Asus B53J-A1B User manual

SKUS
B53J-A1B
B53J-B1B
ATI® Eyefinity™ Technology boosts
productivity by supporting up to
two additional independent display
outputs.
With Intel® vPro™ Technology, PCs
can be fixed and maintained
remotely, reducing maintenance
costs.
ASUS B Series notebooks are
covered by an industry-best three
year global warranty, and a one
year accidental damage warranty.
Docking station support allows
users to quickly connect peripher-
als, power, and communication
devices (docking station sold
separately).
World’s first laptop with a standard
Sonata Long Life Battery, which
lasts up to three times as long as a
normal battery and comes with a 3
year warranty. *
P/N: B53J-A1B, 15.6”, Intel Core i5-520M, ATI®
5470 512MB, 2GB DDR3, 320GB 7200RPM,
802.11 b/g/n, Sonata Long Life Battery with a 3
year warranty, up to 4 hours battery life,* and 3
times as many rechargeable cycles,*
Windows®7 Professional (64 Bit) + XP Pro
Downgrade, 3 YR warranty + 1 YR ADW
P/N: B53J-B1B, 15.6”, Intel Core i7-620M, ATI
5470 512MB, 4GB DDR3, 320GB 7200RPM,
802.11 b/g/n, Sonata Long Life Battery with a 3
year warranty, up to 4 hours battery life,* and 3
times as many rechargeable cycles,* Windows 7
Professional (64 Bit) + XP Pro Downgrade, 3 YR
warranty + 1 YR ADW
B53J Notebook
The Intel® Anti-Theft feature will
automatically disable the laptop if it
is lost or stolen, protecting private
data.
The Business User’s New Best Friend
THE NEW GOLD STANDARD IN
BUSINESS CLASS COMPUTING.
The B53J redefines business computing
with several “firsts.” It is the first
notebook to feature ATI® Eyefinity™ for
improved productivity, the first with a
Sonata® Long Life Battery that comes
with a three year battery warranty, and
the first with a three year global warranty
plus a one year accidental damage
warranty. It also features a scratch-
resistant aluminum casing, Intel® vPro™
support, and docking support. Tested to
a much higher standard than the typical
notebook, the B53J is more reliable in an
environment where downtime is
unacceptable.
B53J Notebook
B53J Notebook
Copyright ASUS Computer International, 2010. All rights reserved. Visit commercial.asus.com for more details.

B53J
Windows 7 Professional (64 bit)
+ XP Pro downgrade CD
15.6” LED backlit
1366 x768
Intel Core i5-520M (B53J-A1B)/
Intel Core i7-620M (B53J-B1B)
802.11 b/g/n
320GB 7200RPM HDD
Altec Lansing® speakers
Operating System
Display
Screen
Processor
2GB DDR3-1333 SO-DIMM, expandable
up to 8GB via additional slot (B53J-A1B);
4GB DDR3-1333 SO-DIMM, expandable up
to 8GB via additional slot (B53J-B1B)
Memory
10/100/1000 Mbps
LAN
Wireless
Storage
Audio
2 x USB 2.0
1 x eSATA/USB combo
RJ-11, RJ-45,
D-sub 15 PIN, HDMI, Display Port, SmartCard,
ExpressCard34, mic-in, headphone (w/ SPDIF), 5-in-1
card reader, others: docking port
Smart Card Reader, 5 in 1 card reader, Express Card reader
(type34)
Sonata Long Life Battery / up to 4 hours* / 3 year warranty
15.12”x10.35”x1.26” ~1.38” (WxDxH)
5.95 lbs. with battery
Black
Input / Output
Card Reader
Battery
Dimensions
Weight
ATI Mobility Radeon™ 5470 512MB
Graphics
2.0 Megapixel with lens cover
Camera
Color
B53J
The Business User’s New Best Friend
Intel vPro, Pre-OS login fingerprint
reader / Trusted Platform Module (TPM)
/ Smart Card Reader
Security
* Battery life tested by Mobile Mark 2007 in reader mode. Actual life varies by usage.
* Battery maintains over 80% of its original capacity after 1000 charge/discharge cycles (vs. 300 cycles for typical batteries)
* All specifications and terms are subject to change without notice. Brand and product names mentioned are trademarks of
their respective companies.
90-XB0IN0CH00010 Notebook 90 Watt Car Charger
90-N0L1B3000Y Sonata Long Life 3 Cell 47WHr (Equivalent to standard 6 Cell)
90-NYX1B2000Y Standard 6 Cell Battery 47WHr
90-N0L1B4000Y Sonata Long Life 4 Cell 63WHr (Equivalent to standard 8 Cell)
90-NYX1B1000Y Standard 8 Cell Battery 63WHr
90-N0LDK1000Y Dedicated Docking Station (VGA/DVI/HDMI)
Part Number Item Description
Black
Black
Black
Black
Black
Black
Color
ACCESSORIES
3 Yr Notebook Standard Limited Warranty and
3 Yr Next Business Day On-site support
3 Yr Notebook Standard Limited Warranty and
3 Yr Accidental Damage Warranty
3 Yr Notebook Standard Limited Warranty and
3 Yr Accidental Damage Warranty with Next Business Day On-site support
4 Yr Notebook Standard Limited Warranty
4 Yr Notebook Standard Limited Warranty and
4 Yr Next Business Day Onsite Service
4 Yr Notebook Standard Limited Warranty and
4 Yr Accidental Damage Warranty
4 Yr Notebook Standard Limited Warranty and
4 Yr Accidental Damage Warranty with Next Business Day On-site support
Warranty and Service Upgrades
OPTIONS
ACCX019-01N0
ACCX019-21N0
ACCX019-51N0
ACCX019-41N0
ACCX019-61N0
ACCX019-11N0
ACCX019-31N0
