Asus E403S User manual

E11439_E403SA_UM_V2_12pages.indd 1
2016/3/17 ��
02:57:32
E11439
Revised Edition V2
March 2016
User Guide

E11439_E403SA_UM_V2_12pages.indd 2
2016/3/17 ��
02:57:33
Top View
NOTE:The keyboard's layout may vary per regionorcountry. The topview may also
vary in appearance depending on the Notebook PC model.
Camera
Camera indicator
Microphone
Display panel
Power button
Keyboard
Touchpad
Front Side
Status indicators
2 Notebook PC UserGuide

E11439_E403SA_UM_V2_12pages.indd 3
2016/3/17 ��
02:57:33
I/O ports and slots
Right Side Left Side
Memory card reader
Power (DC) input port
USB 2.0 port
HDMI port
Security slot
USB 3.0 port
USB Type-C port
Headphone/Headset/Microphone jack
Getting started
1. Charge your Notebook PC
A. Connect the AC power cord to the AC/DC adapter.
B. Plug the AC power adapter into a 100V~240V power source.
C. Connect the DC power connector into your Notebook PC’s power (DC) input.
NOTE:The poweradapter may vary inappearance, depending on models and your
region.
2. Lift to open the display panel
3. Pressthepowerbutton
Charge the Notebook PC
for 3 hours before using
it in battery mode for the
first time.
Notebook PC User Guide 3

E11439_E403SA_UM_V2_12pages.indd 4
2016/3/17 ��
02:57:34
Safety notices for your Notebook PC
WARNING!
The bottom of the Notebook PC can get warm to hot while in use or while charging the battery
pack. When working on your Notebook PC, do not place it onsurfaces that can block the vents.
CAUTION!
• This Notebook PC should only be used in environments with ambient temperatures between
5°C (41°F) and 35°C (95°F).
• Refer to the rating label on the bottom of your Notebook PC and ensure that your power
adapter complies with this rating.
• Thepoweradaptermay become warm tohot while inuse. Do not cover the adapter and keep
it away from your body while it is connected to a power source.
IMPORTANT!
• Ensure that your Notebook PC is connected to agrounded power adapter before turning it
on for the first time.
• WhenusingyourNotebook PConpower adapter mode,the socketoutlet mustbe neartothe
unit and easily accessible.
• Locate the input/output rating label on your Notebook PC and ensure that it matches the
input/output rating information on your power adapter. Some Notebook PC models may
have multiple rating output currents based on the available SKU.
• Power adapter information:
- Input voltage: 100-240Vac
- Inputfrequency:50-60Hz
- Ratingoutputcurrent:1.75A(33W)
- Rating output voltage: 19V
WARNING!
Read the following precautions for your Notebook PC’s battery:
• Only ASUS-authorized technicians should
remove the battery inside the device
(for non-removable battery only).
• The battery used in this device may present
a risk of fire or chemical burn if removed or
disassembled.
• Follow the warning labels for your personal
safety.
• Risk of explosion if battery is replaced by an
incorrect type.
• Do not dispose of in fire.
• Neverattempttoshort-circuityour
Notebook PC’s battery.
• Neverattempttodisassembleand
reassemble the battery
(for non-removable battery only).
• Discontinue usage if leakage is found.
• This battery and its components must be
recycled or disposed of properly.
• Keep the battery and other small
components away from children.
4 Notebook PC UserGuide

E11439_E403SA_UM_V2_12pages.indd 5
2016/3/17 ��
02:57:34
Avis concernant les batteries remplaçables
• Labatteriedel’ordinateurportablepeut
présenterun risque d’incendie ou de brûlure si
celle-ciestretiréeoudésassemblée.
• La batterie et ses composants doivent
être recyclés de façon appropriée.
Copyright Information
You acknowledge that all rights of this Manual remain with ASUS. Any and all rights, including without
limitation, in the Manual or website, are and shall remain the exclusive property of ASUS and/or its
licensors.NothinginthisManualintends totransferany suchrights,or to vest any such rights to you.
ASUS PROVIDES THIS MANUAL“AS IS”WITHOUT WARRANTY OF ANYKIND. SPECIFICATIONS AND
INFORMATIONCONTAINEDINTHISMANUALAREFURNISHEDFORINFORMATIONALUSEONLY,AND
ARE SUBJECTTO CHANGE AT ANYTIMEWITHOUT NOTICE, ANDSHOULD NOT BE CONSTRUED AS A
COMMITMENT BY ASUS.
Copyright © 2016 ASUSTeK COMPUTER INC. All Rights Reserved.
Limitation of Liability
Circumstancesmay arisewherebecause ofa default on ASUS’partor other liability,youare entitledto
recover damages from ASUS. Ineach such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property; or any other actual and direct damages
resulted from omission or failure of performing legal duties under this Warranty Statement, up to the
listedcontractpriceof each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based incontract, tort or
infringement under this Warranty Statement.
This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers,
and your reseller are collectively responsible.
UNDER NOCIRCUMSTANCES ISASUS LIABLE FOR ANY OFTHE FOLLOWING: (1) THIRD-PARTY CLAIMS
AGAINSTYOU FOR DAMAGES; (2) LOSS OF,OR DAMAGE TO,YOUR RECORDS OR DATA;OR (3) SPECIAL,
INCIDENTAL,ORINDIRECTDAMAGESORFORANYECONOMICCONSEQUENTIALDAMAGES(INCLUDING
LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS ORYOUR RESELLER ISINFORMED OF THEIR
POSSIBILITY.
Service and Support
For complete E-Manual version, refer to our multi-language website at:
https://www.asus.com/support/
Notebook PC User Guide 5

E11439_E403SA_UM_V2_12pages.indd 6
2016/3/17 ��
02:57:34
FCC Radio Frequency (RF) Exposure Caution
Statement
WARNING! Any changes or modifications not expressly approved by the party
responsible forcompliance could voidthe user’s authority tooperate this equipment.
“The manufacture declares that this device is limited to Channels 1 through 11 in the
2.4GHzfrequencyby specifiedfirmwarecontrolledintheUSA.”
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.To maintain compliance with FCC RF exposure compliance requirements, please
avoid direct contact to the transmitting antenna during transmitting. End users must follow the
specificoperating instructionsforsatisfyingRFexposurecompliance.
UL Safety Notices
• DONOT use the Notebook PC near water, forexample, neara bath tub,wash bowl, kitchen
sink or laundry tub, in a wet basement or near a swimming pool.
• DO NOT use the Notebook PC during an electrical storm.There may be a remote risk of
electric shock from lightning.
• DO NOT use the Notebook PC in the vicinity of a gas leak.
• DONOT dispose the Notebook PC battery pack in a fire, as they may explode. Check with local
codes for possible special disposal instructions to reduce the risk of injury to persons due to
fireorexplosion.
• DO NOT use power adapters or batteries from other devices to reduce the risk of injury to
persons due to fire orexplosion. Use only UL certified power adapters orbatteries supplied
bythemanufacturerorauthorizedretailers.
GlobalEnvironmentalRegulationComplianceand
Declaration
ASUS follows the green design concept to design and manufacture our products, and
makes sure that each stage of the product life cycle of ASUS product is in line with global
environmentalregulations. Inaddition,ASUS disclose the relevant information based on
regulation requirements.
Please refer to http://csr.asus.com/english/Compliance.htm for information disclosure
based on regulation requirements ASUS is complied with:
Japan JIS-C-0950 Material
Declarations, EU REACH SVHC, Korea RoHS
6 Notebook PC UserGuide

E11439_E403SA_UM_V2_12pages.indd 7
2016/3/17 ��
02:57:34
Coating Notice
IMPORTANT! To provide electrical insulation and maintain electrical safety, a coating
is applied to insulate the device except on the areas where the I/O ports are located.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programscome fromourcommitment tothe higheststandardsfor
protecting our environment. We believe in providing solutions for you to be able to responsibly
recycleourproducts,batteries,othercomponentsaswellasthepackagingmaterials.Please
go to http://csr.asus.com/english/Takeback.htm for detailed recycling information in different
regions.
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more than 3Kg must use
approvedpowercordsgreaterthanorequalto:H05VV-F,3G,0.75mm2 orH05VV-F,2G,0.75mm2.
REACH
Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of
Chemicals) regulatory framework,we publish the chemicalsubstances in our products at ASUS
REACH website at http://csr.asus.com/english/REACH.htm.
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high volume levels for long
periods.
Notebook PC User Guide 7

E11439_E403SA_UM_V2_12pages.indd 8
2016/3/17 ��
02:57:34
Industry Canada statement
This device complies with RSS-247 of the Industry Canada Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
devicemust accept any interference received, including interference thatmay causeundesired
operation.
Ce dispositif est conforme à la norme CNR-247 d’Industrie Canada applicable aux appareils radio
exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif
ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage
reçu,y compris unbrouillage susceptible de provoquerun fonctionnement indésirable.
Caution
(i) the device for operation inthe band 5150-5250 MHz is only for indoor use to reduce the
potential for harmful interference to co-channel mobile satellite systems;
(ii) the maximum antenna gain permitted for devices inthe bands 5250-5350 MHz and 5470-
5725MHz shall be such that the equipment still complies with the e.i.r.p. limit;
(iii) the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such
that the equipment still complies with the e.i.r.p. limits specified for point-to-point and non-
point-to-pointoperationasappropriate;and
(iv) theworst-casetiltangle(s)necessarytoremaincompliantwiththee.i.r.p.elevationmask
requirement set forth in Section 6.2.2(3) shall be clearly indicated.
(v) Users should also be advised that high-power radars are allocated as primary users (i.e.
priority users) ofthe bands 5250-5350 MHz and 5650-5850 MHz andthat these radars could
causeinterferenceand/ordamagetoLE-LANdevices.
8 Notebook PC UserGuide

Notebook PCUserGuide
9
E11439_E403SA_UM_V2_12pages.indd 9
2016/3/17 ��
02:57:34
Avertissement
Le guide d’utilisation des dispositifs pour réseaux locaux doit inclure des instructions précises
sur les restrictions susmentionnées, notamment :
(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour
une utilisationàl’intérieurafin de réduire les risques de brouillage préjudiciable aux systèmes
desatellites mobilesutilisant les mêmescanaux;
(ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes de 5250 à 5 350
MHz et de 5470à 5725 MHz doit être conforme àla limite de la p.i.r.e;
(iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande de 5 725 à 5 850
MHz) doit être conforme à la limite de la p.i.r.e. spécifiée pour l’exploitation point à point et
l’exploitation non point à point,selon le cas;
(iv) lespiresanglesd’inclinaisonnécessairespour resterconformeàl’exigencede la p.i.r.e.
applicable aumasque d’élévation, eténoncée à la section6.2.2 3), doiventêtre clairement
indiqués.
(v) De plus,les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute
puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes
5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer dubrouillage et/ou des
dommages aux dispositifs LAN-EL.
Radiation Exposure Statement
The product comply with the Canada portable RF exposure limit set forth for an uncontrolled
environment and are safe for intended operation as described in this manual.The further RF
exposure reduction can be achieved if the product can be kept as far as possible from the user
body or set the device to lower output power if such function is available.
Déclaration d’exposition aux radiations:
Le produit est conforme aux limites d’exposition pour les appareils portables RF pour les Etats-
Unis et le Canada établies pour un environnement non contrôlé.
Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel. La réduction aux
expositions RF peut être augmentée si l’appareil peut être conservé aussi loin que possible du
corps de l’utilisateur ou que le dispositif est réglé sur la puissance de sortie la plus faible siune
tellefonctionestdisponible.

10
Notebook PC UserGuide
E11439_E403SA_UM_V2_12pages.indd 10
2016/3/17 ��
02:57:34
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.

Notebook PCUserGuide
11
E11439_E403SA_UM_V2_12pages.indd 11
2016/3/17 ��
02:57:35
EU Declaration of Conformity
We, the undersigned,
Manufacturer:
ASUSTeK COMPUTER INC.
Address:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Authorized representative in Europe:
ASUS COMPUTER GmbH
Address, City:
HARKORT STR. 21-23, 40880 RATINGEN
Country:
GERMANY
declare the following apparatus:
Product name :
Notebook PC
Model name :
E403S, L403S, R416S
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
EMC –Directive 2004/108/EC (until April 19th, 2016) and Directive 2014/30/EU (from April 20th, 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55013:2001+A1:2003+A2:2006
R&TTE –Directive 1999/5/EC
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
LVD –Directive 2006/95/EC (until April 19th, 2016) and Directive 2014/35/EU (from April 20th, 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
Ecodesign –Directive2009/125/EC
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
EN 60065:2002 / A12: 2011
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS –Directive 2011/65/EU Ver. 160217
CE marking
Equipment Class 2
(EU conformity marking)
Signature
Jerry Shen
Printed Name
CEO
Position
Taipei, Taiwan
Place of issue
05/06/2015
Original Declaration Date
18/03/2016
Corrected Declaration Date
2016
Year to begin affixing CE marking
EN 300 328 V1.8.1(2012-06)
EN 301 489-1 V1.9.2(2011-09)
EN 300 440-1 V1.6.1(2010-08)
EN 301 489-3 V1.6.1(2013-12)
EN 300 440-2 V1.4.1(2010-08)
EN 301 489-4 V2.1.1(2013-12)
EN 301 511 V9.0.2(2003-03)
EN 301 489-7 V1.3.1(2005-11)
EN 301 908-1 V6.2.1(2013-04)
EN 301 489-9 V1.4.1(2007-11)
EN 301 908-2 V6.2.1(2013-10)
EN 301 489-17 V2.2.1(2012-09)
EN 301 908-13 V6.2.1(2014-02)
EN 301 489-24 V1.5.1(2010-09)
EN 301 893 V1.7.1(2012-06)
EN 301 357-2 V1.4.1(2008-11)
EN 300 330-2 V1.5.1(2010-02)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 302 623 V1.1.1(2009-01)
EN 62479:2010
EN 50566:2013/AC:2014
EN 62311:2008
EN 50385:2002

12
Notebook PC UserGuide
E11439_E403SA_UM_V2_12pages.indd 12
2016/3/17 ��
02:57:35
