 User’s Manual
2
Contents
Prefaces
Revision …………………………………………………..……………….……….. 05
Copyright Notice …………………………………………………………………… 05
Acknowledgement …..……………………………………………….................... 05
Disclaimer ………………………………………………………………………….. 05
Declaration of Conformity ………………………………………………………… 05
Product Warranty Statement …………………………………………………….. 06
Technical Support and Assistance ………………………………………………. 07
Conventions Used in this Manual ……………………………………………….. 07
Safety Precaution ……...………………………………………………………….. 08
Package Content …..……………………………………………………………… 09
Ordering Information …………………….………………………………………… 10
Optional Modules & Accessories ……..……………………………..................... 11
Chapter 1 Product Introductions
1.1 Overview ……………………………………………….……………….. 13
1.1.1 Key Features ……..………….……….……………………....... 13
1.1.2 Photo of Front Panel …..…………………………………….......14
1.1.3 Photo of Rear Panel …..……………………………………....... 14
1.2 Hardware Specification …..…………………………………………… 15
1.3 System I/O ……………………………………………………………… 16
1.4 Mechanical Dimension …..……………………………………………. 18
Chapter 2 Jumpers and Connectors
2.1 Jumper Setting ………………………………………………………..... 20
2.2 Location of the Switches and Connectors……..…………………….... 20
2.2.1 Top View ………………………………………………………… 20
2.2.2 Bottom View …………………………………………………….. 21
2.3 List of Switches and Connectors ……..,……………….………........... 22
2.4 Switches Definitions …..……………………....................................... 23
2.5 Connectors Definitions ..………………………................................... 24
2.5.1 Mini PCI-Express / mSATA Socket….…………………….……24
2.5.2 MINIPCIE1：Mini PCI-Express Socket………..………...…… 25
2.5.3 SIM1：SIM Card Socket…………………………………..…… 26
2.5.4 DC_IN1：DC Power Input Connector (9~48V)………….…… 26
2.5.5 PWR_SW2：External remote power on/off switch……...……26
2.5.6 COM1_1：RS232 / RS422 / RS485 Connector…..…….…… 27
2.5.7 COM2_1：RS232 / RS422 / RS485 Connector.………...……27
2.5.8 COM3、COM4：Voltage Select……….………………...…… 28
2.5.9 DVI_I1：DVI-I Connector……..…………………………..…… 28
2.5.10 LAN1：RJ45 with LED Connector………..…….……….…… 29
2.5.11 LAN2：RJ45 with LED Connector………………………..……29

DA-1000 User’s Manual
3
2.5.12 LED1：Power / HDD Access LED Status……………...…… 29
2.5.13 LINE_OUT1: Line-out Jack (Green)………………..…… 30
2.5.14 MIC1: Microphone Jack (Pink)………………………..….…… 30
2.5.15 SATA1：SATA Connector……………………………..….…… 30
2.5.16 USB1、USB2 、USB3：USB2.0 Connector, Type A...…… 31
2.5.17 USB4：USB3.0 Connector, Type A……………………..…… 31
Chapter 3 System Setup
3.1 Removing the Chassis Bottom Cover ……...………………………... 33
3.2 Removing the Chassis …………………….…..…….……………….... 34
3.3 Installing the Antennas…………………………………………………. 35
3.4 Installing a Full-Size Mini PCIe Card on Bottom Side…....……….... 37
3.5 Installing a SATA Hard Drive……………………………………………. 39
3.6 Installing a SODIMM……….……………………..….……………....... 40
3.7 Installing the Chassis ………….…………..………..….…………….... 41
3.8 Installing the Chassis Bottom Cover …..…………..….…………….... 42
3.9 Installing a SIM Card ………………………………..…………………. 43
3.10 Wall Mount Brackets ..……….………………….…..….…………….... 44
3.11 Side Mount Bracket……………………………………………………….45
3.12 VESA Mount Bracket…………………………………………………… 47
3.13 DIN-Rail Mount Bracket…………………………………………………. 48
Chapter 4 BIOS Setup
4.1 BIOS Introduction ……..……….………………….…..….…………... 50
4.1.1 BIOS Setup…..………………………………………………….. 50
4.1.2 Main Menu……………………………………………………….. 50
4.1.3 Sub-Menu…………………………………………………….….. 50
4.2 Main Setup ……..……….………………….…..………………………... 51
4.2.1 System Date ….………………………………………………….. 51
4.2.2 System Time ….………………………………………………….. 51
4.3 Advanced Setup ...……….………………….…..….…..……………... 52
4.3.1 ACPI Settings …..…….………………………………………….. 52
4.3.2 Super I/O Configuration ..………………………………………. 53
4.3.3 Hardware Monitor…….……………………………………………57
4.3.4 Serial Port Console Redirection………………………………… 58
4.3.5 CPU Configuration……..………………………………………… 59
4.3.6 Thermal Configuration…………..……………………………….. 61
4.3.7 SATA Configuration.……………………………………………… 62
4.3.8 OS Selection……………………..……………………………….. 64
4.3.9 CSM Configuration…..…………………………………………… 65
4.3.10 USB Configuration …………………………………….……….. 67
4.4 Chipset …………………………………………………………………….69
4.4.1 North Bridge……………………………………………………… 69
4.4.2 South Bridge……………………………………………………… 71
4.5 Security…………………………………………………………………….74
4.5.1 Administrator Password………………………………………….. 74
4.5.2 User Password………….……..…………………………………. 74

DA-1000 User’s Manual
4
4.6 Boot…..…………………………………………………………………….75
4.6.1 Setup Prompt Timeout..………………………………………….. 75
4.6.2 Bootup NumLock State.……..…………………………………. 75
4.6.3 Full Screen Logo Show………………………………………….. 75
4.6.4 Fast Boot…………………….. ……………………………………75
4.6.5 UEFI Boot…………… …………………………………………… 75
4.7 Save & Exit …...……….….………………….…..….…..….…………... 76
4.7.1 Save Changes and Reset………………………………………. 76
4.7.2 Discard Changes and Reset……………………………………. 76
4.7.3 Restore Defaults …………………………………………………. 76
4.7.4 Save as User Defaults ……………………………………………76
4.7.5 Restore User Defaults ………………………..…………………. 76
Chapter 5 Product Application (For CMI-DIO100 Only)
5.1 Digital I/O (DIO) application……………………….…..….…………….. 78
5.1.1 Digital I/O Programming Guide ………………………………... 78
5.2 Digital I/O (DIO) Hardware Specification………………………..……. 83

DA-1000 User’s Manual
5
Revision
Copyright Notice
© 2014 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied,
modified, or reproduced in any form or by any means for commercial use without the prior
written permission of Cincoze Co., Ltd. All information and specification provided in this
manual are for reference only and remain subject to change without prior notice.
Acknowledgement
Cincoze is a registered trademark of Cincoze Co., Ltd. All registered trademarks and product
names mentioned herein are used for identification purposes only and may be trademarks
and/or registered trademarks of their respective owners.
Disclaimer
This manual is intended to be used as a practical and informative guide only and is subject to
change without notice. It does not represent a commitment on the part of Cincoze. This
product might include unintentional technical or typographical errors. Changes are periodically
made to the information herein to correct such errors, and these changes are incorporated
into new editions of the publication.
Declaration of Conformity
Prefaces
FCC
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
CE
The product(s) described in this manual complies with all application European
Union (CE) directives if it has a CE marking. For computer systems to remain CE
compliant, only CE-compliant parts may be used. Maintaining CE compliance
also requires proper cable and cabling techniques.
Revision Description Date
1.0 Manual Released 2016/03/14
1.1 Content Revised 2017/01/05
1.2 BIOS OS Selection Revised 2017/01/12
Prefaces
1.3 Side Mount Bracket 2017/05/15
1.31 Modify 3.4 Mini PCI-e Card photos 2017/09/14

DA-1000 User’s Manual
6
Prefaces
Product Warranty Statement
Warranty
Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and
workmanship for 2 years from the date of purchase by the original purchaser.
During the warranty period, we shall, at our option, either repair or replace any product that proves to
be defective under normal operation.
Defects, malfunctions, or failures of the warranted product caused by damage resulting from natural
disasters (such as by lightening, flood, earthquake, etc.), environmental and atmospheric disturbances,
other external forces such as power line disturbances, plugging the board in under power, or incorrect
cabling, and damage caused by misuse, abuse, and unauthorized alteration or repair, and the product
in question is either software, or an expendable item (such as a fuse, battery, etc.), are not warranted.
RMA
Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA
number from us. Our staff is available at any time to provide you with the most friendly and immediate
service.
RMA Instruction
Customers must fill in Cincoze Return Merchandise Authorization (RMA) Request Form and
obtain a RMA number prior to returning a defective product to Cincoze for service.
Customers must collect all the information about the problems encountered and note anything
abnormal and describe the problems on the “Cincoze Service Form” for the RMA number apply
process.
Charges may be incurred for certain repairs. Cincoze will charge for repairs to products whose
warranty period has expired. Cincoze will also charge for repairs to products if the damage
resulted from acts of God, environmental or atmospheric disturbances, or other external forces
through misuse, abuse, or unauthorized alteration or repair. If charges will be incurred for a
repair, Cincoze lists all charges, and will wait for customer’s approval before performing the
repair.
Customers agree to insure the product or assume the risk of loss or damage during transit, to
prepay shipping charges, and to use the original shipping container or equivalent.
Customers can be send back the faulty products with or without accessories (manuals, cable,
etc.) and any components from the system. If the components were suspected as part of the
problems, please note clearly which components are included. Otherwise, Cincoze is not
responsible for the devices/parts.
Repaired items will be shipped along with a "Repair Report" detailing the findings and actions
taken.
Limitation of Liability
Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether
based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original
selling price of the product. The remedies provided herein are the customer’s sole and exclusive
remedies. In no event shall Cincoze be liable for direct, indirect, special or consequential damages
whether based on contract of any other legal theory.

DA-1000 User’s Manual
7
Technical Support and Assistance
1. Visit the Cincoze website at www.cincoze.com/support.php where you can find the latest
information about the product.
2. Contact your distributor or our technical support team or sales representative for technical
support if you need additional assistance. Please have following information ready before
you call:
Product name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software, etc.)
A complete description of the problem
The exact wording of any error messages
Conventions Used in this Manual
Prefaces
This indication alerts operators to an operation that, if not strictly
observed, may result in severe injury.
WARNING
This indication alerts operators to an operation that, if not strictly
observed, may result in safety hazards to personnel or damage to
equipment.
CAUTION
This indication provides additional information to complete a task
easily.
NOTE

DA-1000 User’s Manual
8
Safety Precautions
Before installing and using this device, please note the following precautions:
1. Read these safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Disconnected this equipment from any AC outlet before cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and
must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may
cause damage.
7. Make sure the voltage of the power source is correct before connecting the equipment to
the power outlet.
8. Use a power cord that has been approved for using with the product and that it matches
the voltage and current marked on the product’s electrical range label. The voltage and
current rating of the cord must be greater than the voltage and current rating marked on
the product.
9. Position the power cord so that people cannot step on it. Do not place anything over the
power cord.
10.All cautions and warnings on the equipment should be noted.
11.If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12.Never pour any liquid into an opening. This may cause fire or electrical shock.
13.Never open the equipment. For safety reasons, the equipment should be opened only by
qualified service personnel.
If one of the following situations arises, get the equipment checked by service personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to the user's
manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer.
Prefaces

DA-1000 User’s Manual
9
Package Contents
Before installation, please ensure all the items listed in the following table are included in the
package.
Item Description Q’ty
1 DA-1000 Embedded System 1
2 Utility DVD Driver 1
3 Power Terminal Block Connector 1
4 Screw Pack (For HDD / Mini-PCIe / Wall & VESA Mounting) 1
5 Wall Mount Kit 1
6 DVI-I to VGA Adapter 1
7 Power On/Off Terminal Block Connector 1
Note: Notify your sales representative if any of the above items are missing or damaged.
Prefaces

DA-1000 User’s Manual
10
Ordering Information
Prefaces
Model Name Product Description
DA-1000 Intel® Atom™ Processor E3826 Affordable Fanless Embedded Computer
DA-1000-E45 Intel® Atom™ Processor E3845 Affordable Fanless Embedded Computer
DA-1000-J19 Intel® Celeron® Processor J1900 Affordable Fanless Embedded Computer

DA-1000 User’s Manual
11
Prefaces
Model No. Description
CMI-COM102/UB0403 CMI Module with 2x RS232/422/485, 1x Universal Bracket (96 x 15 mm)
CMI-DIO100/UB0415 CMI Module with 8x Optical Isolated DIO (4 in/4 out), 1x Universal Bracket (96 x 15 mm)
CMI-DP101/UB0406 CMI Module with 1x Display Port, 1x Universal Bracket (96 x 15 mm)
CMI-DVI101/UB0407 CMI Module with 1x DVI-D Connector, 1x Universal Bracket (96 x 15 mm)
CMI-LPPS102/UB0409 CMI Module with 1x LPT Port, 1x PS/2, 1x Universal Bracket (96 x 15 mm)
CMI-VGA101/UB0416 CMI Module with 1x VGA Port, 1x Universal Bracket (96 x 15 mm)
MEC-LAN-M002-R1/UB0411 Mini-PCIe Module with 2x LAN Ports, 1x Universal Bracket (96 x 15 mm)
MEC-USB-M002/UB0414 Mini-PCIe Module with 2x USB 3.0 Ports, 1x Universal Bracket (96 x 15 mm)
SIDE-DA DA Series Side Mount Kit
DINRAIL Diamond Series Din-Rail Mount Kit
Optional Modules & Accessories

Product Introductions
Chapter 1

DA-1000 User’s Manual
13
1.1.1 Key Features
• Onboard Intel® Atom™ or Celeron® Processors
• One DDR3L SO-DIMM Socket, Support Up to 8G
• Support Dual Display, Output from One DVI-I Port
• Dual Intel® I210-AT GbE LAN Ports, Support WoL, Teaming, PXE
• Ultra Compact Size (150x105x56.02mm)
• Support -25˚C~70˚C Extended Operating Temperature
• Support 9~48VDC Input, Support AT/ATX Power Mode
• CMI (Combined Multiple I/O) Interface for I/O Module Expandability
• Various Mounting Options (VESA, DIN-Rail, Side/Wall Mounting)
1.1 Overview
DA-1000 Series is an ultra-compact size fanless embedded computer powered by
Intel® Atom™ or Celeron® Processors; it integrated HD graphics processor
supporting dual display. This can bring economic advantages on budget and also
fulfill the needs for industrial computing tasks. DA-1000 Series manages to pack a
diverse array of I/O into its small form factor, with one DVI-I port, two RS-
232/422/485 COM ports, dual Gbe LAN ports, four USB ports and one set of Mic-
in and Line-out.
DA-1000 Series supports Combined Multiple I/O (CMI) interface and modules
which are specially designed for flexible I/O expandability; it allows users to
extend various I/Os according to their needs. CMI modules are including COMs,
DIO, DisplayPort, DVI, LPT/PS2 or VGA. The rugged construction, wide operating
temperature and high tolerance for shock and vibration enable DA-1000 Series to
deploy in a harsh environment and for critical applications, and it is totally
maintenance-free.
Chapter 1: Product Introductions

DA-1000 User’s Manual
14
Chapter 1: Product Introductions
1.1.3 Photo of Rear Panel
1.1.2 Photo of Front Panel

DA-1000 User’s Manual
15
Processor
• Intel® Atom™ Processor E3826 (1M Cache, Up
to 1.46 GHz SoC, 7W TDP)
• Intel® Atom™ Processor E3845 (2M Cache, Up
to 1.91 GHz SoC, 10W TDP)
• Intel® Celeron® Processor J1900 (2M Cache,
Up to 2.42 GHz SoC, 10W TDP)
BIOS
• AMI 64Mbit SPI BIOS
Memory
• 1x 204-Pin SO-DIMM DDR3L 1066/1333MHz
(Un-buffered and Non-ECC) Max. Up to 8GB
Graphics
• Intel® HD Graphics Max. 667 MHz
• Support Dual Display (with optional split cable)
Expansion
• 2x Full-size Mini-PCIe
• 1x SIM Socket (Internal)
• 1x CMI (Combined Multiple I/O) Interface
Storage
• 1x 2.5" SATA HDD Bay (Internal)
• 1x Internal mSATA Slot (Shared by 1x Mini-PCIe
socket)
External I/O Interface
• 1x DVI-I Port
• 2x GbE LAN Ports (Intel® I210, Support Wake
On Lan, Teaming, Jumbo Frame, PXE)
• 2x COM Ports (DB9, RS232/RS422/RS485
with Auto Flow Control)
• 1x USB 3.0 Ports
• 3x USB 2.0 Ports
• 1x Mic-in and 1x Line-out (Codec: Realtek
ALC888S)
• 1x Power On/Off Switch
• 1x AT/ATX Switch
• 1x Remote Power On/Off Connector (2-pin
Terminal Block)
• 1x Universal I/O Bracket
• 2x Antenna Holes
Watchdog Timer
• Software Programmable Supports 1~255 sec.
System Reset
Power Requirement
• Support AT/ATX Power Mode
• Power Input Voltage 9~48VDC
• One 3-pin Terminal Block Connector
• Optional Power Adapter AC/DC 12V/5A 60W
• Power Consumption Typical 8.3W, Max.15W
Physical
• Dimension: 150 (W) x 105 (D) x 56.02 (H) mm
• Weight: 0.86kg
• Construction: Aluminum Chassis with Fan-less
Design
• Mounting: VESA/Wall Mounting (Optional DIN-
Rail/Side Mounting)
• Cable-less Design
Environment
• Operating Temperature: -25°C to 70°C
(With extended temperature peripherals;
Ambient with Air Flow by IEC60068-2-1,
IEC60068-2-2, IEC60068-2-14)
• Storage Temperature: -40°C to 85°C
• Relative Humidity: 95% RH @ 40˚C (Non-
Condensing)
• Shock: 50 Grms
(With SSD According to IEC 60068-2-27, Half
Sine, 11ms Duration)
• Vibration: Random: 5 Grms
(With SSD According to IEC 60068-2-64,
5~500Hz, 1 hr/axis)
Protection
• Reverse Power Input Protection Supported
• Over Voltage Protection (OVP) Up to 51V
• Over Current Protection (OCP) 120V/ 20A
• ESD Protection Air Discharge: 8 kV; Contact
Discharge: 4 kV (by IEC 61000-4-2)
Operating System
• Windows® 10
• Windows® 8.1
• Windows® 7
Certification
• CE
• FCC Class A
Chapter 1: Product Introductions
1.2 Hardware Specification

DA-1000 User’s Manual
16
Chapter 1: Product Introductions
Front Panel
Power On/Off Switch
Press to power-on or power-off the system
AT/ATX Mode Select Switch
Used to select AT or ATX power mode
Power LED
Indicates the power status of the system
HDD LED
Indicates the status of the hard drive
Remote Power Terminal Block
Used to plug a remote power on/off switch with
terminal block
USB 3.0 Port
Used to connect USB 3.0/2.0/1.1 device
USB 2.0 Port
Used to connect USB 2.0/1.1 device
LAN Port 1 & 2
Used to connect the system to a local area network
Mic-in
Used to connect a microphone
Line-out
Used to connect a speaker
1.3 System I/O

DA-1000 User’s Manual
17
Chapter 1: Product Introductions
Rear Panel
DC IN Terminal Block
Used to plug a DC power input with terminal block
DVI-I Port
Used to connect a DVI monitor or connect optional
split cable for dual display mode
Antenna Hole
Used to connect an antenna for optional Mini-PCIe
WiFi module
COM Port
COM 1 ~ COM 2 support RS232/422/485 serial
device
Universal I/O Bracket
This expansion area is reserved for Mini-PCIe expansion or Cincoze
own pin-defined interface (CMI). CMI interface supports various type
of I/O modules such as COM / DIO / DisplayPort / DVI / LPT & PS2 /
VGA.
Do not change the CMI module by yourself, it may cause damage to
your DA-1000. Please contact with your regional dealer for more
information about it.

DA-1000 User’s Manual
18
Chapter 1: Product Introductions
1.4 Mechanical Dimensions
Each of DA-1000 series computers has the same mechanical dimension.
Unit: mm

Jumpers and Connectors
Chapter 2

DA-1000 User’s Manual
20
2.1 Jumpers Settings
DA-1000 is featured with jumper-free design.
Chapter 2: Jumpers and Connectors
2.2 Locations of the Switches and Connectors
2.2.1 Top View
