Asus INTEL TUSL2-M User manual

®
TUSL2-M
Intel®815E Chipset
microATX Motherboard
USER’S MANUAL

2ASUS TUSL2-M User’s Manual
USER'S NOTICE
Product Name: ASUS TUSL2-M
Manual Revision: 1.04 E905
Release Date:
No part of this manual, including the products and software described herein, may be repro-
duced, transmitted, transcribed, stored in a retrieval system, or translated into any language in
anyformorbyanymeans,exceptfordocumentationkeptbythepurchaserforbackuppurposes,
without the expressed written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE
IMPLIEDWARRANTIESORCONDITIONSOFMERCHANTABILITYORFITNESSFOR
APARTICULAR PURPOSE. INNO EVENTSHALLASUS,ITS DIRECTORS,OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF
PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-
NESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification or alteration is authorized in writing byASUS; or (2)
the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trade-
marks or copyrights of their respective companies, and are used only for identification or
explanation, for the owners’ benefit, without intent to infringe.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.
• Trend and ChipAwayVirus are trademarks of Trend Micro, Inc.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• ADI and SoundMAX are trademarks of Analog Devices, Inc..
The product name and revision number are both printed on the product itself. Manual revi-
sions are released for each product design represented by the digit before and after the period
of the manual revision number. Manual updates are represented by the third digit in the manual
revision number.
For more information on manuals, BIOS, drivers, or recent product releases, contactASUS at
http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FUR-
NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT
ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-
MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR
ANYERRORSOR INACCURACIESTHATMAYAPPEARINTHIS MANUAL, INCLUD-
ING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright © 2001 ASUSTeK COMPUTER INC. All Rights Reserved.
December 2001

ASUS TUSL2-M User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: +886-2-2894-3447
Fax: +886-2-2894-3449
Email: [email protected]
Technical Support
MB/Others (Tel): +886-2-2890-7121 (English)
Notebook (Tel): +886-2-2890-7122 (English)
Desktop/Server (Tel):+886-2-2890-7123 (English)
Fax: +886-2-2890-7698
Newsgroup: cscnews.asus.com.tw
Email: [email protected]
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: +1-510-608-4555
Email: [email protected]
Technical Support
Fax: +1-510-608-4555
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com/Pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: +49-2102-442066
Technical Support
Hotline: MB/Others: +49-2102-9599-0 Notebook: +49-2102-9599-10
Fax: +49-2102-9599-11
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

4ASUS TUSL2-M User’s Manual
CONTENTS
1. INTRODUCTION ............................................................................. 7
1.1 How This Manual Is Organized .................................................. 7
1.2 Item Checklist ............................................................................. 7
2. FEATURES ........................................................................................ 8
2.1 The ASUS TUSL2-M ................................................................. 8
2.2 TUSL2-M Motherboard Components ...................................... 12
3. HARDWARE SETUP ...................................................................... 14
3.1 TUSL2-M Motherboard Layout ............................................... 14
3.2 Layout Contents ........................................................................ 15
3.3 Hardware Setup Procedure ....................................................... 17
3.4 Motherboard Settings................................................................ 17
3.5 System Memory (DIMM) ......................................................... 24
3.5.1 General DIMM Notes .................................................... 24
3.5.2 Memory Installation ...................................................... 25
3.6 Central Processing Unit (CPU) ................................................. 26
3.7 Expansion Cards ....................................................................... 27
3.7.1 Expansion Card Installation Procedure ......................... 27
3.7.2 Assigning IRQs for Expansion Cards............................ 27
3.7.3 Communication and Networking Riser (CNR) Slot...... 28
3.7.4 Accelerated Graphics Port (AGP) Slot .......................... 29
3.8 Connectors ................................................................................. 30
3.8.1 External Connectors ...................................................... 30
3.8.2 Internal Connectors ......................................................... 34
3.9 Starting Up the First Time ........................................................ 43
4. BIOS SETUP..................................................................................... 45
4.1 Managing and Updating Your BIOS ......................................... 45
4.1.1 Upon First Use of the Computer System....................... 45
4.1.2 Updating BIOS Procedures ........................................... 47
4.2 BIOS Setup Program ................................................................ 49
4.2.1 BIOS Menu Bar ............................................................. 50
4.2.2 Legend Bar .................................................................... 50

ASUS TUSL2-M User’s Manual 5
CONTENTS
4.3 Main Menu................................................................................ 52
4.3.1 Primary & Secondary Master/Slave .............................. 53
4.3.2 Keyboard Features ......................................................... 56
4.4 Advanced Menu ........................................................................ 58
4.4.1 Chip Configuration ........................................................ 61
4.4.2 I/O Device Configuration .............................................. 64
4.4.3 PCI Configuration ......................................................... 66
4.4.4 Shadow Configuration ................................................... 68
4.5 Power Menu .............................................................................. 69
4.5.1 Power Up Control.......................................................... 71
4.5.2 Hardware Monitor ......................................................... 73
4.6 Boot Menu ................................................................................ 74
4.7 Exit Menu ................................................................................. 76
5. SOFTWARE SETUP....................................................................... 79
5.1 Operating Systems .................................................................... 79
5.1.1 Windows 98 First Time Installation .............................. 79
5.2 TUSL2-M Motherboard Support CD ....................................... 79
5.2.1 Installation Menus ......................................................... 79
5.2.2 Applications................................................................... 80
6. SOFTWARE REFERENCE ........................................................... 83
6.1 ASUS PC Probe ........................................................................ 83
6.1.1 Starting ASUS PC Probe ............................................... 83
6.1.2 Using ASUS PC Probe .................................................. 84
6.1.3 ASUS PC Probe Task Bar Icon ..................................... 87
6.2 Winbond Smart Manager ........................................................... 89
6.3 CyberLink PowerPlayer SE ...................................................... 93
6.4 CyberLink VideoLive Mail ....................................................... 94
6.5 ASUS LiveUpdate .................................................................... 96
7. APPENDIX........................................................................................ 97
7.1 Glossary .................................................................................... 97
INDEX ................................................................................................. 101

6ASUS TUSL2-M User’s Manual
FCC & DOC COMPLIANCE
FederalCommunicationsCommissionStatement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with manufacturer's instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! Any changes or modifications to this product not expressly ap-
proved by the manufacturer would void any assurances on its safety or
performance and could result in violation of Part 15 of the FCC Rules.
Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the
Federal Register, National Archives and Records Administration, U.S. Government Printing Office.
CanadianDepartmentofCommunicationsStatement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.

ASUS TUSL2-M User’s Manual 7
1.1 How This Manual Is Organized
This manual is divided into the following sections:
1. INTRODUCTION Manual information and checklist
2. FEATURES Production information and specifications
3. HARDWARE SETUP Instructions on setting up the motherboard.
4. BIOS SETUP Instructions on setting up the BIOS
5. SOFTWARE SETUP Instructions on setting up the included software
6. SOFTWARE REFERENCE Reference material for the included software
7. APPENDIX Optional items and general reference
1.2 Item Checklist
Check that your package is complete. If you discover damaged or missing items,
contact your retailer.
1. INTRODUCTION
1. INTRODUCTION
Manual / Checklist
Optional Items
AIMM card
LCD controller module
TVOUT controller module
ASUS iPanel
ASUSIrDA-compliantinfraredmodule
Smart Card Reader
Package Contents
(1) ASUS Motherboard
(1) 40-pin 80-conductor ribbon cable
for internal UltraDMA100/66/33
IDE drives
(1) Ribbon cable for (1) 5.25”and (2)
3.5”floppy disk drives
(1) Serial COM2 connector with
bracket
(1) Bag of spare jumpers
(1) Support drivers and utilities
(1) User’s Manual
(1) ASUS 2-port USB connector set
with bracket

8ASUS TUSL2-M User’s Manual
2.1 The ASUS TUSL2-M
TheASUS TUSL2-M motherboard is carefully designed for the demanding PC user
who wants advanced features processed by the fastest processors.
2.1.1 Specifications
•Latest Intel Processor Support
PIII
®
Tualatin™133/100MHz FSB FC-PGA2
PIII
®
Coppermine™133/100MHz FSB FC-PGA
Celeron™100/66MHz FSB FC-PGA
•NorthBridgeSystemChipset: The Intel
®
82815E Graphics Memory Controller
Hub (GMCH) chipset supports 66/100/133 Front Side Bus (FSB), up to 512MB
of PC100/PC133 SDRAM, and AGP 4X interface which delivers twice the
amount of data than the current AGP standard.
•SouthBridgeSystemChipset: The Intel
®
82801BAI/O Controller Hub (ICH2)
delivers twice the I/O bandwidth, and supports UltraDMA/100, allowing burst
mode data transfer rates of up to 100MB/sec. Two USB controllers provides
four USB ports.
•Intel
®
Accelerated Hub Architecture: Features a dedicated high speed hub
link between the ICH2 and GMCH with a bandwidth of 266MB/sec –twice the
maximum bandwidth of the PCI bus.
•PC100/PC133 Memory Support: Equipped with three Dual Inline Memory
Module (DIMM) sockets which support PC133/PC100 non-ECC SDRAMs
(available in 64, 128, 256, 512Mb densities) up to 512MB.
•UltraDMA33/66/100 Support: Comes with an onboard PCI Bus Master IDE
controller with two connectors that support four IDE devices on two channels.
Supports UltraDMA/100, UltraDMA/66, UltraDMA/33, PIO Modes 3 & 4 and
up to four ATAPI devices like DVD-ROM, CD-ROM, CD-R/RW, LS-120, and
tape backup drives.
•ASUS JumperFree™Mode:Allows processor settings and easy overclocking
of frequency and Vcore voltage all through BIOS setup when JumperFree™
mode is enabled. Easy-to-use DIP switches instead of jumpers are included to
allow manual adjustment of the processor external frequency.
•Wake-Up Support: Supports Wake-On-LAN and Wake-On-Ring, Keyboard
Wake-Up, and BIOS Wake-Up.
•Around-the-Clock Intrusion Detection: Chassis intrusion circuitry can log
chassis open events into LDCM. The onboard battery supports detection even
when normal power is removed and through a new design, battery drain is even
lower than the RTC used for keeping time!
•PC Health Monitoring: Provides an easy way to examine and manage system
status information, such as CPU and system voltages, temperatures, and fan
status through the onboard hardware ASUS ASIC and the bundled ASUS PC
Probe or Intel LDCM software.
2. FEATURES
Specifications
2. FEATURES

ASUS TUSL2-M User’s Manual 9
2. FEATURES
2. FEATURES
Specifications
•CNR Support: A Communication and Networking Riser (CNR) slot provides
an interface to support very affordable multichannel audio,V.90 analog modem,
HomePNA,10/100 Ethernet networking, USB hub, as well as future technologies
such as xDSL.
•PCI Expansion Slots: Provides three 32-bit PCI (PCI 2.2 compliant) expansion
slots. All PCI slots can support Bus Master PCI cards, such as SCSI or LAN
cards. (PCI supports up to 133MB/s maximum throughput.)
•Super Multi-I/O: Provides two high-speed UART compatible serial ports and
one parallel port with EPP and ECP capabilities. UART2 can also be directed
from COM2 to the Infrared Module for wireless connections. The Super I/O
controller also supports a floppy disk dirve, PS/2 keyboard, and PS/2 mouse.
•Smart BIOS: 2Mbit firmware gives a new easy-to-use interface which provides
more control and protection over the motherboard. Provides Vcore and CPU/
SDRAM frequency adjustments, boot block write protection, and HD/SCSI/MO/
ZIP/CD/Floppybootselection. Hardware random number generator supports new
security software for data protection and secured Internet transactions.
•Enhanced ACPI & Anti-Boot Virus Protection: Programmable BIOS (Flash
EEPROM), offering enhanced ACPI for Windows 98 compatibility, built-in
firmware-based virus protection, and autodetection of most devices for virtually
automatic setup.
•Onboard LED: The onboard LED lights up when there is standby power to the
motherboard. This acts as a reminder to the user to turn OFF the power before
plugging and unplugging devices so as not to damage the motherboard,
peripherals, and/or components.
•Onboard Audio: Audio models come with the AC ’97-compliant interfaces
that support integrated audio and modem features that comprise digital audio
engine with 3D-hardware accelerator, on-chip sample rate converter, and a
professional wavetable.
•Easy Connectivity and System Information Access: Supports an optional
ASUS iPanel, an easy-to-access box with system diagnostic display area, system
status LEDs, USB ports, and hot keys. The AFPANEL connector on the
motherboard accommodates the ASUS iPanel.
•Smartcard Reader Connector: Features a connector that provides the
convenience of financial, telephony, and traveling services through the optional
Smartcard Reader interface.
•LCD/TV Output: The LCD/TV interface can support either an optional LCD
module for LCD output or a TV-out module for TV output.
•SMBus: Features the System Management Bus interface that physically
transports commands and information between SMBus devices.

10 ASUS TUSL2-M User’s Manual
2. FEATURES
Performance
2. FEATURES
2.1.2 Specifications–Optional Components
The following onboard components are optional at the time of purchase:
•Smart Networking: Features 3Com’s 3C920 Fast Ethernet controller, which
supports Wired for Management, remote wake-up, and OnNow initiatives to
reduce Total Cost of Ownership (TCO).
•OnboardAudio: AC’97Audio chipset supports the latest audio sound circuitry.
A software package helps setup the multi-channel PC sound system.
2.1.3 Performance
•UltraPerformance:Onboard IDE Bus Mastercontrollerwithtwo connectors that
support four IDE devices in two channels. Supports UltraDMA/100, UltraDMA/
66,UltraDMA/33 (IDE DMA Mode 2), PIO Modes 3 & 4,andsupportsEnhanced
IDEdevices,suchasDVD-ROM,CD-ROM,CD-R/RW,LS-120, andTapeBackup
drives.
• High-Speed Data Transfer Interface: IDE transfers using UltraDMA/66 Bus
Master IDE can handle rates up to 66.6MB/s. This motherboard with its chipset
and support for UltraDMA/100 increases the data transfer rate to 100MB/s.
UltraDMA/100 is backward compatible with DMA/66, DMA/33, and DMA and
with existing DMA devices and systems so there is no need to upgrade current
EIDE/IDE drives and host systems. (UltraDMA/66/100 requires a 40-pin 80-
conductor cable to be enabled.)
•ConcurrentPCI:Concurrent PCI allows multiple PCI transfers from PCI master
buses to memory and processor.
• SDRAM Optimized Performance: This motherboard supports PC133-
compliant Synchronous Dynamic Random Access Memory (SDRAM), which
increases the data transfer rate to 1066MB/s max.
• ACPI Ready: Advanced Configuration and Power Interface (ACPI) is also
implementedon allASUS smart series motherboards.ACPI providesmoreEnergy
Saving Features for future operating systems (OS) supporting OS Direct Power
Management (OSPM) functionality. With these features implemented in the OS,
PCs can be ready around the clock, yet satisfy all the energy saving standards.
To fully utilize the benefits of ACPI, anACPI-supported OS, such as Windows
98, must be used.
• Suspend and Go: Suspend-to-RAM (STR) provides maximum power savings
as an alternative to leaving the computer ON and QuickStart™ so that you do
not have to wait for a long time for system bootup.
• Stepless Frequency Selection: Allows CPU external (FSB) frequency settings
to be raised or lowered in MHz increments.

ASUS TUSL2-M User’s Manual 11
2. FEATURES
2. FEATURES
Intelligence
•PC’99 Compliant: Both the BIOS and hardware levels of ASUS smart series
motherboards are PC’99 compliant. The new PC’99 requirements for systems
and components are based on the following high-level goals: support for Plug-
n-Playcapability and power managementforconfiguring and managing allsystem
components, and 32-bit device drivers and installation procedures for
Windows95/98/NT . Color-coded connectors and descriptive icons make
identification easy as required by PC’99.
2.1.4 Intelligence
•Fan Status Monitoring and Alarm: To prevent system overheat and system
damage, the CPU, power supply, and system fans can be monitored for RPM
and failure. All the fans are set for its normal RPM range and alarm thresholds.
•Voltage Monitoring andAlert: System voltage levels are monitored to ensure
stable current to critical motherboard components. Voltage specifications are
more critical for future processors, so monitoring is necessary to ensure proper
system configuration and management.
•System Resources Alert: Windows 98, Windows NT, and OS/2, require much
more memory and hard disk space to present enormous user interfaces and run
large applications.The onboard hardwareASUSASIC in conjunction with either
the bundled ASUS PC Probe or Intel LDCM, will warn you before the system
resources are used up to prevent possible application crashes.
•Dual Function Power Button: Through BIOS, the power button can be defined
as the “Stand by”(a.k.a. Suspend or Sleep) button or as the Soft-Off button (see
ATX Power / Soft-Off Switch Lead in 3.8 Connectors for more information).
Regardlessof the setting, pushingthepower button for morethan4seconds allows
the computer to enter the Soft-Off mode.
•Remote Ring On (requires modem): This allows a computer to be turned on
remotely through an internal or external modem. With this benefit on hand, you
can access any information from their computers from anywhere in the world.
•Message LED (requires ACPI OS support): Message LEDs now act as
information providers. Through the way a particular LED illuminates, you can
determine if a message has been received from a fax/modem.A simple glimpse
provides useful information.This function requiresACPI OS and driver support.
•PeripheralPowerUp:Keyboard or Mouse power up can be enabled or disabled
throughBIOS setup to allow the computer to be powered ON using your keyboard
or mouse click.

12 ASUS TUSL2-M User’s Manual
2. FEATURES
2. FEATURES
MB Components
2.2 TUSL2-M Motherboard Components
See opposite page for locations. Location
Processor Support Socket 370 for Pentium III/Celeron/Tualatin CPUs.. ............... 2
Feature Setting DIP Switches ................................................... 8
Chipsets Intel 82815E Graphics Memory Controller Hub (GMCH) ...... 3
Intel 82801BA I/O Controller Hub (ICH2) .......................... 13
2Mbit Firmware Hub (FWH) ................................................. 11
Low Pin Count (LPC) Multi-I/O Chipset ............................... 21
Main Memory 3 DIMM Sockets (maximum 512MB support) ........................ 4
PC133 SDRAM support
Expansion Slots 3 PCI Slots .............................................................................. 19
1 Accelerated Graphics Port (AGP) Slot ................................ 20
1 Communications & Network Riser (CNR) Slot .................. 15
System I/O 1 USB Header......................................................................... 10
1 Floppy Disk Drive Connector ............................................... 5
2 IDE Connectors (UltraDMA/100 Support) ........................... 6
1 Serial COM2 Header ........................................................... 23
1 ASUS iPanel Connector ........................................................ 9
1 Parallel Port Connector ............................................. (Top) 26
1 Serial COM1 Port Connector .............................. (Bottom) 27
2 USB Port Connectors .......................................... (Bottom) 28
1 PS/2 Mouse Connector .............................................. (Top) 29
1 PS/2 Keyboard Connector ................................... (Bottom) 29
3D Graphics Graphics and Memory Controller Hub
1 VGAMonitor Output Connector ......................... (Bottom) 25
TV-Out/Digital LCD Module Headers ................................... 24
Audio AC’97 Audio Codec............................................................. 18
1 Game/MIDI Connector.............................................. (Top) 22
1 Line Out Connector ............................................. (Bottom) 22
1 Line In Connector................................................ (Bottom) 22
1 Microphone Connector ........................................ (Bottom) 22
Network Features 3Com 3C920 Fast Ethernet Controller ................................... 16
Wake-On-LAN Connector...................................................... 17
Wake-On-Ring Connector ...................................................... 12
RJ-45 Connector ...................................................... (Top) 28
Hardware Monitoring System Voltage Monitoring (integrated in ASUS ASIC) ....... 14
3 Fan Power and Speed Monitoring Connectors
Power ATX Power Supply Connector ................................................. 1
Onboard LED ........................................................................... 7
Form Factor micro ATX

ASUS TUSL2-M User’s Manual 13
2. FEATURES
2. FEATURES
Component Location
2.2.1 Component Locations
2345
19
21
86
17
15
14 91213 11
16
22
25
26
27
28
29
24
20
1
23
7
10
18

14 ASUS TUSL2-M User’s Manual
3. HARDWARE SETUP
3.1 TUSL2-M Motherboard Layout
Motherboard Layout
3. H/W SETUP
NOTE: TheAC’97 audio codec, external GAME/AUDIO connectors, and
internal audio connectors are optional components, and present in audio
models only. The components are grayed in the above motherboard layout.
ACHA
PWR_FAN
PANEL IDELED
FLOPPY
SECONDARYIDE
PRIMARYIDE
TUSL2-M
CHA_FAN
CD
AUX
®
LED
Accelerated Graphics Port (AGP)
CR2032 3V
Lithium Cell
CMOS Power
CLRTC
DSW
Socket 370
CNR_SLOT
ATX Power Connector
CPU_FAN
MODEM
WOL_CON
WOR
CNRUSB2
CNRUSB1
AAPANEL
MIC2
HEADPHONE
JEN
COM2
AFPANEL
DIP
Switches
ASUS ASIC
with
Hardware
Monitor
LCDTV
Intel I/O
Controller
Hub
(ICH2)
Intel 815E
Graphics &
Memory
Controller
Hub (GMCH)
SMB
2Mbit
Firmware
Hub
(FWH)
USB2
LAN_EN
USBPWR2
SMARTCARD
USBPWR1
KBPWR
Super
I/O
3Com
3C920
Fast
Ethernet
DIMM1 (64/72 bit, 168-pin module)
1
0
DIMM2 (64/72 bit, 168-pin module)
3
2
DIMM3 (64/72 bit, 168-pin module)
5
4
PCI3
PCI2
PCI1
11
1
COM1
PARALLEL PORT
VGA
GAME_AUDIO
Mic
In
Line
Out
Line
In
PS/2KBMS
T: Mouse
B: Keyboard
AUD_EN
Audio
Codec
JTPWR
USB
T: USB1
B: USB2
Top:
RJ-45

ASUS TUSL2-M User’s Manual 15
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) JEN p. 18 JumperFree™Mode (Enable/Disable)
2) USBPWR1 p. 19 USB Device Wake Up (Enable/Disable)
USBPWR2
3) USBCNR1/USBCNR2 p. 19 USB/CNR Selection (USB2 Connect/CNR)
4) AUD_EN1 p. 20 Onboard Audio CODEC Setting (Enable/Disable)
5) LAN_EN p. 20 Onboard LAN Setting (Enable/Disable)
6) KBPWR p. 21 Keyboard Power Up (Enable/Disable)
7) DSW p. 22 CPU External Frequency Setting
Expansion Slots
1) DIMM1/2/3 p. 24 168-Pin System Memory Support
2) CPU p. 26 Central Processing Unit (CPU)6
3) PCI1/2/3 p. 27 32-bit PCI Bus Expansion Slots
4) CNR1 p. 28 Communication and Network Riser Slot
5) AGP p. 29 Accelerated Graphics Port (AGP) Slot
External Connectors
1) PS2KBMS p. 30 PS/2 Mouse Connector (6-pin female)
2) PS2KBMS p. 30 PS/2 Keyboard Connector (6-pin female)
3) USB p. 31 Universal Serial Bus Ports (Two 4-pin female)
4) PRINTER p. 31 Parallel Port Connector (25-pin female)
5) COM1/COM2 p. 32 Serial Port Connectors (9-pin male, 10-1 pin)
6) VGA p. 32 Monitor Output Connector (15-pin female)
7) GAME_AUDIO p. 33 Game/MIDI Connector (15-pin female) (optional)
8) LINE-IN, LINE-OUT, MIC p. 33 Audio Port Connectors (Three 1/8”female) (optional)
9) RJ-45 p. 33 Fast Ethernet Port Connector (optional)
Internal Connectors
1) FLOPPY p. 34 Floppy Disk Drive Connector (34-1pins)
2) PRIMARY/SECONDARYIDE p. 35 Primary/Secondary IDE Connectors (Two 40-1pins)
3) IDELED p. 35 IDE Activity LED (2 pins)
4) CPU_FAN, PWR_FAN p. 35 CPU,Power Supply,ChassisFanConnectors(Three3-pin)
CHA_FAN
5) CD1, AUX, MODEM p. 36 InternalAudio Connectors (optional)
6) HEADPHONE p. 36 Headphone True-Level Line Out Header (3 pins)
7) MIC2 p. 37 Internal Microphone Connector (3 pins)
8) AFPANEL p. 37 ASUS iPanel Connector (24-1 pins)
9) AAPANEL p. 37 ASUS iPanel Audio Connector (10-1 pins)
10) SMB p. 38 SMBus Connector (6-1 pins)
Layout Contents
3. H/W SETUP

16 ASUS TUSL2-M User’s Manual
3. HARDWARE SETUP
Layout Contents
3. H/W SETUP
11) ACHA p. 38 Chassis Intrusion Connector (2 pins)
12) WOL_CON p. 39 Wake-On-LAN Connector (3 pins)
13) WOR p. 39 Wake-On-Ring Connector (2 pins)
14) LCDTV p. 40 LCD-TV Headers (18-1 pins/18 pins)
15) USB2 p. 40 USB Headers (5-1 pins)
16) ATXPWR p. 41 ATX Power Supply Connector (20 pins)
17) PWRLED (PANEL) p. 42 System Power LED Lead (3-1 pins)
18) KEYLOCK (PANEL) p. 42 Keyboard Lock Switch Lead (2 pins)
19) SPEAKER (PANEL) p. 42 System Warning Speaker Connector (4 pins)
20) MSG.LED (PANEL) p. 42 System Message LED (2 pins)
21) SMI (PANEL) p. 42 System Management Interrupt Switch Lead (2 pins)
22) PWRSW (PANEL) p. 42 ATX Power / Soft-Off Switch Lead (2 pins)
23) RESET (PANEL) p. 42 Reset Switch Lead (2 pins)

ASUS TUSL2-M User’s Manual 17
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
3.3 Hardware Setup Procedure
Before using your computer, you must complete the following steps:
•Check Motherboard Settings
•Install Memory Modules
•Install the Central Processing Unit (CPU)
•Install Expansion Cards
•Connect Ribbon Cables, Panel Wires, and Power Supply
3.4 Motherboard Settings
WARNING! Computer motherboards and expansion cards contain very delicate
IntegratedCircuit (IC)chips.To protect themagainstdamage fromstaticelectricity,
you should follow some precautions whenever you work on your computer.
1. Unplug your computer when working on the internal components.
2. Use a grounded wrist strap or touch a safely grounded object or to a metal
object, such as the power supply case, before handling computer components.
3. Hold components by the edges and try not to touch the IC chips on them.
4. Whenever you install any component, place the components on a grounded
antistatic pad or in the bag that came with the components.
5. Before you install orremove any component, ensure that theATX power
supply is switched off or the power cord is detached from the power
supply. Failure to do so may cause severe damage to the motherboard,
peripherals, and/or components.
TUSL2-M
®
TUSL2-M Onboard LED
ON OFF
Standby
Power Powered
Off
LED

18 ASUS TUSL2-M User’s Manual
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
Motherboard Feature Settings
The motherboard’s onboard functions are either adjusted through jumpers or DIP
switches. When using DIPswitches, the white block represents the switch’s position.
The example below shows all the switches in the OFF position.
1) JumperFree™Mode (JEN)
This jumper allows you to enable or disable the JumperFree™mode. The
JumperFree™mode allows processor settings to be made through the BIOS
setup (see 4.4 Advanced Menu).
NOTE: In JumperFree™mode, all dip switches must be set to OFF.
Setting JEN
Disable (Jumper) [1-2]
Enable (JumperFree) [2-3] (default)
TUSL2-M
®
1. Frequency Selection
2. Frequency Selection
3. Frequency Selection
4. Frequency Selection
5. Frequency Selection.
TUSL2-M DIP Switches
DSW
ON OFF
ON
12345
TUSL2-M
®
TUSL2-M JumperFree™ Mode Setting JEN
DSW
ON
12345
OFF
Disable
12 Enable
(default)
23

ASUS TUSL2-M User’s Manual 19
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
2) USB Device Wake Up (USBPWR1,USBPWR2)
These allow you to disable or enable the USB device wake up function. Set these
jumpers to Enable if you wish to use your USB devices to wake up your computer.
ThisfeaturerequiresanATXpowersupplythatcansupply atleast 2Aonthe +5VSB
lead. The default is set to Disable because not all computers have the appropriate
ATX power supply. Your computer will not power ON if you set this to Enable and
do not have the appropriateATX power supply. NOTE: This jumper must be set in
conjunction with Wake On USB for STR State in 4.5.1 Power Up Control.
NOTES
1. For suspend to RAM function, these jumpers must be set to Enable.
2. The total current consumed must NOT exceed the power supply capability
(+5VSB) whether under normal working conditions or in the sleep mode.
3) CNR/USB Selection (CNRUSB1/CNRUSB2)
The CNR slot can support an optional USB hub CNR card. If a USB hub CNR
card is used, set these jumpers to CNR. Otherwise, leave them on the default
setting of USB2 Connect.
TUSL2-M
®
TUSL2-M USB Device Wake Up
USBPWR2
USBPWR1
Disable
(Default) Enable
1223
Disable
(Default) Enable
1223
TUSL2-M
®
TUSL2-M USB/CNR Selection
CNRUSB1
CNRUSB2 12 23
CNRUSB2 Connect
(default)

20 ASUS TUSL2-M User’s Manual
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
4) Onboard Audio CODEC Setting (AUD_EN1)
(available on audio model only)
Theonboard audio CODEC maybeenabledor disabled using allofthese jumpers.
Disable the onboard audio CODEC if you are using an ISA or PCI audio card on
any of the expansion slots or a primary audio/modem CNR on a CNR slot (see
CNR Slot later in this section). If using a PCI audio expansion card, Onboard
AC97 Audio Controller in 4.4.2 I/O Device Configuration must also be
disabled.
Setting AUD_EN1
Enable [1-2] (default)
Disable [2-3]
5) Onboard LAN Setting (LAN_EN)
The onboard LAN may be enabled/disabled with this jumper.
Setting LAN_EN
Enable [1-2] (default)
Disable [2-3]
TUSL2-M
®
TUSL2-M Audio Codec Setting
AUD_EN1
Enable
(Default)
12
Disable
23
TUSL2-M
®
TUSL2-M On Board Lan Setting
Enable
(default) Disable
12 23
LAN_EN
