Asus I220GC User manual

Motherboard
I220GC

ii
Copyright © 2008 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E3912
Second Edition
May 2008

iii
Contents
Notices......................................................................................................... vi
Safety information ..................................................................................... vii
About this guide ....................................................................................... viii
I220GC specications summary ................................................................ x
Chapter 1: Product introduction
1.1 Welcome! ...................................................................................... 1-2
1.2 Package contents......................................................................... 1-2
1.3 Special features............................................................................ 1-2
1.3.1 Product highlights ........................................................... 1-2
1.3.2 Innovative ASUS features ............................................... 1-3
1.4 Before you proceed ..................................................................... 1-4
1.5 Motherboard overview................................................................. 1-5
1.5.1 Placement direction ........................................................ 1-5
1.5.2 Screw holes .................................................................... 1-5
1.5.3 Motherboard layout ......................................................... 1-6
1.6 Central Processing Unit (CPU) ................................................... 1-7
1.7 System memory ........................................................................... 1-8
1.7.1 Overview ......................................................................... 1-8
1.7.2 Memory congurations.................................................... 1-9
1.7.3 DDR2 Qualied Vendors List .......................................... 1-9
1.7.4 Installing a DIMM .......................................................... 1-12
1.7.5 Removing a DIMM ........................................................ 1-12
1.8 Expansion slots.......................................................................... 1-13
1.8.1 Installing an expansion card ......................................... 1-13
1.8.2 Conguring an expansion card ..................................... 1-13
1.8.3 Interrupt assignments ................................................... 1-14
1.8.4 PCI slots........................................................................ 1-15
1.8.5 PCI Express x1 slot....................................................... 1-15
1.9 Jumpers ...................................................................................... 1-16
1.10 Connectors ................................................................................. 1-18
1.10.1 Rear panel connectors.................................................. 1-18
1.10.2 Internal connectors ....................................................... 1-19

iv
Contents
Chapter 2: BIOS setup
2.1 Managing and updating your BIOS ............................................ 2-2
2.1.1 Creating a bootable oppy disk....................................... 2-2
2.1.2 ASUS EZ Flash 2 utility................................................... 2-3
2.1.3 AFUDOS utility................................................................ 2-4
2.1.4 ASUS CrashFree BIOS 3 utility ...................................... 2-6
2.1.5 ASUS Update utility ........................................................ 2-9
2.2 BIOS setup program .................................................................. 2-12
2.2.1 BIOS menu screen........................................................ 2-13
2.2.2 Menu bar....................................................................... 2-13
2.2.3 Navigation keys............................................................. 2-13
2.2.4 Menu items ................................................................... 2-14
2.2.5 Sub-menu items............................................................ 2-14
2.2.6 Conguration elds ....................................................... 2-14
2.2.7 Pop-up window ............................................................. 2-14
2.2.8 Scroll bar....................................................................... 2-14
2.2.9 General help ................................................................. 2-14
2.3 Main menu .................................................................................. 2-15
2.3.1 System Time ................................................................. 2-15
2.3.2 System Date ................................................................. 2-15
2.3.3 Legacy Diskette A ......................................................... 2-15
2.3.4 Primary, Third and Fourth IDE Master/Slave ................ 2-16
2.3.5 IDE Conguration.......................................................... 2-17
2.3.6 System Information ....................................................... 2-18
2.4 Advanced menu ......................................................................... 2-19
2.4.1 JumperFree Conguration ........................................... 2-19
2.4.2 USB Conguration ........................................................ 2-21
2.4.3 CPU Conguration ........................................................ 2-22
2.4.4 Chipset.......................................................................... 2-23
2.4.5 Onboard Devices Conguration.................................... 2-25
2.4.6 PCI PnP ........................................................................ 2-26
2.5 Power menu................................................................................ 2-28
2.5.1 Suspend Mode.............................................................. 2-28
2.5.2 ACPI 2.0 Support .......................................................... 2-28
2.5.3 ACPI APIC support ....................................................... 2-28

v
Contents
2.5.4 APM Conguration........................................................ 2-29
2.5.5 Hardware Monitor ......................................................... 2-31
2.6 Boot menu .................................................................................. 2-32
2.6.1 Boot Device Priority ...................................................... 2-32
2.6.2 Boot Settings Conguration .......................................... 2-33
2.6.3 Security ......................................................................... 2-34
2.7 Tools menu ................................................................................. 2-36
ASUS EZ Flash 2......................................................................... 2-36
2.8 Exit menu.................................................................................... 2-37
Chapter 3: Software support
3.1 Installing an operating system ................................................... 3-2
3.2 Support CD information .............................................................. 3-2
3.2.1 Running the support CD ................................................. 3-2
3.2.2 Drivers menu................................................................... 3-3
3.2.3 Utilities menu .................................................................. 3-4
3.2.4 ASUS Contact information .............................................. 3-6

vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian
ICES-003.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.

vii
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. If possible, disconnect all power cables from the existing system
before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure
that all power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord.
These devices could interrupt the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using,
contact your local power company.
• If the power supply is broken, do not try to x it by yourself. Contact a
qualied service technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all
the manuals that came with the package.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in
any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied
service technician or your retailer.
This symbol of the crossed out wheeled bin indicates that the product (electrical,
electronic equipment, and Mercury -containing button cell battery) should not
be placed in municipal waste. Check local regulations for disposal of electronic
products.

viii
About this guide
This user guide contains the information you need when installing and conguring
the motherboard.
How this guide is organized
This manual contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new
technology it supports. This chapter also lists the hardware setup procedures
that you have to perform when installing system components. It includes
description of the jumpers and connectors on the motherboard.
• Chapter 2: BIOS setup
This chapter tells how to change system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.
• Chapter 3: Software support
This chapter describes the contents of the support CD that comes with the
motherboard package.
Where to nd more information
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and
software products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty
yers, that may have been added by your dealer. These documents are not
part of the standard package.

ix
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.
Typography
DANGER/WARNING: Information to prevent injury to yourself
when trying to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
NOTE: Tips and additional information to help you complete a
task.
IMPORTANT: Instructions that you MUST follow to complete a
task.
Bold text Indicates a menu or an item to select
Italics Used to emphasize a word or a phrase
<Key> Keys enclosed in the less-than and greater-than sign means
that you must press the enclosed key
Example: <Enter> means that you must press the Enter or
Return key
<Key1+Key2+Key3> If you must press two or more keys simultaneously, the
key names are linked with a plus sign (+)
Example: <Ctrl+Alt+D>
Command Means that you must type the command exactly as shown,
then supply the required item or value enclosed in
brackets
Example: At the DOS prompt, type the command line:
afudos /i[lename]
afudos /iI220GC.ROM

x
I220GC specications summary
(continued on the next page)
CPU Integrated (FC-BGA6) Intel®Celeron® Processors 200
Series
Intel®EM64T and Execute Disable Bit Technology
Chipset Northbridge: Intel®945GC
Southbridge: Intel®ICH7
Front Side Bus CPU supports 533 MHz; Chipset supports 800/533 MHz.
Memory Dual-channel memory architecture
2 x 240-pin DIMM sockets support up to 4GB of
unbufferred non-ECC 667/533 MHz DDR2 DIMMs
* Max. memory frequency is limited by the system FSB.
*When you install a total memory of 4GB or more,
Windows® 32-bit operation system may only recognize
less than 3GB. Hence, a maximum of 3GB system
memory is recommended if you are using a Windows
32-bit operation system.
VGA Integrated Intel® Graphics Media Accelerator 950
- Max. resolution: 2048 x 1536 @75Hz
- Max. UMA Memory size: 224MB
Expansion slots 1 x PCI Express x1 slot
2 x PCI 2.2 slots
Storage Intel®ICH7 SouthBridge supports:
- 1 x Ultra DMA 100/66
- 4 x Serial ATA 3Gb/s ports
Audio Realtek ALC662 High-Denition audio CODEC, 6-channel
audio port S/PDIF out interface
LAN Atheros L2 10/100
USB Supports up to 8 USB 2.0 ports (four ports at mid-board,
four ports at back panel)
Rear panel 1 x Parallel port
1 x Serial port
1 x LAN (RJ-45) port
4 x USB 2.0 ports
1 x VGA port
1 x PS/2 keyboard port
1 x PS/2 mouse port
6-channel high-denition audio I/O port
BIOS features 8 Mb Flash ROM, AMI BIOS, PnP, ACPI2.0a, WfM2.0,
DMI2.0, SM BIOS 2.4
Special features ASUS EZ Flash2
ASUS CrashFree BIOS 3
ASUS MyLogo2™
Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME

xi
I220GC specications summary
*Specications are subject to change without notice.
Internal connectors 2 x USB 2.0 connectors for 4 additional USB 2.0 ports
1 x Floppy disk drive connector
1 x IDE connector
4 x Serial ATA connectors
1 x CPU fan connector
1 x Chassis fan connector
1 x 24-pin ATX power connector
1 x 4-pin ATX 12 V power connector
1 x CD audio in connector
1 x Chassis intrusion connector
1 x 4-pin Speaker connector
1 x Front panel high-denition audio connector
1 x S/PDIF out connector
1 x System Panel connector
Power Requirement ATX power supply (with 24-pin and 4-pin 12 V plugs)
Support CD contents Device drivers
ASUS PC Probe II
ASUS Live Update utility
Anti-virus software (OEM version)
Form Factor uATX form factor: 9.6 in x 7.4 in (24.4cm x 18.8cm)

xii

1
Product
introduction
This chapter describes the motherboard
features and the new technologies
it supports.

1-2 Chapter 1: Product introduction
1.1 Welcome!
Thank you for buying an ASUS®I220GC motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.
Motherboard ASUS I220GC motherboard
Cables 1 x Serial ATA cable
1 x Serial ATA power cable
1 x Ultra DMA 100/66 cable
1 x Floppy disk drive cable
Accessories I/O shield
Application CDs ASUS motherboard support CD
Documentation User guide
If any of the above items is damaged or missing, contact your retailer.
1.3 Special features
1.3.1 Product highlights
64-bit CPU support
The motherboard supports 64-bit processors that provides high-performance
computing and faster memory access required for memory and data intensive
applications.
DDR2 memory support
The motherboard supports DDR2 memory which features data transfer rates of
667/533 MHz to meet the higher bandwidth requirements of the latest 3D graphics,
multimedia, and Internet applications. The dual-channel DDR2 architecture
doubles the bandwidth of your system memory to boost system performance,
eliminating bottlenecks with peak bandwidths of up to 10.7 GB/s. See pages 1-9 to
1-12 for details.

ASUS I220GC 1-3
Serial ATA 3.0 Gb/s technology
The motherboard supports the Serial ATA technology through the Serial ATA
interfaces and the Intel® ICH7 chipset. The SATA specication allows for thinner,
more exible cables with lower pin count, reduced voltage requirement, and up to
300 MB/s data transfer rate.
High Denition Audio
Enjoy high-end sound quality on your PC! The onboard HD audio (High Denition
Audio, previously codenamed Azalia) CODEC enables high-quality 192KHz/24-bit
audio output, and multi-streaming technology that simultaneously sends different
audio streams to different destinations. You can now talk to your partners on the
headphone while playing multi-channel network games.
1.3.2 Innovative ASUS features
ASUS CrashFree BIOS 3
The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a
USB ash disk containing the BIOS le. See page 2-6 for details.
ASUS EZ Flash 2
EZ Flash 2 is a user-friendly BIOS update utility. Simply press the predened
hotkey to launch the utility and update the BIOS without entering the OS. Update
your BIOS easily without preparing a bootable diskette or using an OS-based ash
utility. See page 2-3 for details.
ASUS MyLogo2™
This feature allows you to convert your favorite photo into a 256-color boot logo for
a more colorful and vivid image on your screen. See page 2-33 for details.

1-4 Chapter 1: Product introduction
• Unplug the power cord from the wall socket before touching any
component.
• Use a grounded wrist strap or touch a safely grounded object or to a metal
object, such as the power supply case, before handling components to
avoid damaging them due to static electricity
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic
pad or in the bag that came with the component.
• Before you install or remove any component, ensure that the ATX power
supply is switched off or the power cord is detached from the power
supply. Failure to do so may cause severe damage to the motherboard,
peripherals, and/or components.
Onboard LED
The motherboard comes with a standby power LED that lights up to indicate that
the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you
should shut down the system and unplug the power cable before removing or
plugging in any motherboard component. The illustration below shows the location
of the onboard LED.
1.4 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
I220GC
R
I220GC Onboard LED
SB_PWR
ON
Standby
Power
OFF
Powered
Off

ASUS I220GC 1-5
I220GC
R
1.5 Motherboard overview
Before you install the motherboard, study the conguration of your chassis to
ensure that the motherboard ts into it.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so can cause you physical injury and damage
motherboard components.
Do not overtighten the screws! Doing so can damage the motherboard.
1.5.1 Placement direction
When installing the motherboard, make sure that you place it into the chassis in
the correct orientation. The edge with external ports goes to the rear part of the
chassis as indicated in the image below.
1.5.2 Screw holes
Place six (6) screws into the holes indicated by circles to secure the motherboard
to the chassis.
Place this side towards
the rear of the chassis

1-6 Chapter 1: Product introduction
1.5.3 Motherboard layout
Intel ICH7
Intel
MCH 945GC
18.8cm(7.4in)
24.4cm(9.6in)
DDR2 DIMM_A1(64 bit,240-pin module) DDR2 DIMM_B1(64 bit,240-pin module)
PCI1
PCI2
PCIEX1_1 CR2032 3V
Lithium Cell
CMOS Power
EATXPWR
ATX12V
PRI_IDE
CPU_FAN
CHA_FAN
8Mb
BIOS
F_PANEL
SPEAKER
SATA1 SATA2
SATA4SATA3
USB56 USB78
FLOPPY
AAFP
ALC662
Super I/O
CD
SPDIF_OUT
PS2_USBPWR1-8
RTM876-660
CLRTC CHASSIS
PS/2KBMS
T: Mouse
B: Keyboard
LAN_USB12
COM1
PARALLEL PORT
VGA1
USB34
AUDIO
SB_PWR
I220GC
R
Celeron 200 Series
Atheros
L2

ASUS I220GC 1-7
1.6 Central Processing Unit (CPU)
The motherboard comes with an onboard Intel®Celeron® 200 Series processor
and a specially designed CPU heatsink and fan.
• Ensure that the CPU fan cable is connected to the onboard CPU_Fan
connector.
• Use only ASUS qualied CPU on this motherboard to get the maximum
performance.
I220GC
R
I220GC CPU Socket Celeron 220 Series
Celeron 220 Series processor
I220GC
R
I220GC CPU Fan Connector
CPU_FAN
GND
+12V
CPU FAN IN

1-8 Chapter 1: Product introduction
1.7 System memory
1.7.1 Overview
The motherboard comes with two Double Data Rate 2 (DDR2) Dual Inline Memory
Modules (DIMM) sockets.
A DDR2 module has the same physical dimensions as a DDR DIMM but has a
240-pin footprint compared to the 184-pin DDR DIMM. DDR2 DIMMs are notched
differently to prevent installation on a DDR DIMM socket.
The gure illustrates the location of the DDR2 DIMM sockets:
I220GC
R
I220GC 240-pin DDR2 DIMM Sockets
128 Pins 112 Pins
DIMMB1
DIMMA1
Channel Sockets
Channel A DIMM_A1
Channel B DIMM_B1
