Asus AAEON VPC-5620S User manual

Last Updated: July 15, 2021
VPC-5620S
Industrial & Mobile NVR
User’s Manual 1st Ed

Preface II
Industrial & Mobile NVR VPC-5620S
Copyright Notice
This document is copyrighted, 2021. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.

Preface III
Industrial & Mobile NVR VPC-5620S
Acknowledgements
All other products’ name or trademarks are properties of their respective owners.
⚫Microsoft Windows is a registered trademark of Microsoft Corp.
⚫Intel® and Celeron® are registered trademarks of Intel Corporation
⚫Intel Core™ is a trademark of Intel Corporation
⚫ITE is a trademark of Integrated Technology Express, Inc.
⚫IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines
Corporation.
All other product names or trademarks are properties of their respective owners.

Preface IV
Industrial & Mobile NVR VPC-5620S
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
⚫VPC-5620S
1
⚫Wall Mount Bracket
2
⚫SATA Cable
2
⚫Power Cable (for SATA)
2
⚫Mating Connector for Power Input
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
Industrial & Mobile NVR VPC-5620S
About this Document
This User’s Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver installation
instructions (if any), to facilitate users in setting up their product.
Users may refer to the product page at AAEON.com for the latest version of this
document.

Preface VI
Industrial & Mobile NVR VPC-5620S
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future reference.
1. All cautions and warnings on the device should be noted.
2. All cables and adapters supplied by AAEON are certified and in accordance with
the material safety laws and regulations of the country of sale. Do not use any
cables or adapters not supplied by AAEON to prevent system malfunction or
fires.
3. Make sure the power source matches the power rating of the device.
4. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
5. Always completely disconnect the power before working on the system’s
hardware.
6. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
7. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
8. Always disconnect this device from any AC supply before cleaning.
9. While cleaning, use a damp cloth instead of liquid or spray detergents.
10. Make sure the device is installed near a power outlet and is easily accessible.
11. Keep this device away from humidity.
12. Place the device on a solid surface during installation to prevent falls.
13. Do not cover the openings on the device to ensure optimal heat dissipation.
14. Watch out for high temperatures when the system is running.
15. Do not touch the heat sink or heat spreader when the system is running.
16. Never pour any liquid into the openings. This could cause fire or electric shock.

Preface VII
Industrial & Mobile NVR VPC-5620S
17. As most electronic components are sensitive to static electrical charge, be sure to
ground yourself to prevent static charge when installing the internal components.
Use a grounding wrist strap and contain all electronic components in any
static-shielded containers.
18. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
19. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
Industrial & Mobile NVR VPC-5620S
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur.
Recycler les batteries usées en accord avec les instructions du fabricant et les directives
gouvernementales de recyclage.

Preface IX
Industrial & Mobile NVR VPC-5620S
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON System QO4-381 Rev.A0
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
○
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
×
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
电池
×
○
○
○
○
○
本表格依据 SJ/T 11364 的规定编制。
○ ：表示该有毒有害物质在该部件所有均质材料中的含量均在
GB/T 26572标准规定的限量要求以下。
×：表示该有害物质的某一均质材料超出了GB/T 26572的限量要求，然而该部件
仍符合欧盟指令2011/65/EU 的规范。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、电源为选购品。
三、上述部件物质液晶模块、触控模块仅一体机产品适用。

Preface X
Industrial & Mobile NVR VPC-5620S
China RoHS Requirement (EN)
Hazardous and Toxic Materials List
AAEON System QO4-381 Rev.A0
Component
Name
Hazardous or Toxic Materials or Elements
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Hexavalent Chromium (Cr(VI))
Polybrominat ed biphenyls (PBBs)
Polybrominat ed diphenyl ethers (PBDEs)
PCB and
Components
X
O
O
O
O
O
Wires &
Connectors for
Ext.Connections
X
O
O
O
O
O
Chassis
O
O
O
O
O
O
CPU & RAM
X
O
O
O
O
O
HDD Drive
X
O
O
O
O
O
LCD Module
X
X
O
O
O
O
Optical Drive
X
O
O
O
O
O
Touch Control
Module
X
O
O
O
O
O
PSU
X
O
O
O
O
O
Battery
X
O
O
O
O
O
This form is prepared in compliance with the provisions of SJ/T 11364.
O: The level of toxic or hazardous materials present in this component and its parts is below the
limit specified by GB/T 26572.
X: The level of toxic of hazardous materials present in the component exceed the limits specified
by GB/T 26572, but is still in compliance with EU Directive 2011/65/EU (RoHS 2).
Notes:
1. The Environment Friendly Use Period indicated by labelling on this product is applicable only
to use under normal conditions.
2. Individual components including the CPU, RAM/memory, HDD, optical drive, and PSU are
optional.
3. LCD Module and Touch Control Module only applies to certain products which feature these
components.

Preface XI
Industrial & Mobile NVR VPC-5620S
Table of Contents
Chapter 1 - Product Specifications.......................................................................................... 1
1.1 Specifications............................................................................................................ 2
Chapter 2 –Hardware Information ....................................................................................... 5
2.1 Dimensions ............................................................................................................... 6
2.1.1 Industrial Chassis.......................................................................................... 6
2.1.2 Main Board.................................................................................................... 8
2.1.3 VPC-5620S with PER-T529 (3 x COM Ports).........................................10
2.1.4 VPC-5620S with PER-T623 (4 x USB Ports)...........................................12
2.1.5 VPC-5620S with PER-T626 (4 x Smart PoE)..........................................14
2.2 Jumpers and Connectors......................................................................................16
2.3 List of Jumpers ........................................................................................................17
2.3.1 Clear CMOS (CN10)....................................................................................17
2.3.2 Front Panel (CN12)......................................................................................17
2.4 List of Connectors...................................................................................................18
2.4.1 SATA Power Connector (CN8/CN11) .......................................................19
2.4.2 Front Panel Connector (CN12) .................................................................19
2.4.3 RS-232 Serial Port 3/ 4 Connector (CN19/CN20) ...............................20
2.4.4 Digital I/O Connector (CN20) .................................................................20
2.4.5 DC Input (12~24V) (CN22)........................................................................21
2.4.6 RS-232 Serial Port 1/ 2 Connector (CN24/CN25) ................................21
2.5 Block Diagram........................................................................................................22
2.6 PER-T528 Jumpers and Connectors..................................................................23
2.7 PER-T528 List of Connectors ..............................................................................23
2.7.1 Power Connector (CN1)............................................................................23
2.7.2 MCU Programming Pin (CN5) ................................................................24
2.7.3 Communication Pin Connector (CN9) ..................................................24

Preface XII
Industrial & Mobile NVR VPC-5620S
2.7.4 Communication Pin Header (CN10).......................................................25
2.8 PER-T529 Jumpers and Connectors..................................................................26
2.9 PER-T529 List of Jumpers ....................................................................................27
2.9.1 Pull High Register (CN6)...........................................................................27
2.9.2 Pull Low Register (CN7)............................................................................27
2.10 PER-T529 List of Connectors ..............................................................................28
2.10.1 Power Connection (CN12)........................................................................28
2.11 System Assembly (Industrial Chassis)................................................................29
2.11.1 2.5” SATA Drive and Bottom Panel Assembly ......................................29
2.11.2 Wall Mount Assembly ...............................................................................30
2.12 System Assembly (Expanded Chassis) ...............................................................31
2.12.1 2.5” SATA Drive and Bottom Panel Assembly .......................................31
2.12.2 RAM Installation .........................................................................................33
2.12.3 Wall Mount Assembly ...............................................................................35
Chapter 3 - AMI BIOS Setup ................................................................................................ 36
3.1 System Test and Initialization ..............................................................................37
3.2 AMI BIOS Setup .....................................................................................................38
3.3 Setup Submenu: Main..........................................................................................39
3.4 Setup Submenu: Advanced.................................................................................40
3.4.1 CPU Configuration .....................................................................................41
3.4.2 PCH-FW Configuration.............................................................................42
3.4.2.1 Firmware Update Configuration....................................................43
3.4.3 SATA and RST Configuration ...................................................................44
3.4.4 NVMe Configuration.................................................................................45
3.4.5 Hardware Monitor .....................................................................................46
3.4.6 SIO Configuration......................................................................................47
3.4.6.1 Serial Port 1 Configuration ..............................................................48
3.4.6.2 Serial Port 2 Configuration .............................................................49

Preface XIII
Industrial & Mobile NVR VPC-5620S
3.4.6.3 Serial Port 3 Configuration .............................................................50
3.4.6.4 Serial Port 4 Configuration ..............................................................51
3.4.6.5 Serial Port 5 Configuration .............................................................52
3.4.6.6 Serial Port 6 Configuration .............................................................53
3.4.6.7 Serial Port 7 Configuration..............................................................54
3.4.6.8 Serial Port 8 Configuration .............................................................55
3.4.6.9 Serial Port 9 Configuration .............................................................56
3.4.7 Power Management..................................................................................57
3.4.8 Digital IO Port Configuration ..................................................................59
3.4.9 Status LED Configuration.........................................................................60
3.4.10 Network Stack Configuration...................................................................61
3.4.10.1 Network Stack Configuration (Enabled).......................................62
3.5 Setup Submenu: Chipset .....................................................................................64
3.5.1 System Agent (SA) Configuration ..........................................................65
3.5.2 PCH-IO Configuration ..............................................................................66
3.6 Setup Submenu: Security.....................................................................................67
3.6.1 Secure Boot.................................................................................................68
3.6.2 Key Management.......................................................................................70
3.7 Setup Submenu: Boot ..........................................................................................74
3.8 Setup Submenu: Save & Exit...............................................................................75
Chapter 4 –Drivers Installation............................................................................................ 76
4.1 Driver Download and Installation.......................................................................77
Chapter 5 –SDK Guide......................................................................................................... 79
5.1 Introduction ............................................................................................................80
5.2 CAN Bus ...................................................................................................................81
5.2.1 CAN Bus Utility............................................................................................81
5.2.2 CAN Bus SDK..............................................................................................85
5.3 Accelerometer & Gyroscope Utility ...................................................................94

Preface XIV
Industrial & Mobile NVR VPC-5620S
5.4 Power MCU Utility .................................................................................................96
5.5 Smart PoE Utility ....................................................................................................97
5.5.1 About Smart PoE .......................................................................................97
5.5.2 Smart PoE Utility Description...................................................................98
Appendix A - I/O Information.............................................................................................100
A.1 I/O Address Map ..................................................................................................101
A.2 IRQ Mapping Chart............................................................................................. 103
A.3 Memory Address Map ........................................................................................115

Industrial & Mobile NVR VPC-5620S
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 –Product Specifications 2
Industrial & Mobile NVR VPC-5620S
1.1 Specifications
System
Form Factor
Multi-PoE & Fanless Appliance
Processor
8th Generation Intel® Core™ Processor:
Default: Core i7-8665UE
Project Base:
Core i5-8365UE
Core i3-8145UE
Celeron® 4305UE
Chipset
—
Main Memory
Up to 64GB, DDR4 260-pin SODIMM
Display
HDMI x 1
DP x 1
Ethernet
1 x Gbps Ethernet, Intel® i211 chipset;
Wake-on-LAN and PXE supported
Smart PoE
4 ports (max. 8 ports per project basis);
IEEE 802.3 at/af, total 60W output per four
ports. Supports independent power
management of individual PoE ports via SDK
package.
RAID support
0/1
Expansion Slot
1 x mPCIe Full-Size (USB + PCIe)
1 x mPCIe Full-Size (USB + SATA) colay SATA
1 x M.2 2280 (USB + PCIe), supports NVME
PCIe [x4] SSD
GPS, G-Sensor
Built-in GPS, Gyro & G-Sensor (in-vehicle
configuration by project basis)

Chapter 1 –Product Specifications 3
Industrial & Mobile NVR VPC-5620S
System
Front I/O Panel
4 x RJ45 Smart PoE Port (60W total)
4 x USB3.2 Gen 1
1 x Gbps LAN port
1 x DP
Power Button
Status LED
HDD LED
Wireless LED
2 x Micro SIM slots
2 x Antenna holes
Rear I/O Panel
1 x Audio Jack (Line Out & Mic In)
1 x HDMI port
2 x RS-232/422/485 (isolated per project
basis)
1 x Hardware Reset
1 x 3-pin Power Input
8-bit DIO (8-in/ 8-out set by BIOS option;
Isolated 4-in & 4-out per project basis)
2 x Antenna holes
Storage
HDD Tray
2 x 2.5” HDD/SSD Bay
CF/CFast/mSATA Slot
—
Envrionmental
Operating Temperature
-4°F ~ 158°F (-20°C ~ 70°C)
Storage Temperature
-40°F ~ 185°F (-40°C ~ 85°C)

Chapter 1 –Product Specifications 4
Industrial & Mobile NVR VPC-5620S
Envrionmental
Storage Humidity
10%~80% at 40°C, non-condensing
Vibration/Shock
MIL-STD-810G
Certification
CE & FCC Class A
Power Requirements
Power Supply
DC 12~24V
DC 9~36V with power ignition (in-vehicle
configuration by project basis)
Mechanical
Removable HDD Tray
—
Internal System HDD Bay
2.5" HDD x 2
Dimension
Industrial Chassis: 6.3” x 5.87” x 2.16” (180mm
x 149mm x 55mm)
Expanded Chassis: 6.3” x 5.87” x 2.95”
(180mm x 149mm x 75mm)
Gross Weight
TBD
Note
—

Industrial & Mobile NVR VPC-5620S
Chapter 2
Chapter 2 –Hardware Information

Chapter 2 –Hardware Information 6
Industrial & Mobile NVR VPC-5620S
2.1 Dimensions
2.1.1 Industrial Chassis
7
204
50.5
4.5
24.5
101
220
180
55
149
180
